Cedarshed Montrose Shingle Roof User manual

CEDARSHED INSTRUCTIONS
MONTROSE- SHINGLE ROOF
Base size: 3000mm x 2490mm deep

MONTROSE
 Baery Drill
 Riveter
 Hammer
 Tape Measure
 Ladder
 Skillsaw
 Level
 Screwdriver - Flat
 3/8 Hex Drive bit
 Drill Bit 3.2mm
 Read all instrucons carefully.
 Idenfy all parts and check quanes against checklist.
 Do not aempt to build your shed in high winds.
 Beware of sharp edges.
 Protect your eyes and ears.
 Use electric tools with care. Use a Safety Trip Switch.
 It is easier and quicker if this shed is erected by two people.
 Your shed must be level. Achieve this by either levelling the
ground or by using blocks.
Tools Required:
Select your site:
Safety:
Before you start:
PG 1

MONTROSE PARTS LIST
Descripon Size Qty
PACK ONE - ROOF Shingle Roof Panels (L/H) 1550 x 1425 2
Shingle Roof Panels (R/H) 1550 x 1425 2
PACK TWO - SHED Standard Door 895 x 1780 1
Std Wall Panels 900 x 1937 3
Std Wall Panels 1200 x 1937 2
End Wall Panels (L/H) 1200 x 2460 2
End Wall Panels (R/H) 1200 x 2460 2
Cedar Corner Clashings 65 x 17 x 1962 4
30 x 17 Std Cedarbead 30 x 17 x 1937 2
15 x 17 Std Cedarbead 15 x 17 x 1937 6
30 x 17 Gable Cedarbead 30 x 17 x 2465 2
Bargeboards 90 x 17 x 1480 4
Door Stop 45 x 45 x 900 1
Door Lintel 167 x 900 1
Weatherstrip 50mm x 20m Roll 1
Soakers 240 x 50mm 14
Diamonds 230 x 95 x 17 2
Raer Gussets 400 x 98 x 12 6
Silicone Tubes 300g 2
Ridge Flashings 240 x 1700 2
Collar Ties 45 x 45 x 1280 3
Temporary Spacer 45 x 45 x 2490 1
20mm Packer 20 x 45 x 1720 1
Hardware Pack
Tek Screws 14G x 75mm, CL4 60
Framing Nails 75 x 3.15mm 50
Bead Nails 50 x 2.5mm 125
Clouts 30 x 2.5mm 120
Colour Rivets 3.2 x 8.2mm 4
Door Handle 1
Door Latch 1
Door Handle Screws 3/16 x 2.5" 2
Touch Up Paint & Brush 1
Instrucons 1
PACK THREE - STIFFENERS (& FLOOR if required)
Top plate seners 45 x 45 x 3000 2
Floor Joists 70 x 45 x 2990 5
Floor Boards 150 x 19 x 2485 20
Floor Nails 50 x 2.5mm 200
Packed by: Date: / /
PG 2

MONTROSE FLOOR - OPTIONAL
Step 1: Lay out oor joists, spacing them evenly
as shown. Using 50mm ooring nails, nail a oor
board on each end, ensuring ends are ush with
joists. Make sure oor is level and joists are sup-
ported at 900mm centres.
Step 2: Lay out remaining oor boards. Measure
diagonals to ensure measurements are equal (i.e.
oor is square). Rip down last oor board to suit
gap, and nail o oor with 50mm ooring nails
(10 nails per board).
Step 3: Nail plasc weather strip to edge of oor
on all four sides, with 30mm clouts, (approx 5
nails per side) ensuring top edge is ush with top
of oor. This isn't required if shed is on a concrete
base.
Step 4: Unpack panels and idenfy wall and door
posions as per plan on following page.
Select two panels that go either side of a corner
(gable and standard panel) and stand together.
PG 3

MONTROSE CONCRETE FLOOR - OPTIONAL
Step 1: Establish size of shed and excavate sucient area.
Remember to allow for rear roof overhang up to 150mm, and
120mm on each end.
Step 2: Ensure that the base substrate is compacted rmly.
We suggest that the slab should be 80mm thick in the middle
and 100mm thick around the edges.
Step 3: Lay boxing to the required size, the raised slab
size should be 2985 x 2475mm and at least 30mm
above the ground line.
Step 4: Lay plasc sheeng if required. Plasc sheeng under slab
will prevent moisture coming through from underneath.
Step 5: Pour concrete and screed ush
Building a Raised Concrete Base
100mm
80mm
100mm
PG 4

MONTROSE WALL PLAN
15 x 17mm Std Cedar bead
30 x 17mm Std Cedar bead
30 x 17mm Gable Cedar bead
Corner Clashing
45 x 20mm Packer
MONTROSE WALL PLAN
900 1200 900
1200R
1200R
1200L
1200L
1200
900
PG 5

MONTROSE WALLS
Step 5: Screw wall panels together using 75mm
tek screws (3 per standard join, 4 per gable join),
ensuring end wall panels are inside side wall pan-
els as per wall plan.
Step 6: Silicone edge of weatherboards on stand-
ing panel and nail on cedar beads with 5 x bead
nails. (Refer to wall plan for correct beads).
Make sure bead is properly sealed to avoid leaks.
Note: On standard beads only, top of bead is bev-
elled to allow for slope of roof.
Step 7: Silicone and nail remaining beads on each
panel. Screw panels together using 3 tek Screws
per join and 4 on the longer joins on gable end
panels.
PG 6

MONTROSE TOP STIFFENER
Step 9: Using 75mm framing nails, nail both top
plate seners into standard wall panels studs, as
shown using 2 nails per stud (1 nail per stud at
panel joins). Ensure ends are ush before nailing.
MONTROSE TOP LINTEL
Step 10: Using 30mm clouts nail top cedar boards
to seners (2-3 per board). Predrill holes to stop
boards from spling.
Step 8: Using 4 x 75mm tek screws screw door
lintel to studs. Ensure outside cedar weather-
board on lintel is ush with weatherboards
each side.
Door Lintel shown from inside
Door Lintel shown from outside.
PG 7

MONTROSE CORNER CLASHINGS
Step 11: Silicone and nail 15 x 17mm beads on all
corners as shown using 5 x 50mm bead nails, per
bead.
Step 12: Silicone and nail corner clashings on all
corners as shown using 5 x bead nails per clash-
ing.
Silicone both edges of clashing to ensure this
doesn't leak.
MONTROSE ROOF
Step 13: Ensure shed is square, by measuring diagonals at top corner of wall panels.
Temporarily screw mber spacer between front and back walls to ensure top of walls
are correct distance apart.
Step 14: Note—shed shown has 1 panel per
side. Montrose has 2 panels per side. Place 1
back and 1 front panel in posion.
Step 15:Using 75mm tek screws, screw roof
panels into end wall panels, (2 screws per pan-
el), ensuring end of raer lines up with centre
of gable panel.
Repeat with remaining 2 panels.
PG 8

Step 17: Using 12 x 75mm framing nails,
nail roof raers to front and back top plate
seners. Predrill if necessary.
MONTROSE ROOF
Step 16: Using 4 x 75mm Tek screws, screw
roof panels together through raers as
shown.
(2 screws per raer)
Step 19: Aach a plywood gusset to each
side of raers as shown using 8 x 30mm
clouts per side.
Step 20: Rivet ridge ashings together and
aach to roof panels with 30mm clouts
nailing into top purlin at approx 300mm
centres.
Step 18: Using 6 x 75mm tek screws , screw
3x collar es to underside of raers.
Predrill before screwing if necessary.
