CES CESeasy 347102V User instructions

CESeasy
Communication module
Assembly and Operating Manual
English
Version VB
BRO2280-2

Contents
1 About this manual 4
1.1 Design characteristics 4
1.2 Target group of this manual 4
2 Manufacturer’s information 5
2.1 Manufacturer and service 5
2.2 Manufacturer’s warranty 5
3 For your safety 6
3.1 EU Declaration of conformity 6
3.2 Intended use 6
3.3 Basic safety instructions 6
3.4 Notes on dealing with batteries 7
4 CESeasy communication module 9
4.1 About communication modules 9
4.2 Scope of application 9
5 Scope of delivery 10
6 Assembly 11
7 Connections 14
7.1 How to connect the power supply unit 14
7.2 How to connect the inputs and outputs 15
8 Batteries 21
8.1 Required batteries 21
8.2 Battery consumption 21
8.3 Battery warnings 21
8.4 Check the battery status 22
8.5 How to insert and change batteries 23
8.6 Battery disposal 23
9 How to couple a lock 24
Page 2 of 37 CESeasy communication module

9.1 Coupling 24
9.2 Decoupling 26
9.3 Coupling to a new lock 26
10 Administration 27
10.1 Firmware 27
10.2 Reset of the communication module 27
11 Operation 29
11.1 Privacy mode 29
11.2 Night locking mode (only motor cylinders) 29
12 Technical data 31
12.1 Equipment features 31
12.2 Dimensions 32
13 Disposal 33
13.1 Notes on disposal 33
14 Index 35
CESeasy communication module Page 3 of 37

1 About this manual
These assembly and operating instructions, hereinafter referred to as the “manual”, will help you
with the assembly and in a proper, safe, and beneficial use of the CESeasy products acquired.
Anyone who assembles, administers, maintains, or disposes of CESeasy products, must have read
and understood the complete contents of this manual.
If you do not understand the functions of the CESeasy products, please contact your CES partner
for further information.
Always use the latest version of this manual. The version number of this manual is shown
on the cover page. You can get the latest version free of charge from www.ces.eu
1.1 Design characteristics
Refers to other documents.
Marks additional information and tips.
Marks warnings in step-by-step instructions and specially important information.
1.2 Target group of this manual
This manual is intended for
lTrained service and assembly personnel
lMaintenance personnel
lOperators
The necessary expertise regarding the intended use of the product is presumed for the use of this
manual.
The necessary product training is conducted by your CES partner. If this has not yet taken place,
please contact your CES partner to get the product training.
Page 4 of 37 CESeasy communication module
1 About this manual

2 Manufacturer’s information
2.1 Manufacturer and service
C.Ed. Schulte GmbH
Zylinderschlossfabrik
Friedrichstr. 243
42551 Velbert
Tel: [phone]
Fax: [phone]
www.ces.eu
2.2 Manufacturer’s warranty
The following damage is not covered by the manufacturer’s warranty:
lDamage to the exterior mechanical parts as well as subsequent damage arising from nor-
mal wear and tear.
lDamage caused by external events or influences
lDamage caused by deficient assembly
lDamage caused by deficient maintenance
lDamage caused by false operation
lDamage caused by overvoltage
lDamage caused by fire, water or smoke
All technical data and features are subject to change without prior notice. All information and
data contained in this document is subject to change without prior notice. Without express
written approval from C.Ed. Schulte GmbH Zylinderschlossfabrik, no part of this document may be
copied or transmitted for any purposes whatsoever.
© 2018 C.Ed. Schulte GmbH Zylinderschlossfabrik, Velbert/Germany
VB
BRO2280-2
CESeasy communication module Page 5 of 37
2 Manufacturer’s information

3 For your safety
3.1 EU Declaration of conformity
You can find the EU Declaration of conformity on the Internet at www.ces.eu.
3.2 Intended use
CESeasy products are intended to control access at doors. They are exclusively intended for this
purpose and may only be used for this. They may never be altered in any way without written
permission from C.Ed. Schulte GmbH Zylinderschlossfabrik.
All other uses are regarded as improper use and may lead to material damage or even personal
injuries. C.Ed. Schulte GmbH Zylinderschlossfabrik assumes no liability for damage caused by
improper use.
3.3 Basic safety instructions
CESeasy products have been built with state-of-the-art technology and established safety
regulations. Nevertheless, their use may constitute function-related hazards for the user or third
parties and may impair the handle set and other material assets.
Please observe all warnings and notices in this manual while assembling, configuring and using
CESeasy products.
3.3.1 Life-threatening danger
lCESeasy products have not been developed, tested and/or approved for access in
life-threatening situations. Do not use CESeasy products on fire doors or panic doors.
lCESeasy products must be suitable for your door system. If you are in doubt, please contact
the manufacturer of the door or lock to check suitability.
lAll components which are required for a complete installation at your door must be CE-
compliant. Please check before installation whether all components used are CE-compliant.
3.3.2 Danger of personal injury
Danger of explosion
lLive parts may cause explosion. Do not use parts in potentially explosive areas.
Page 6 of 37 CESeasy communication module
3 For your safety

3.3.3 Danger of damage to material assets
Transportation
lDo not drop the device on the floor, on hard surfaces or objects.
Assembly
lThe device contains highly sensitive electronic components, which can be damaged or
destroyed through electrostatic charges. Therefore, do not assemble the handle set in
areas affected by electrostatic charge.
lFor assembly and dismantling, use the tools indicated in the "Assembly" section only.
lOnly use a dry or protected or indoors place for device installation.
Operation
lProtect the electronic components against water and other fluids.
Maintenance
lAlways have repairs performed by qualified personnel.
lUse only the accessories and spare parts recommended by CES.
Danger through climatic influences
lDo not use the device in corrosive atmosphere (chlorine, ammonia, lime water)
lDo not use the device in areas with high dust formation.
lDo not use the device near heat sources.
Please observe the maximum permissible temperatures and the information on air humidity in
the section “Technical Data".
3.4 Notes on dealing with batteries
lAlways insert new batteries only. Never use old and new batteries together.
lBefore inserting the batteries, check whether the contacts in the device and on the bat-
teries are clean. Otherwise, clean them. Do not touch the contacts after the cleaning pro-
cess.
lWhen inserting the batteries, ensure that the polarity is correct (+/-).
lNever try to recharge the batteries. There is a risk of explosion!
lDo not short-circuit the batteries.
lStore batteries in a cool and dry place. Direct heat may damage the batteries. Therefore, do
not expose battery-operated devices to any strong heat source, and do not throw the bat-
teries into fire.
CESeasy communication module Page 7 of 37
3 For your safety

lIf you do not use devices for a longer time, take out the batteries.
lRemove leaking batteries immediately from the device. Clean the contacts before inserting
new batteries. There is danger of injury from battery acid.
lRemove the empty batteries from the device.
lPlease take note of the information on battery disposal (see "Disposal" on page33).
Page 8 of 37 CESeasy communication module
3 For your safety

4 CESeasy communication module
4.1 About communication modules
A CESeasy communication module allows you to control CESeasy motor cylinders and CESeasy
door controllers with devices from other manufacturers.
A communication module can control both a motor cylinder and a door controller.
Therefore, the term “lock” is used as an umbrella term. This can refer to either a motor
cylinder or a door controller.
The communication module has several inputs through which orders are forwarded to the lock.
There are additional outputs which reflect the lock status. The communication module and the
lock communicate wirelessly.
4.2 Scope of application
Due to the available inputs and outputs and the functions which are linked to them, the
communication module can be used in a very versatile manner. The communication module is to
be used together with a CESeasy motor cylinder or a CESeasy door controller.
CESeasy products have not been developed, tested and/or approved for access to escape
and emergency routes. Do not use CESeasy products on fire doors or panic doors.
The device must be installed in a dry and protected place in the building.
CESeasy communication module Page 9 of 37
4 CESeasy communication module

5 Scope of delivery
1 1 Communication module
2 2 Batteries
3 1 Power supply unit
Page 10 of 37 CESeasy communication module
5 Scope of delivery
