Cellvine BDA-AWS21-26-4UT-AB-JXX User manual

USER MANUAL
BDA-AWS21-26-4UT-AB-JXX
OVER-THE –AIR REPEATER
VER. 1.06

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
Important Notice
This manual contains information that is proprietary to
Cellvine Ltd. No part of this publication may be
reproduced in any form whatsoever without prior
written approval by Cellvine Ltd.
No representation or warranties for fitness for any
purpose other than what is specifically mentioned in
this manual is made either by Cellvine or its agents.
For further information contact Cellvine at the address
below or contact your local distributor.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA
-
AWS21
-
26
-
4UT
-
AB
-
JXX
Rev
1.0
6
200
9
-
05
1-YEAR LIMITED HARDWARE
AND SOFTWARE WARRANTY
Cellvine Ltd. warrants all Repeater
Products against electrical
malfunction for a period of One (1)
year from shipment of the product to
the purchaser. If Cellvine receives
notice of defects during the warranty
period, Cellvine will either replace or
repair the products.
WARRANTY EXCLUSIONS AND
LIMITATIONS
The warranty shall not apply to
defects resulting from improper
operation, inadequate maintenance,
or unauthorized use or modification
by the customer of the Repeater
products or software. The warranty
service and service beyond the
warranty period described herein
are the customer's sole remedies.
OBTAINING SERVICE DURING
AND BEYOND WARRANTY
PERIOD
To obtain warranty service, the
customer shall return the Repeater
product to Cellvine Ltd with date
and proof of purchase and an
explanation of the problem. The
customer shall pay for shipping
charges and Cellvine shall pay for
return shipping. For service beyond
the warranty period, contact
Cellvine for details of available
service.
GETTING HELP
The Repeaters have undergone
extensive testing prior to shipment.
All of the functions have been
thoroughly tested. However, if there
are problems that you discover,
please call us. We are here to help.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
Contacting Cellvine
Headquarter
Cellvine Ltd.
Phone: [phone]
Fax: [phone]
[e-mail]
U.S. Office
55 Madison Ave , Suite 400
Morristown , NJ 07960
Phone : [phone]
Fax : [phone]
[email protected]m

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
About this Manual
This User’s Manual is intended for e perienced installation technicians
and engineers.
It contains the following:
•A general description of the BDA-AWS21-26-4UT-AB-JXX
Repeater system and system components
•Installation overview
•Repeater system operation

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
Contents
1. INTRODUCTION................................................................1
1.1. General Description..........................................................1
2. SYSTEM COMPONENTS..................................................2
2.1. BDA-AWS21-26-4UT-AB-JXX Repeater Kit .....................2
2.2 REPEATER UNIT ...............................................................2
2.3 Repeater UNIT RF Specifications ....................................3
2.4 Repeater Block diagram...................................................4
2.5 Repeater UNIT Pass-band Filters ....................................5
2.6 Dimensions and Weight ...................................................6
2.7 Repeater unit Interfaces ...................................................6
3. INSTALLATION.................................................................7
3.1 Unpacking and Inspection ...............................................7
3.2 Operating Environment ....................................................8
3.3 Pre-Installation Inspection ...............................................8
3.4 Antennas Installation........................................................8
3.5 Repeater unit Mechanical Installation ........................... 10
3.6 Repeater cable connection ............................................ 15
3.7 System INDICATIONS ..................................................... 16
3.8 Tuning Donor antenna.................................................... 17
3.9 Antenna Isolation............................................................ 17

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
4REPEATER MONITORING AND CONTROL..................18
4.1 preparing the repeater for local connection ................. 18
4.2 repeater monitoring and control.................................... 22
4.3 preparing the repeater for remote connection via
intRAnet:......................................................................... 31
5TROUBLESHOOTING.....................................................32

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
Figures
Figure 1-1: BDA-AWS21-26-4UT-AB-JXX Repeater ...................................1
Figure 2-1: System Block Diagram .............................................................4
Figure 2-2: Repeater dimensions................................................................6
Figure 3-1: Repeater Installation............................... האיגש !תרדגומ הניא הינמיסה.
Figure 3-2: Cable Connections .................................................................15
Figure 3-3: Repeater Indications LEDs.....................................................16

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
Abbreviations
The terms, acronyms and abbreviations used in this manual are detailed
in the following list:
Abréviation Description
AGC Automatic Gain Control
BDA Bi Directional amplifier
BL Bluetooth
Div Diversity
DU Donor Antenna Unit
LED Light Emitting Diode
LNA Low Noise Amplifier
NMS Network Management System
PA Power Amplifier
PSU Power Supply Unit
REP Repeater
RF Radio Frequency
RSSI Received Signal Strength Indication
RU Remote Unit
RX Receiver
SC Service Channel
TX Transceiver unit

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
General Safety Warning
Always observe standard safety precautions during installation, operation
and maintenance of this product. Only qualified and authorized personnel
should carry out adjustment, maintenance or repairs to the components of
this system.
DANGER:ELECTRICAL SHOCK
The power supply unit contains dangerous voltage that can cause electric
shock. Disconnect the mains prior to any work in the Repeater. Any local
regulations are to be followed when servicing Repeaters.
This equipment is usually installed indoors. Wet conditions increase the
potential for receiving an electric shock when installing or using
electrically powered equipment. To prevent electrical shock when
installing or modifying the system power wiring, disconnect the wiring at
the power source before working with insinuated wires or terminals.
Repeaters supplied from the mains must be connected to grounded outlets
and in conformity with any local regulations.
CAUTION:HIGH GROUND
When working on a Repeater on high ground, e.g. on a mast or pole, be
careful not to drop parts or the entire Repeater. Falling parts can cause
serious personal injury.
CAUTION:COAX CABLE BENDING
Allow sufficient coa cable length to permit routing of patch cords or
pigtails without severe bends.
CAUTION:RADIATION
Any Repeater, including this Repeater, will generate radio signals and
thereby give rise to electromagnetic fields that may be hazardous to the
health of any person who is e tensively e posed to the signals at the
immediate pro imity of the Repeater and the Repeater antennas.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
CAUTION:STATIC ELECTRICITY
Static electricity means no risk of personal injury but it can severely
damage essential parts of the Repeater, if not handled carefully.
Parts on the printed circuit board as well as other parts in the Repeater
are sensitive to electrostatic discharge.
Never touch the printed circuit board or uninsulated conductor surfaces
unless absolutely necessary.
If you must handle the printed circuit board or uninsulated conductor
surfaces, use ESD protective equipment, or first touch the Repeater
chassis with your hand and then do not move your feet on the floor.
Never let your clothes touch printed circuit boards or uninsulated
conductor surfaces.
Always, store printed circuit boards in ESD-safe bags.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his e pense. Changes or
modifications not e pressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
1
1. Introduction
1.1. GENERAL DESCRIPTION
The goal of the Repeater system is to improve coverage for T-MOBILE AWS
(1710-1755MHz, 2110-2155 MHz) in medium size indoor areas of up to
50,000 sq. ft.
Figure 1-1: BDA-AWS21-26-4UT-AB-JXX Repeater
The system implements BDA technology to enhance coverage in urban
areas. Repeaters are used to fill out uncovered areas in cellular mobile
systems, such as base station fringe areas, road tunnels, business and
industrial buildings, etc. A Repeater receives signals from a base station,
amplifies the signals and retransmits them to service area. It also receives,
amplifies and retransmits signals in the opposite direction. Both directions
are served simultaneously.
In order to receive and transmit signals in both directions, the Repeater is
connected to a donor antenna directed towards the base station and to a
service antenna directed towards the area to be covered.
Control of the Repeaters is performed using a desktop or laptop computer
equipped with standard browser (no special software) which can
communicate with the Repeaters, either locally or remotely via modem
(optional).

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
2
2. System components
2.1. BDA-AWS21-26-4UT-AB-JXX REPEATER
KIT
1. Power Supply
2. Ethernet CAT5E cable for Operation and Maintenance of the unit
using a PC .
3. Repeater unit
4. Wall mounting
5. Power supply optional installation kit
6. This manual
2.2 REPEATER UNIT
Cellvine’s indoor BDA
BDABDA
BDA-
--
-AWS21
AWS21AWS21
AWS21-
--
-26
2626
26-
--
-4UT
4UT4UT
4UT-
--
-AB
ABAB
AB-
--
-JXX
JXXJXX
JXX Repeater has been designed
to enhance and e tend cellular coverage into small and medium-size
buildings, restaurants, underground areas, office buildings and other
similar indoor environments. It provides the following functionalities:
•High linearity and low noise amplifiers
•Telco grade reliability
•High gain AWS +80dB
•Advanced AGC
•Oscillation detection and protection
•Output power +26 dBm Downlink, 18dBm Uplink
•Full local and remote control and diagnostics
•Available communication through Ethernet protocol
•cellular modem for remote monitoring and control
•Adjustable filters for various T-MOBILE AWS sub bands

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
3
2.3 REPEATER UNIT RF SPECIFICATIONS
Parameters Specifications
Frequency Range (Down / Up) See AWS BANDS table below
Output Power DL: 26 dBm
UL: 18 dBm
System Max Gain 80dB +/-2dB
Delay Less then 5usec
Waveform EVM<12%
Ripple +/-2dB
Noise Figure <7dB
Filter rejection >-40dBc @1Mhz from corner frequency
Gain tuning range 30dB in 1dB steps
VSWR 1.5:1
Operating Temperature Standard: -20C to + 60C.
Manual Indicators\Controls See below
Alarms See below
Dimension 16X 10.5X 5 (inches)
Power Requirements 10VDC,<80W from external power supply
(included)
RF Connector N Type female

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
4
2.4 REPEATER BLOCK DIAGRAM
Figure 2-1: System Block Diagram

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
5
2.5 REPEATER UNIT PASS-BAND FILTERS
The BDA-AWS21-26-4UT-AB-JXX Repeater unit supports simultaneously
and independently, two of the following sub band options:
REPEATER SUB BAND OPTIONS
Configuration Uplink [MHz] Downlink [MHz]
A 1710-1720 2110-2120
B 1720-1730 2120-2130
C 1730-1735 2130-2135
D 1735-1740 2135-2140
E 1740-1745 2140-2145
F 1745-1755 2145-2155
C+D 1730-1740 2130-2140
D+E 1735-1745 2135-2145
NOTE
The system can be configured to one or two sub bands from the above list
of BW 5 or 10 MHz. Any filter can be turned off, if needed

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
6
2.6 DIMENSIONS AND WEIGHT
The dimension of the Repeater, including the mounting bracket, is shown in
Figure2-2.
Figure 2-2: Repeater dimensions
Appro imate Repeater weight: 12 Kg (26 lbs)
2.7 REPEATER UNIT INTERFACES
The Repeaters interfaces are located at the bottom, op and the side of the
Repeater.
Table 2-1 :
: :
: Repeater
RepeaterRepeater
Repeater Interfaces
Interfaces Interfaces
Interfaces
Name Type Function
SERVICE N-Type female connector Connect to Service antenna
DONOR N-Type female connector Connect to Donor antenna
POWER PLT DC connector Connect to Power supply
COM RJ 45 Ethernet connection to PC
SNMP RJ 45 Ethernet connection to LAN

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
7
3. Installation
This section provides information for the installation and setup of the
Cellvine Repeaters.
The information consists of procedures for unpacking, inspection and
preparation for the installation, as well as the actual installation and the
setup. It is important that the Repeater will be installed correctly at its
working location. It is recommended that installation be done by a certified
radio technician.
The Repeater installation consists of five basic steps:
(1) Unpacking and inspection
(2) Antenna installation
(3) Repeater installation
(4) Cable installation
(5) Repeater parameters Set-Up and tuning with Control application.
3.1 UNPACKING AND INSPECTION
E amine the shipping package for damage before unpacking the unit. If the
shipping package is damaged, try to have the carrier’s agent present when
the equipment is unpacked. If visual inspection reveals physical damage(s)
to the equipment, you should send it back for replacement.
Verify that the equipment includes all components, as listed under packing
slip. Contact Cellvine Ltd. if you find missing components.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
8
3.2 OPERATING ENVIRONMENT
Cellvine's indoor Repeaters are intended for installation indoors only.
Do not install them where they might be e posed to direct sunlight and
rain\snow conditions as this could be harmful to the unit. For normal
operation, the environmental conditions should be as follows:
Ambient temperature range: –20 °C to +60 °C, Ma imum Humidity: 90 %.
3.3 PRE-INSTALLATION INSPECTION
Before beginning the Repeater installation determine the following:
oBase station location and receiving power ( T power in dBm )
oLocation where the DONOR/ Service antenna is to be installed
oLocation where the Repeater is to be installed
oLength of coa ial cable needed to connect from the Donor antenna
to the Repeater unit
oLength of coa ial cable needed to connect from the Repeater unit
to the indoor antenna/s.
oIsolation estimation between the donor and the coverage antenna/s.
3.4 ANTENNAS INSTALLATION
3.4.1 Coverage (Service) Antennas
Coverage (service) antennas are facing to the service area. The mostly used
Antennas for indoor applications are Omni or panel antennas. When
multiple indoor areas need coverage, more than one antenna can be used.
The indoor antennas are usually placed near the ceiling with decorative
covers, antenna location decisions take into account isolation issues and
overcoming interfering signals. For outdoor coverage, panel antennas are
commonly used, location of the antenna is defined by coverage and isolation
matter.

CELLVINE LTD. BDA-AWS21-26-4UT-AB-JXX
BDA-AWS21-26-4UT-AB-JXX Rev 1.06 2009-05
9
3.4.2 DONOR Antenna
DONOR antenna is installed outside, facing to the donor BTS. The donor
cell site should be chosen by considering capacity, range and signal level in
the outdoor antenna location. The location should be chosen so that the
donor cell site will be received at a higher level than all other adjacent cell
sites. If possible this antenna should be faced directly to the nearest cellular
site with a line of sight view. This antenna should also be properly
grounded with an appropriate grounding strap and lightning protection if
needed. Install the antenna according to antenna manufacturer
instructions.
