Challenger SLDC2 User manual

SLDC2 User Guide Issue 1.0 Page No. 2
The SLDC2
This innovative self contained video and photo system will automatically
record images when movement is detected.
With its powerful floodlight, the SL DC2 works day and night, giving you
peace of mind and protection for your property.
SLDC2 camera unit.
Shown without floodlight fitted.

Page No. 3 SLDC2 User Guide Issue 1.0
Everything in the box?
SLDC2
Box contents
SLDC2 Digital Security Video Light
H alogen bulb
U SB lead for PC connection
SD memory card
Mounting screws
Warning sticker
If you are missing an item please contact your retailer .
IMPORTANT
The SLDC2 is designed for external use only
We recommend before installing your SLDC2 into position that you read
the full user guide to familiarise yourself with the controls, the
operation and settings before you mount the unit.

SLDC2 User Guide Issue 1.0 Page No. 4
Get to know your equipment

Page No. 5 SLDC2 User Guide Issue 1.0
Applications
The SLDC2 automatically records digital photos and videos when
movement is detected. It is a great way to protect your property and
record evidence of trespassers or unwanted visitors, day or night.
With a SLDC2 you can protect : -
Cars and driveways
Factories and offices
Homes and gardens
Sheds and garages
Outbuildings
Farms and yards
Stab les and livestock
Building sites
Remote locations
Halls and club houses
Using the web cam feature, the SLDC2 can also be used for general
observation or for monitoring wildlife in your garden.

SLDC2 User Guide Issue 1.0 Page No. 6
INDEX
SLDC2 Quick start guide 8
SLDC2 Full u ser guide
Understanding your SLDC2 15
How it works 16
Basic operation
SD Memory card 18
Recording format 19
Floodlight light level 20
Floodlight on time 21
Arming period 21
USB connection 22
SLDC2 mounting and the movement sensor 24
Advanced settings and functions 27
Menu structure
Main Setup 28
Menu structure
Image Setup 29
Main Setup Menu 30
Memory 31
Time / Date 32
Floodlight 34
Flicker 34
LED 35
PIR delay 35
USB 36
Default 37

Page No. 7 SLDC2 User Guide Issue 1.0
INDEX continued
Image Setup Menu
Image mode 38
Photo setup 39
Resolution 39
Burst Mode 39
Burst Delay 40
Video Setup 41
Duration 41
Audio 41
Versatile image capture options 42
Understanding digital images 43
Digital video 43
Digital photos 44
SD card speed 48
Photo burst 48
Using your SLDC2 with a PC 49
Camera driver 49
Recor ding and uploading to the web 50
Your suggestions 51
Other Challenger products 51
Features and specifications 52
General information and safety 53
CE, ROHS and WEEE 54
Product support Back cover

SLDC2 User Guide Issue 1.0 Page No. 8
SLDC2 q uick start guide
Your SLDC2 has been designed to be quick and easy to setup and operat e
with factory settings that should suit most applications.
By default, when it detects movement, your SLDC2 will automatically
record 2 photographs followed by a 30 second video clip .
You can change these settings via the easy to use menu.
Please refer to the full guide for more information.
Basic s etup is as easy as A,B,C.
A. Fit the SD card and po sition the unit.
F it the SD card into the slot
provided. Ensure you insert
the card with the metal
contact end in first and with
these contacts facing the
front (camera end ) of the
unit.
The card should click into
place.

Page No. 9 SLDC2 User Guide Issue 1.0
Carefully and without touching the glass of the bulb fit the halogen bulb
ensuring you secure the floodlight glass cover afterwards.
NOTE: Halogen bulbs get very hot and contamination from your skin can
cause the glass to break during operation.
We recommend positioning the unit bet ween 3m and 4m on a sound wall
and angled towards the area of interest so that most traffic crosses the
PIR zones and triggers your SLDC2 to start recording.
Good results can also be obtained by positioning the SLDC2 higher and
facing down to the area of interest
See the section SLDC2 mounting and the movement sensor for details.
You can replace an existing outside light or undertake a new installation.

SLDC2 User Guide Issue 1.0 Page No. 10
B. Connect the mains supply.
Your SLDC2 requires mains power which should already be in place, i f
not you will need to arrange for a competent and qualified person to
install the necessary cabling.
We recommend you use a switched circuit and that power is turned off
during installation.
Observe correct wiring
failure to do so will damage the unit and will
invalidate your warranty.

Page No. 11 SLDC2 User Guide Issue 1.0
C. Set the time and date
Tu rn on the power. The floodlight will come on for a short time. The LED
will flash rapidly as the SLDC2 arms. When this flashing stops, the SLDC2
will be ready to record when ever movement is detected
day or night.
Try to return to your SLDC2 without triggering the motion sensor .
NOTE: You can only access the menu when the unit is not recording.
Below is the Normal screen o f your SLDC2 display . It show s the software
ver sion, the number of recordings, the Imag e Mode and the Photo
Resolution.
To access the menu, press the menu key,
the
display will light up and will show: -
NOTE: When in a menu, if you do nothing for 20 seconds the software
will return to the n ormal screen.
