CERTIFIED 060-2360-6 User manual

IMPORTANT:
Readand followall safety rules andoperating instructions before using
this product.
INSTRUCTION
MANUAL
ELECTRIC HEDGE TRIMMER
model no. 060-2360-6

2
model no. 060-2360-6 | contact us 1.877.888.3872
WARRANTY INFORMATION
This product carries a one (1) year warranty from the date of purchase against
defective parts and workmanship. The warranty does not cover damage due to
mishandling or abuse. Proof of purchase is required. If the hedge trimmer is used
for commercial or rental purposes, this warranty only applies for 90 days from
the date of purchase.
Made in China
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
SPECIFICATIONS
ELECTRIC HEDGE TRIMMER
Motor .........................................................................................................................................................2.7 A
Speed ................................................................................................................................... 3000 (±10%) SPM
Blade length ....................................................................................................................................18” (46 cm)
Unit weight .......................................................................................................................... 4 lb 12 oz (2.16 kg)
Cutting capacity ........................................................................................................................ 5/8’’ (1.6 cm)

3
TABLE OF CONTENTS
TABLE OF CONTENTS
Important Safety Instructions 4
Symbols 7
Electrical 9
Know Your Hedge Trimmer 11
Assembly 12
Operation 13
Maintenance 17
Troubleshooting 19
Exploded View 20
Parts List 21

model no. 060-2360-6 | contact us 1.877.888.3872
4
IMPORTANT SAFETY INSTRUCTIONS
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in all of the warnings
listed below refers to your mains-operated
(corded) power tool or battery-operated
(cordless) power tool.
1. WORK AREA SAFETY
• Keepworkareacleanandwell-lit.Cluttered
or dark areas are more prone to accidents.
• Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose
control.
2. ELECTRICAL SAFETY
• Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
• Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body
is earthed or grounded.
• Do not expose power tools to rain, snow or
wet conditions. Water entering a power tool
will increase the risk of electric shocks.
• Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep the cord away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of
electric shocks.
• When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
• If operating a power tool in a damp location
is unavoidable, use a residual current
device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
3. PERSONAL SAFETY
• Stay alert, watch what you are doing
and use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools
may result in serious personal injury.
• Use personal protective equipment. Always
wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
• Avoid accidental starting. Ensure the
switch is in the off-position before plugging
in. Carrying can cause accidents.
• Remove any adjusting key or wrench before
turning the power tool on. A wrench or a
WARNING!
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire, and/or serious injury.

5
IMPORTANT SAFETY INSTRUCTIONS
key left attached to a rotating part of the
power tool may result in personal injury.
• Do not overreach. Keep proper footing and
balance at all times. This enables better
control the power tool in unexpected
situations.
• Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught
in moving parts.
• If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce
dust-related hazards.
4. POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer
at the rate for which it was designed.
• Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch
is dangerous and must be repaired.
• Disconnect the plug from the power source
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
• Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired
by a qualified technician before use. Many
accidents are caused by poorly maintained
power tools.
• Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
• Use the power tool, accessories, tool bits,
etc., in accordance with these instructions
and in the manner intended for the
particular type of power tool, taking into
account the working conditions and the
work to be performed. Use of the power
tool for operations different from those
intended could result in a hazardous
situation.
5. SERVICE
• Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
WARNING! (PROPOSITION 65)
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
•Leadfromlead-basedpaints;
•Crystallinesilicafrombricksandcementandothermasonryproducts;and
•Arsenicandchromiumfromchemicallytreatedlumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of
work. To reduce your exposure to these chemicals, work in a well-ventilated area, and work
with approved safety equipment, such as dust masks that are specially designed to filter out
microscopic particles.

6
IMPORTANT SAFETY INSTRUCTIONS
HEDGE TRIMMER SAFETY WARNINGS
•Use both hands when operating the
hedge trimmer. Using one hand could
cause loss of control and result in
serious personal injury.
• Keep all parts of the body away from
the cutter blade. Do not remove cut
material or hold material to be cut when
blades are moving. Make sure the switch
is off when clearing jammed material.
Blades coast after the trimmer is
turned off. Make sure you give sufficient
time for the device to come to a
complete stop. A moment of inattention
while operating the hedge trimmer may
result in serious personal injury.
• Carry the hedge trimmer by the
handle with the blade stopped. When
transporting or storing the hedge
trimmer always fit the cutting device
cover. Proper handling of the hedge
trimmer will reduce the risk of injury
from the cutter blades.
• Hold the power tool by its insulated
gripping surfaces only, because the
cutter blade may contact hidden
wiring or its own cord. Cutter blades
contacting a live wire may make
exposed metal parts of the power tool
live and could give the operator an
electric shock.
• Keep cable away from cutting area.
During the operation, the cable
may be hidden in shrubs and can be
accidentally cut by the blade.
• DANGER – Keep hands away from blade.
Contact with blade will result in serious
personal injury.
SAVE THESE INSTRUCTIONS
model no. 060-2360-6 | contact us 1.877.888.3872
WARNING!
Only use with handle and guard properly assembled to hedge trimmer. The use of the hedge
trimmer without the proper guard or handle provided may result in serious personal injury.

7
SYMBOLS
Symbol Name Designation/Explanation
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watts Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
Class II Construction Double-insulated construction
Read The Operator’s Manual To reduce the risk of injury, users must read and understand operator’s
manual before using this product.
Safety Alert Precautions that involve your safety.
Keep Bystanders Away Keep all bystanders at least 50’ (15 m) away.
Ricochet Thrown objects can ricochet and result in personal injury or property
damage.
Sharp Blade Danger – keep hands and feet away from blade.
Wear Eye Protection Wear eye protection with side shields that are marked to comply with
ANSI Z87.1 when operating this equipment.
Ear protection Wear era protection when operating this
equipment.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Gloves Wear non-slip, heavy duty gloves.
Remove the plug Remove plug from the mains immediately before maintenance or if
cable is damaged or cut.

model no. 060-2360-6 | contact us 1.877.888.3872
8
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
Symbol Signal Meaning
DANGER Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
SERVICE
Servicing requires extreme care and knowledge and should be performed by a qualified service
technician. For service, we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTRE for repair. When servicing, use only identical replacement parts.
WARNING!
The operation of any power tool can result in foreign objects being thrown into
people’s eyes, which can result in severe eye damage. Before beginning power tool
operation, always wear safety goggles or safety glasses with side shields and,
when needed, a full face shield. We recommend using a wide vision safety mask for
use over eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.
WARNING!
To avoid serious personal injury, do not attempt to use this product until you have thoroughly
read and completely understood the operator’s manual. If you do not understand the warnings and
instructions in the operator’s manual, do not use this product.

9
ELECTRICAL
DOUBLE INSULATED
This hedge trimmer has a plug that looks like the one shown in Fig. 1. The hedge trimmer is double
insulated to provide a double thickness of insulation between you and the tool’s electrical system. All
exposed metal parts are isolated from the internal metal motor components with protective insulation.
1) 2-prong plug
2) Properly grounded extension cord Fig. 1
1
2
GROUNDING INSTRUCTIONS
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for
electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that
has a POLARIZED plug. The power cord MUST be plugged into a matching outlet that is properly installed
and grounded in accordance with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the outlet, have the proper outlet installed by a
qualified electrician.
WARNING!
TO AVOID ELECTRIC SHOCKS:
• Use only identical replacement parts when servicing a tool with double insulation. Servicing
should be performed by a qualified technician.
• Do not use in wet or damp areas or expose to rain.
WARNING!
USE ONLY IDENTICAL REPLACEMENT PARTS WHEN SERVICING THE HEDGE TRIMMER TO AVOID INJURY.
WARNING!
DOUBLE INSULATION DOES NOT TAKE THE PLACE OF NORMAL SAFETY PRECAUTIONS WHEN OPERATING
THIS TOOL.

model no. 060-2360-6 | contact us 1.877.888.3872
10
ELECTRICAL
GUIDELINES FOR USING EXTENSION CORDS
USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an
extension cord, be sure to use one of heavy enough gauge to carry the current your product will draw.
An undersized cord will cause overheating. The table below shows the correct size to use depending on
cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The smaller the gauge
number, the heavier the cord. Make sure your extension cord is properly wired and in good electrical
condition. Always replace a damaged extension cord or have it repaired by a qualified technician before
it. Keep your extension cords away from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your tools. This circuit should not be less than #12 wire and should
be protected with a 15 A time delayed fuse. Before connecting the motor to the power line, make sure
the switch is in the OFF position and the electric current is rated the same as the current stamped on
the motor nameplate. Running at a lower voltage will damage the motor.
MINIMUM GAUGE FOR EXTENSION CORDS (AWG)
(WHEN USING 120 V ONLY)
Amp Rating Total Length of Cord in Feet (meters)
MORE THAN NOT MORE THAN 25’ (7.6 M) 50’ (15 M) 100’ (30.4 M) 150’ (45.7 M)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
WARNING!
ALTHOUGH THIS TOOL IS DOUBLE INSULATED, THE EXTENSION CORD AND RECEPTACLE MUST STILL BE
GROUNDED WHILE IN USE TO PROTECT THE OPERATOR FROM ELECTRIC SHOCKS.
WARNING!
THIS HEDGE TRIMMER IS FOR OUTDOOR USE ONLY. DO NOT EXPOSE TO RAIN, SNOW OR USE IN DAMP
LOCATIONS.
WARNING!
ALWAYS MAKE SURE THAT YOUR OUTLET IS PROPERLY GROUNDED. IF UNCERTAIN, HAVE IT CHECKED
BY A CERTIFIED ELECTRICIAN.

11
KNOW YOUR HEDGE TRIMMER
The safe use of this product requires an understanding of the information on the product and in this
operator’s manual as well as a knowledge of the project you are attempting. Before using this product,
familiarize yourself with all operating features and safety rules. (See Fig. 2)
CORD RETAINER
A convenient cord retainer helps keep the extension cord connection secure during trimmer operations.
GUARD
The guard helps to deflect chips or other debris away from the operator’s hands.
TRIGGER SWITCH AND LOCK-OFF BUTTON
The trigger switch, located beneath the rear handle, and the lock-off button, located
behind the front handle, must be depressed simultaneously to allow blade rotation.
The lock-off button may be released once the hedge trimmer is running.
Blade
Blade support slot
Guard
Auxiliary handle
Trigger switch
Cord retainer
Fig. 2
Lock-off button

model no. 060-2360-6 | contact us 1.877.888.3872
12
ASSEMBLY
UNPACKING
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items listed in
the packing list are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily operated
the product.
• If any parts are damaged or missing, please call 1-877-888-3872 for assistance.
PACKING LIST
• Electrichedgetrimmer
• Instruction manual
WARNING!
Do not connect to power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
WARNING!
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modification is misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING!
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Failure to heed this warning could result in serious personal injury.

13
OPERATION
CONNECTING TO POWER SUPPLY
This product is designed with a cord retainer that prevents the extension cord from being pulled loose
while using.
• Form a loop with the end of the extension cord.
• Insert loop portion of extension cord through opening in the bottom of the rear handle and place
over cord retainer.
• Slowly pull the loop against cord retainer until the slack is removed. (See Fig. 3)
• Plug the product into an extension cord.
NOTE:
Failure to remove all excess cord slack from the extension cord retainer could result in
the plug loosening from the receptacle.
WARNING!
Do not use any attachments or accessories not recommended by the manufacturer of this
product. The use of attachments or accessories not recommended can result in serious personal
injury.
WARNING!
Always wear safety goggles or safety glasses with side shields when operating power tools. Failure
to do so could result in objects being thrown into your eyes, resulting in possible serious injury.
WARNING!
Do not allow familiarity with this product to make you careless. Remember that a fraction of a
second of carelessness is sufficient to inflict serious injury.

model no. 060-2360-6 | contact us 1.877.888.3872
14
OPERATION
STARTING THE HEDGE TRIMMER (SEE FIG. 3–4)
• Attach an extension cord to your hedger.
• Place one hand on the trigger handle (1). Place the other hand on the auxiliary handle (2).
• Slide the lock-off button (4) backwards you then squeeze the trigger switch (3) to turn ON the
hedge trimmer. The trimmer will stay on as long as the trigger switch is squeezed. The lock-off
button may be released once the hedge trimmer is running.
STOPPING THE HEDGE TRIMMER
• Release the trigger switch (3).
• Allow at least 5 seconds for the cutting blade to stop moving.
Fig. 3
Cord
Extension
Fig. 4
1
3
2 4
cord
retainer

15
OPERATION
CUTTING TIPS
• When operating the hedge trimmer, keep the extension cord behind the trimmer. Never drape it over
the hedge being trimmed.
• Do not force the hedge trimmer through heavy shrubbery. This can cause the blades to bind and slow
down. If the blades slow down, reduce the pace.
• Do not attempt to cut stems or twigs that are larger than 3/8’’ (1 cm), or those obviously too large
to feed into the cutting blade. Use a non-powered hand saw or pruning saw to trim large stems.
• If blades do become jammed, stop the motor, allow the blades to come to a complete stop, and
disconnect the plug from the power source before attempting to remove the obstruction.
• If desired, you can use a string to help cut your hedge level. Decide how high you want the hedge.
Stretch a piece of string along the hedge at the desired height. Trim the hedge just above the guide
line of string. Trim the side of a hedge so that it will be slightly narrower at the top. More of the
hedge will be exposed when shaped this way, and it will be more uniform.
• Wear gloves when trimming thorny or prickly growth. When trimming new growth, use a wide
sweeping action, so that the stems are fed directly into the cutting blade. Older growth will have
thicker stems and will be trimmed easiest by using a sawing movement.
WARNING!
Clear the area to be cut before each use. Remove all objects such as cords, lights, wires, or loose
strings which can become entangled in the cutting blade and create a risk of serious personal
injury.
WARNING!
Always keep both hands on the hedge trimmer handles. Never hold shrubs with one hand and
operate hedge trimmer with the other. Failure to heed this warning can result in serious injury.

model no. 060-2360-6 | contact us 1.877.888.3872
16
OPERATION
OPERATING THE HEDGE TRIMMER
• Always hold hedge trimmer with both hands when operating. Use a firm grip on the handles. The unit
is used for cutting in either direction in a slow, sweeping action from side to side.
• Stand so that you are stable and balanced on both feet. Do not overreach.
• Inspect and clear the area of any hidden objects.
• Never use the hedge trimmer near power lines, fencing, posts, buildings, or other immovable objects.
• Never use a blade after hitting a hard object without first inspecting it for damage. Do not use if any
damage is detected.
• Never touch blades or service unit with the power supply connected.
WARNING!
Read the safety information for safe operation using the blade. Extreme care must be taken when
using blades to ensure safe operation.

17
MAINTENANCE
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
WARNING!
BEFORE INSPECTING, CLEANING, OR SERVICING THE MACHINE, DISCONNECT THE PLUG FROM THE
POWER SOURCE AND WAIT FOR ALL MOVING PARTS TO COME TO A COMPLETE STOP. FAILURE TO
FOLLOW THESE INSTRUCTIONS CAN RESULT IN SERIOUS PERSONAL INJURY OR PROPERTY DAMAGE.
WARNING!
ALWAYS WEAR SAFETY GOGGLES OR SAFETY GLASSES WITH SIDE SHIELDS DURING PRODUCT
OPERATION. IF OPERATION IS DUSTY, ALSO WEAR A DUST MASK.
WARNING!
WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS. USE OF ANY OTHER PARTS MAY
CREATE A HAZARD OR CAUSE PRODUCT DAMAGE.
WARNING!
BLADES ARE SHARP. WHEN HANDLING THE BLADE ASSEMBLY, WEAR NON-SLIP, HEAVY-DUTY
PROTECTIVE GLOVES. DO NOT PLACE YOUR HAND OR FINGERS BETWEEN BLADES OR IN ANY POSITION
WHERE THEY COULD GET PINCHED OR CUT. NEVER TOUCH BLADES OR SERVICE UNIT WITH THE POWER
SUPPLY CONNECTED.
WARNING!
DO NOT AT ANY TIME LET BRAKE FLUIDS, GASOLINE, PETROLEUM-BASED PRODUCTS, PENETRATING
OILS, ETC., COME IN CONTACT WITH PLASTIC PARTS. CHEMICALS CAN DAMAGE, WEAKEN, OR DESTROY
PLASTIC WHICH MAY RESULT IN SERIOUS PERSONAL INJURY. ONLY THE PARTS SHOWN ON THE PARTS
LIST ARE INTENDED TO BE REPAIRED OR REPLACED BY THE CUSTOMER. ALL OTHER PARTS SHOULD BE
REPLACED AT AN AUTHORIZED SERVICE CENTRE.

model no. 060-2360-6 | contact us 1.877.888.3872
18
MAINTENANCE
CLEANING THE HEDGE TRIMMER
• Stop the motor and disconnect from the power supply.
• Clean dirt and debris from the body of the hedge trimmer using a damp cloth with a mild detergent.
STORING THE TRIMMER
• Clean all foreign material from the product.
• Store it in a well-ventilated place that is inaccessible to children.
• Keep away from corrosive agents such as garden chemicals and de-icing salts.
NOTE:
Do not use any strong detergents on the plastic housing or the handle. They can be
damaged by certain aromatic oils such as pine and lemon, and by solvents such as
kerosene.

19
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Unit will not start.
1. Cord not plugged in. 1. Plug in cord.
2. Cord or switch is damaged. 2. Have cord or switch replaced.
Motor runs, but
cutting blades do
not move.
Hedge trimmer damaged.
Do not use hedge trimmer. Call for technical service.
Hedge trimmer
smokes during
operation.
Hedge trimmer damaged.
Do not use hedge trimmer. Call for technical service.

model no. 060-2360-6 | contact us 1.877.888.3872
20
EXPLODED VIEW
5 6
4
32
1
15
14
13
12
10 9 8 7 1611
