Celestron HomeCast 47021 User manual

USERS MANUAL
MODEL #47021
ENGLISH
WEATHER STATION
WITH REMOTE SENSOR

MAIN UNIT
LCD
A1: Outdoor temperature trend
A2: Air pressure trend
A3: Outdoor temperature
A4: Weather forecast
A5: Indoor temperature
A6: Indoor humidity
A7: Comfort indicator bar
A8: Time
A9: Moon phase
A10: Date, day of week
INTRODUCTION
2
A2
B1 B2 B3 B4 B5
A4
A6
A7
A1
A3
A5
A8 A10
A9

BUTTONS
B1: ALARM Button
B2: + (12/24) Button
B3: SNOOZE/LIGHT
Button
B4: -(C/F) Button
B5: MODE Button
B6: RESET Button
B7: MAX/MIN Button
B8: WEATHER Button
B9: CHANNEL Button
HOUSING
C1: Wall mount hole
C2: Battery cover
C3: Stand
3
B6
B7
B8 B9
C1
C2
C3

SENSOR
D1: Transmission indication LED
D2: Wall mount hole
D3: Battery compartment
D4: RESET button
D5: Channel select switch
D6: Stand
4
D1
D6
D2
D3
D4
D5

FEATURES
Weather Forecast
- LCD animation displays sunny, slightly cloudy, overcast, rainy
and freezing rain/snow
Time - 12/24 Hour - User selectable
- Dual time setting
- Snooze alarm function
- Internal calendar (up to 2099)
- Day of week displayed in choice of 8 languages
Humidity
- Measurable range: 20 ~ 99%
- High and low temperature readings (max/min)
Temperature
- Indoor measurable range: 0 ~ 50°C [+32 ~ +122°F]
- Measures °C and °F – User selectable
- Outdoor measurable range: -20 ~ 50°C [-4 ~ +122°F]
- Max/Min memory [indoor & outdoor]
- Comfort indicator bar
Wireless Outdoor Sensor
- Low-battery indicator for outdoor thermo sensor
- Wall mount or table stand
- One wireless thermo sensor included
- 433MHz RF transmitting frequency
- 30 Meter [98 feet] transmission range in an open area
5

GETTING STARTED
Main Unit:
 
 
 
 RESET
 
Outdoor Sensor:
 
 
 
 
INSTALLATION
 

 

Note: Transmissions between the main unit and the sensor can reach up to 30m barring
any interfering obstacles such as buildings, trees, vehicles, high voltage lines, etc.
6

WEATHER FORECAST DISPLAY
 

 

 WEATHER button (B8) for 3 seconds until the

 
 WEATHER
Note: The current weather status should be reset if there is a change of altitude.
There are 5 different weather status animations in the weather forecast:







 

7
Freezing or Snow Rain Overcast Partly Cloudy Sunny



THERMOMETER TRANSMISSION PROCEDURE
 
installed and will start to receive transmission from the sensor(s) as soon as



 


Note: Buttons (except CHANNEL and LIGHT buttons) will not function while scanning for
sensor’s temperature signal.
BAROMETRIC TREND POINTER (A2)
The trend pointer displayed on the LCD (A2) indicates the Barometric

Indicating the barometric
pressure trend is rising
Indicating the barometric
pressure trend is falling
Indicating the barometric
pressure trend is steady
8

Temperature& Humidity
 

 CHANNEL
 

 
 

Outdoor Temperature Trend
 

Outdoor temperature
is rising
Outdoor temperature
is steady
Outdoor temperature
is falling
 

 LL.L (beyond the minimum
temperature) or HH.H (beyond the maximum temperature) will be shown on

9

10
Maximum and Minimum Temperature and Humidity Readings
 
and outdoor temperatures and relative humidity readings within a desired
MAX/MIN button (B7)

“start” time for the weather station to monitor the high and low temperatures

MAX icon will be displayed atop the inside and outside maximum

the minimum temperature and relative humidity reading will be displayed,
accompanied by the MIN
Humidity
 

Comfort Indicator Bar:
 




11
CLOCK AND ALARM
Time and Alarm Setting
 MODE button (B5) for 3 seconds to enter the Clock/Calendar

 -
MODE
 

 

 

 

LanguageSundayMondayTuesdayWednesdayThursdayFridaySaturday
German,GESOMODIMIDOFRSA
English,ENSUMOTUWETHFRSA
Russian,RUBCПНBTCPЧТ ПТСБ
Denmark,DASOMATIONTOFRLO
Dutch,NEZOMADIWODOVRZA
Italian,ITDOLUMAMEGIVESA
Spanish,ESDOLUMAMIJUVISA
French,FRDILUMAMEJEVESA

Note: Your device’s time zone should be set at “0”


12
12/24 Hour Display Mode:
 12/24
Daily Snooze Alarm Function:
 MODE button (B5) twice, until AL is displayed on the LCD (where

 MODE button (B5) for 3 seconds


 MODE
 ALARM 

 SNOOZE/LIGHT (B3) button to activate

 
 
Dual Time Setting Function
 

 MODE button (B5) 3 times until DT is displayed on the LCD


13
 MODE button (B5) for

 
 
 MODE
Moon Phase Display
 



A. B. C. D. E. F. G. H.
A. New Moon
B. Waxing Crescent
C. First Quarter
D. Waxing Gibbous
E. Full Moon
F. Waning Gibbous
G. Last Quarter
H. Waning Crescent
Low Battery Indicator
 
Backlight
 SNOOZE/LIGHT
 



14
PRECAUTIONS
 
 

 
 

 

 

 
Abrasive cleaning agents may scratch plastic parts and corrode electronic

 

The manufacturer will not be held responsible for incorrect forecasting from


15
SPECIFICATIONS
Indoor:
Temperature Range: 0 to 50°C [+32 to +122°F]
Temperature Units Measured: °C or °F [switchable]
Humidity Range: 20% to 99%
Weather Forecast 5 icons (sunny, slightly cloudy, cloudy,
and rainy & snow)
Outdoor:
Transmission Distance: 30m @ 433MHz
Temperature Range: -20°C to 50°C [-4 to +122°F]
Mount: wall / table
Main Unit Dimensions: w130 x h130 x d30 mm
Sensor Dimensions: w62 x h101 x d24 mm
Battery Requirements:
Base Station:
Sensors:
3 x AA batteries
2 x AAA batteries




©2012 Celestron

FCC Statement

the following two conditions:
 
 
 






MANUEL DE
L'UTILISATEUR
MODÈLE #47021
FRANÇAIS
STATION MÉTÉOROLOGIQUE
AVEC CAPTEUR À DISTANCE

UNITÉ PRINCIPALE :
LCD
A1 : Tendance température extérieure
A2 : Tendance pression atmosphérique
A3 : Température extérieure
A4 : Prévision météorologique
A5 : Température intérieure
A6 : Humidité intérieure
A7 : Barre d'indicateur de confort
A8 : Heure
A9 : Phase lunaire
A10 : Date. jour de la semaine
INTRODUCTION
2
A2
B1 B2 B3 B4 B5
A4
A6
A7
A1
A3
A5
A8 A10
A9

BOUTONS
B1 : Bouton
ALARME
B2 : Bouton + (12/24)
B3 : SNOOZE/LUMIÈRE
Bouton
B4 : Bouton - (C/F)
B5 : Bouton MODE
B6 : Bouton RESET
B7 : Bouton MAX/MIN
B8 : Bouton MÉTÉO
B9 : Bouton CANAL
BOÎTIER
C1 : Trou montage
mural
C2 : Couvercle de piles
C3 : Support
3
B6
B7
B8 B9
C1
C2
C3

CAPTEUR
D1 : DEL indicateur de transmission
D2 : Trou montage mural
D3 : Compartiment de pile
D4 : Bouton RESET
D5 : Commutateur de sélection de
canal
D6 : Support
4
D1
D6
D2
D3
D4
D5
