Celsi B-160940 User manual

BFM EUROPE LTD Page 1
HOME OWNERS INSTRUCTIONS & OPERATING MANUAL
FLAMONIK ENCHANT & RAPTURE ELECTRIC FIRE
Model No.: B-160940 & B-160940-1 & B-160950
Article No.: MH36BLC/P & MH36MR & MH27BLC/P
Packing Check list
Package 1 1 off Electric fire
1 off Remote control handset and battery
1 off Instructions manual and fixing kit
1 off Coal fuel bed or crystal beads (depending on model)
1 off Fascia
IMPORTANT
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved!
Children shall not play with the appliance!
Cleaning and user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it
has been placed or installed in its intended normal operation position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 2
IMPORTANT INSTRUCTIONS
PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND/OR
USE OF THIS ELECTRIC FIRE AND RETAIN FOR FUTURE REFERENCE.
WHEN USING ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS,
INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
Regarding installation of the appliance;
· This appliance is supplied with a rewirable plug fitted with
a 13A fuse. Should the fuse or plug need replacing, and
you are competent to do so, it must be replaced with a
13A fuse and the plug muse be a 13amp BS1363A
approved fitted with a 13A fuse.
· Connect this appliance to single-phase AC supply of the
voltage specified on the rating plate.
· This heater must be earthed. If in any doubt consult a
suitable competent person.
· Ensure that the plug socket-outlet connection for this appliance is accessible.
It MUST be readily accessible for easy electrical isolation in the event of servicing and replacing
components etc.
· This appliance MUST NOT be located immediately below an electrical socket-outlet.
· Avoid the use of an extension cord as this may overheat and cause a risk of fire.
· This appliance is fitted with an automatic thermal cut out to reduce the risk of damage in the event of
abnormal operation e.g. when covered. If the heater stops operating whilst the flame effect continues
normally this indicates that the cut out is in operation. If this occurs disconnect the power supply at
the plug socket-outlet and ensure that any obstructions to the fan heater outlet or fan blades etc. are
removed. The heater will automatically reset when cool enough. The thermal cut out WILL NOT
RESET unless the obstruction is removed and the appliance cools. If the heater is still not operating
after 10 minutes disconnect the appliance and seek expert advice.
· If the supply cord is damaged it must be replaced by the manufacturer, its service agent or a similarly
qualified person in order to avoid a hazard. The cable used MUST be capable of handling 2.5kW of
power at 240V and MUST contain an earth wire.
· To completely shut this appliance off turn all the controls to OFF and remove the plug from the socket-
outlet.
· Use the heater in a well-ventilated area.
Regarding persons operating the appliance;
· This appliance is not intended for use by persons (including children) with reduced physical, sensory
or learning disabilities, or lack of experience and knowledge, unless given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
· Children should be supervised at all times to ensure that they do not play with the appliance.
· Extreme caution is necessary when any heater is used by or near children, disabled or elderly persons
and whenever the heater is left operating unattended.

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 3
IMPORTANT INSTRUCTIONS
DO NOT cover the heater. The meaning of figure is “WARNING! DO NOT COVER”. This is to avoid
over-heating of the product.
DO NOT leave the heater unattended while it is in use. Always turn the appliance to the OFF position and
unplug it from the electrical outlet when not in use.
DO NOT operate this appliance with a damaged cord or plug, or after the appliance malfunctions, has
been dropped or damaged in any way.
DO NOT use this appliance with a programmable timer or any other device that switches the appliance
on and off automatically. In order to avoid a hazard due to inadvertent resetting of the thermal cut out.,
this appliance must not be supplied through an external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by an utility.
DO NOT use this appliance as a freestanding appliance. It must always be fixed to a wall, fireplace or
floor etc.
DO NOT insert or allow objects to enter any ventilation or exhaust openings on the appliance. To
prevent a possible fire do not block air intakes or exhaust openings in any manner.
DO NOT use this appliance on soft surfaces, such as beds, where openings may become blocked. Use
the appliance on flat, dry surfaces only.
DO NOT place this appliance near flammable materials, surfaces or substances, as there may be a risk
of fire. Keep flammable materials, surfaces or substances at least 1 metre from the front of the product
and keep them away from the sides and rear.
DO NOT use this appliance in any areas where petrol, paint or other flammable liquids are stored e.g. a
garage or a workshop as the appliance contains components capable of producing a spark.
DO NOT use this appliance in the immediate surroundings of a bath, shower or swimming pool. Make
sure it cannot fall into water. Never touch the appliance with wet hands.
DO NOT let bare skin touch any hot surfaces to avoid burns and personal injury. This heater is hot
when in use.
DO NOT use outdoors.
CAUTION- Some parts of this product can become very hot and cause burns. Particular attention has to
be given where children and vulnerable people are present.
This appliance is for household use only.
This heater is not equipped with a device to control the room temperature.Do not use this heater in small
rooms when they are occupied by persons not capable of leaving the room on their own ,unless constant
supervision is provided.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE.

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 4
INSTALLATION PREPARATION
CAUTION: This carton includes a GLASS panel! Always use extreme caution when handling glass. Failure
to do so could result in personal injury or property damage.
PRODUCT SPECIFICATION
Voltage…………………………………230 V AC, 50Hz
Total Watts……………………………1.8kW (2X900 Watts)
Fire Dimensions
Rapture 27”
(Heater only)…………………………H 357 mm x W 625 mm x D 102mm
(With fascia fitted)…………………H 441 mm x W 686 mm x D 110mm
Enchant 36”
(Heater only)…………………………H 357 mm x W 855 mm x D 120mm (102mm for mirror trim version)
(With fascia fitted)…………………H 441 mm x W 916 mm x D 126mm (110mm for mirror trim version)
STRUCTURE AND PARTS
1
2
3
4
5
6
TOOLS REQUIRED
1. Screen
2. Manual Keypad
3. Back Light LED
4. ON/OFF Switch
5. Power Inlet
6. Air Outlet

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 5
INSTALLATION PREPARATION
WANING! DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER.
IMMEDIATELY CALL A QUALIFIED SERVICE TECHNICIAN TO INSPECT AND TO REPLACE ANY
PART OF THE ELECTRICAL SYSTEM IF NECESSARY.
· Open the packaging carefully and remove the foam.
· Remove and discard the plastic bag.
· Be responsible when handling the packing materials.
· Keep the original packaging for future transportation and/or storage.
· Check all accessories are removed from the packaging before storing it away for future use.
NOTE: KEEP PLASTIC WRAPPING AWAY FROM CHILDREN!
LOCATING YOUR ELECTRIC FIREPLACE/HEATER
This appliance may be installed virtually anywhere in your home. However, when choosing a location
please ensure that the general instructions are followed. For best results, install out of direct sunlight.
Make sure that the plug or fused spur is accessible after the electric fire is fitted.
Before connecting the appliance make sure that its rating corresponds to that of the mains supply and
the fuse is the correct rating.
The appliance should be located close to a suitable mains socket-outlet to enable connection. The
electrical socket-outlet must be easily accessible to allow disconnection.
NOTE: the appliance is fitted with an inlet plug and socket underneath the right side of the
casing. Always make sure that it is fully pushed in and secure before operating the fire. Damage
could occur if it is not fitted properly.
WARNING! KEEP DRAPERY AND OTHER FURNISHINGS AT LEAST 3’/0.9M FROM THE
FRONT AND SIDES OF THE ELECTRIC HEATER
CLEARANCE TO COMBUSTIBLES
Sides…………… 4in. (100mm)
Floor…………… 15 3/4 in. (400mm)
Top…………….. 0 in. (0mm)
Back…………… 0 in. (0mm)

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 6
INSTALLATION INSTRUCTIONS
Step 1: Using a screwdriver loosen the two screws that secure the wall mounting bracket to the top of the
appliance and remove the wall mounting bracket as shown below (Figure 1).
Figure 1
Step 2: Choose a solid and plain wall. Position the mounting bracket where the appliance is to be
installed on the wall and ensure that the bracket is level. Using a pen mark the 4 holes through the 4
holes on the mounting bracket as shown below (Figure 2)
Figure 2
Step 3: Take away the mounting bracket and then drill four 8mm diameter holes on the wall. Insert
plastic wall plug into the drilled holes (Figure 3). If installing the appliance on a solid wood wall there is
no need to drill the holes in the wood and no need for the plastic wall plug.
Figure 3

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 7
INSTALLATION INSTRUCTIONS
Step 4: Fix the mounting bracket using the four screws supplied (Figure 4).
Step 5: Hang the appliance on the hooks at the bottom of the bracket and push the top of the appliance
into the mounting bracket. Now fix the appliance to the mounting bracket by refitting the two M4×8
screws which were removed in step 1(Figure 5).
Figure 4 Figure 5
Step 6: The Electric fire is supplied with 2 fuel bed options. Firstly remove the 2 cardboard fitments which
hold the fitted fuel bed in place. Depending on the product purchased there will be a second fuel bed
option included.
The Enchant has the option of a log or Coal effect Fuel bed.
The Rapture has the option of a Coal effect fuel bed or loose crystal beads.
Place the desired fuel bed effect into position along the bottom ledge of the screen.
Coal effect fuel bed (set) Log (set)
crystal (set)

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 8
INSTALLATION INSTRUCTIONS
Step 7: Fit the appliance front fascia by locating the two tabs into the slots on top of the electric fire as
shown below . (Figure 6)
Secure the fascia in place at both sides using the two supplied screws.
Figure 6
NOTE: Removal of the electric fire is carried out by following the previous steps in reverse order.
CAUTION! THE UNIT’S POWER CORD MUST BE CONNECTED TO A PROPERLY
EARTHED AND PROTECTED 230V OUTLET. ALWAYS USE EARTH FAULT PROTECTION
WHERE REQUIRED BY THE ELECTRICAL CODE.
This appliance can be operated by both a remote control and a manual keypad. Once the unit has been
properly connected to an earthed electrical socket-outlet ensure the manual On/Off switch, located on
the right hand side of the appliance, is in the ‘ON’ position.
MAUNAL ON/OFF SWITCH
This switch turns the appliance on/off. The manual on/off switch must be in the ‘ON’ position when
using both remote and manual operation.
WARNING! DO NOT OPERATE THE UNIT IF IT IS DAMAGED OR HAS MALFUNCTIONED. IF
YOU SUSPECT THE UNIT IS DAMAGED PLEASE CALL A QUALIFIED SERVICE TECHNICIAN TO
INSPECT AND TO REPLACE ANY PART OF THE ELECTRICAL SYSTEM IF NECESSARY.
OPERATING INSTRUCTIONS

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 9
OPERATING INSTRUCTIONS
The Fireplace/Heater Unit
On the top right side plate of the fireplace/heater unit is the control panel. This panel contains the
buttons to properly operate the fireplace/heater unit. Refer to below figure for placement of the control
buttons.
The upper segment of the control panel, (1), is the Main Power button. As the name infers, the Main
Power button controls the overall power to the fireplace/heater unit. Pressing the button once turns
power on to the entire unit, and pressing the button again will turn power off to the entire unit. If you
find that none of the other buttons appear to work, check to make sure that Main Power is turned on to
the unit.
The next segment, (2) is the Flames Control button. Like the Main Power button it controls the
flames and fuel bed lights of the electric heater unit. Pressing the button once turns the flames on and
the fuelbed lights up orange, a second press of the button will keep the flames on and change the
fuelbed to blue. Further button presses will cycle through the options listed below.
BUTTON PRESS
Flame State
Fuel bed Colour
1st press
ON
Orange
2nd press
ON
Blue
3rd press
ON
Orange & Blue
4th press
ON
Automatically Display
5th press
OFF
OFF
The next segment, (3),L_heat Control, is a low heat button for the heater. Pressing the button
once ,the low heat function is on, and pressing the button twice ,the low heat function is off.
The next segment, (4), H_heat Control , is a high heat button for the heater. Pressing the button once ,the
high heat function is on, and pressing the button twice ,the high heat function is off.

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 10
Lock or unlock heat function mode:
When the Main Power button is on, pressing and holding this H_heat Control button 10 seconds to enter heating
function locked mode, the fuel bed lights will flicker 6 times. Then every time you press the button, there are 6
times flash only the fuel bed lights but no heating function in this mode. Anew pressing and holding this H_heat
Control button 10 seconds, this mode will be unlocked after 6 times flash.When you press the L_heat button or
the H_heat button, The fuel bed lights will flash one time to indicate heat function is on or off.
The last segment, (5), is the Decorative lights Control button. Like the Flames Control button,Pressing
the button once ,the sidelights display orange, and pressing the button twice,it will show you the blue
sidelights .You can control the sidelights colour as the following:
BUTTON PRESS
Sidelights Colour
1st press
Orange
2nd press
Blue
3rd press
Magenta
4th press
Automatically Display
5th press
OFF
The automatically mode will show you: the orange sidelights is on and running 10 seconds, then off; then the blue
sidelights is on and running 10 seconds, then off; then the white sidelights are on and running 10 seconds, then off;
and then the orange sidelights is on and running 10 seconds, then off…. This mode will be circulating running.
NOTE: If this product experiences exceptionally high temperature, it may automatically stop heating. If this occurs
the product should be unplugged or isolated from the main supply and allowed to cool before the power is
resupplied.
The Fireplace/Heater Remote Control
A great feature of the BFM Fireplace/Heater unit is the small remote control. This remote combines all the
functions of the front panel controls of the fireplace/heater with the convenience of not having to leave the
comfort of your seat to change the settings of the fireplace/heater.
The first thing to do with the remote control is to install the battery. The battery is supplied with the remote
control. Replacement battery can be purchased at any electronics store. The part number for the battery is
CR2032
1. Turn the remote control over, and locate the battery cover.
2. Remove the battery cover by pressing the small convex hull and sliding the cover towards the bottom
end of the remote control.
Battery Cover

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 11
3. The battery has two sides, one with a button feature, and the other is flat.
4. Insert the battery the button side into the remote control, and make sure the battery is firmly seated.
5. Reinstall the battery cover, making sure it clicks into position.
6. Turn the remote over and aim it towards the fireplace/heater unit.
7. Press the power button on the upper left, and see if the flames on the fireplace/heater turn on or
off.
8. If nothing appears to happen, check to make sure the battery is installed correctly, and try again.
Remote Control Button Functions
The remote control mimics the buttons on the front panel of the fireplace/heater. The remote control does not
have a display function. The buttons on the remote control work as follows:
Main Power
Decorative lights Control
H_heat Control
CControl
Flames Control
L_heat Control

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 12
These remote control buttons work exactly the same as the buttons on the front panel of the fireplace/heater.
See the FIREPLACE/HEATER section above to review the side plate panel button functions, and familiarize
yourself with the remote control.
NOTE: Whatever the heat function is on or off,when you press the low heat button or the high heat
button,the uplights will flash one time at 0.3 second interval.
NOTE: Ensure the batteries are installed properly in the remote control handset.
NOTE: The effective range of the remote control is up to 4 meters (13 feet).
NOTE: The remote control cannot be used to lock or unlock the heat fuction mode.
MAINTENANCE INSTRUCTIONS
· Always remove the plug from the socket-outlet and allow the heater to cool down before cleaning it.
· Wipe the exterior surface of the appliance occasionally with a soft damp cloth (not dripping wet) and
dry the exterior surface before operating the heater.
WARNING!
Do not immerse the heater in water.
Do not use any cleaning chemicals such as detergents and abrasives.
Do not allow the interior to get wet as this could create a hazard.
· Light accumulated dust may be removed from the appliance with a soft dry cloth.
· To store away the appliance put it back in to its original packaging and store it in a clean dry place.
· In the event of malfunction do not try to repair the heater yourself as this may result in a fire hazard or
electric shock.
NOTE: The blower motor and flame motor are pre-lubricated for a durable period of time and need no further
lubrication or maintenance. As the dust particles will accumulate on/in the fireplace,so periodic cleaning/
vacuuming of the fireplace is recommended.
Meaning of crossed –out wheeled bin
Do not dispose of electrical appliances as unsorted municipal waste.
Use separate collection facilities. Contact your local government for information
regarding the collection services available in your local area. If electrical appliances
are disposed of in landfills or dumps hazardous substances can leak into the
groundwater and get into the food chain, thus damaging your health and well being.
When replacing old appliances with new ones the retailer is legally obligated to take
away you old appliance for disposal free of charge.
ENVIRONMENT

WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 13
BFM EUROPE LTD
GORDON BANKS DRIVE, TRENTHAM LAKES STOKE-ON-TRENT ST4 4TJ
Technical Queries: 01782 339039
Service Fault Enquiries: 01782 339008
Please note there are no user replaceable parts on this appliance.
Issue 2
QUALITY GUARANTEE

Check out our full range of Heating Products
Central Heating Controls
Honeywell Heating Controls
Danfoss Heating Controls
Radiator Valves
Fernox
Sentinel
Magnaclean
Warmup underfloor heating
Water Heaters
Hand Dryers
