Challenge MPPHA-05CRN1-QB6 User manual

INSTRUCTION MANUAL
5000BTU LOCAL AIR CONDITIONER

The rating data indicated on the energy label is based
on the testing condition of installing the un-extended
air exhaust duct without adaptor A & B (The duct and
the adaptor A & B are listed in the accessories chart
of the Instruction Manual).
NOTE
1
CONTENTS
Safety rules........................................................................................................................................2
Operating condition.....................................................................................................................................3
Suggested tools for window kit installation..................................................................................................3
SAFETY PRECAUTIONS
Names of parts...................................................................................................................................4
Accessories.................................................................................................................................................4
IDENTIFICATION OF PARTS
Installation instruction................................................................................................................……..5
Exhaust hose installation………..............................................................................................................…6
Water drainage...................................................................................................................................…….8
INSTALLATION INSTRUCTIONS
Control panel………......................................................................................................................…..9
Operating instruction……......................................................................................................................…10
Remark……..............................................................................................................................................10
OPERATION
Care and maintenance……………....................................................................................................14
CARE AND MAINTENANCE
Remote Control……………...............................................................................................................11
REMOTE CONTROL
Trouble shooting ……… …….........................................................................................................….15
TROUBLE SHOOTING TIPS
Product specification………..............................................................................................................16
PRODUCT SPECIFICATION
Connection to power……..................................................................................................................17
CONNECTIONTO POWER
Technical information (ERP)…………................................................................................................18
TECHNICAL INFORMATION (ERP)
Product guarantee…………...............................................................................................................19
PRODUCT GUARANTEE

To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring of instructions may cause harm or damage.
Your air conditioner should be used in such a way
that it is protected from moisture. e.g. condensation,
splashed water, etc.Do not place or store your air
conditioner where it can fall or be pulled into water
or any other liquid.Unplug immediately if it occurs.
Always transport your air conditioner in a vertical
position and stand on a stable, level surface during
use.
Turn off the product when not in use.
Always contact a qualified person to carry out
repairs. If the supply cord is damaged it must be
repaired by a qualified repairer.
Keep an air path of at least 30cm all around the
unit from walls, furniture and curtains.
If the air conditioner is knocked over during use,
turn off the unit and unplug from the mains supply
immediately.
!
Always do this
Do not operate your air conditioner in a wet room
such as a bathroom or laundry room.
Do not touch the unit with wet or damp hands or
when barefoot.
Do not press the buttons on the control panel with
anything other than your fingers.
Do not remove any fixed covers. Never use this
appliance if it is not working properly, or if it has
been dropped or damaged.
Never use the plug to start and stop the unit.
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come
into contact with the unit. Do not use the unit in the
presence of inflammable substances or vapour such
as alcohol, insecticides, petrol,etc.
Do not allow children to operate the unit
unsupervised.
Do not use this product for functions other than
those described in this instruction manual.
Never do this
Safety rules
SAFETY PRECAUTIONS
For your safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove
any prong from the power cord.
2
CAUTION:
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.

Energy Save
Use the unit in the recommended room size.
Locate the unit where furniture cannot obstruct the air flow.
Keep blinds/curtains closed during the sunniest part of the day.
Keep the filters clean.
Keep doors and windows closed to keep cool air in and warm air out
The air conditioner should be operated within the temperature range indicated below:
Operating condition
Suggested tools for window kit installation
1.
Note:
1. If temperature higher than 35 degree, the air conditioner will stop frequently.
2. If the temperature lower than 17 degree in cool mode, the compressor will
not work and the fan motor will stop as well. If the temperature lower than
13 degree in dry mode, the compressor will not work
Screwdriver(medium size Phillips)
2. Tape measure or ruler
3. Knife or scissors
4. Saw(In the event that the window kit needs to be cut down in size because
the window is too narrow for direct installation)
MODE ROOM TEMPERATURE
COOL
DRY
O O
17 C ~35 C
O O
13 C ~35 C
SAFETY PRECAUTIONS
3

5
NAMES OF PARTS
Front
Fig.1
Fig.2
Rear
IDENTIFICATION OF PARTS
Check all the accessories are included in the package and please refer to the installation instructions for
their usage.
Accessories
4
Operation Panel
Carrying Handle
(both sides)
1
2
Cold air outlet
3
1
3
2
Air Filter
Air Outlet
Wheel
Air intake (with filter)
Drain Outlet
Air intake
10
Bottom tray drain outlet
10
4
5
6
7
8
9
4
5
6
7
8
9
1 pc
1 pc
4 set
Wall Exhaust Adaptor A (only for wall installation)
Wall Exhaust Adaptor B(with cap)(only for wall installation)
Screw A ST4.5x45 and wall plug(only for wall installation)
PARTS : PARTS NAME :
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
2 pc
2 pc
1 set
1 pc
2 pc
Unit Adaptor
Window Slider Adaptor
Window Slider A
Window Slider B
Exhaust Hose(Length: 1.4m, diameter: 130mm)
Bolt
Foam Seal A (Adhesive)
Foam Seal B (Adhesive)
Foam Seal C (Non-adhesive)
Bracket x 1 and screw (ST3.9x13) x 2
Drain Hose(Length: 0.6m, diameter: 16.5mm)
QUANTITY :
Remote control
Battery(LR03)
ON/OFF
TEMP
SHORT
CUT
TIMER
ON
TIMER
OFF
MODE
FAN
LED
SLEEP

INSTALLATION INSTRUCTIONS
Location
The air conditioner should be placed on a firm
foundation to minimize noise and virbration. For
safe and secure positioning, place the unit on a
smooth, level floor strong enough to support the unit.
The unit has casters to aid placement, but it should
only be rolled on smooth, flat surfaces. Use caution
when rolling on carpet surfaces. Do not attempt to
roll the unit over objects.
The unit must be placed within reach of a properly
rated grounded socket.
Never place any obstacles around the air inlet or
outlet of the unit.
Allow at least 30cm of space from the wall for
efficient air-conditioning.
INSTALLATION INSTRUCTIONS
Fig. 3
5

Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed
in accordance with the usage mode.
Preparing the Adjustable Window Slider
1. Depending on the size of your window, adjust the size of the
window slider.
2. If the length of the window requires two window sliders, use
the bolt to fasten the window sliders once they are adjusted
to the proper length.
Fig. 4
COOL, AUTO mode
FAN,DEHUMIDIIFY mode
Install
Remove
Fig.5
1. Connect the exhaust hose into the window slider adaptor (into
wall window slider adaptor for wall installation) and unit adaptor,
clamp automatically by elastic buckles of the adaptors (See Fig.4).
2. Push the Exhaust hose into the air outlet opening along the
the arrow direction(See Fig. 5).
INSTALLATION INSTRUCTIONS
6
Unit adaptor
For hung/sliding window
For wall installation
Window slider adaptor
Exhaust hose
Exhaust hose assembly
Exhaust hose assembly
Unit adaptor Wall exhaust adaptor A
Exhaust hose
Installation
Note: Once the Exhaust Hose assembly and Adjustable Window
Slider are prepared, choose from one of the following three
installation methods.
Type 1: Hung Window Installation(optional)
Cut the adhesive foam seal A
and B strips to the proper
lengths, and attach them to
the window sash and frame
as shown.
Cut the non-adhesive foam
seal C strip to match the width
of the window. Insert the seal
between the glass and the
window frame to prevent air
and insects from getting into
the room.
If desired, install the security
bracket with 2 screws as shown.
Insert the window slider
assembly into the window
opening.
Foam seal B
(Adhesive type-shorter)
2 Screws
Security Bracket
Foam seal A
(Adhesive type)
Window slider A
Window slider B
(if required)
Foam seal C
(Non-adhesive type)

INSTALLATION INSTRUCTIONS
7
Cut the adhesive foam seal A
and B strips to the proper
lengths, and attach them to
the window sash and frame
as shown.
Insert the window slider adaptor
into the hole of the window slider.
Insert the window slider
assembly into the window
opening.
Type 2: Sliding Window Installation(optional)
Foam seal B
(Adhesive type-shorter)
Foam seal A
(Adhesive type)
Window slider A
Window slider B
(if required)
Cut the non-adhesive foam
seal C strip to match the
window height. Insert the foam
seal between the glass and the
window frame to prevent air
and insects from getting into
the room.
If desired, install the security
bracket with 2 screws as shown.
Insert the window slider adaptor
into the hole of the window slider.
Foam seal C
(Non-adhesive type)
2 Screws
Security
Bracket
Type 3: Wall Installation(optional)
-Cut a 125mm (4.9inch) diameter hole into the wall for the Wall Exhaust Adaptor B.
-Secure the Wall Exhaust Adaptor B to the wall using the four Anchors
and Screws provided in the kit.
-Connect the Exhaust Hose Assembly(with Wall Exhaust Adaptor A) to the
Wall Exhaust Adaptor B.
Note: Cover the hole using the
adaptor cap when not in use.
Note: To ensure proper function, DO NOT overextend or bend
the hose. Make sure that there is no obstacle around the air
outlet of the exhaust hose (in the range of 500mm) in order to
the exhaust system works properly. All the illustrations in this
manual are for explanation purpose only. Your air conditioner
may be slightly different. The actual shape shall prevail.
max 120cm or 47 inch
min 30cm or 12 inch
Expansion anchor
position
Adaptor cap
Wall Exhaust
Adaptor B

Water drainage:
- During dehumidifying modes, remove the drain
plug from the back of the unit, install the drain
connector(5/8 universal female mender) with
3 4 hose(not included). Place the open end
of the hose directly over the drain area .
Please refer to Fig.6 & 7.
-Under dehumidifying mode, when the water level
of the bottom tray reaches a predetermined level,
Carefully move the unit to a drain location,
remove the bottom drain plug and let the
water drain away (Fig.8). Re-install the bottom
drain plug and Restart the machine until the P1
symbol disappears. If the error repeats, call for
service.
the unit beeps 8 times, the digital display area
shows "P1". At this time the air conditioner will
stop immediately. However, the fan motor will
continue to operate (this is normal).
Fig.6
Fig. 7
Fig.8
NOTE: Be sure to reinstall the bottom drain plug
before using the unit.
INSTALLATION INSTRUCTIONS
8
Remove the
drain plug
Continuous
drain hose
Bottom drain
plug

Fig. 9
OPERATION
Control Panel
9
MODE button
Selects the appropriate operating
mode. Each time you press the button,
a mode is selected in a sequence that
goes from COOL, FAN and DRY .The
mode indicator light illuminates under
the different mode setting.
NOTE: On above modes, the unit
operates the auto fan speed
automatically. You can set fan speed
only by the remote control on
COOL and FAN modes.
Used to adjust (increasing/decreasing)
temperature settings in 1°C/2°F(or 1°F)
increments in a range of 17°C/62°F to
30°C/88°F (or 86°F).
NOTE: The control is capable of
displaying temperature in degrees
Fahrenheit or degrees Celsius. To
convert from one to the other, press
and hold the Up and Down buttons
at the same time for 3 seconds.
Power button
Turn the unit on/off.
Power
indicator light
Timer mode indicator
light (set only by
remote control)
Up (+) and Down (-) buttons
LED display
Shows the set temperature while on cool
mode. While on DRY and FAN modes, it
shows the room temperature.
Shows Error codes:
E1-Room temperature sensor error.
E2-Evaporator temperature sensor error.
E4-Display panel communication error.
EC-Refrigerant leakage detection
malfunction(on some models).
Shows protection code:
P1-Bottom tray is full--Connect the drain
hose and drain the collected water away.
If protection repeats,call for service.
Note: When one of the above malfunctions
occurs, turn off the unit, and check for any
obstructions. Restart the unit, if the
malfunction is still present, turn off the unit
and unplug the power cord. Contact the
manufacturer or its service agents or a
similar qualified person for service.
