Toshiba RAS-M10SMUV-E User manual

ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΑPORTUGUÊSSVENSKA РУССКИЙ ЯЗЫК
AIR CONDITIONER (SPLIT TYPE)
INSTALLATION MANUAL
MANUEL D’INSTALLATION
INSTALLATIONS-HANDBUCH
MANUALE DI INSTALLAZIONE
MANUAL DE INSTALACIÓN
ΕΓΧΕΙΡΙ∆ΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
MANUAL DE INSTALAÇÃO
ИНСТРУКЦИЯ ПО УСТАНОВКЕ
INSTALLATIONSANVSNING
Not accessible to the general public
CLIMATISEUR (TYPE SEPARE) Vente interdite au grand public
KLIMAGERÄT (SPLIT-TYP) Kein öffentlicher Zugang
CONDIZIONATORE D’ARIA (TIPO SPLIT) Non accessibile a clienti generici
AIRE ACONDICIONADO (TIPO SPLIT) No destinado al público en general
ΚΛΙΜΑΤΙΣΤΙΚΟ (∆ΙΑΙΡΟΥΜΕΝΟΥ ΤΥΠΟΥ)Μη προσβάσιµοαπό το γενικό κοινό
AR CONDICIONADO (TIPO SPLIT) Não acessível ao público em geral
КОНДИЦИОНЕР (РАЗДЕЛИТЕЛЬНЫЙ ТИП) Ограничено для доступа широкой
общественности
LUFTKONDITIONERINGSAPPARAT (SPLITTYP) Inte tillgänglig för allmänheten
4-Way Air Discharge Cassette Type
Type cassette à 4 voies de soufflage
4-Wege-Belüftungskassette
Tipo a cassetta con scarico d'aria a 4 vie
Modelo de casete de distribución de aire de
4vías
Εκροή αέρα 4-∆ιευθύνσεων Τύπου Κασέτας
Descarga de ar tipo cassete de 4 vias
4-направленная кассета выписка воздуха
Apparat med 4-vägars luftutsläpp
Indoor Unit/Unité intérieure/Raumeinheit/Unità interna/Unidad interior
Εσωτερική µονάδα/Unidade interior/Внутренний блок/Inomhusenhet
Heat Pump Model
Modèle à thermopompe
Geräte mit Heizung
Modello con pompa di riscaldamento
Modelo con bomba de calor
Μοντέλο µεΑντλία Θερµότητας
Modelo de bomba térmica
Модель теплового насоса
Värmepumpsmodell
Cooling Only Model
Modèle à froid seul
Geräte nur zur Kühlung
Modello solo per raffreddamento
Modelo de refrigeración únicamente
Μοντέλο Ψύξης αποκλειστικά
Modelo Apenas para Refrigeração
Модель только c охлаждением
Modell endast för avkylning
RAS-M10SMUV-E
RAS-M13SMUV-E
RAS-M16SMUV-E
RAS-M10SMUCV-E
RAS-M13SMUCV-E
RAS-M16SMUCV-E
Ceiling panel/Panneau pour plafond/Deckenrahmen/Pannello al soffitto/
Panel de techo/Φάτνωµα οροφής/Painel de tecto/Потолочная панель/
Takpanel
RB-B11MC(W)E

i
1 SAFETY PRECAUTIONS.......................................................... 1
2 ACCESSORY PARTS AND PARTS TO BE PROCURED
LOCALLY .................................................................................. 3
3 SELECTION OF INSTALLATION PLACE................................. 4
4 INSTALLATION OF INDOOR UNIT .......................................... 6
5 DRAIN PIPING WORK............................................................ 11
6 REFRIGERANT PIPING AND EVACUATING......................... 15
7 EVACUATING......................................................................... 17
8 ELECTRICAL WORK.............................................................. 18
9 APPLICABLE CONTROLS...................................................... 21
10 TEST OPERATION................................................................. 23
11 INSTALLATION/SERVICING TOOLS..................................... 23
12 MAINTENANCE ...................................................................... 24
Please read this Installation Manual carefully before installing the Air
Conditioner.
• This Manual describes the installation method of the indoor unit.
• For installation of the outdoor unit, follow the Installation Manual
attached to the outdoor unit.
This Air Conditioner is a new type which adopts the new refrigerant
HFC (R410A) instead of the conventional refrigerant R22. R410A is
an ozone friendly refrigerant.
1 MESURES DE SECURITE........................................................ 1
2 PIÈCES ACCESSOIRES ET PIÈCES NON FOURNIES.......... 3
3 SELECTION DU LIEU D’INSTALLATION................................. 4
4 INSTALLATION DE L’UNITE INTERIEURE.............................. 6
5 INSTALLATION DES TUYAUX D’EVACUATION ................... 11
6 TUYAUTERIE DE FRIGORIGÈNE ET ÉVACUATION............ 15
7 EVACUATION DE L’AIR ......................................................... 17
8 INSTALLATION ELECTRIQUE............................................... 18
9 COMMANDES APPLICABLES ............................................... 21
10 ESSAI DE FONCTIONNEMENT............................................. 23
11 OUTILS D’INSTALLATION/D’ENTRETIEN............................. 23
12 ENTRETIEN ............................................................................ 24
Veuillez lire attentivement ce Manuel d'installation avant d'installer le
climatiseur.
• Ce manuel décrit la procédure d'installation de l'unité intérieure.
• Pour installer l'unité extérieure, reportez-vous au Manuel
d'installation fourni avec l'unité extérieure.
Ce nouveau type de climatiseur utilise le nouveau réfrigérant HFC
(R410A) au lieu du traditionnel R22. Le R410A est un réfrigérant qui
respecte la couche d'ozone.
1 SICHERHEITSVORKEHRUNGEN............................................ 1
2 ZUBEHÖR UND BAUSEITS BEREITZUSTELLENDE TEILE... 3
3 AUSWAHL DES AUFSTELLUNGSORTES .............................. 4
4 INSTALLATION DER RAUMEINHEIT....................................... 6
5 INSTALLATION DES KONDENSWASSER-ABLAUFS........... 11
6 KÜHLMITTELLEITUNGSSYSTEM UND ENTLÜFTUNG ....... 15
7 ENTLÜFTEN DER ROHRLEITUNGEN................................... 17
8 ELEKTROINSTALLATION ...................................................... 18
9 STEUERUNGSMÖGLICHKEITEN.......................................... 21
10 TESTLAUF .............................................................................. 23
11 INSTALLATIONS / WARTUNGSWERKZEUGE ..................... 23
12 WARTUNG.............................................................................. 24
Bitte lesen Sie dieses Handbuch sorgfältig, bevor Sie mit der
Installation des Klimagerätes beginnen.
• In diesem Handbuch wird die Installation der Inneneinheit
beschrieben.
• Um die Außeneinheit zu installieren, folgen Sie den Anweisungen
des Handbuchs, das der Außeneinheit beiliegt.
Dies ist ein neuartiges Klimagerät. Anstatt des herkömmlichen
Kältemittels R22 verwendet es das neue HFC Kältemittel R410A.
R410A schont die Ozonschicht.
1 PRECAUZIONI PER LA SICUREZZA....................................... 1
2 ACCESSORI E PARTI DA ACQUISTARE SUL POSTO .......... 3
3 SCELTA DEL POSTO D’INSTALLAZIONE............................... 4
4 INSTALLAZIONE DELL’UNITÀ INTERNA................................ 6
5 LAVORO PER TUBAZIONE DI SCARICO.............................. 11
6 TUBAZIONI DEL REFRIGERANTE E SCARICO ................... 15
7 SPURGO................................................................................. 17
8 ESECUZIONE DEI COLLEGAMENTI ELETTRICI.................. 18
9 COMANDI UTILIZZABILI......................................................... 21
10 FUNZIONAMENTO DI PROVA............................................... 23
11 ATTREZZI PER L’INSTALLAZIONE/PER LA
MANUTENZIONE.................................................................... 23
12 MANUTENZIONE.................................................................... 24
Prima di eseguire l'installazione del condizionatore d'aria, leggere
attentamente il Manuale d'installazione.
• Questo manaule il metodo d'installazione dell'unità interna.
• Per l'installazione dell'unità esterna, fare riferimento al Manuale
d'installazione fornito con l'unità esterna.
Questo condizionatore d'aria è di dipo nuovo e impiega il nuovo
refrigerante HFC (R410A) invece del R22, tradizionalmente usato.
R410A è un refrigerante ecologicamente rispettoso dello strato
d'ozono.
CONTENTS/SOMMAIRE/INHALT/INDICE
ENGLISH
ADOPTION OF NEW REFRIGERANT
FRANÇAIS
UTILISATION DU NOUVEAU REFRIGERANT
DEUTSCH
EINFÜHRUNG EINES NEUEN KÜHLMITTELS
ITALIANO
ADOZIONE DI UN NUOVO REFRIGERANTE

ii
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΑPORTUGUÊSSVENSKA РУССКИЙ ЯЗЫК
1 PRECAUCIONES SOBRE SEGURIDAD.................................. 1
2 COMPONENTES ACCESORIOS Y COMPONENTES DE
SUMINISTRO LOCAL............................................................... 3
3 SELECCIÓN DEL LUGAR DE INSTALACIÓN ......................... 4
4 INSTALACIÓN DE LA UNIDAD INTERIOR.............................. 6
5 CANALIZACIÓN DE DRENAJE.............................................. 11
6 TUBOS DE REFRIGERANTE Y EVACUACIÓN..................... 15
7 EVACUACIÓN......................................................................... 17
8 TRABAJOS EN EL SISTEMA ELÉCTRICO............................ 18
9 CONTROLES APLICABLES................................................... 21
10 FUNCIONAMIENTO DE PRUEBA.......................................... 23
11 HERRAMIENTAS DE INSTALACIÓN/REPARACIÓN............ 23
12 MANTENIMIENTO .................................................................. 24
Lea atentamente este Manual de instalación antes de proceder a la
instalación del aparato de aire acondicionado.
• Este manual describe el método de instalación de la unidad interior.
• Para la instalación de la unidad exterior, consulte el Manual de
instalación que acompaña a la unidad exterior.
Este acondicionador de aire es un tipo Nuevo que adopta el
refrigerante nuevo HFC (R410A) en vez del refrigerante convencional
R22. El R410A es un refrigerante que no daña la capa de ozono.
1ΠΡΟΦΥΛΑΞΕΙΣ ΑΣΦΑΛΕΙΑΣ ................................................... 1
2ΠΑΡΕΛΚΌΜΕΝΑ ΑΝΤΑΛΛΑΚΤΙΚΆ ΚΑΙ ΕΞΑΡΤΉΜΑΤΑ ΑΠΌ
ΤΗΝ ΤΟΠΙΚΉ ΑΓΟΡΆ ............................................................... 3
3ΕΠΙΛΟΓΗ ΤΟΥ ΧΩΡΟΥ ΕΓΚΑΤΑΣΤΑΣΗΣ ................................ 4
4ΕΓΚΑΤΑΣΤΑΣΗ ΤΗΣ ΕΣΩΤΕΡΙΚΗΣ ΜΟΝΑ∆ΑΣ....................... 6
5ΕΓΚΑΤΑΣΤΑΣΗ ΣΩΛΗΝΩΣΕΩΝ ΑΠΟΣΤΡΑΓΓΙΣΗΣ ............... 11
6ΣΩΛΗΝΩΣΕΙΣ ΨΥΞΗΣ ΚΑΙ ΑΠΟΣΤΡΑΓΓΙΣΗΣ ....................... 15
7ΕΚΚΕΝΩΣΗ ............................................................................. 17
8ΗΛΕΚΤΡΟΛΟΓΙΚΑ .................................................................. 18
9ΕΦΑΡΜΟΣΙΜΟΙ ΕΛΕΓΧΟΙ ...................................................... 21
10 ∆ΟΚΙΜΑΣΤΙΚΗ ΛΕΙΤΟΥΡΓΙΑ .................................................. 23
11 ΕΡΓΑΛΕΙΑ ΕΓΚΑΤΑΣΤΑΣΗΣ/ ΕΠΙΣΚΕΥΗΣ ............................ 23
12 ΣΥΝΤΗΡΗΣΗ........................................................................... 24
Παρακαλώ διαβάστε προσεχτικά το Εγχειρίδιο Εγκατάστασης πριν
από την εγκατάσταση του Κλιµατιστικού.
•Το παρόν Εγχειρίδιο περιγράφει τη µέθοδο εγκατάστασης της
εσωτερικής µονάδας.
•Για την εγκατάσταση της εξωτερικής µονάδας, συµβουλευτείτε το
Εγχειρίδιο Εγκατάστασης που συνοδεύει την εξωτερική µονάδα.
Το παρόν Κλιµατιστικό είναι νέου τύπου και υιοθετεί το νέο ψυκτικό
HFC (R410A) αντί για το συµβατικό ψυκτικό R22. Το R410A είναι ένα
ψυκτικό φιλικό ως προς το όζον.
1 PRECAUÇÕES DE SEGURANÇA............................................ 1
2 ACESSÓRIOS E PEÇAS ADQUIRIDAS LOCALMENTE ......... 3
3 SELECÇÃO DO LOCAL DE INSTALAÇÃO.............................. 4
4 INSTALAÇÃO DA UNIDADE INTERIOR .................................. 6
5 INSTALAÇÃO DA TUBAGEM DE DRENAGEM ..................... 11
6 TUBAGEM DE REFRIGERANTE E EVACUAÇÃO................. 15
7 EXPURGO............................................................................... 17
8 LIGAÇÕES ELÉCTRICAS....................................................... 18
9 CONTROLOS APLICÁVEIS.................................................... 21
10 OPERAÇÃO DE TESTE.......................................................... 23
11 FERRAMENTAS DE INSTALAÇÃO/REPARO ....................... 23
12 MANUTENÇÃO....................................................................... 24
Leia atentamente o presente Manual de Instalação antes de instalar
o Ar Condicionado.
• O presente manual descreve o método de instalar a unidade
interior.
• Para a instalação de uma unidade exterior, siga o Manual de
Instalação que acompanha a unidade exterior.
O presente aparelho de ar condicionado é um novo tipo que adopta o
novo refrigerante HFC (R410A) em vez do refrigerante convencional
R22. O R410A é um refrigerante que não prejudica o ozono.
1 МЕРЫ ПРЕДОСТОРОЖНОСТИ............................................. 1
2 ДОПОЛНИТЕЛЬНЫЕ ПРИНАДЛЕЖНОСТИ И
КОМПОНЕНТЫ, ПРИОБРЕТАЕМЫЕ НА МЕСТЕ ................. 3
3 ВЫБОР МЕСТА УСТАНОВКИ ................................................ 4
4 УСТАНОВКА ВНУТРЕННЕГО БЛОКА ................................... 6
5 РАБОТЫ HA ДРЕНАЖНОМ ТРУБОПРОВОДЕ ................... 11
6 ПОДАЧА И ОТКАЧКА XЛAДAГEHTA.................................... 15
7 ОТКАЧКА................................................................................ 17
8 ЭЛЕКТРОМОНТАЖНЫЕ РАБОТЫ ...................................... 18
9 ПРИМЕНИМЫЕ СРЕДСТВА УПРАВЛЕНИЯ........................ 21
10 ТЕСТОВАЯ РАБОТА ............................................................. 23
11 УСТАНОВКА/ИНСТРУМЕНТЫ ДЛЯ ОБСЛУЖИВАНИЯ..... 23
12 ТЕХНИЧЕСКОЕ ОБСЛУЖИВАНИЕ ..................................... 24
Внимательно прочитайте данное Руководство перед установкой
кондиционера.
• B данном Руководстве описывается метод установки
внутреннего блока.
• Для установки наружного блока следуйте инструкциям
Руководства по установке, прилагаемого к наружному блоку.
Данный кондиционер является кондиционером нового типа. в
котором предусмотрено использование нового хладагента НЕС
(R410A) вместо традиционного R22. R410A - хладагент, не
разрушающий озоновый слой.
ÍNDICE/ΠΕΡΙΕΧΟΜΕΝΑ/ÍNDICE/СОДЕРЖАНИЕ
ESPAÑOL
ADOPCIÓN DE NUEVO REFRIGERANTE
ΕΛΛΗΝΙΚA
ΥΙΟΘΕΤΗΣΗ ΝΕΟΥ ΨΥΚΤΙΚΟΥ
PORTUGUÊS
ADOPCIÓN DE NUEVO REFRIGERANTE
РУССКИЙ ЯЗЫК
ВНЕДРЕНИЕ НОВОГО ХЛАДАГЕНТА

iii
1 SÄKERHETSFÖRESKRIFTER................................................. 1
2 TILLBEHÖR OCH DELAR SOM ANFÖRSKAFFAS LOKALT... 3
3 VAL AV INSTALLATIONSPLATS.............................................. 4
4 INOMHUSENHETENS INSTALLATION ................................... 6
5 ARBETE MED TÖMNINGSRÖREN........................................ 11
6 KYLVÄTSKANS RÖRLEDNING OCH TÖMNING................... 15
7 TÖMNING................................................................................ 17
8 ELEKTRISKT ARBETE ........................................................... 18
9 TILLÄMPBARA KONTROLLER .............................................. 21
10 TESTFUNKTION..................................................................... 23
11 INSTALLATION / SERVICEVERKTYG................................... 23
12 UNDERHÅLL........................................................................... 24
Vänligen läs denna Installationshandbok noga innan du installerar
luftkonditioneringsapparaten.
• Denna handbok beskriver hur inomhusenheten ska installeras.
• För installation av utomhusenheten, följ Installationshandboken
som är ansluten till utomhusenheten.
Denna luftkonditioneringsapparat är en ny typ som använder den nya
kylvätskan HFC (R410A) i stället för den vanliga kylvätskan R22.
R410A är en kylvätska som inte är skadlig för ozonskiktet.
INNEHÅLL
SVENSKA
ANVÄNDANDE AV NY KYLVÄTSKA

1EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
• Ensure that all Local, National and International regulations are satisfied.
• Read this “SAFETY PRECAUTIONS” carefully before Installation.
• The precautions described below include the important items regarding safety. Observe them without fail.
• After the installation work, perform a trial operation to check for any problem. Follow the Owner’s Manual to explain how to use and
maintain the unit to the customer.
• Turn off the main power supply switch (or breaker) before the unit maintenance.
• Ask the customer to keep the Installation Manual together with the Owner’s Manual.
1 SAFETY PRECAUTIONS
CAUTION
New Refrigerant Air Conditioner Installation
• THIS AIR CONDITIONER ADOPTS THE NEW HFC REFRIGERANT (R410A) WHICH DOES NOT DESTROY OZONE
LAYER.
R410A refrigerant is apt to be affected by impurities such as water, oxidizing membrane, and oils because the working pressure of
R410A refrigerant is approx. 1.6 times as that of refrigerant R22. Accompanied with the adoption of the new refrigerant, the
refrigeration machine oil has also been changed. Therefore, during installation work, be sure that water, dust, former refrigerant,
or refrigeration machine oil does not enter the new type refrigerant R410A air conditioner circuit.
To prevent mixing of refrigerant or refrigerating machine oil, the sizes of connecting sections of charging port on main unit and
installation tools are different from those of the conventional refrigerant units. Accordingly, special tools are required for the new
refrigerant (R410A) units as shown on page 23. For connecting pipes, use new and clean piping materials with high pressure
fittings made for R410A only, so that water and/or dust does not enter. Moreover, do not use the existing piping because there are
some problems with pressure fittings and possible impurities in existing piping.
CAUTION
TO DISCONNECT THE APPLIANCE FROM THE MAIN POWER SUPPLY
Disconnection from the supply mains:
The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
WARNING
• Ask an authorized dealer or qualified installation professional to install/maintain the air conditioner.
Inappropriate installation may result in water leakage, electric shock or fire.
• Turn off the main power supply switch or breaker before attempting any electrical work.
Make sure all power switches are off. Failure to do so may cause an electric shock.
• Connect all of the installation wiring correctly.
If the installation wiring is incorrect, electrical parts may be damaged.
• When moving the air-conditioner for installation to another place, be very careful not to allow the specified refrigerant
(R410A) to become mixed with any other gaseous body into the refrigeration circuit. If air or any other gas mixes with the
refrigerant, the gas pressure in the refrigeration circuit will become abnormally high and it may result in the pipe bursting or
personnel injuries.
• Do not modify this unit by removing any of the safety guards or by overriding any of the safety interlock switches.
• Exposure of the unit to water or other forms of moisture before installation may cause a short circuit of the electrical parts.
Do not store it in a wet basement or expose to rain or water.
• The electrical work should be performed by a qualified electrician in accordance with the technical standards for electrical
equipment, internal wiring regulations, and installation manual for the electrical equipment. A dedicated circuit should be
used, and the voltage should match the rated voltage of the product. If the power supply circuit does not have enough
capacity or the work is performed improperly, an electric shock or fire can result.
• Be sure to connect the indoor and outdoor unit wires at their tips. Do not connect the wires below the tips. If the connections
and fixtures are not made properly, overheating or a fire can result.
• Connect the wiring between the indoor and outdoor units so that the cord clamp does not stick out, and attach the covers
properly. If the clamp is not attached properly, the terminal sections can overheat, and a fire or electric shock can result.
• Always use the supplied parts or specified parts for the installation work parts. Usage of different parts can cause the unit to
fall, a water leak, fire, or electric shock.
• After unpacking the unit, examine for possible damage.
• Do not install in a place that might increase the vibration of the unit.
• To avoid personal injury (with sharp edges), be careful when handling parts.
• Perform installation work properly according to the Installation Manual.
Incorrect installation may result in water leakage, electric shock or a fire.

2
EN
• When the air conditioner is installed in a small room, provide appropriate measures to ensure that in the event of a refrigerant
leak the rooms does not exceed the critical level.
• Install the air conditioner securely in a location where the base can sustain the weight of the unit adequately.
• Perform the specified installation work to guard against an earthquake.
If the air conditioner is not installed appropriately, accidents may occur due to the unit falling.
• If refrigerant gas has leaked during the installation work, ventilate the room immediately.
If the leaked refrigerant gas comes in contact with fire, noxious gases may be generated.
• After the installation work, confirm that refrigerant gas does not leak.
If refrigerant gas leaks into the room and flows near a fire source, such as a cooking range, noxious gases maybe generated.
• Use only the specified wiring during the unit installation. Ensure that all terminals are securely fixed, so preventing any
external forces having a negative effect on the terminals.
• Be sure to provide grounding.
Do not connect ground wires to gas pipes, water pipes, lightning rods or ground wires for telephone cables.
• Do not install the air conditioner in a location that maybe subjected to a risk of exposure to a combustible gas.
If a combustible gas leaks and becomes concentrated around the unit, a fire may occur.
• Do not install in locations where the unit will get splashed by water or with high humidity such as bathrooms. This can cause
deterioration of the insulation, resulting in an electric shock or fire.
• Check the following points before starting operation in the installation work.
- The pipes are securely connected and do not leak.
- The service valve is opened.
Operating the compressor while the service valve is closed will result in an abnormally high pressure, and can possibly
damage the compressor and other parts. Also, any leaks in the connections can cause air to be sucked in, resulting in an
even higher abnormally pressure, and can cause a pipe rupture or injury.
• When carrying out the pump-down work, shut down the compressor before disconnecting the refrigerant pipe. Disconnecting
the refrigerant pipe with the service valve left open and with the compressor still operating will cause air, etc. to be sucked in,
raising the pressure inside the refrigeration cycle to an abnormally high level, and possibly resulting in rupturing, injury, etc.
CAUTION
• Wear work gloves when carrying out the installation work or repairs. Contact with parts, etc. may cause injury if the work or
repairs are conducted without wearing gloves.
• Earth leakage breakers are required in certain installation locations. Failure to install the earth leakage breakers can result in
an electric shock.
• The pipes for the drain work should be installed properly in accordance with the installation manual to ensure proper
draining. Failure to install the pipes properly can cause a leak indoors and wet the furniture and other objects in the home.
• Tighten the flare nut with a torque wrench using the specified method. If the flare nut is over-tightened, it can crack over a
long period of time, resulting in a refrigerant leak.
• Do not touch the inlets or aluminum fins of the indoor and outdoor unit. An injury could result.
• Do not install the outdoor unit where small animals typically live. If small animals get inside the unit and touch the electrical
parts, a failure or fire can result. Also, please keep the area around the outdoor unit clear of fallen leaves and other objects.
• After the installation work is completed, perform test operation to check that there is nothing abnormal, and explain to the
customer the operating and cleaning procedures based on the owner's manual. Also, ask the customer to store this
installation manual together with the owner's manual.

3EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
Separate sold parts
• Connecting pipe (Liquid side)
(6.4 mm (diam.), Nominal (diam.) 1/4" thick 0.8 mm)
• Connecting pipe (Gas side)
(9.5 mm (diam.), Nominal (diam.) 3/8" thick 0.8 mm)
RAS-M10SMUV-E, RAS-M10SMUCV-E, RAS-M13SMUV-E, RAS-M13SMUCV-E
(12.7 mm (diam.), Nominal (diam.) 1/2" thick 0.8 mm)
RAS-M16SMUV-E, RAS-M16SMUCV-E
• Power supply cord
2.5 mm2(H07RN-F or 60245IEC66)
• Connecting wire
1.0 mm2(H07RN-F or 60245IEC66)
• Thermal insulation for refrigerant pipe (10 mm or more, thermal insulating foam polyethylene)
• Thermal insulation for drain pipe (10 mm or more, foam polyethylene)
• Drain pipe (Outer 26 mm (diam.))
• Tapes
• Grounding wire (1.6 mm (diam.) or more)
2 ACCESSORY PARTS AND PARTS TO BE PROCURED
LOCALLY
Accessory parts
Part name Q'ty Shape Usage
Installation Manual 1 This manual (Be sure to hand over to customers)
Wireless remote controller 1 —
Remote controller holder 1 —
Mounting screws for remote
controller holder
3.1 mm (diam.) × 16 mm 1—
Batteries (Manganese) 2 —
Heat insulating pipe 2 For heat insulation of pipe connecting section
Installation pattern 1 —For confirmation of ceiling opening and main unit position
Installation gauge 2 For positioning of ceiling position (united with installation
pattern)
Pattern fixing screw 4 M5 × 16L For attach the installation pattern
Heat insulator 1 For heat insulation of drain connecting section
Washer 8 For hanging-down unit
Hose band 1 For connecting drain pipe
Flexible hose 1 For adjusting core-out of drain pipe
Heat insulator A 1 For sealing of wire connecting port
Heat insulator B 1 For sealing of wire connecting port
Owner’s Manual 1 (Be sure to hand over to customers)
Part name Q'ty Shape Usage
Ceiling panel 1 Model: RB-B11MC(W)E
Parts to be procured locally

4
EN
Secure the specified space in the figure for installation and servicing.
Ensure there is sufficient space to install the unit and to perform maintenance work as and when required. Keep 15 mm or more for
clearance between top plate of the indoor unit and the ceiling surface.
Installation space
3 SELECTION OF INSTALLATION PLACE
WARNING
• The air conditioner must be installed in a location that can support the weight of the unit effectively.
If the unit is not installed on a foundation that can support its weight effectively, the unit may fall down, resulting in possible
human injury.
• Where required ensure that the units installation is sufficient enough to withstand against an earthquake.
An insufficient installation could result in the unit falling, causing possible human injury.
• Install the air conditioner at a minimum height of 2.5 m from the floor.
Do not insert your hands or others into the unit while the air conditioner is operating.
CAUTION
Do not install the air conditioner in a location subject to a risk of exposure to a combustible gas.
• If a combustible gas leaks and stays around the unit, a fire may occur.
Upon approval of the customer, install the air conditioner in a place that satisfies the following conditions.
• Place where the unit can be installed horizontally.
• Place where a sufficient servicing space can be ensured for safety maintenance and check.
• Place where drained water will not cause any problem.
Avoid installing in the following places.
• Place exposed to air with high salt content (seaside area), or place exposed to large quantities of sulfide gas (hot spring).
(Should the unit be used in these places, special protective measures are needed.)
• Place exposed to oil, vapor, oil smoke or corrosive gas.
• Place where organic solvent is used nearby.
• Place close to a machine generating high frequency.
• Place where the discharged air blows directly into the window of the neighboring house. (For outdoor unit)
• Place where noise of the outdoor unit is easily transmitted. (When installing the air conditioner on the boundary with the
neighbor, pay due attention to the level of noise.)
• Place with poor ventilation.
(Before air ducting work, check whether value of air volume, static pressure and duct resistance are correct.)
Installation space
15 or more
283 or
more
1000 or
more
15 or more
283 or
more
1000 or more 1000 or more
Obstacle

5EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
In case of continued operation of the indoor unit under high-humidity conditions as described below, dew may condense and water
may drop.
Especially, high-humidity atmosphere (dew point temperature: 23°C or more) may generate dew inside the ceiling.
1. Unit is installed inside the ceiling with slated roof.
2. Unit is installed at a location using inside of the ceiling as fresh air intake path.
3. Kitchen
When installing a unit at such place, put insulating material (glass wool, etc.) additionally on all the positions of the indoor unit, which
contact with high-humidity atmosphere.
ADVICE
Set a service check opening panel at right side of the unit (size: 450 × 450 mm or more) for piping, maintenance, and servicing.
When the height of the ceiling exceeds the distance of the item Standard in Table above, the hot air is difficult to reach the floor.
Therefore, it is necessary to change the setup value of the high ceiling switch. (RAS-M16SMUV-E and M16SMUCV-E only)
When changing the setting of the ceiling height in the models, RAS-M10SMUV-E, M10SMUCV-E, M13SMUV-E and M13SMUCV-E, if
it is set over 2.7 m, the hot air is difficult to reach the floor.
How to set the High ceiling switch
• Remove the cover of the electric parts box by taking off the mounting screws (3 positions) and pushing the hooking section. (The
cover of the electric parts box remains hanged to the hinge.)
• There are the selector switches (SW02) on the P.C. board of the electric parts box.
No.1 and No.2 of the selector switches (SW02) are provided to select the height of the ceiling.
According to the ceiling height in the following table, select No.1 or No.2 of the selector switches (SW02).
REMARK
• When using the high ceiling (1) or (2), cold air may be felt due to the temperature drop of discharge air.
Height list of ceiling possible to be installed
Selection of installation place
Ceiling height
Model RAS- Possible installed ceiling height
M10SMUV-E, M10SMUCV-E, M13SMUV-E, M13SMUCV-E Up to 2.7 m
M16SMUV-E, M16SMUCV-E Up to 3.5 m
Model RAS- M10SMUV-E
M10SMUCV-E M13SMUV-E M13SMUCV-E M16SMUV-E M16SMUCV-E SW02
No.1 No.2
Standard (Factory setting) 2.5 to 2.7 m 2.5 to 2.7 m 2.5 to 2.9 m OFF OFF
High ceiling (1) — — 2.9 to 3.2 m ON OFF
High ceiling (2) — — 3.2 to 3.5 m ON ON

6
EN
• Should be placed where there are no obstacles, such as
curtains, that may block the signal.
• Do not install the remote controller in a place exposed to direct
sunlight or close to a heating source such as a stove.
• Keep the remote controller at least 1 m away from the nearest TV
set or stereo equipment. (This is necessary to prevent image
disturbance or noise interference.)
• The location of the remote controller should be determined as
shown the right.
WARNING
Install the air conditioner certainly to sufficiently withstand the weight.
If the strength is insufficient, the unit may fall down resulting in human injury.
Perform a specified installation work to guard against an earthquake.
An incomplete installation can cause accidents by the units falling and dropping.
Remote controller
4 INSTALLATION OF INDOOR UNIT
WARNING
The installation of the air conditioning unit must be positioned in a location that can sufficiently support its weight and give
protection against adverse environmental conditions. Failure to do so may result in unit damage and possible human injury. Any
incomplete installation may also cause possible risk of human injury.
• Unpack the package, take out the product and then place it on the floor so that the same surface directs underneath as it is
placed in the package.
• Never put the products in a pile or put weight on them, which are taken out from
the packing box; otherwise there is a possibility to damage electric parts, fan
parts, draining mechanism, and etc.
If the both sides are turned over, a deformation of mounting metal of the ceiling
panel which is sold separately, etc. may be caused. Accordingly the product may
be damaged and the installation becomes impossible in some cases.
REQUIREMENT
Strictly comply with the following rules to prevent damage of the indoor units and human injury.
• Do not place heavy objects on the indoor unit. (Even when units are still packaged)
• Always carry the unit as packaged from the factory wherever possible. If carrying in the indoor unit unpacked by necessity,
be sure to use buffering cloth, etc. to prevent damaging the unit.
• To move the indoor unit, hold the hanging brackets (4 positions) only. Do not apply force to other parts (refrigerant pipe, drain
pan, foamed parts, or resin parts etc.).
• To be carried by two or more people. Do not strap the unit in positions other than stated.
Ceiling panel
Remote controller
Sensor part
Signal-receiving range
Ceiling panel base
5morless
NO GOODOK

7EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
Dimensional view
1000 or more
Obstacle
1000 or more
15 or more
595 to 660 Ceiling open dimension
595 to 660 Ceiling open dimension
Knockout for fresh air intake 100 (diam.)
Space required for
installation and servicing
Sensor part
Check port
(!450) Check port
(!450)
Check port
(!450)
Drain-up standing-up size
Stand-up
850 or less
Stand-up
627.5
or less
Indoor unit
Bottom face
of ceiling
Note
As ABS is used for the drain discharge port of the main
unit, the vinyl chlor paste cannot be used.
Use the flexible hose (Band fix) included in the package.
Bottom face
of ceiling
162 (diam.)
For branch duct knockout
square hole 150 (diam.)
575 Unit external dimension
700 Panel external dimension
595 to 660 Ceiling open dimension
525 Hanging bolt pitch
510 Hanging bolt pitch
595 to 660 Ceiling open dimension
700 Panel external dimension
Drain discharge port
Hanging bolt
M10 or W3/8
local arrange
Refrigerant pipe
(Liquid) 6.4 (diam.)
Refrigerant pipe
(Gas) 9.5 (diam.) (RAS-M10SMUV-E, M13SMUV-E,
M10SMUCV-E, M13SMUCV-E)
(Gas) 12.7 (diam.) (RAS-M16SMUV-E, M16SMUCV-E)
For branch duct
knockout square
hole 150 (diam.)
Bottom face of ceiling
575 Unit external dimension
162 (diam.)
Bottom face of
ceiling
Ceiling panel
Wiring connection
port
220.5
145.5
139.5
190.5
97.5
320.5
145.5
368.5
1000 or more
15 or more
Electric parts box
177

8
EN
• Evaluate and determine the piping and wiring requirements inside the ceiling prior to the hanging of the unit.
• After installation place of the indoor unit has been determined, create opening in ceiling and install the hanging bolts.
• For the ceiling opening size and pitch for hanging bolts refer to the dimensional drawing and the supplied installation pattern.
• Once the ceiling void has been created, ensure that the drain pipe, refrigerant pipes, inter-connecting wires and all control wires are
in place prior to installing the actual indoor unit.
Please procure the hanging bolts and nuts for installation of
the indoor unit at local site.
How to use the supplied installation pattern
The installation pattern is enclosed within the packaging of the air conditioner.
Existing ceiling void
Use the pattern to determine the position and size of the opening and location of
the hanging bolts.
New ceiling void
Use the pattern to determine the position of the new ceiling opening. Cut off slit
section of the main unit of the installation pattern.
Cut off the outside of the pattern according to size of the ceiling opening. (There is
a slit on the standard opening size section.)
• Install the indoor unit after installation of the hanging bolts.
• Using the supplied pattern attach it to the indoor unit using the supplied fixing
screws (M5 × 16L 4 pieces). (Screw pattern to the ceiling panel hanging
brackets of the indoor unit)
• When creating the opening ensure it is as per the outer dimensions of the
supplied pattern.
Treatment of ceiling
The ceiling differs according to the structure of the building. For details, consult your architect.
In the process after the ceiling panels have been removed, it is important to reinforce the ceiling construction and ensure the ceiling
remains in a horizontal position. This is to prevent possible vibration of the ceiling panels.
1. Cut and remove the ceiling material.
2. Reinforce the cut surface of the ceiling construction and add support for fixing the end of ceiling panel.
Ceiling opening and installation of hanging bolts
Opening a ceiling and installation of hanging bolts
Hanging bolt M10 or W3/8 4 pieces
Nut M10 or W3/8 12 pieces
Indoor unit
Installation pattern
(Attached)
M5 × 16L screws (Attached)
(These screws are exclusive to the
installation pattern. When installing the
ceiling panel, the other exclusive
screws attached to the ceiling panel
(sold separately) are used.)
Cut off the installation
pattern along slit of the
main unit.

9EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
Installation of hanging bolt
Use M10 hanging bolts (4 pieces, locally procured).
When mounting the unit, set the pitch of the hanging bolts according to the size of the unit as detailed on the dimensional drawing.
New concrete slab
Install the bolts with insert brackets or anchor bolts.
Steel flame structure
Use existing angles or install new support angles.
Existing concrete slab
Use a hole-in anchors, hole-in plugs, or a hole-in bolts.
• Attach the nut (M10 or W3/8: Procured locally) and washer (34 mm
(diam.)) to the hanging bolt.
• Put washers at either side of the T-groove on the hanging bracket of the
indoor unit in order to hang the unit.
• Using a spirit level, check that all four sides are horizontal. (Horizontal
positioned within 5 mm)
• Cut off the installation gauge from the installation pattern.
• Using the installation gauge, check and adjust clearance between the
indoor unit and the ceiling opening (1) (10 to 42 mm on each side).
Ensure that the unit is level to the ceiling and within a distance of (2) 23 mm
to 28 mm below.
The installation gauge has details of how to use printed on it.
NOTE
Install the indoor unit so that the end part of opening does not come into contact with the drain socket piping.
Installation of indoor unit
(Blade type bracket) (Slide type bracket) (Pipe hanging anchor bolt)
Reinforcing steel
Anchor bolt
Hanging bolt Support angle
Hanging bolt
Hanging bolt
(W3/8 or M10) (1)
M10 flat washer
(Accessory)
(2)
M10 flat washer
(Accessory)
Nut
(W3/8 or M10)
Nut
(W3/8 or M10)
(1) M10 washer supplied, all other material must
be procured locally.
(2) To ensure that the unit is mounted safely, the
hanging bolt must be positioned just below
the hanging bracket as shown in the diagram.
Level vial (Horizontal: within 5 mm)
Hanging bolt
Indoor unit
Ceiling board
23 to 28 mm (2)
Hanging
metal
10 to 42 mm (1)
Installation gauge
Indoor unit
Ceiling board Installation
gauge 10 to 42 mm (1)
23 to 28 mm (2)

10
EN
Install the ceiling panel after completion of the installation of the indoor unit, including all piping and wiring.
Install the ceiling panel as per the supplied Installation Manual.
Check the installation dimensions of the indoor unit and the ceiling opening are correct and then install.
REQUIREMENT
Before installation of the indoor unit be sure to remove the transportation cushion found between the fan and the bell mouth.
Running the unit without removing the cushion may damage the fan motor.
Installation of ceiling panel (Sold separately)
REQUIREMENT
Ensure the ceiling panel is mated to the ceiling surface or the indoor unit.
If the panel and unit are not mated together this may result in the formation of dew condensation causing a possible water leak.
First remove the 4 corner caps from the ceiling panel and fit to the indoor unit.
Be sure to remove the cushion for transportation
between the fan and the bell mouth.

11 EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
The following materials for piping work and insulation are to be procured locally.
5 DRAIN PIPING WORK
CAUTION
• Install the drain piping so that the water drains effectively.
• Apply heat insulation to prevent dew condensation from forming.
• Incorrectly installed pipework may result in a water leak.
Pipe material/Insulator and size
Pipe material Hard vinyl chloride pipe socket for VP25
Hard vinyl chloride pipe VP25 (Outer diameter 32 mm (diam.))
Insulator Foamed polyethylene foam, thickness: 10 mm or more
REQUIREMENT
• Ensure insulating of the drain pipes and connecting parts on the indoor units.
• The drain pipe should have a downward slope of at least 1/100 and ensure
there are no swells or blockages as this will cause abnormal sounds.
• The maximum traverse length of drain pipe is 20 m. Provide support brackets
at intervals of 1.5 to 2 m where necessary to prevent movement.
• Install the combined piping as shown in the illustration.
• Do not create an air purge in the pipework, as the water would leak from this
point.
• The hard vinyl-chloride pipe cannot be connected directly to the
drain pipe connecting port of the indoor unit. For connection with
the drain pipe connecting port, ensure that the supplied flexible
hose is fitted.
• Adhesive agent cannot be used for the pipe connecting port (hard
socket) on the indoor unit. Be sure to use the supplied hose band
for fixing, otherwise there is a risk of damage or water leakage
from the drain pipe connecting port.
1.5 m to 2 m
Heat insulator 1/100 or more
downward
Support
bracket
Trap
Arched
shape NO
GOOD
As long as possible (10 cm)
(Collective pipes)
VP30 or more Downward slope
1/100 or more
Drain pipe connecting port
(Hard socket)
Adhesive agent prohibited
VP25 vinyl
chloride pipe
(Procured locally)
Attached hose band Attached hose band
Soft socket Hard socket Socket for VP25
(Procured locally)

12
EN
• Insert the soft socket of the supplied flexible hose into the connecting port of the drain pipe.
• Align the supplied hose band to the pipe connecting port end, and tighten.
• Connect the hard socket (Procured locally) to the hard socket side of the supplied flexible hose which has been installed.
• Connect the drain pipes (Procured locally) in turn to the connected hard sockets.
Connection of flexible hose
REQUIREMENT
• Fix the soft socket with the supplied hose band, tighten at the upper position of the unit.
• The supplied flexible hose can bend up to a maximum of 45°.
Connection of drain pipe
REQUIREMENT
• Using a adhesive agent for vinyl chloride, connect the hard vinyl chloride pipes so that water does not leak.
• Allow sufficient time for the adhesive to set and harden. (Refer to the instructions of the adhesive.)
NO GOOD
OK
max
45°
max
45°
Riser (Trap)
90° Bend Socket for VP25 vinyl chloride pipe
(Local procure)
VP25 vinyl chloride
pipe (Local procure)
Flexible hose
(Accessory)
Align the attached hose band to the
end of hose, set the tightening position
upward, and then tighten it.
Drain pipe
connecting port
(Transparent)
Indoor unit body

13 EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
When it is not possible to achieve a natural downward slope on the
drain pipe, you can create a vertical lift (Drain up) on the pipe.
• Set the height of the drain pipe within 850 mm from the bottom
surface of the ceiling.
• The drain pipe should be piped from the drain pipe connecting
port horizontally for a maximum of 300 mm and then piped
vertically.
• After piping the vertical lift, ensure the pipework is set to a
downward gradient.
After completion of drain piping, check water drains away and that no water leaks from any of the connecting parts. At the same time
check for any abnormal sounds from the drain pump.
Ensure drainage is checked during cooling mode.
When the electric work has finished:
• Before installing the ceiling panel, pour water as shown in the following figure, check water drains from the drain pipe connecting
port (Transparent) in COOL mode and then check there are no water leaks from the drain pipes.
When the electric work has not finished:
• Pull out the float switch connector (3P: Red) from P.C. board
connector (CN34: Red) of the electric parts box. (Ensure the
power is turned off.)
• Connect the single-phase 220-240V, 1N, 50 Hz power to the
terminal blocks (1) and (2).
• Pour water referring to the figure. (Amount: 1500 cc to 2000 cc)
• When the power is turned on, the drain pump motor drives
automatically.
Check water is drained from the drain pipe connecting port
(Transparent), and then check there is no water leak from the
drain pipes.
• After checking for water leaks on the drain, turn off the power
supply, and re-attach the float switch connector to the original
position (CN34) on the P.C. board and refit the electric parts box.
Drain up
Check the draining
Indoor unit
300mm or
less
Underneath of ceiling
Rising up
850mm or less
Risingup
627.5mm
or less
Black
Pull out connector CN34 (Red) from P.C. board.
Black
CN34
(RED) Black
White
Power supply
terminal block
220–240V, 1N ~, 50Hz

14
EN
• After checking the draining, wrap the supplied thermal insulation
material for the drain connecting part around the flexible hose
leaving no clearance from the root of the drain pipe connecting
port of the indoor unit.
• Wrap the thermal insulation material (procured locally) around
the drain pipe so that it piles up on the supplied the thermal
insulation material for the drain connecting part, leaving no
clearance.
Thermal insulating process
CAUTION
Ensure water is poured slowly.
If water is poured vigorously, it is scattered inside of the indoor unit resulting in a cause of unit trouble.
Flexible hose
Attached heat insulator
Hose band
Heat insulator to be
procured locallyHard vinyl chloride pipe
Drain pan
Air discharge
area
Check panel
Insert the leading part of
the hose between the
heat exchanger and the
drain pan, and then bend
it downward.
Polyethylenehandpump for
pouring water in drain pan
Vessel Water (1500cc to 2000cc)

15 EN
ENGLISHFRANÇAISDEUTSCHITALIANOESPAÑOLΕΛΛΗΝΙΚΗPORTUGUÊS###SW######RU###
1. If the outdoor units are to be mounted on a wall, make sure that the supporting platform is sufficiently strong. The platform should
be designed and manufactured to maintain its strength over a long period of time, and sufficient consideration should be given to
ensuring that the outdoor unit will not fall.
2. Use copper pipe with 0.8 mm or more thickness.
3. Flare nut and flare works are different from those of the conventional refrigerant.
Take out the flare nut attached to the main unit of the air conditioner, and use it.
They vary according to the outdoor unit.
For details, refer to the Installation Manual attached to the outdoor unit.
Flaring
Insert a flare nut into the pipe, and flare the pipe. As the flaring sizes of R410A differ from those of refrigerant R22, the flare tools
newly manufactured for R410A are recommended.
However, the conventional tools can be used by adjusting projection margin of the copper pipe.
• Projection margin in flaring: B (Unit: mm)
Rigid (Clutch type)
Imperial (Wing nut type)
• Flaring diam. meter size : A (Unit: mm)
* In the case of flaring for R410A with the conventional flare tool, pull it approx. 0.5 mm further out than that for R22 to adjust to the
specified flare size. The copper pipe gauge is useful for adjusting the projection margin size.
6 REFRIGERANT PIPING AND EVACUATING
Refrigerant piping
CAUTION
IMPORTANT 4 POINTS FOR PIPING WORK
1. Remove dust and moisture from the inside of the connecting pipes.
2. Tight connection (between pipes and unit)
3. Evacuate the air in the connecting pipes using VACUUM PUMP.
4. Check the gas leakage. (Connected points)
Permissible piping length and heat
Outer diameter of copper pipe R410A tool used Conventional tool used
R410A R22 R410A R22
6.4 0 to 0.5 (Same as left) 1.0 to 1.5 0.5 to 1.0
9.5 0 to 0.5 (Same as left) 1.0 to 1.5 0.5 to 1.0
12.7 0 to 0.5 (Same as left) 1.0 to 1.5 0.5 to 1.0
Outer diameter of copper pipe R410A R22
6.4 1.5 to 2.0 1.0 to 1.5
9.5 1.5 to 2.0 1.0 to 1.5
12.7 2.0 to 2.5 1.5 to 2.0
Outer diameter of copper pipe A
R410A R22
6.4 9.1 9.0
9.5 13.2 13.0
12.7 16.6 16.2
+0
–0.4

16
EN
Tightening connection
(Unit: N·m)
• Tightening torque of flare pipe connections.
Pressure of R410A is higher than that of R22. (Approx. 1.6 times) Therefore, using a torque wrench, tighten the flare pipe
connecting sections which connect the indoor and outdoor units of the specified tightening torque. Incorrect connections may cause
not only a gas leak, but also a trouble of the refrigeration cycle.
Align the centers of the connecting pipes and tighten the flare nut as far as possible with your fingers. Then tighten the nut with a
spanner and torque wrench as shown in the figure.
CAUTION
• Do not apply excessive torque. Otherwise, the nut may crack depending on the conditions.
Outer diameter of copper pipe Tightening torque
6.4 mm (diam.) 14 to 18 (1.4 to 1.8 kgf·m)
9.5 mm (diam.) 33 to 42 (3.3 to 4.2 kgf·m)
12.7 mm (diam.) 50 to 62 (5.0 to 6.2 kgf·m)
Flare at indoor
unit side
Flare at outdoor unit
side
Half union Flare nut
Externally threaded side
Use a wrench to secure.
Internally threaded side
Use a torque wrench to tighten.
