CEL-MAR ADA-14110 User manual

User manual
ADA-14110
RS232 to Wi-Fi (802.11b) Wireless Serial Server ith MODBUS
GATEWAY
1
io_ada-14110_v1.13_en
ADA-14110
Copyright © 2001-2017 CEL-MAR sp. .

Contents
1. GENERAL INFORMATION...................................................................................................................................................................... 4
1.1. WARRANTED INFORMATION....................................................................................................................................................... 4
1.2. GENERAL CONDITIONS FOR SAFE USE....................................................................................................................................4
1.3. CE LABEL....................................................................................................................................................................................... 4
1.4. ENVIRONMENTAL PRESERVATION.............................................................................................................................................4
1.5. SERVICE AND MAINTENANCE..................................................................................................................................................... 4
1.6. PACK CONTENTS.......................................................................................................................................................................... 4
2. PRODUCT INFORMATION..................................................................................................................................................................... 4
2.1. PROPERTIES................................................................................................................................................................................. 4
2.2. DESCRIPTION................................................................................................................................................................................ 5
2.3. WIRELESS NETWORK COMMUNICATIONS (WLAN)..................................................................................................................6
2.3.1. COMMUNICATIONS IN THE TCP/UDP SOCKETS MODE...................................................................................................6
2.3.2. COMMUNICATIONS IN THE VIRTUAL SERIAL PORT MODE (RealPort)............................................................................6
2.3.3. COMMUNICATIONS IN THE SERIAL BRIDGE MODE..........................................................................................................6
2.3.4. COMMUNICATIONS IN THE INDUSTRIAL AUTOMATION MODE (Modbus Gateway)........................................................6
2.3.5. OTHER COMMUNICATION TYPES.......................................................................................................................................6
2.4. ISOLATION..................................................................................................................................................................................... 6
3. INSTALLATION........................................................................................................................................................................................ 6
3.1. ASSEMBLING................................................................................................................................................................................. 7
3.2. CONNECTION TO WI-FI WIRELESS NETWORK (WLAN)...........................................................................................................7
3.2.1. CONNECTION OF THE WIRELESS SERIAL SERVER TO COMPUTER BY THE USE OF WIRELESS NETWORK
ADAPTER......................................................................................................................................................................................... 7
3.2.2. CONNECTION TO COMPUTER VIA NETWORK DEVICES ACCESS-POINT TYPE, ROUTER WI-FI................................7
3.2.3. CONNECTION TO COMPUTER VIA INTERNET BY THE USE ROUTER WI-FI / DSL........................................................8
3.2.4. CONNECTION FOR FUNCTIONING IN MODE TCP/UDP SERIAL BRIDGE.......................................................................9
3.2.5. CONNECTION OF THE WIRELESS SERIAL SERVER TO FUNCTIONING IN MODBUS GATEWAY MODE...................10
3.3. CONNECTING OF RS232 INTERFACE DEVICES......................................................................................................................11
3.3.1. CONNECTING OF DEVICE WITH RS232 POR, DTE TYPE (PC COMPUTER).................................................................11
3.3.2. CONNECTING OF DEVICE WITH RS232 POR,T DCE TYPE (MODEM, CODE READER)...............................................11
3.4. CONNECTING POWER SUPPLY.................................................................................................................................................11
4. STARTUP............................................................................................................................................................................................... 12
5. CONFIGURATION................................................................................................................................................................................. 12
5.1. INITIAL CONFIGURATION USING ADAFINDER SOFTWARE....................................................................................................12
5.1.1. ADAFINDER INSTALLATION...............................................................................................................................................12
5.1.2. NETWORK SETTING.......................................................................................................................................................... 12
5.2. CONFIGURATION AND MANAGEMENT BY THE USE OF INTERNET BROWSER...................................................................14
5.2.1. NETWORK CONFIGURATION............................................................................................................................................ 14
5.2.1.1. IP ADDRESS CONFIGURATION................................................................................................................................14
5.2.1.2. WLAN CONFIGURATION........................................................................................................................................... 15
5.2.1.3. WLAN SECURITY SETTINGS....................................................................................................................................15
5.2.1.4. CONFIGURATION SETTINGS FOR WLAN NETWORK ACCESS AUTHORIZATION...............................................16
5.2.1.5. NETWORK SERVICES SETTINGS............................................................................................................................16
5.2.1.6. IP FORWARDING SETTINGS.....................................................................................................................................16
5.2.1.7. SOCKET TUNNEL SETTINGS....................................................................................................................................16
5.2.1.8. ADVANCED NETWORK SETTINGS...........................................................................................................................16
5.2.2. SERIAL PORT CONFIGURATION.......................................................................................................................................16
5.2.2.1. PORT PROFILES (OPERATING MODES)..................................................................................................................16
5.2.2.1.1. REALPORT (VIRTUAL PORT ) CONFIGURATION............................................................................................17
5.2.2.1.2. TCP SOCKETS CONFIGURATION....................................................................................................................17
5.2.2.1.2.1. TCP SERVER AND CLIENT CONFIGURATION........................................................................................18
5.2.2.1.2.2. THE 'ENABLE TCP KEEP-ALIVE' OPTION CONFIGURATION................................................................19
5.2.2.1.2.3. SERIAL PORT TRANSMISSION PARAMETERS CONFIGURATION........................................................19
5.2.2.1.3. UDP SOCKETS CONFIGURATION....................................................................................................................19
5.2.2.1.3.1. UDP CLIENT & SERVER CONFIGURATION IN CASE OF MASTER DEVICE.........................................19
5.2.2.1.3.2. UDP CLIENT & SERVER CONFIGURATION IN CASE OF SLAVE DEVICE............................................20
5.2.2.1.3.3. SERIAL PORT TRANSMISSION PARAMETERS......................................................................................21
5.2.2.1.4. SERIAL BRIDGE PROFILE CONFIGURATION.................................................................................................21
5.2.2.1.4.1. SERIAL PORT TRANSMISSION PARAMETERS......................................................................................22
5.2.2.1.5. INDUSTRIAL AUTOMATION (MODBUS GATEWAY) CONFIGURATION..........................................................22
5.2.2.1.5.1. CONFIGURATION FOR COMMUNICATION WITH DEVICES MODBUS-MASTER TYPE.......................22
5.2.2.1.5.2. CONFIGURATION FOR COMMUNICATION WITH MODBUS-SLAVE TYPE DEVICE.............................24
5.2.2.1.5.3. SERIAL PORT TRANSMISSION PARAMETERS......................................................................................26
5.2.3. SYSTEM SETTINGS............................................................................................................................................................ 26
5.2.4. USERS CONFIGURATION.................................................................................................................................................. 26
5.2.4.1. CHANGING USER MANE AND PASSWORD.............................................................................................................26
5.2.4.2. ADDING NEW USER WITH LIMITED PERMISSIONS FOR CONFIGURATION OR MANAGEMENT.......................26
5.2.5. MANAGMENT...................................................................................................................................................................... 27
5.2.5.1. SERIAL PORTS MANAGEMENT................................................................................................................................27
2
ADA-14110

5.2.5.2. CONNECTIONS MANAGMENT.................................................................................................................................. 27
5.2.6. ADMINISTRATION............................................................................................................................................................... 27
5.2.6.1. FILE MANAGEMENT................................................................................................................................................... 27
5.2.6.2. BACKUP & RESTORE CONFIGURATION..................................................................................................................27
5.2.6.3. FIRMWARE UPDATE..................................................................................................................................................27
5.2.6.4. FACTORY DEFAULT SETTINGS................................................................................................................................27
5.2.6.5. SYSTEM INFORMATION............................................................................................................................................27
5.2.6.6. REBOOT...................................................................................................................................................................... 27
5.2.6.7. LOGOUT – ENDING MANAGEMENT AND CONFIGURATION..................................................................................27
6. USING VIRTUAL PORT SERVICE [REALPORT]..................................................................................................................................27
6.1. VIRTUAL PORT DRIVER INSTALLATION IN WINDOWS XP......................................................................................................27
6.2. REALPORT CONFIGURATION IN WINDOWS XP......................................................................................................................28
7. FACTORY DEFAULT............................................................................................................................................................................. 30
8. TROUBLESHOOTING........................................................................................................................................................................... 30
9. VERSIONS............................................................................................................................................................................................ 31
10. SPECIFICATION.................................................................................................................................................................................. 31
3
ADA-14110

1. GENERAL INFORMATION
Thank you for your purchase of CEL-MAR Company product. This product has been completely tested and is covered by a two year
warranty on parts and operation from date of sale.
If any questions or problems arise during installation or use of this product, please do not hesitate to contact Technical Support at +48
41 362-12-46 or e-mail [e-mail].
1.1. WARRANTED INFORMATION
The ADA-14110 Serial Server is covered by a two year warranty from date of sale. In case of being damaged it will be repair or the
damaged component will be replace. The warranty does not cover damage caused from improper use, materials consumption or any
unauthorized changes. If the product does not function (is damaged), or not operate in accordance with the instructions, will be
repaired or replaced.
All warranty and no warranty repairs must be returned with paid transport and insuring to the CEL-MAR Company.
CEL-MAR Company under no circumstances won't be responsible for ensuing damage from improper using the product or as a result
of random causes: the lightning discharge, the flood, the fire and the like.
CEL-MAR Company is not be held responsible for damages and loss including: loss of profits, loss of data, pecuniary losses ensuing
from using or the impossibility of using this product.
In specific cases CEL-MAR Company discontinue all warranties and in particular do not follow the user manual and do not accept
terms of warranty by the user.
1.2. GENERAL CONDITIONS FOR SAFE USE
The device should be installed in a safe and stable places (eg, electroinstallation cabinet), the powering cable should be arranged so
as not to be exposed to trampling, attaching, or pulling out of the circuit.
Do not put device on the wet surface.
Do not connect devices for nondescript powering sources,
Do not damage or crush powering wires.
Do not make connection with wet hands.
Do not adapt, open or make holes in casings of the device!
Do not immerse device in water or no other liquid.
Do not put the fire opened on device sources: candles, an oil lamps and the like.
Complete disable from the supply network is only after disconnecting the power supply circuit voltage.
Do not carry out the assembly or dis-assembly of the device if it is enabled. This may result to short circuit and damage the device.
The device can not be used for applications that determine human life and health (eg. Medical).
1.3. CE LABEL
The CE symbol on the device CEL-MAR means compatibility with electromagnetic compatibility Electromagnetic
Compatibility Directive EMC 2014/30/WE. Declaration of Conformity is available by contact with Technical Service (email:
[e-mail]; phone: [phone]).
1.4. ENVIRONMENTAL PRESERVATION
This sign on the device inform about putting expended device with other waste materials. Device should send to the
recycling. (In accordance with the act about the Electronic Appliance Expended from day 29 of July 2005)
1.5. SERVICE AND MAINTENANCE
ADA-14110 does not require the servicing and maintenance.
Technical support is available at number [phone] in 8.00-16.00, from Monday to Friday.
1.6. PACK CONTENTS
The device is delivered with: User Manual, antenna and ADANet software CD.
2. PRODUCT INFORMATION
Attention!
Class A device designed for installation in environments commercial and light industrial. In residential environment may cause harmful
interference radio-electric, in which case the user will have to to take appropriate steps to eliminate them.
2.1. PROPERTIES
●Operating with the data rates up to 11Mbps on the 2,4GHz frequency in the wireless network (IEEE 802.11b standard),
●Baud rate in wireless network 1, 2, 5.5, 11 Mbps,
●Modulation CCK(11/5 Mbps), DQPSK(2 Mbps), DBPSK(1Mbps),
●Sensitivity of receiver: -82dBm for 11Mbps, -87dBm for 5.5Mbps, -89dBm for 2Mbps, -92dBm for 1Mbps,
●Channels number: 11 (USA/Canada), 13 (Europe), 14 (Japan),
●Antenna connection via SMA connector,
●Wireless network security: WEP (64/128-bit encryption), WPA (128-bit encryption), WPA2 (128-bit encryption), PEAP, PSK (pre-
shared key mode),
●Protocols: TCP, UDP, DHCP, SNMP, SSL/TLS, Telnet, Rlogin, LPD, HTTP/HTTPS, SMTP, ICMP, IGMP, ARP,
●WWW sever implemented for configuration of the server ports,
●Configuration of net service
●Configuration of net services according to user personal setting,
●Static or dynamic IP address (added by DHCP server),
●Diagnostics of serial and network port,
●Encoded transmission: SSL v3.0/TLS v1.0 - DES (56-bit), 3DES (168-bit), AES (128/256-bit),
4
ADA-14110

●Operating in modes: virtual serial port, serial bridge TCP, serial bridge UDP, TCP or UDP socket, MODBUS Data Gateway,
●Transmitted RS232 signals: a) for version without interface isolation: Rx, Tx, RTS, CTS, DTR, DSR, DCD, b) for version with
interface isolation: Rx, Tx, RTS,
●Baud rate of RS232 (bps): 50, 75, 110, 134, 150, 200, 300, 600, 1200, 1800, 2400, 4800, 9600, 14400, 19200, 28800, 38400,
57600, 115200, 230400,
●RS232 data format: number of data bits: 5, 6, 7, 8; Parity control: None, Odd, Even, Constantly 1, Constantly 0; Stop Bits: 1, 2,
●Transparent for all protocols which data format is compatible with above specification of RS232 interface eg. MODBUS, DNP,
PROFIBUS and other,
●Implemented protocol converter MODBUS-TCP to MODBUS-RTU/ASCII (MODBUS Data Gateway),
●Operating in the mode MODBUS-RTU Master/Slave and MODBUS-ASCII Master/Slave,
●Connection of the RS-232 interface via DSUB-9M (male) connector,
●Stable external power supply 10 - 30 VDC,
●Up to 4W power consumption,
●~3kV= optoisolation between interfaces RS232 and Wi-Fi (version 2-way isolation),
●1kV= or 3kV= galvanic isolation between RS232 interface and power supply (version 2-way isolation),
●1000V= or 3000V= galvanic isolation between RS232 interfaces and power supply,
●Protection against power supply reverse connection,
●DIN 43880 standard - mounting in typical electro-installation unit,
●Rail mounting according to DIN35 / TS35 standard,
●Dimensions (W x D x H) 53mm x 62mm x 90mm,
●Antenna dimensions: length 110mm, diameter 9mm.
2.2. DESCRIPTION
The ADA-14110 wireless serial server transmits data between devices equipped with the RS232 interface via the wireless network
WLAN. The data transmission is without the interference into the format of transmitted data. The operating in the Wi-Fi WLAN wireless
network can be in the virtual serial port mode (port server), MODBUS Data Gateway, TCP and UDP serial bridge, TCP and UDP
socked. The MODBUS Data Gateway converts protocols MODBUS-RTU master/slave and MODBUS-ASCII master/slave to MODBUS-
TCP protocol and reverse. It lets to integrate devices MODBUS-RTU/ASCII with MODBUS-TCP devices in one network. ADA-14110
supports protocols such as: TCP, UDP, DHCP, SNMP, SSL/TLS, Telnet, Rlogin, LPD, HTTP/HTTPS, SMTP, ICMP, IGMP, ARP. The
server has WWW server for remote configuration and management by the use of internet browser and has the baud rate up to
230,4kbps.
This device has standard DB-9M (male) connector for RS232 interface, screw terminal block for connection of power supply and SMA
for aerial Wi-Fi network. ADA-14110 use signals as follow: Rx, Tx, RTS, CTS, DTR, DSR, DCD of RS232 interface and to this interface
can be connected telephone switchboards, barcode scanners, modems, scales, magnetic card readers, etc.
It is adapted to supply an external voltage source in scope from 10V= to 30V= and 4W power. The server has protection against
power supply reverse connection and ESD 15kV short-circuit protection and surge on RS232 interface lines.
The range of transmission in the wireless network Wi-Fi (IEEE 802.11b) :
- in buildings from 30m to 150m,
- in open area to 300m,
The transmission range can be increased after the application of additional directional antennas.
ADA-14110 is sold with drivers, which after installation, create in operating system additional COM port on the next free number e.g.
COM3. It can be use as standard COM port but it isn't hardware port but virtual, create in Windows system. This is the reason why
some applications running in DOS and use this port, can operate improperly.
Fig. 1. ADA-14110 vie Fig. 2.Vie of Wi-Fi and po er connectors
5
ADA-14110
ACT
Network activity
transmitting / receiving
LINK
Connection activity
- +
SMA connector
of Wi-Fi interface
58mm
7 mm
90mm
53mm
10mm
Vss-
Vss+
LINK
RST
(Wi-Fi)
ACT
10mm
Version ith RS232 interface
isolation
ADA-14110
PWRTXRXRTSCTSDTRDSR
RS-232
DCD
RS-232 to Wi-Fi
WIRELESS SERIAL SERVER
(RS-232)
90mm
53mm
10mm
Vss-
Vss+
LINK
RST
(Wi-Fi)
ACT
10mm
(RS-232)
Version ithout RS232 interface
isolation
ADA-14110
PWRTXRXRTS
RS-232
RS-232 to Wi-Fi
WIRELESS SERIAL SERVER

2.3. WIRELESS NETWORK COMMUNICATIONS (WLAN)
2.3.1. COMMUNICATIONS IN THE TCP/UDP SOCKETS MODE
Communication in the mode TCP/UDP sockets allows an application (SCADA, MMI) to transfer data to the serial port of ADA-14110
via Wi-Fi network, by the use client and server TCP/UDP services.
2.3.2. COMMUNICATIONS IN THE VIRTUAL SERIAL PORT MODE (RealPort)
Communication in the virtual serial port mode allows an application (SCADA, MMI) to transfer data to the serial port of ADA-14110 via
Wi-Fi network, by the use virtual COM port, created in an operating system.
2.3.3. COMMUNICATIONS IN THE SERIAL BRIDGE MODE
Communication in the serial bridge mode allows to transfer data via Wi-Fi network between serial ports of the servers port in one-to-
one topology or one-to-many by the use client and server TCP/UDP services.
2.3.4. COMMUNICATIONS IN THE INDUSTRIAL AUTOMATION MODE (Modbus Gate ay)
Communication in the MODBUS Gateway (IA) mode allows to convert MODBUS-RTU master/slave protocol and MODBUS-ASCII
master/slave protocol to MODBUS-TCP protocol and inversely. It's let to integrate MODBUS-RTU/ASCII devices with MODBUS-TCP
devices in a single network.
2.3.5. OTHER COMMUNICATION TYPES
The ADA-14110 port server can be configured in other communication types, like:
–terminal mode,
–modem emulation mode,
–console mode,
–user mode.
2.4. ISOLATION
The ADA-14110 has not the galvanic isolation or has 2-way, 1kV= or 3kV= galvanic isolation (depend on version, described in section
VERSIONS).
Fig. 3. Isolation diagram
3. INSTALLATION
This chapter will show how to connect the ADA-14110 to RS232 bus, Wi-Fi wireless network (WLAN) and power supply and how to
use it.
To reduce disturbance from environment, it is recommended to:
–use multipair type shielded cables, which shield can be connected to the earthing on one end of the cable,
–use the suitable diameter cable for power supply on account of voltage drop,
–use the powering cable with a suitable section because of the voltage drops,
–use the interference eliminators for powering the converter,
–lay signal cables at a distance of not less than 25 cm away from power cables,
–not powering the converters form the power-circuit of devices generate large impulse disturbance like contactors, relays, inverters.
6
ADA-14110
Power Supply
10 - 30VDC
Wi-FiR232
2-WAY ISOLATION
Power Supply
10 - 30VDC
Wi-FiR232
WITHOUT ISOLATION

3.1. ASSEMBLING
The ADA-14110 case is adapted to assembly on TS-35 (DIN35) rail. To install converter should mount device on the rail upper part of
the case then press bottom part to to hearing characteristic „Click” sound.
Attention!!
Do not install Wi-Fi devices at a distance of less than 20cm from each other.
3.2. CONNECTION TO WI-FI WIRELESS NETWORK (WLAN)
Connection of the ADA-14110 to WI-FI wireless network (WLAN) can be done by the use of a devices like ACCESS-POINT, ROUTER
Wi-Fi or directly to computer, equipped with Wi-Fi card or other ADA-14110 port server.
In the connector of Wi-Fi interface of the serial server are two diodes (fig.2):
–ACT green, signalling the state of data transferring or receiving,
–LINK orange, signalling the active network connection.
Wireless Serial Server ADA-14110 can be use like :
–virtual serial port [RealPort],
–TCP serial bridge,
–UDP serial bridge,
The factory default settings of the ADA-14110 is:
–to connect to any free wireless network Wi-Fi. Therefore should be set the lowest, free channel of wireless transmission in the
setting of devices like ACCESS-POINT, ROUTER Wi-Fi, Wi-Fi card.
–to downloading the IP address from DHCP server. Therefore if there is not the DHCP server, to change IP address should be used
ADAFinder software (see p.5.1).
Details of the connection to wireless network will be described in the bellow chapters.
3.2.1. CONNECTION OF THE WIRELESS SERIAL SERVER TO COMPUTER BY THE USE OF
WIRELESS NETWORK ADAPTER
If there is not Access-POINT or Wi-Fi Router, the ADA-14110 can be connected directly to computer by the use of wireless network
adapter as on the figure below. Recommended network adapters USB to Wi-Fi:
–PENTAGRAM HORNET P6132-30,
–PENTAGRAM HORNET P6132-08,
–or other, operating in mode: Client Wi-Fi or Access Point (AP).
For configuration of the ADA-14110 wireless serial server, set wireless network adapter in the Access Point mode and make the
configuration as below:
–SSID adapter name: no name,
–channel: 1,
–authentication: non,
–encryption: non.
Power the ADA-14110 and when will connect to wireless network adapter run the ADAFinder software and make the initial
configuration according to pt. 5.1. INITIAL CONFIGURATION USING ADAFINDER SOFTWARE.
Fig. 4. Connection AD-HOC type bet een ADA-14110 and PC
3.2.2. CONNECTION TO COMPUTER VIA NETWORK DEVICES ACCESS-POINT TYPE, ROUTER
WI-FI
Figure below shows correct connection of the ADA-14110 to wireless network WLAN\LAN, by the use ACCESS-POINT, ROUTER Wi-
Fi. This type of connection allows the Wireless Serial Server functioning with PC in virtual serial port mode (RealPort) or TCP/UDP
sockets.
7
ADA-14110
PC with Wi-Fi adapter ADA-14110
Wi-Fi (802.11b/g) connection,
„Ad-Hoc” type

Fig. 5. Connection the ADA-14110 to WLAN/LAN net ork, functioning in virtual serial port mode or TCP/UDP sockets
3.2.3. CONNECTION TO COMPUTER VIA INTERNET BY THE USE ROUTER WI-FI / DSL
Figure below shows the correct connection of the ADA-14110 to PC via INTERNET, by the use wireless network with devices like
ROUTER Wi-Fi / DSL type. This type of connection allows the Wireless Serial Server functioning with PC in virtual serial port mode
(RealPort) or TCP/UDP sockets.
Fig. 6. Connection to functioning in virtual serial port mode (RealPort) or TCP/UDP sockets via INTERNET
8
ADA-14110
ADA-14110
ROUTER Wi-Fi or
ACCESS POINT / ETHERNET
Wi-Fi (802.11b/g) LAN
Device with
RS232
interface
RS232
PC with Wi-Fi adapter
LAN ETHERNET
Location - B
Device with
RS232 interface
INTERNET
ROUTER Wi-Fi / DSL
Public IP address
Location - A
PC with Wi-Fi adapter
ROUTER Wi-Fi / DSL
Public IP address
ADA-14110
RS232

3.2.4. CONNECTION FOR FUNCTIONING IN MODE TCP/UDP SERIAL BRIDGE
Figures below show correct connection of ADA-14110 to wireless network and INTERNET network to functioning in TCP serial bridge
mode or UDP.
Fig. 7. Connection to functioning in TCP/UDP serial bridge mode, one-to-one in LAN net ork
Fig. 8. Connection to functioning in UDP serial bridge mode, one-to-many in WLAN net ork
9
ADA-14110
Wi-Fi (802.11b/g) Network, the connection „Ad-Hoc” type between
ADA-14110 Serial Servers.
Functioning in the mode of serial bridge TCP / UDP
Device with
RS232 interface
RS232
ADA-14110
RS232
Device with
RS232 interface
ADA-14110
SLAVE Device
with RS232
interface
RS232
ADA-14110
Static IP address
RS232
Urządzenie
z interfe sem
RS232
RS232
MASTER Device
with RS232
interface
SLAVE Device
with RS232
interface
Wi-Fi (802.11b/g) Network, the connection „Ad-Hoc” type between
ADA-14110 Serial Servers.
Functioning in the mode of serial bridge UDP

Fig. 9. Connection to functioning in TCP or UDP serial bridge mode via INTERNET net ork
3.2.5. CONNECTION OF THE WIRELESS SERIAL SERVER TO FUNCTIONING IN MODBUS
GATEWAY MODE
Figure below shows the correct connection of the ADA-14110 to wireless network Wi-Fi (WLAN) to operating in Industrial
Automation Mode (MODBUS Gate ay). This type of connection allows to integrate the MODBUS-TCP devices and the MODBUS-
RTU/ASCII devices in one network.
Fig. 10. Integration MODBUS-TCP ith MODBUS-RTU/ASCII in one net ork by the use ADA-14110 ith MODBUS Gate ay
10
ADA-14110
LOCATION - B
Device with
RS232
interface
INTERNET
ROUTER Wi-Fi / DSL
Public IP address
LOCATION - A
ROUTER Wi-Fi / DSL
Public IP address
ADA-14110 RS232
Device with
RS232
interface
ADA-14110 RS232
RS485 Bus
MODBUS-RTU/ASCII
ROUTER Wi-Fi / ETHERNET
PC with the SCADA / HMI
software
ADA-14040
MODBUS Gateway
ADA-14110
MODBUS Gate ay
RS232
MODBUS-RTU/ASCII
PLC
MASTER
MODBUS-TCP
MODBUS-TCP
LAN ETHERNET
LAN \ WLAN
Created on the ROUTER

3.3. CONNECTING OF RS232 INTERFACE DEVICES
3.3.1. CONNECTING OF DEVICE WITH RS232 POR, DTE TYPE (PC COMPUTER)
The ADA-14110 can be connected to RS232 port of PC computer by the use of the crossover cable CAB-DB9F/DB9F-C-1,8m
(available in our offer). Figure below shows the example connecting of the Wireless Serial Server to RS232 PC port.
Fig. 11. The example connecting of the ADA-14110 to RS232 PC port
3.3.2. CONNECTING OF DEVICE WITH RS232 POR,T DCE TYPE (MODEM, CODE READER)
The ADA-14110 can be connected to the RS232 device DCE port type, by the use of of RS232 cable CAB-DB9F/DB9M-S-1,8m
(available in our offer). Figure below shows the example connecting.
Fig. 12. The example connecting of a device ith RS232 port DCE type (e.g. modem, barcode reader)
3.4. CONNECTING POWER SUPPLY
The power supply to the ADA-14110 should be DC (regulated) from the scope 10 V= to 30V= and nominal power more then 4W
(available in our offer). The power cable from DC power supplies to the device must not be longer than 3m. Observe the polarity,
connect positive (+) of DC power supplies to Vss+ and negative (-) end to Vss- terminal. The ADA-14110 has the protection from
opposite connection power supply.
11
ADA-14110
ADA-14110
Wi-Fi
Vss+
Vss-
Power
RS232
DTE/DB-9M
Rx -2
Tx -3
DTR -4
DSR -6
RTS -7
RI -9
GND -5
V -
V +
Socked
DB-9F
1
2
3
4
6
5
9
Socked
DB-9F
Device with RS232
DTE type
RS232
DTE/DB-9M
DCD -1
7
CTS -8
8
1
2
3
4
6
5
9
7
8
Rx -2
Tx -3
DTR -4
DSR -6
RTS -7
RI -9 (NC)
GND -5
DCD -1
CTS -8
SMA connector
Wi-Fi
ADA-14110
Wi-Fi
Vss+
Vss-
Power
RS232
DTE/DB-9M
Tx -2
Rx -3
DSR -4
DTR -6
CTS -7
RI -9
GND -5
V -
V +
Socked
DB-9M
1
2
3
4
6
5
9
Socked
DB-9F
Device with RS232
DCE type
RS232
DCE/DB-9F
DCD -1
7
RTS -8
8
1
2
3
4
6
5
9
7
8
Rx -2
Tx -3
DTR -4
DSR -6
RTS -7
RI -9 (NC)
GND -5
DCD -1
CTS -8
SMA connector
Wi-Fi

4. STARTUP
If connection was made properly the green LED PWR on front panel of converter should lit, if not check polarization of connected
power. When data is transmitted LEDs on Wi-Fi interface and RX, TX should blink. Those LED are described below:
LED Description
Power
PWR Signalization of the Power Supply
RS232 interfa e
RX Signalling of data receiving from RS232 port
TX Signalling of data transmitting from through RS232 port
RTS ADA-14110 reports to device readiness data collection
CTS Device confirms reception RTS signal from ADA-14110. (version without isolation)
DTR Readiness of ADA-14110 to receive/send data (version without isolation)
DSR Readiness of Device to receive/send data (version without isolation)
DCD Level of the signal received (version without isolation)
Wi-Fi wireless interfa e
Yello Lights continuously – indicates the connection between ADA-14110 and the Access Point.
Flashing of low frequency - indicates work in "ad hoc" mode.
Flashing at a high frequency - network searching.
Green Signalling data transmission
5. CONFIGURATION
The ADA-14110 Wireless Serial Server like most of network devices should be configured for proper functioning, it's needed
configuration of network services and network setting.
Below are described the stages of software installation and network setting configuration of converter.
5.1. INITIAL CONFIGURATION USING ADAFINDER SOFTWARE
5.1.1. ADAFINDER INSTALLATION
The initial configuration of wireless Wi-Fi (WLAN) network setting at the ADA-14110 can be made by using ADAFinder or ADAWiz
software. The installation is automatically after insert the CD (compact disc) to an optical drive. If the autorun doesn't start, should run
the file setup.exe located in main CD catalogue. After installation the software ADAFinder and ADAWiz are available in Start-
>Programs->CEL-MAR->ADANet.
Before running ADA Finder software should be set the option [Obtain an IP address automatically] in TCP/IP protocol configuration
of Wi-Fi network adapter - it let find the Wireless Serial Server in WLAN network. Run ADAFinder software.
5.1.2. NETWORK SETTING
The ADAFinder is use for configuration of the Serial Server's network setting.
Before running the ADAFinder should be disabled the System FireWall!
After running, the program is searching local network (LAN , WLAN) and if find the ADA-14110, will add them to the list of available
port servers [Devices:] Fig.13.
To change the network setting of ADA-14110, should:
–select the converter from the list [Devices:] and press [Configure IP Settings],
–in windows [Set IP Address] select option 'Automatically obtain net ork settings via DHCP' (default setting) or 'Manually
configure network setting'. In case of manual configuration should be enter IP Address of the converter, Subnet Mask, Default
Gateway and the Password (default: dbps) of the ADA-14110 administrator for authorization of changes.
–press [Apply], the configuration will be saved to the serial server and will restart. After message 'Operation made successfully',
press [Refresh List] in ADAFinder window. After re-searching the lists of available port servers [Devices:] will be refreshed.
Other buttons of the program main menu:
–selecting the serial server from the list and pressing [Reboot Device], will make programmable reset – new configuration of
network setting will be activated,
–selecting the serial server from the list and pressing [Device Information], will show a window information about the settings,
–selecting the serial server from the list and pressing [Open Web Interface], will run Internet browser and open the configuration
page of the serial server.
12
ADA-14110

Fig. 13. The initial configuration by ADAFinder soft are
Fig. 14. ADAFinder configuration of IP net ork address
13
ADA-14110

5.2. CONFIGURATION AND MANAGEMENT BY THE USE OF INTERNET BROWSER
Integrated WWW server to the ADA-14110 enable to easy configuration and diagnostics of LAN and WAN network devices by the use
Internet browser.
For configuration open the Internet Browser and type the address http://<converter-ip-address>/admin/administration.htm. The
login windows will open. Enter User name and Password as follow:
Username: root
Password: dbps
If the the Username and the Password are correct will open the page as below.
Fig. 15. The eb page for configuration and management of the ADA-14110
5.2.1. NETWORK CONFIGURATION
5.2.1.1. IP ADDRESS CONFIGURATION
To make a changes of default setting or new configuration of the ADA-14110, select on left panel Configuration -> Net ork and then
on right [ WiFi IP Settings] (Fig.16) and make the selection: Obtain an IP address automatically using DHCP or Use the follo ing
IP address (in this option, enter IP Address of the serial server, Subnet Mask, Default Gateway), press [Apply] for save. After the
message Changes have been saved successfully, from left menu select Administrator -> Reboot on right press [Reboot], will be
programmable reset of the serial server and new configuration of network setting will be activated.
14
ADA-14110

Fig. 16. The eb page for net ork setting of the ADA-14110
5.2.1.2. WLAN CONFIGURATION
To make a changes of default setting or new configuration of the ADA-14110, select on left panel Configuration -> Net ork and then
on right [WiFi LAN Settings].
Enter in [Net ork name] or [SSID] the name of the network, to which the serial server will be connected. If the [Net ork name] will
be empty, the ADA-14110 will connect to first, found wireless network.
The type of connection to wireless network can be configured by options like:
[• Connect to any available ireless net ork]
[• Connect to access point (infrastructure) net orks only]
[• Connect to peer-to-peer (ad-hoc) net orks only]
From the list [Country] select the country, this choice will reduce settings of channels to the list of legally defined for the country.
From the list [Channel] select the channel on which the server will operate. Selection the Auto-Scan from list will cause searching of
all available frequencies until the Server will not find available wireless networks Access Point type or Ad-Hoc to which can connect.
Selection [Enable Short Preamble] let enlarge capacity/ efficiency of wireless network - if the network supports the Short Preamble.
5.2.1.3. WLAN SECURITY SETTINGS
To make a changes of default setting or new configuration of ADA-14110, select on left panel Configuration -> Net ork and then on
right [WiFi Security Settings]. In this section can be configured security and access authorization to W-Fi network in many ways.
The serial server automatically will choose and specify the mode of authentication and encryption method at accessing to Wi-Fi
network.
If wireless network uses Open System structure, an unsecured, should not be switched the factory settings.
Attention !
The settings of WPA protection need ireless net ork based on devices Access Point type and are not available in net orks
Ad-Hoc (peer-to-peer) type.
WPA-PSK protection is available only if is entered the name of net ork in [Net ork Name] or SSID.
Section [WiFi Security Settings] consists of:
• Network Authentication
• Data Encryption
• WEP Keys
• WPA PSK
• Username/Password
Attention !
For detailed information about configuration this section are available after logging on the port server.
15
ADA-14110

5.2.1.4. CONFIGURATION SETTINGS FOR WLAN NETWORK ACCESS AUTHORIZATION
To make a changes of default setting or new configuration of the ADA-14110, select on left panel Configuration -> Net ork and then
on right [WiFi 802.1x Authentication Settings]. These options are only configurable when [WEP ith 802.1x authentication] or
[WPA ith 802.1x authentication] are enabled on the [WiFi Security Settings] tab.
Attention !
For detailed information about configuration this section are available after logging on the port server.
5.2.1.5. NETWORK SERVICES SETTINGS
To make a changes of default setting or new configuration of the ADA-14110, select on left panel Configuration -> Net ork and then
on right [Net ork Services Settings]. This section is used to enable or disable many of network services or configuration of
TCP/UDP ports on which they operate.
Attention !
For detailed information about configuration this section are available after logging on the port server.
5.2.1.6. IP FORWARDING SETTINGS
To make a changes of default setting or new configuration of ADA-14110, select on left panel Configuration -> Net ork and then on
right [IP For arding Settings]. This section is used to manage of IP routing (forwarding) of packets between network interfaces.
Static routes may be configured and added to the IP routing table to provide additional packet routing rules.
Attention !
For detailed information about configuration this section are available after logging on the port server.
5.2.1.7. SOCKET TUNNEL SETTINGS
To make a changes of default setting or new configuration of ADA-14110, select on left panel Configuration -> Net ork and then on
right [Socket Tunnel Settings]. This section is used to connect two network devices - one the ADA-14110 Wireless Serial Server's
local network and the other on the remote network.
Attention !
For detailed information about configuration this section are available after logging on the port server.
5.2.1.8. ADVANCED NETWORK SETTINGS
To make a changes of default setting or new configuration of ADA-14040, select on left panel Configuration -> Net ork and then on
right [Advanced Net ork Settings]. This section is used to fine tune the network connection and network interfaces. The default
settings will typically work in most situations.
Attention !
For detailed information about configuration this section are available after logging on the port server.
5.2.2. SERIAL PORT CONFIGURATION
The configuration of serial port of the ADA-14110 server includes: port description, setting of port profile (operating mode) and setting
of serial transmission parameters (baud rate, data bits, parity, stop bits).
Select on left panel Configuration -> Serial Ports and then on right [Port 1], will open the configuration details page, includes:
- Port Profile Settings,
- Basic Serial Settings,
- Advanced Serial Settings,
5.2.2.1. PORT PROFILES (OPERATING MODES)
Select on right panel Serial Port Configuration -> Port Profile Settings and then press Change Profile... will open the page Select
Port Profile for selection of port profiles (fig. 17).
Attention !
For detailed information about configuration this section are available after logging on the port server.
16
ADA-14110

Fig. 17. The eb page of selection the serial port profile
5.2.2.1.1. REALPORT (VIRTUAL PORT ) CONFIGURATION
Choosing RealPort (Virtual Port, Fig. 17) is configured the serial port of ADA-14110, for communication with virtual port COM of
computer. Press [Apply] for save. After installation driver (RealPort) of virtual port COM (see chapter 6) in operating system, data
sending by application to this port are transferred through WLAN/WAN to the ADA-14110 serial server and are present on his serial
port. The driver RealPort installation is presented in chapter 6. Normally RealPort service allows for one connection through
WLAN/LAN/WAN, between computer and server port.
Connection from other computers to the converter will be not taken, what will cause the error message.
5.2.2.1.2. TCP SOCKETS CONFIGURATION
Choosing TCP Sockets is configured the serial port of ADA-14110, for direct communication with PC by the use of TCP socked. Data
sending by application to TCP socked are transferred through WLAN/LAN/WAN to the ADA-14110 serial server and are present on his
serial port. To save selected configuration, press the button [Apply].
17
ADA-14110

5.2.2.1.2.1. TCP SERVER AND CLIENT CONFIGURATION
After saving the TCP Sockets profile, will open section TCP Server Settings (picture below), includes configuration of:
–port for Telnet service; standard 2001,
–port for serial port service; standard 2101 (through this port are transferred data to serial port of converter),
–port for security access to serial port service; standard 2601 (through this port are transferred data to serial port of converter),
and possibility of selection Enable TCP Keep Alive – connection will be kept, even if the data is not transmitted over the network.
Fig. 18. Example configuration of TCP server
For configuration of TCP Client Settings (Fig 19), select Automatically establish TCP connections, connection between client and
TCP server will be automatically. Then select Al ays connect and maintain connection option and in section Establish connection
to the follo ing net ork service enter IP address of device to which TCP client will send data, select service and enter port. There
is also possible to select an option Enable TCP Keep-Alive – connection will be kept, even if the data is not transmitted over the
network.
For saving the configuration press [Apply].
Fig. 19. Example configuration of TCP client
ATTENTION !
Default port of serial port service is 2101.
If on the local net ork is conflict ith other net ork service using the same port, in the serial server's port configuration
change number of port into another for the server and client service .
18
ADA-14110

5.2.2.1.2.2. THE 'ENABLE TCP KEEP-ALIVE' OPTION CONFIGURATION
Option Enable TCP Keep-Alive keeps connection between server and client, even if the data is not transmitted over the network and
reconnection in case of interruption.
Configuration of this option can be made by selection Configuration > Net ork > Advanced Net ork Settings > TCP Keep-Alive
Settings. In this section can be configured:
–Idle Time – specifies the period of time (scope 10 sec. - 24 hours) that a TCP connection has to be idle before a keep-alive is sent.
–Probe Interval – the time in seconds between each keep-alive probe (scope 10 – 75 sec.),
–Probe Count – the number of times TCP probes the connection to determine (scope 5 – 30 trials).
5.2.2.1.2.3. SERIAL PORT TRANSMISSION PARAMETERS CONFIGURATION
For proper operation of the ADA-14110 wireless serial server with device connected to his RS232 serial port, should be set the same
transmission parameters for both devices.
Select Basic Serial Settings and enter Baud Rate, Data Bits, Parity, Stop Bits, the same parameter like has device connected to
the serial port of the ADA-14110.
5.2.2.1.3. UDP SOCKETS CONFIGURATION
Choosing UDP Sockets is configured the serial port of the ADA-14110 for direct communication with PC or other device connected to
the network by the use of UDP socked. Data sending by application or other device/s to this port are transferred through
WLAN/LAN/WAN to the ADA-14110 and are present on his serial port. Press [Apply] for save the configuration
5.2.2.1.3.1. UDP CLIENT & SERVER CONFIGURATION IN CASE OF MASTER DEVICE
After saving the UDP Sockets profile, will open section UDP Server Settings with operating parameters like on picture below. Set an
access to UDP server on e.g. 2101 port. Then select Automatically send serial data in section UDP Client Settings, this
automatically send received data by the use UDP client service to the SLAVE device connected to LAN/WAN through e.g. ADA-13020,
ADA-13028L, ADA-13040MG, ADA-13110, ADA-14040, ADA-14110.
On the lists Send data to the follo ing net ork services are addresses of network devices and ports to which will be send data. In
field:
–Description - enter e.g. location of the serial server and SLAVE device,
–Send To - enter IP address of e.g. serial server, connected to SLAVE device,
–UDP Port - enter the number of port on which is working UDP Server of the serial server connected to SLAVE device and press
[Add]
In the section Send data under any of the follo ing conditions, is recommended to set parameters like on picture bellow.
For saving the configuration of UDP client and server for MASTER device, press [Apply].
19
ADA-14110

Fig. 20. Example configuration of the UDP server&client on serial server connected to MASTER device
5.2.2.1.3.2. UDP CLIENT & SERVER CONFIGURATION IN CASE OF SLAVE DEVICE
Set operating parameters of UDP server for SLAVE device connected via serial port to ADA-14110, eg like on picture below. Set an
access to UDP server on e.g. 2101 port. Then select Automatically send serial data in section UDP Client Settings, this
automatically send received data by the use UDP client service to the MASTER device connected to LAN / WAN through e.g.
ADA-13020, ADA-13028L, ADA-13040MG, ADA-13110, ADA-14040, ADA-14110.
On the lists Send data to the follo ing net ork services are addresses of network devices and ports to which will be send data. In
field:
–Description - enter e.g. location of the serial server and MASTER device,
–Send To - enter IP address of e.g. serial server , connected to MASTER device,
–UDP Port - enter the number of port on which is working UDP Server of the serial server connected to MASTER device and
press [Add]
In the section Send data under any of the follo ing conditions is recommended to set parameters like on picture bellow.
For saving the configuration of UDP client and server for SLAVE device, press [Apply].
20
ADA-14110
