Remote Control Unit Manual
2019 Cervis, Inc.
i
Notes/Definitions
Associate
SmaRT configuration method using a series of specific remote unit button presses to establish a
communication link between a SmaRT Remote Control Unit and a SmaRT Base Unit.
DSSS
Direct sequence spread spectrum; an advanced wireless communication technology.
Dissociate
Dissolution of established communication links between remote control units and base units
involved in the process.
Line of Sight (aka Direct-Line-of-Sight)
Type of communication between transceivers, or a transmitter and a receiver, where the
pathway between the two units must be clear of obstacles.
TX/RX
Transmit/Receive
Document Conventions
Note: Notes are used to indicate points of interest or pertinent information.
Cautions are used to warn of serious consequences of actions or inactions that
may result in injury, death, or serious damage to the equipment.

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
ii
Table of Contents
Notes/Definitions ...........................................................................................................................i
Document Conventions ................................................................................................................i
Table of Contents .........................................................................................................................ii
List of Figures...............................................................................................................................ii
List of Tables.................................................................................................................................ii
Cervis, Inc. Safety Precautions...................................................................................................1
1.0 SmaRT HH-x10 Remote Control Unit..................................................................................2
2.0 Remote Control and Base Unit Communication ...............................................................4
2.1 Associate HH-xH10 Remote Control to Base Unit.........................................................4
2.2 Dissociate HH-xH10 Remote Control from Base Unit ...................................................5
3.0 Battery Installation or Change ............................................................................................6
4.0 Using a Standard SmaRT Remote Control ........................................................................7
5.0 Low Battery Warning and Low Battery Auto-Shutdown ..................................................8
6.0 Specifications .......................................................................................................................9
7.0 Spare Parts List ..................................................................................................................10
Appendix A: Exposure to Radio Frequency Energy...............................................................11
Appendix B: Agency Identification Label Locations ..............................................................11
List of Figures
Figure 1. HH-x10 6-LED Remote Control Button Assignments .................................................2
Figure 2. Standard Ten-Button Example......................................................................................3
Figure 3. Associate an HH-x10 Remote Control to a Base Unit.................................................4
Figure 4. Dissociate an HH-x10 Remote control from a Base Unit............................................5
Figure 5. Remote Control Battery Installation .............................................................................6
Figure 6. HH-x10 Front Panel.........................................................................................................7
Figure 7. HH-x10 Remote Low Battery Warning and Auto-Shutdown ......................................8
Figure 8. Agency Identification Label Locations...................................................................... 11
List of Tables
Table 1. HH-x10 Remote Control Options....................................................................................3
Table 2. SmaRT HH-x10 Remote Control Specifications............................................................9
Table 3. Spare Parts List............................................................................................................. 10

Remote Control Unit Manual
2019 Cervis, Inc.
1
Cervis, Inc. Safety Precautions
Read and follow all instructions.
Failure to abide by Safety Precautions may cause equipment failure, loss of authority
to operate the equipment, and personal injury.
Use and maintain proper wiring. Follow equipment manufacturer instructions.
Improper, loose, and frayed wiring can cause system failure, equipment damage, and
intermittent operation.
Equipment changes or modifications not expressly approved by the manufacturer will
void the warranty.
Equipment owner/operators must abide by all applicable Federal, State, and Local
laws concerning equipment installation and operation. Failure to comply could result
in penalties and could void user authority to operate the equipment.
Make sure that the machinery and surrounding area is clear before operating. Do not
activate the remote control system until you are certain that it is safe to do so.
Turn off the remote control and disconnect power from the base unit before
attempting any maintenance. This will prevent accidental operation of the controlled
machinery.
Power can safely be disconnected from the remote by removing the source power
(batteries) from the unit.
Power can be removed from the base unit by disconnecting the source power from
the circuit.
Use a damp cloth to keep units clean. Remove mud, concrete, dirt, etc. after use to
prevent obstructing or clogging the buttons, levers, wiring, and switches.
Do not allow liquid to enter the remote control or base unit enclosures. Do not use
high-pressure equipment to clean the remote control or base unit.
Disconnect the base unit before welding on the machine. Failure to disconnect the
base unit may cause destruction of or damage to the base unit.
Operate and store units only within the specified operation and storage temperatures
defined in this document’s Specifications.

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
2
1.0 SmaRT HH-x10 Remote Control Unit
Remote Control Features
License-free 900MHz or 2.4GHz Direct Sequence Spread Spectrum Technology (DSSS)
Direct-line-of-sight communications up to 1000 ft. (330m) range
Powered by two AAA cell batteries
Low Battery Warning and Low Battery Auto-Shutdown
Discrete ON and OFF buttons
Ten function buttons
Diagnostic light-emitting diode (LED) indicators
Rugged high-impact polymer enclosure; compact weatherproof design
Removable rubber bumper and detachable lanyard or belt clip
Operating temperature: -4°F to +131°F (-20°C to +55°C)
SmaRT wireless high-power HH-x10 remote control units communicate with and control SmaRT
base units operating in the 900MHz or 2.4GHz range. The HH-x10 remote control unit has
individual ON and OFF buttons and ten function control buttons. The remote control has an
automatic shutdown timeout–a period of time after which the remote turns itself off to conserve
power if no function buttons are pushed.
Figure 1. HH-x10 6-LED Remote Control Button Assignments
The HH-x10 remote control can communicate with a wide variety of SmaRT base units using
direct sequence spread spectrum (DSSS) wireless technology at 2.4GHz or 900MHz. A
standard HH-x10 offers up to ten command functions, and up to twenty command functions with
the dual use of the green button as both ON and SHIFT functions. It offers a robust link with a
base unit in congested radio environments. SmaRT remote control units feature seamless
association with SmaRT base units without needing to open either the remote control or base
unit cases.
The weatherproof remote control enclosure is made of rugged high-impact plastic with a face
plate securely sealed and attached by eight screws. It is further protected by a removable rubber
bumper that covers the unit’s back and sides. A lanyard that can be attached to the unit through
a recess on the bottom of the rubber bumper is available; or the unit can be ordered with a
convenient belt clip.
User Writable Label
Custom Text Label
Custom Label
(Example)

Remote Control Unit Manual
2019 Cervis, Inc.
3
Two size AAA cell batteries power the SmaRT HH-x10, and it operates between 2.0VDC to
3.2VDC. Six visible status/diagnostic LEDs (see Figure 2) indicate transmit (TX) and receive
(RX) activity, communications errors (ERR), and low battery (BAT) warning. Two additional
LEDs—A1 and A2—offer custom-programmed auxiliary status indications.
Figure 2. Standard Ten-Button Example
Notice in Figure 2 that the ten function pushbuttons are unassigned to specific SmaRT base unit
outputs. This allows for maximum flexibility while programming to interface with the wide array of
available SmaRT base units. An example of a custom programmed HH-x10 is shown as the
center unit in Figure 1.
HH-x10 Remote Control Remote Options
The HH-x10 can be ordered with or without a belt clip. Table 1 lists the available models.
Table 1. HH-x10 Remote control Options
Model Name
Frequency
RF Power
Activation,
Deactivation
Belt
Clip
HH-9H10
900MHz
10mW
ON,OFF
NO
HH-9H10B
900MHz
10mW
ON,OFF
YES
HH-2H10
2.4GHz
100mW
ON,OFF
NO
HH-2H10B
2.4GHz
100mW
ON,OFF
YES
HH-9X10
900MHz
100mW
ON,OFF
NO
HH-9X10B
900MHz
100mW
ON,OFF
YES
OFF Button
ON Button
B1 through B10 are
FUNCTION Buttons
ASSOCIATE (button B1)
TX blinking Green when transmitting
RX blinking Amber when receiving
ERR blinking Red when error occurs
BAT blinking Amber when Low Battery
Protective Bumper
A1 (Auxiliary 1) Custom program use
A2 (Auxiliary 2) Custom program use
DISSOCIATE (button B2)

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
4
2.0 Remote Control and Base Unit Communication
2.1 Associate HH-xH10 Remote Control to Base Unit
An HH-x10 remote control unit must establish a communications link with a base unit before it
can be used for control. An HH-x10 remote (as part of a system) is associated with the system
base unit before leaving Cervis, Inc. But, it is possible to associate an HH-x10 in the field either
to address a communication problem or to add or replace a remote control unit. The procedure
to establish the link is called “Association”.
In situations where it is necessary to establish or re-establish remote control-to-base unit
communications, use the following steps:
HH-9H10/2H10 Models:
1. Stand near the base unit with the remote control OFF and power removed from
the base unit.
2. Push and hold the B1 and ON buttons. All six LEDs light solid.
3. Observe the LEDs. When only the TX LED begins to blink, power up the base
unit while continuing to hold B1 and ON.
4. When all six LEDs light solid, release both buttons.
HH-9X10 Models:
1. Stand near the base unit with the remote control OFF and power removed from
the base unit.
2. Push and hold the B1 and ON buttons for approximately two seconds. The A1,
A2, and TX LEDs light. Release the B1 and ON buttons.
3. Press and hold button B1. Turn base unit power on. Release button B1 when
base unit powers up.
The remote control and base unit are connected when both the TX and RX LEDs on both
devices start blinking simultaneously as messages pass between them.The SmaRT system is
ready for use.
Figure 3. Associate an HH-x10 Remote Control to a Base Unit
Hold to ASSOCIATE
TX
RX
B1
B2
Hold to
ASSOCIATE
BAT
ERR

Remote Control Unit Manual
2019 Cervis, Inc.
5
2.2 Dissociate HH-xH10 Remote Control from Base Unit
In some circumstances, it may become necessary to break the communication link, or
“dissociate”a remote control and a base unit. The dissociate procedure is almost identical to the
associate procedure, except the dissociate button (B2) is used and held throughout the process
instead of the Associate button (B1).
Using the following steps will break all previously established remote
control links.
HH-9H10/2H10 Models:
1. Stand near the base unit with the remote control OFF and power removed from
the base unit.
2. Push and hold B2 and the ON button. All six LEDs light solid.
3. Observe the LEDs. When only the TX LED begins to blink, power up the base
unit while continuing to hold B2 and ON.
4. When all six LEDs light solid, release both buttons.
HH-9X10 Models:
1. Stand near the base unit with the remote control OFF and power removed from
the base unit.
2. Push and hold the B2 and ON buttons for approximately two seconds. The A1,
A2, and TX LEDs light. Release buttons B2 and ON.
3. Press and hold button B2. Turn base unit power on. Release button B2 when
base unit powers up.
4. Remote control and base unit are disconnected when the TX LED (only) starts
blinking.
Established links with base units are removed. To re-establish a communication link with a base
unit, use the Associate Procedure (Section 2.1).
Figure 4. Dissociate an HH-x10 Remote control from a Base Unit
Hold to DISSOCIATE
B1
B2
Hold to
DISSOCIATE
TX
RX
BAT
ERR

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
6
3.0 Battery Installation or Change
Two size AAA cell batteries power SmaRT HH-x10 remote control units. When installing
batteries, be sure to observe proper polarity—as marked on the inside of the compartment—to
avoid damaging the unit.
To replace or install remote control batteries:
1. Loosen the four small Phillips screws on the battery compartment cover, and lift
the cover from the remote control. The screws remain attached to the cover.
2. If installing batteries in an empty battery compartment, install two fresh size AAA
cell batteries. Be sure to position the batteries as illustrated in Figure 5 below.
3. If replacing expired batteries, remove the old batteries, and install two fresh size
AAA cell batteries. (Discard the used batteries according to local regulations.) Be
sure to position the batteries as illustrated in Figure 5 below.
4. Replace the compartment cover and tighten the four Phillips screws. Do not over-
tighten these screws, but make sure they are tight enough to properly seal the
gasket.
Note: Discard expired batteries according to local regulations.
Figure 5. Remote Control Battery Installation
Note: Cover screws must be tight enough to compress the sealing gasket. Do not over-
tighten the screws.
Be sure to observe proper polarity when placing batteries in
the remote control battery compartment.
Sealing gasket
Cover
screws

Remote Control Unit Manual
2019 Cervis, Inc.
7
4.0 Using a Standard SmaRT Remote Control Unit
Remote control is achieved under the following conditions:
Communication between the remote control and base unit must be established. If the
remote control and base unit are not communicating while under power, the link must be
established using the Associate Procedure (Section 2.1).
You must be in clear line of sight of the base unit while holding the remote control–usually
within approximately 300m of the unit.
Usually, each button is programmed for a particular assigned function or hardwired output driven
by the base unit. The control may be either:
Momentary,where the command is active only while the button is engaged.
Latched,where, once pushed, the output or function remains active when the button is
released.
Figure 6. HH-x10 Front Panel
Turn the HH-x10 remote control on by pushing and releasing the green ON button at the bottom
of the unit. The remote control remains under power until either:
1. The red OFF button is pushed.
2. The Inactivity timeout occurs, where no button activity is sensed for a
programmed amount of time (default=four minutes).
When the remote control is turned off—and the base unit Safety Link is enabled—all active base
unit functions are deactivated.
OFF Button
ON, ASSOCIATE, and
DISSOCIATE
B1 through B10 are
FUNCTION Buttons
ASSOCIATE (button B1)
TX blinking Green when transmitting
RX blinking Amber when receiving
ERR blinking Red when error occurs
BAT blinking Amber when Low Battery
A1 (Auxiliary 1) Custom program use
A2 (Auxiliary 2) Custom program use
DISSOCIATE (button B2)

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
8
5.0 Low Battery Warning and Low Battery Auto-Shutdown
At 2.1VDC and below, the Amber battery (BAT) LED begins flashing approximately once per
second to indicate a Low Battery Warning. Messages are still being transmitted, and the remote
control can still be used; but Cervis, Inc. recommends installing a fresh set of two AAA cell
batteries as soon as possible.
At 2.0VDC, the Amber BAT LED will turn on solid, and the unit will begin a self power shutdown.
The associated device will receive a low-battery power-down message.
Note: At 2.0VDC the BAT LED only lights for approximately 1.25 seconds. Be aware that
you can easily miss this brief time. Once the remote control automatically shuts down, the
unit will not function properly until a fresh set of two AAA cell batteries are installed.
Figure 7. HH-x10 Remote Low Battery Warning and Auto-Shutdown
LOW BATTERY
The
BAT LED begins flashing once per second, indicating that a LOW BATTERY (2.1V or
less) condition is present. Two fresh AAA cell batteries should be installed as soon as
possible. The LED continues flashing at one-second intervals either unit the batteries are
changed, or until the voltage level drops to 2.0V and Auto-Shutdown occurs.
AUTO-SHUTDOWN
At 2.0V, the
BAT LED flashes briefly for approximately 1.25 seconds before the remote
control unit automatically shuts down.
Two fresh AAA cell batteries must be installed before the transmitter can be used again.

Remote Control Unit Manual
2019 Cervis, Inc.
9
6.0 Specifications
Table 2. SmaRT HH-x10 Remote Control Unit Specifications
Item
Description
Power
Vin +2.1V to +3.2VDC
Source Two AAA cell batteries
Auto-shutdown Four minutes of button inactivity (default)
Low Battery Warning ≈2.1V –batteries should be immediately replaced
Low Battery Shutdown 2.0V –batteries must be replaced to operate
Environment
Operating Temp -20°C to 55°C (-4°F to 131°F)
Storage Temp -40°C to 55°C (-40°F to 131°F)
Humidity 0 to 100%
Radio
Frequency 906–924MHz @ 10mW (HH-9H10)
906–924MHz @ 100mW (HH-9X10)
2405–2480MHz @ 100mW (HH-2H10)
License None required
Modulation DSSS
Antenna Internal
Enclosure
Dimensions mm: 136.38 x 68.96 x 28.42
inches: 5.37 x 2.68 x 0.92
Total Weight 200g/7.2 oz. (with lanyard or belt clip)
Durability High Impact Polymer case
Polycarbonate faceplate
Impact absorbing bumper
LED
Indicators
TX (Green) Transmit –Flashes when transmitting messages
RX (Amber) Receive –Flashes when receiving messages
ER (Red) Flashes when errors are detected
BAT (Amber) Blinks when low battery condition exists
A1 Used when custom-programmed
A2 Used when custom-programmed
Buttons
Twelve Pushbuttons
Number of Functions Ten to twenty, program-dependent

SmaRT HH-x10
U089.1.1-SmaRT_HH-x10
10
7.0 Spare Parts List
Table 3. Spare Parts List
Item
Cervis, Inc. Bin Location
Protective Rubber Bumper
AA6-02
Lanyard
AA8-01B
Battery Cover with 4 Attached Screws
Call Cervis, Inc. @ 724-741-9000
AAA 1.5V Cell Batteries (Two-pack)
AA6-03
Belt Clip
AA5-07
Replacement Antenna
Disallowed

Remote Control Unit Manual
2019 Cervis, Inc.
11
Appendix A: Exposure to Radio Frequency Energy
SmaRT remote control units contain radio transceivers. A handheld remote emits radio
frequency (RF) energy through its internal antenna while active.
For optimal performance—and to ensure that human exposure to RF energy does not exceed
the recommended guidelines—always follow these instructions and precautions.
When using the handheld remote control unit:
Hold the remote so that the top buttons are away from the body in the direction of the base
unit.
Keep the remote at least 15mm (⅝inch) away from the body.
Only use carrying cases, belt clips, or holders approved by the Cervis, Inc.
Appendix B: Agency Identification Label Locations
Figure 8. Agency Identification Label Locations
Note: The unit label location is identical for both
900MHz and 2.4GHz handheld remote control units.
This manual suits for next models
5
Table of contents
Other Cervis Control Unit manuals
Popular Control Unit manuals by other brands

CIAT
CIAT XtraConnect 2 Installation, Operation, Commissioning, Maintenance

Festo
Festo MS6N-SV Assembly Installation Safety Instructions

Panasonic
Panasonic FP7 Series user manual

Emerson
Emerson Fisher ACE95 Series instruction manual

Racal Instruments
Racal Instruments 1260 user manual

BFT
BFT B EBA RS 485 LINK installation manual
