Timed Gas Controller
Model: CGS TGC

Installation, Operation & Maintenance Manual
Please read this manual carefully and retain for future use.
For specific requirements that may deviate from the information in this guide –contact your supplier.
Canadian Gas Safety LLC
www.canadiangassafety.com

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 2
Contents
Important Warning Statements .................................................................. 3
Installation................................................................................................... 4
Typical Application & Location ............................................................................................ 4
Mounting & Cabling............................................................................................................... 4
Circuit Board Terminals........................................................................................................ 5
Wiring –Power Inputs ........................................................................................................... 5
Wiring –Gas Valve Outputs ................................................................................................. 6
Wiring –Remote Emergency Stop...................................................................................... 6
Selectable Automatic Timeout Switches............................................................................ 6
Basic Operation........................................................................................... 7
Basic Maintenance...................................................................................... 7
Specification ............................................................................................... 8

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 3
Important Warning Statements
Before any installation, use or maintenance read this manual carefully.
The information contained within this manual should be referenced for typical installation and operation only.
For site specific requirements that may deviate from the information in this guide –contact your supplier.
If this product is used in a manner not specified by the manufacturer, the safety provided by the product may
be impaired.
This product is designed for indoor operation only unless used in conjunction with a weatherproof cover.
Cables must be protected against mechanical damage.
The internal fuse should be replaced only with the same type. Anti-surge fuse 3.15A 250Vac 5x20.
This product is not designed to detect smoke, fire or other gases and should NOT be used as such.
This device requires a continual supply of electrical power –it will not work without power.
A switch or circuit breaker must be fitted, it must be accessible and marked as the disconnecting device!
This device should not be used to substitute proper installation, use and / or maintenance of fuel burning
appliances including appropriate ventilation and exhaust systems.
Seek fresh air supply and contact your local gas emergency service should you suspect a gas leak.
This device may not fully safeguard individuals with specific medical conditions. If in doubt, consult a doctor /
physician.
Any parts that form part of the connections/installation must have a minimum fire-retardant rating of UL 94V-2!
Use with a low-profile surface mount or flush cover available from CGS!
Your product should reach you in perfect condition, if you suspect it is damaged, contact your supplier.
Manufacturer’s Warranty Statement
Warranty coverage: The manufacturer warrants to the original consumer purchaser, that this product will be free of defects in
material and workmanship for a period of twelve months (1 year) from date of purchase.
The manufacturer’s liability hereunder is limited to replacement of the product with repaired product at the discretion of the
manufacturer. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, tampering or other
causes not arising from defects in material or workmanship. This warranty extends to the original consumer purchaser of the product
only.
Warranty disclaimers: Any implied warranties arising out of this sale, including but not limited to the implied warranties of
description, merchantability and intended operational purpose, are limited in duration to the above warranty period. In no event shall
the manufacturer be liable for loss of use of this product or for any indirect, special, incidental, or consequential damages, or costs,
or expenses incurred by the consumer or any other user of this product, whether due to a breach of contract, negligence, strict
liability in tort or otherwise. The manufacturer shall have no liability for any personal injury, property damage or any special,
incidental, contingent or consequential damage of any kind resulting from gas leakage, fire, or explosion. This warranty does not
affect your statutory rights.
Warranty Performance: During the above warranty period, your product will be replaced with a comparable product if the defective
product is returned together with proof of purchase date. The replacement product will be in warranty for the remainder of the
original warranty period or for six months –whichever is the greatest.
Information on waste disposal for consumers of electrical & electronic equipment.
When this product reaches the end of its life it must be treated as Waste Electrical & Electronics Equipment (WEEE).
WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and
recycling of the materials used. Please contact your supplier or local authority for details of recycling schemes in your area.

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 4
Installation
Typical Application & Location
Installation must be in accordance with the recognised standards of the appropriate authority in the country concerned!
Access to the interior of the device, when carrying out any work, must only be conducted by trained personnel!
Before carrying out any work ensure local regulations and site procedures are followed!
Isolate the equipment from all hazardous live power sources before opening the cover!
The CGS –Timed Gas Controller (TGC) is carefully designed for the commercial and hospitality sector to
control the gas supply for a range of appliances such as fireplaces, fire pits and barbeques etc.
The controller incorporates a simple user interface to open/close gas lines and an automatic shutoff
timeout feature is configurable via switches upon installation. The controller can also be integrated with
remote devices with an open/close circuit isolating the gas supply in an emergency.
Located and installed in positions determined by those who have knowledge of the process plant system
and equipment involved, and in consultation with both safety and electrical engineering personnel.
The controller should be installed in the correct orientation, as recommended by the manufacturer at a
height to suit public access and status observation (if intended for public use) and is designed for indoor
operation unless used in conjunction with a weatherproof cover (sold separately).
Mounting & Cabling
If mounting direct to wall - ensure the wall surface is flat to prevent base distortion!
Where cable glands/conduits are used for wire entry, use 20mm (3/4 inch) max separated by at least 20mm!
Any parts that form part of the connections/installation must have a minimum fire-retardant rating of UL 94V-2!
Restrain the hazardous live wiring from accidental loosening to prevent wires from moving after installation and touching
parts of opposite polarity or at low voltages!
A switch or circuit breaker must be fitted, it must be accessible and marked as the disconnecting device!
Isolate the equipment from all hazardous live power sources before opening the cover!
Weatherproof covers are available for outside installation accommodating flush and wall mounted type!
1. Carefully remove the front cover from the unit by using an M3 socket wrench.
2. Using the rear base - mark mounting holes to the wall or align with an appropriate gang/pattress box.
3. Fixing straight to wall –drill 0.2” (5mm) hole, insert plugs and use the four screws (No.4 Pozi) provided.
Alternatively –Fix direct to a 2-gang/double electrical pattress box.
4. There are pre-fractured areas for cable entry on the rear of the base and pilot holes positioned on the top
and bottom of the enclosure suitable for entry points up to ¾” (20mm).
5. Secure the front cover with all M4 bolts and insert security caps provided.

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 5
Clear Weatherproof Covers
These indoor/outdoor low-profile covers protect devices
without restricting legitimate operation.
The versatile cover offers excellent protection against
physical damage (both accidental and intentional), dust
and grime as well as severe environmental conditions
inside and out.
Wall Mount Cover. Part No: CGS-TGC-WM-COVER
Flush Mount Cover. Part No: CGS-TGC-FM-
COVER
Contact your CGS Representative to order.
Circuit Board Terminals
Damage to PCBs when creating cable entry points may void any warranty!
Take care when making connections to high voltage connectors!
Any damage attempting to remove the circuit board may void any warranty!
All Class 2 wiring is to be installed within flexible tubing to maintain segregation between circuits!
Wiring of different circuits shall be separated by means of routing, clamping or barrier!
For field connections use wires suitable for at least 167°F (75°C)
Any parts that form part of the connections/installation must have a minimum fire-retardant rating of UL 94V-2!
Wiring –Power Inputs
The controller requires a power supply of 100-120V~ Wired to the [POWER/LINE IN] connector using a 3A
switched fused spur. Alternatively, the unit can be powered via the 24V [POWER IN] terminal. This can be
AC or DC.
When power is connected/live, a red LED will illuminate on the front of the controller on the CGS Logo.

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 6
Wiring –Gas Valve Outputs
A gas solenoid valve should be powered using one of the terminals marked [VALVE OUT].
Terminals offer control via mains 100-120V~ or 24V~
When wired to a normally closed gas solenoid valve, the TGC controller can be used to isolate the gas
supply either by; pressing the Off button on the unit; when the configured time runs out or if remote
emergency devices are activated.
Wiring –Remote Emergency Stop
The Timed Gas Controller can be connected to remote devices with an open /close circuit via the [EM
STOP] volt free switch terminal.
This terminal has a factory fitted link installed (normally closed circuit) and when open will isolate the gas
supply resetting the gas supply timer. No audible alarm will occur –only EM Stop LED indicator.
Selectable Automatic Timeout Switches
On the circuit board are two dipswitches used for selecting the automatic gas shutoff timeout.
The controller LED will turn yellow ten (10) minutes before the selected time is reached and when five (5)
minutes remain the buzzer will beep, and the yellow LED will then intermittently flash.
After this time, the gas will automatically shut off until reactivated.

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 7
Basic Operation
Isolate the equipment from all hazardous live power sources before opening the cover!
When power is supplied to the TGC controller, the LED on the log of the cover will illuminate Red. To turn
the TGC controller off, disconnect electrical power supply.
The Status LED changes colour when the controller enters three (3) different states as follows.
Green. Remains illuminated when gas is being supplied.
Yellow. The controller LED will turn yellow ten (10) minutes before the automatic gas shut off
timeout is reached and when five (5) minutes remain the buzzer will beep, and the yellow LED will
then intermittently flash. After this time, the gas will automatically shut off until reactivated.
Red. Remains illuminated when a remote emergency stop device has been activated.
The gas supply is isolated until the emergency has been investigated, rectified, and reset. Press
ON to re-enable/open the gas supply.
Basic Maintenance
Keep your gas controller in good working order - follow these basic principles.
✓Remove any dust/debris from the outer enclosure regularly using a slightly damp cloth.
✓Never use detergents or solvents to clean your device.
✓Never spray air fresheners, hair spray, paint or other aerosols near the device.
✓Never paint the device.

CGS TGC Installation, Operation & Maintenance
CGS TGC v2 220322 8
Specification
General
Model:
CGS TGC –Timed Gas Controller
Size: (H x W x D)
5.95 x 4.37 x 1.97” (151 x 111 x 50mm)
Housing Material:
ABS PA765 (Flame Rating UL94 V-1)
Mounting:
Wall/Flush Mounted. Indoor/Outdoor use –Outdoor using weatherproof cover.
Cover (Optional Part)
UV stabilized. 1lb. 5x5x5”
Weight:
11.2 oz (0.32g)
User Interface
Display:
N/A
Screen Brightness:
N/A
Visual Indicators:
LED. Gas On / Timeout / Emergency Stop
Audible Buzzer:
>60dB @ 3.28ft (1m). Quiet conditions.
Buttons:
Multi-Function –Gas On / Reset Timer / Gas Off
Language:
English
Power Supply
Power Consumption:
1.2W Max
Power Input #1:
100-120V~ 50-60Hz
Power Input #2
24V AC or DC
Internal Fuse:
Anti-Surge 3.15A @ 250Vac
Equipment
Overvoltage Category:
II
Pollution Degree:
2
Relays
One
3A @ 110V~
Environmental
Ingress Protection:
Not Formally Evaluated
Operating:
-20 ~ 50°C / 14 ~ 122°F 20 ~ 95% RH (non-condensing)
Storage:
-25 ~ 50°C / -13~122F° up to 95% RH (non-condensing)
Altitude Rating:
2000m
Wiring
Typical
Min. 18AWG / 75°C min / Tinned copper.
Pre-Approvals
Electrical Safety
UL/CSA/BS/EN 61010-1
Electromagnetic Compatibility
FCC CFR 47 Parts 15, 107 & 109
Every effort is made to ensure the accuracy of this document; however, CGS can assume no responsibility for any errors or
omissions in this document or their consequences. CGS would greatly appreciate being informed of any errors or omissions
that may be found in the content of this document. For information not covered in this document, or if there is a requirement to
send comments/corrections, please contact CGS using the contact details.
Canadian Gas Safety LLC
www.canadiangassafety.com
Head office:
150 King Street West, Suite 200, Toronto ON M5H 1J9
Tel: [phone]
Email: [e-mail]
Canadian Gas Safety LLC is the owner of this document and reserves all rights of modification without prior notice.
