Centech 95364 Assembly instructions

Manual Revised 11f
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
95364
DIGITAL SCALE
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 19d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2006 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 95364
Specifications
Max. Tray Capacity 11 LB. / 176 OZ. / 5,000 G
Measurements Pounds / Ounces / Grams
Shut-Off 40-second auto shut-off
Battery 4 “AA” Batteries
(not included)
NOTE: Do not use scale for
commerce or trade.
Important Safety Information
1. Do not exceed Scale’s 11 LB. /
176 OZ. / 5,000 G max. weight
capacity. An “ERR” will appear on
digital display if scale is overloaded.
2. Do not mix old and new
batteries. Do not mix alkaline,
standard (carbon-zinc), or
rechargeable (nickel-cadmium)
batteries. Position batteries
in proper polarity. Do not use
swollen or leaking batteries.
3. This product is not a toy.
Do not allow children to play
with or near this item.
4. Weight readings are for
household use only. Do not
use for commerce or trade.
5. Inspect before every use; do not
use if parts are loose or damaged.
Instructions
Read the ENTIRE
IMPORTANT SAFETY
INFORMATION section
at the beginning of this
document including all text
under subheadings therein
before set up or use of
this product.
Note: Place Scale in sheltered area
when in use as air movement and
breathing on Scale will affect accuracy.
Always place objects on platform gently.
Installing/Replacing Batteries
1. Turn Scale on its side.
Remove battery compartment
cover by pressing tab towards
cover and lifting it off.
2. Insert four “AA” batteries
into battery compartment.
Be sure to align batteries with
corresponding polarity.
3. Replace battery
compartment cover.
Using Adaptor
NOTE: The Digital Scale can also
be operated with the AC Adaptor
that is included with the Scale.
1. Connect the Adaptor plug to
the receptacle located at the
rear of the Digital Scale.
2. Plug the Adaptor into the
wall outlet. The Digital Scale
is ready for operation.

Page 3For technical questions, please call 1-888-866-5797.Item 95364
Operation
1. Place the Digital Scale on a
flat surface in the work area.
2. Press the ON/TARE button once.
The Scale will start operating.
When “0” “and” “ 0 ” appear
on the digital display, the
Scale is ready for weighing.
3. Gently place item to be weighed
on platform. The weight will
appear on the display.
4. When weighing substances that
must be put into a container
(such as powders or liquids), place
empty container on Scale platform.
Press ON/TARE button.
The digital display will return
to zero, adjusted to ignore
weight of empty container and
only weigh contents.
A “ 0 ” readout will appear in
lower left corner of display.
5. Place contents into container.
The weight of contents only will
appear on the digital display.
6. To turn off Scale, press the OFF
button. The Scale is also equipped
with an auto shut-off function.
The scale will automatically turn off
40 seconds after item is weighed.
Changing Weight Unit
1. When turning on Digital Scale,
the default weight unit is
always “g” (grams).
2. When there is no item on the
platform, the “g” indicator on the
upper right corner of the digital
display will light on and point to “g”.
3. Press MODE to change weight
unit from “g” to “oz” (ounces)
or to “lb” (pounds).
Calibrating the Scale
1. To Calibrate, or balance, Scale,
press CAL for three seconds.
Once the display shows “CAL”,
stop pressing button.
2. Press CAL button again. Place an
item that weighs exactly 5.5 lb.
(2500 G) on scale. Press CAL
button again. The display will show
“0”. Keep the item on the platform
3. Place another item weighing 5.5 lb.
on platform. Press CAL again. The
display will show “ACC”, meaning
the Scale is successfully calibrated.
Troubleshooting
1. Digital display flashes “LO”:
Battery charge is low.
Replace battery or use Adaptor
to ensure accuracy.
2. Display doesn’t respond
to controls:
Circuit needs to be reset.
Remove the battery,
wait 30 seconds, replace battery
and turn the Scale “ON”.
3. Display does not show:
Battery has poor connection
or battery voltage is too low.
Take battery out and adjust
connections. Replace the battery
as necessary or use Adaptor.

26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
This item is UPC 792363953641.
