Challenger SMART FORCE ASFCAM3 User manual

1
Installation Instructions
General Introduction
The IP Camera is compatible with the SmartForce system designed to monitor
an outdoor area where it can send video images to the server. The recording
function will be activated if an event is triggered under warning conditions.
Product Overview
Description of Cables Connectors:
Binding with SmartForce Hub
1. - Connect an Ethernet cable direct to the router than has internet access
- Plug in 12V DC PSU to the DC power Connector
2. Log into the SmartForce account from a web browser (not APP).
3. Select “System”, then “Add a device”.
ASFCAM3
1080P Outdoor Wireless IP Camera
Camera
lens
IR LED
LED
indicator
Ethernet
connector
DC Power
connector
Reset wires

2
4. Select “Camera”.
5. Enter the Access Code on the label behind the camera and click “Next step”
6. The screen below will appear. Switch the power off to the camera for 10 secs
and then turn power back on again. The binding is complete.
Operation
Live video
1. To watch live video of the camera, go to LIVE, and click on any image.
2. Click the snapshot image to view live view images.
Playback Recorded Videos
1. To display recorded videos, go to VIDEO page. All videos are displayed with
recording date and video duration.
2. Click on any image to play the video.
3. During playback, it is possible to move forward and back the video by
dragging the time bar, change volume level, and display in full screen.

3
4. To download a copy of the video this can only be completed via a Web
browser, click “Download Video”
Setting up The camera for Wi-Fi
The camera connects to Wi-Fi by scanning the QR on the App.
Preparing the QR Code
1. On the SmartForce App, go to System page and tap the QR code icon on
the top bar.
2. Enter your home Wi-Fi network and your Wi-Fi password.
3. The App will then generate a large size QR code image. Leave the App on
that page.
Setting the Camera
4. Unplug both the power and Ethernet cable from the camera.
5. Plug back only the power connector, leaving the Ethernet cable
disconnected.
6. The camera will power on, followed by flashing red LED.
7. After one minute the LED will flash blue rapidly, this means the camera is
waiting to scan a QR code.
8. Place the QR code created earlier by the App at about 10~15cm in front of
the camera lens.
9. If the scan is successful, the LED will flash blue slowly indicating QR scan is
successful.
Note: If the camera does not respond from scanning after 30 seconds, try
moving the smartphone further away from the camera in gradual steps.
10. The camera will attempt to connect to the Wi-Fi network. You can check
the status from the LED indicator on the camera:
Status LED Colour
Connecting to Wi-Fi Flashing Blue LED slowly
Wrong Wi-Fi password Flashing Purple LED
Scanning QR code… Flashing Blue LED rapidly
No network connection Flashing Red LED
11. Once the Wi-Fi connection is successful, the camera LED colour will
indicate the Wi-Fi signal strength for one minute the LED will turn off:

4
12. The LED will turn off after one minute after connection to the Wi-Fi.
Mounting the Camera
The camera can be wall or ceiling mounted.
1. Select an appropriate location for the camera:
- Place the camera at least 1m away from surrounding metalwork which can
affect the Wi-Fi transmission (it may be worth checking the Wi-Fi signal using
a mobile phone prior to installing).
- Do not install the device near fire or heat sources to avoid damage.
- Do not install the device at humid places
2. Loosen the joint lock and use supplied screw and wall plugs to secure the
camera in place.
3. Adjust the viewing angle of the camera , then rotate to fasten the joint
lock.
Troubleshooting
The below table lists some possible causes and solutions.
Symptom
Possible Cause
Recommendation
The LED never turns
ON
There is no power
or not connected
correctly.
Check the camera’s connection to
the power adapter and ensure
correct polarity.
Unable to connect to
Wi-Fi network.
1. Wi-Fi password
error
2. Unknown Wi-Fi
issue.
1. Create a new QR code and try
again. Before retrying, power off
and power on the camera.
2. Move the camera near the Wi-Fi
router.
3. Connect an Ethernet cable to the
internet to verify the connection
works properly.
Cannot play the live
video from the camera
Wi-Fi network is
out of range
Change the mounting location of
camera
Local internet
upload speed not
enough
Each camera requires at least
512kbit upload speed.
Need to connect to
another Wi-Fi network
N/A Reset the camera.
Reset camera
Resetting the camera will delete its Wi-Fi settings, this may be required as an
example, if you have moved home or changed your broadband router.
1. Power on the camera.
2. Connect the two wires labeled “RESET” and “GND” together (you may have
to strip some of the wire insulation off).
3. The LED will start flashing red-blue alternately. Disconnect the wires (ensure
the wires are insulated so they cannot accidentally short together.
4. The camera will restart.
5. If you want to register the camera to a different SmartForce account, then
please delete the camera from the SmartForce account via a web browser or
APP before you reset the camera.
Signal strength: LED Colour
Strong Constant Blue LED
Normal Constant Purple LED
Weak Constant Red LED

5
LED indication summary
LED Colour Status
Flashing Red No network connection
Flashing Blue & Red Resetting camera
Flashing Blue slowly Connecting to Wi-Fi
Flashing Purple Wrong Wi-Fi password
Flashing Blue Setting camera…
Wi-Fi strength indicator:
LED Colour Signal strength
Blue light Strong
Purple light Normal
Red light Weak
Note: This is displayed only for one minute after successful connection to Wi-Fi.
Specifications
Max. Image resolution 1920 x 1080 (1080P)
Encryption H.265
View angle 89°(H), 46°(V), f3.6mm
IR LED range Up to 25m
Power supply DC adaptor,12V 1A
Wi-Fi protocol Wi-Fi 802.11 b/g/n 2.4GHz
Operating Humidity <90% RH
Operating Temperature: 0°C - +40°C
IP Rating: IP66
Dimensions: 72×72×118mm
Environment:
Please do not dispose the packaging as unsorted waste, use the recycling facilities
provided by your local authorities. When the camera comes to the end of its life or you
choose to update or upgrade by replacing it, then do not dispose with your normal
household waste. Please recycle where facilities exist.
When you need to dispose of this fitting, check with your retailer or local authority for
suitable options.
Due to our policy of continuous improvement we reserve the right to change specification
without prior notice. Errors and omissions excepted. These instructions have been
carefully checked prior to publication. However, no responsibility can be accepted by
Challenger for any misinterpretation of these instructions.
