Celestron 60EQ User manual

P
Po ow we er rS Se ee ek ke er r 6 60 0E EQ Q
I
IN NS ST TR RU UC CT TI IO ON N M MA AN NU UA AL L
#21043

2
INTRODUCTION
Congratulations on your purchase and welcome to the Celestron world of amateur astronomy. Some of the terms
and parts described in these instructions may be new to you, so a few commonly used terms you’ll want to be
familiar with are defined below.
Equatorial mount – a type of mounting that allows the telescope to be aligned with the earth's axis in order to track
the motion of the sky.
Focal length - the distance from the optical center of the lens to the point where the incoming light rays converge,
creating a clear, focused image.
Objective lens - the front lens of the telescope. It gathers incoming light to create a sharply focused image.
Refracting telescope - a long, thin tube where light passes in a straight line from the front objective lens directly to
the eyepiece at the opposite end of the tube.
First, you need to take the time to familiarize yourself with the parts of your PowerSeeker telescope, then assemble
it, following the easy instructions provided. Next, read over the operating instructions and become familiar with how
your telescope works, to prepare for hours of viewing enjoyment.
CAUTION: READ THIS SECTION BEFORE USING YOUR TELESCOPE
Your PowerSeeker telescope is designed to give you hours of fun and rewarding observing. However, there are a
few things to be aware of before using your telescope that will ensure your safety and protect your equipment.
NEVER LOOK DIRECTLY AT THE SUN WITH THE NAKED EYE OR WITH A TELESCOPE. NEVER
POINT YOUR TELESCOPE AT THE SUN UNLESS YOU’RE USING THE PROPER SOLAR FILTER.
PERMANENT AND IRREVERSIBLE EYE DAMAGE MAY RESULT.
NEVER USE YOUR TELESCOPE TO PROJECT AN IMAGE OF THE SUN ONTO ANY SURFACE, OR USE
AN EYEPIECE SOLAR FILTER OR A HERSCHEL WEDGE. INTERNAL HEAT BUILD-UP CAN DAMAGE
THE TELESCOPE AND/OR ANY ACCESSORIES THAT MAY BE ATTACHED TO IT.
NEVER LEAVE YOUR TELESCOPE UNSUPERVISED, ESPECIALLY WHEN CHILDREN ARE PRESENT.
THIS ALSO HOLDS TRUE FOR ADULTS WHO MAY NOT BE FAMILIAR WITH THE CORRECT
OPERATING PROCEDURES FOR YOUR TELESCOPE.
ALWAYS COVER THE FINDERSCOPE WHEN USING YOUR TELESCOPE WITH THE CORRECT SOLAR
FILTER. ALTHOUGH SMALL IN APERTURE, THIS INSTRUMENT HAS ENOUGH LIGHT GATHERING
POWER TO CAUSE PERMANENT AND IRREVERSIBLE EYE DAMAGE. THE IMAGE PROJECTED BY
THE FINDERSCOPE IS HOT ENOUGH TO BURN SKIN OR CLOTHING.

3
P
Po ow we er rS Se ee ek ke er r 6 60 0 E EQ Q
Figure 1-1

4
T
TH HE E P PO OW WE ER RS SE EE EK KE ER R 6 60 0 E EQ Q R Re ef fr ra ac ct to or r
The PowerSeeker is a refracting telescope that comes on an equatorial mount. This section instructs you on the
proper assembly and use of your PowerSeeker telescope, which is shipped in one box, containing all the parts you
need to assemble it. Unpack and lay out all of the parts in a large, clear area where you’ll have room to work.
Keeping track of the parts, use the list below and the telescope diagram to confirm you have, and can identify each
part.
PowerSeeker 60 EQ
1. Lens Cap 12. Equatorial Head Mounting Screw
2. Optical Tube 13. Tripod Leg
3. 5x24 Finderscope 14. Accessory Tray
4. Finderscope Bracket 15. Center Support Brace
5. Focuser 16. Tripod Tightening Screws
6. Eyepiece 17. Counterweight
7. Star Diagonal 18. Counterweight Bar
8. Declination Locking Screw 19. R.A. Slow Motion Control
9. Declination Slow Motion Control 20. Equatorial Mount
10. Latitude Adjustment Screw 21. Mounting Platform
11. Tripod Mounting Head 22. Objective Lens
A
As ss se em mb bl li in ng g Y Yo ou ur r T Te el le es sc co op pe e
To set up the tripod, locate the equatorial mount (20), the tripod legs (13), and the tripod mounting head (11).
1. Slide the two top portions of each tripod leg around the sides of each flange on the tripod mounting head (11).
Make sure that the tripod center support brace hinges (15) are located on the inside of the each leg.
2. Slide the provided screws through the tripod leg and flange,
until the screw extends out the other side (see Figure 1-2).
Slide the washer and the nut over the screw and tighten. This
can be left slightly loose, to allow for positioning the legs
later, when attaching the accessory tray.
You are now ready to attach the tripod accessory tray.
3. The tripod tray fits over the holes in the tripod's center
support brace (15). Insert the winged bolts through the holes
in each of the tripod center support braces and thread them
into the holes in the accessory tray. Tighten all bolts to ensure
proper stability to the mount.
A
At tt ta ac ch hi in ng g t th he e E Eq qu ua at to or ri ia al l M Mo ou un nt t
1. Place the base of the equatorial mount (20) into the hole on the top of the tripod mounting head (11).
2. Rotate the equatorial mount until the declination axis (where the counterweight bar (18) goes) is positioned over
one of the tripod legs.
3. Attach the mount to the tripod by threading the equatorial head mounting screw (12) into the bottom of the
mount
Before attaching the optical tube, the counterweight and slow motion controls should be added to the mount:
1. Thread the counterweight bar (18) clockwise into the declination axis of the equatorial mount. Slide the
counterweight (17) over the counterweight bar and lock down the screw on the side of the counterweight.
Tri
p
od
Mountin
g
Head
(
11
)
Figure 1-2

5
2. Locate the declination slow motion control (9) and attach to the mount by tightening the set screw on the control
cable. See Figure 1-3. The set screw should be tightened down hard on the flat surface of the cable holder after
backing off the cable about 1/4" from being fully engaged. This method helps ensure there is no slippage when
using the cable.
3. Locate the right ascension slow motion control (19) and attach it the same way as
the declination cable was attached.
A
At tt ta ac ch hi in ng g t th he e O Op pt ti ic ca al l T Tu ub be e
You are now ready to put the telescope optical tube (2) onto the equatorial mount
(20).
1. Remove the two locking wing nuts from the telescope optical tube (2).
2. Place the telescope tube on the mount so that the treaded post at the bottom of the
tube's mounting platform (21) go through the holes on the top of the mount.
3. Thread a wing nut onto the end of the threaded posts and tighten to secure the
tube to the mount.
A
At tt ta ac ch hi in ng g t th he e A Ac cc ce es ss so or ri ie es s
Your telescope comes with the following optical accessories:
• 20mm eyepiece 1¼"
• 4mm eyepiece 1¼ "
• 3x Barlow Lens 1¼"
• 1.5x Erect Image Eyepiece 1¼"
1. Remove the caps from the focuser (5).
2. Place the chrome barrel end of the eyepiece into the star diagonal (see Figure 1-
4). Lock it into place with the thumb screw on the side of the star diagonal.
3. The PowerSeeker comes with a 1.5x erecting eyepiece, primarily for daytime
terrestrial viewing. This eyepiece corrects the image you see in your telescope,
so that it’s both right side up and corrected from left to right. Without this
eyepiece, the image you see is reversed from left to right, when using the
standard diagonal. To use the erecting eyepiece, remove the diagonal and
insert the erecting eyepiece directly into the focuser. Then use a low power
eyepiece such as the 20mm, inserting it directly into the erecting eyepiece. See
Figure 1-5.
4. Your telescope also comes with a 3x Barlow lens which triples the
magnifying power of each eyepiece (see Magnification section of the
manual). To use the barlow lens, remove the diagonal and insert the
barlow lens directly into the focuser. Then start by using the low power
eyepiece such as the 20mm, and insert it either directly into the barlow
lens or into the diagonal. See Figure 1-5.
A
At tt ta ac ch hi in ng g t th he e F Fi in nd de er rs sc co op pe e
1. Remove the two small, silver thumbscrews located on top of the telescope tube. See Figure 1-6.
2. Place the finderscope bracket (4) over the two holes in the telescope tube, lining up the holes on the
finderscope bracket with those in the telescope tube.
3. Insert the thumbscrews through the finderscope bracket and thread them into the telescope tube.
Figure 1-3
Figure 1-4
Figure 1-5

6
A
Al li ig gn ni in ng g t th he e F Fi in nd de er rs sc co op pe e
1. Locate a distant daytime object and center it in a low power eyepiece in the main telescope.
2. Look through the finderscope and take notice of the position of the same object.
3. Without moving the main telescope, turn the adjustment thumb screws located
around the finderscope bracket until the crosshairs of the finder are centered on the
alignment object.
F
Fi in nd di in ng g O Ob bj je ec ct ts s
In order to use the equatorial mount's setting circles, the mount must first be aligned with the
earth's axis of rotation.
1. Turn the latitude adjustment screw (10) located at the rear of the mount to adjust the angle of the mount.
Look at the latitude scale and move the mount to the latitude of your location. This only has to be done
once unless you take the telescope to a different location. For example, Los Angeles, California is located
at about 34º. If you do not know your latitude, it can be
found on most road atlases of your area.
To change the direction your telescope is pointing:
2. To move the telescope in declination (north/south) there
are two options. For large and quick movements, loosen the
declination locking screw and manually move the
telescope, then tighten the knob when you are near the
position you want. For very small movements and fine
adjustments, use the declination slow motion control (9).
The declination cable has a range of about 30°. Do not try
to force movement when the declination cable has
reached the stop.
3. To move the telescope in right ascension (east/west) there are two options. For large and quick movements,
loosen the right ascension locking screw (located above the setting circle) and manually move the telescope,
then tighten the screw when you are near the position you want. For very small movements and fine
adjustments, use the right ascension slow motion control (19).
The telescope should be properly balanced in order for it to move smoothly in both axes. Proper balance is essential
if using an optional motor drive for accurate tracking.
4. To balance the right ascension axis, move the counterweight bar so it is parallel (horizontal) to the ground.
Slowly release the right ascension locking screw and see if the optical tube moves. If the optical tube
moves, then slide the counterweight up or down the counterweight bar until the optical tube remains
stationary in the parallel position to the ground. When this happens, make sure the counterweight lock
(located on the tip of the counterweight bar) is tight.
F
Fo oc cu us si in ng g
1. Once you have found an object in the telescope, turn the focusing knob until the image is sharp.
2. To focus on an object that is nearer than your current target, turn the focusing knob toward the eyepiece
(i.e., so that the focusing tube moves away from the front of the telescope). For more distant objects, turn
the focusing knob in the opposite direction.
3. To achieve a truly sharp focus, never look through glass windows or across objects that produce heat waves,
such as asphalt parking lots.
Declination
Setting Circle Right Ascension
Setting Circle
Figure 1-7
Latitude
Scale
Figure 1-6

7
I
Im ma ag ge e O Or ri ie en nt ta at ti io on n
1. When observing with a diagonal, the image will be right side up, but reversed from left to right.
2. When observing straight through, with the eyepiece inserted directly into the telescope, the image will
be inverted. Also, the image in the finderscope is inverted.
M
Ma ag gn ni if fi ic ca at ti io on n
The magnification (or power) of a telescope varies depending upon the focal length of the eyepiece being used and
the focal length of the telescope.
The PowerSeeker 60EQ telescope has a focal length of 900mm and comes with a 20mm 1¼" eyepiece. To calculate
magnification, use the following formula, in which FL = focal length:
Therefore, if you use the 20mm eyepiece your magnification is 900/20 = 45x. The same formula can be applied to
any of your eyepieces.
Magnification through any telescope has its limits. These limits are determined by the laws of optics and the nature
of the human eye. Most of your viewing will be done in the range of 35x to 120x. Higher powers are used mainly
for lunar and sometimes planetary observing where you can greatly enlarge the image and the atmospheric conditions
are near perfect. The images at extremely high powers magnify the image, but remember that the contrast will be
very low due to the high magnification. For the brightest images with the most contrast, start by using the lower
power eyepiece with a smaller image scale.
The following magnification levels can be achieved when using the standard eyepieces in conjunction with the 3x
Barlow lens:
Eyepiece Magnification Mag. with 1.5x
Erecting Eyepiece
Mag. with 3x Barlow
Lens
20mm 45x 68x 135x
4mm 225x 338x 675x
T
TE EL LE ES SC CO OP PE E M MA AI IN NT TE EN NA AN NC CE E
With proper care, your telescope should rarely need any maintenance work. To maintain your telescope in the best
possible condition, observe the follow suggestions:
1. When your telescope isn’t in use, replace all lens covers to keep dust and contaminants off the optical surfaces.
2. A small amount of dust on any optical surface isn’t a problem and doesn’t need to be removed. If the dust
builds up, then use a can of compressed air and a camels hair brush to remove the dust. To remove fingerprints
or other contaminants, use an optical cleaning kit or the Celestron Lens Pen (#93575).
3. If the inside of the objective lens needs cleaning, it should be done by a professional. Either have your
instrument serviced by a telescope repair facility or return it to the factory for servicing.
S
SP PE EC CI IF FI IC CA AT TI IO ON NS S
PowerSeeker 60EQ
Aperture 60mm
Focal Length 900mm
Focal Ratio f/15
Mounting Equatorial
Tripod Adjustable Aluminum Tripod
NOTE: Specifications are subject to change without notice.
Magnification =
FL (telescope) in mm
FL (eyepiece) in mm
Important!

8
O
Op pt ti io on na al l A Ac cc ce es ss so or ri ie es s
Celestron offers a full line of optional accessories for your telescope. Please refer to the Celestron Accessory
Catalog (#93685) for a complete description, or logon to our web site at www.celestron.com.
Eyepieces – An assortment of 1¼” eyepieces are available to give you a wide range of magnifications.
• OMNI Plössl - Plössl eyepieces have a 4-element lens designed for low-to-high power observing. The Plössls offer razor
sharp views across the entire field, even at the edges! In the 1-1/4" barrel diameter, they are available in the following focal
lengths: 4mm, 6mm, 9mm, 12.5mm, 15mm, 20mm, 25mm, 32mm and 40mm.
• Ultima – Ultima is not really a design, but a trade name for our 5-element, wide field
eyepieces. In the 1-1/4” barrel diameter, they are available in the following focal lengths:
5mm, 7.5mm, 10mm, 12.5mm, 18mm, 24mm, 30mm, 35mm, and 42mm. These eyepieces
are all parfocal. The 35mm Ultima gives the widest possible field of view with a 1-1/4”
diagonal.
Filters, Eyepiece - To enhance your visual observations of solar system objects, Celestron
offers a wide range of colored eyepiece filter sets that thread into the 1-1/4" oculars. Available
sets are:
#94119-10 – Orange, Light Blue, ND13%T, Polarizing (#s 21, 80A, 96ND-13, Polarizing)
#94119-20 - Deep Yellow, Red, Light Green, ND25% T (#s 12, 25, 56, 96ND-25)
#94119-30 - Light Red, Blue, Green, ND50% T (#s 23A, 38A, 58, 96ND-50)
#94119-40 - Yellow, Deep Yellow, Violet, Pale Blue (#s 8, 15, 47, 82A)
Flashlights - #93588 LED (light emitting diode) flashlights conveniently allow you to read star maps without
diminishing your night vision. Feature adjustable brightness and is lightweight.
Light Pollution Reduction (LPR) Filter (#94126A) - A 1¼” filter that threads into a 1¼” eyepiece, designed to
enhance your views of deep-sky astronomical objects when observed from urban areas. The LPR filter selectively
reduces the transmission of certain wavelengths of light, specifically those produced by artificial lights. This includes
mercury, and high and low pressure sodium vapor lights. Additionally, it blocks unwanted natural light (also known as
sky glow).
Sky Maps (#93722) – When learning the night sky, Celestron Sky Maps offer just the
guidance you need. The maps show all the constellations and brighter deep-sky objects
and are printed on heavy, moisture-resistant paper for durability. The front cover
features a rotating planisphere, indicating when specific constellations are visible.
Peterson First Guides® - Astronomy (#93728)
A simplified field guide to the stars, the planets and the universe featuring full color maps showing the positions of
the stars throughout the year. This useful guide also includes beautiful constellation paintings, photographs, and
clear, concise descriptions of stars, the planets, the sun, the moon, comets, black holes, galaxies and more.

CELESTRON TWO YEAR WARRANTY
a. Celestron warrants this telescope to be free from defects in materials and workmanship for two years. Celestron will repair or
replace such product or part thereof which, upon inspection by Celestron, is found to be defective in materials or workmanship. As a
condition to the obligation of Celestron to repair or replace such product, the product must be returned to Celestron together with
proof-of-purchase satisfactory to Celestron.
b. The Proper Return Authorization Number must be obtained from Celestron in advance of return. Call Celestron at [phone] to
receive the number to be displayed on the outside of your shipping container.
All returns must be accompanied by a written statement setting forth the name, address, and daytime telephone number of the owner,
together with a brief description of any claimed defects. Parts or product for which replacement is made shall become the property of
Celestron.
The customer shall be responsible for all costs of transportation and insurance, both to and from the factory of Celestron, and
shall be required to prepay such costs.
Celestron shall use reasonable efforts to repair or replace any telescope covered by this warranty within thirty days of receipt. In the event
repair or replacement shall require more than thirty days, Celestron shall notify the customer accordingly. Celestron reserves the right to
replace any product which has been discontinued from its product line with a new product of comparable value and function.
This warranty shall be void and of no force of effect in the event a covered product has been modified in design or function, or
subjected to abuse, misuse, mishandling or unauthorized repair. Further, product malfunction or deterioration due to normal
wear is not covered by this warranty.
CELESTRON DISCLAIMS ANY WARRANTIES, EXPRESS OR IMPLIED, WHETHER OF MERCHANTABILITY OF FITNESS FOR
A PARTICULAR USE, EXCEPT AS EXPRESSLY SET FORTH HEREIN.
THE SOLE OBLIGATION OF CELESTRON UNDER THIS LIMITED WARRANTY SHALL BE TO REPAIR OR REPLACE THE
COVERED PRODUCT, IN ACCORDANCE WITH THE TERMS SET FORTH HEREIN. CELESTRON EXPRESSLY DISCLAIMS
ANY LOST PROFITS, GENERAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHICH MAY RESULT FROM
BREACH OF ANY WARRANTY, OR ARISING OUT OF THE USE OR INABILITY TO USE ANY CELESTRON PRODUCT. ANY
WARRANTIES WHICH ARE IMPLIED AND WHICH CANNOT BE DISCLAIMED SHALL BE LIMITED IN DURATION TO A
TERM OF TWO YEARS FROM THE DATE OF ORIGINAL RETAIL PURCHASE.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitation on how long an implied warranty
lasts, so the above limitations and exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Celestron reserves the right to modify or discontinue, without prior notice to you, any model or style telescope.
If warranty problems arise, or if you need assistance in using your telescope contact:
Celestron
Customer Service Department
2835 Columbia Street
Torrance, CA 90503 U.S.A.
Tel. [phone]
Fax. [phone]
Monday-Friday 8AM-4PM PST
This warranty supersedes all other product warranties.
NOTE: This warranty is valid to U.S.A. and Canadian customers who have purchased this product from an Authorized Celestron
Dealer in the U.S.A. or Canada. Warranty outside the U.S.A. and Canada is valid only to customers who purchased from a Celestron
Distributor or Authorized Celestron Dealer in the specific country and please contact them for any warranty service.
Printed in China #21043-INST
04-03
