Chamberlain 2110 1/3 HP User manual

The Chamberlain Group, Inc.
845 Larch Avenue
Elmhurst, Illinois 60 26- 96
www.liftmaster.com
GARAGE DOOR OPENER
Model 2110 1/3 HP
2220 1/2 HP
2220-267 1/2 HP
For Residential Use Only
®
Owner’s Manual
■Please read this manual and the enclosed safety materials carefully!
■Fasten the manual near the ara e door after installation.
■The door WILL NOT CLOSE unless the Protector System®is connected and
properly ali ned.
■Periodic checks of the opener are required to ensure safe operation.
■The model number label is located on the front panel of your opener.

2
Introduction Pages 2-5
Safety symbol and signal word review........................2
Preparing your garage door ........................................3
Tools needed ...............................................................3
Planning .....................................................................4
Carton inventory ..........................................................5
Hardware inventory .....................................................5
Assembly Pages 6-7
Fasten rail to the motor unit ........................................6
Install the trolley ..........................................................6
Attach the rail brackets................................................7
Installation Pages 7-23
Installation safety instructions .....................................7
Determine the header bracket location....................8-9
Install the header bracket.......................................... 0
Attach the rail to the header bracket .........................
Install the Protector System®................................ 2- 4
Position the opener ................................................... 5
Hang the opener ....................................................... 6
Install the door control............................................... 7
Install the lights ........................................................ 8
Attach the emergency release rope and handle ....... 8
Electrical requirements.............................................. 9
Complete safety reversing sensor installation .......... 9
Fasten the door bracket .......................................20-2
Connect the door arm to the trolley .....................22-23
Adjustment Pages 24-26
Adjust the travel limits ...............................................24
Adjust the force .........................................................25
Test the safety reversal system.................................26
Test the Protector System®........................................26
Operation Pages 27-30
Operation safety instructions.....................................27
Using your garage door opener ................................27
Using the wall-mounted door control ........................28
To open the door manually........................................28
Care of your garage door opener..............................29
Having a problem?...............................................29-30
Programming Pages 31-32
To add a hand-held remote control ...........................3
To erase all codes .....................................................3
3-Channel remotes....................................................3
To add or change a Keyless Entry PIN .....................32
Repair Parts Pages 33-34
Rail assembly parts...................................................33
Installation parts ........................................................33
Motor unit assembly parts .........................................34
Accessories 35
Repair Parts and Service 36
Warranty 36
TABLE OF CONTENTS
When you see these Safety Symbols and Signal
Words on the following pages, they will alert you to
the possibility of serious injury or death if you do
not comply with the warnings that accompany them.
The hazard may come from something mechanical
or from electric shock. Read the warnings carefully.
When you see this Signal Word on the following
pages, it will alert you to the possibility of damage to
your garage door and/or the garage door opener if
you do not comply with the cautionary statements
that accompany it. Read them carefully.
INTRODUCTION
Safety Symbol
and Signal Word Review
This garage door opener has been designed and tested to offer safe service provided it is installed, operated,
maintained and tested in strict accordance with the instructions and warnings contained in this manual.
Mechanical
Electrical
WARNING
CAUTION WARNING
WARNING
WARNING
CAUTION WARNING
WARNING
WARNING
CAUTION
WARNING
WARNING

3
To prevent damage to garage door and opener:
• ALWAYS disable locks before installing and operating
the opener.
• ONLY operate garage door opener at 20V, 60 Hz to
avoid malfunction and damage.
To prevent possible SERIOUS INJURY OR DEATH:
• ALWAYS call a trained door systems technician if
garage door binds, sticks, or is out of balance. An
unbalanced garage door may not reverse when
required.
• NEVER try to loosen, move or adjust garage door, door
springs, cables, pulleys, brackets or their hardware, all
of which are under EXTREME tension.
• Disable ALL locks and remove ALL ropes connected to
garage door BEFORE installing and operating garage
door opener to avoid entanglement.
Preparing your garage door
Before you begin:
• Disable locks.
• Remove any ropes connected to garage door.
•Complete the followin test to make sure your
garage door is balanced and is not sticking or
binding:
. Lift the door about halfway as shown. Release
the door. If balanced, it should stay in place,
supported entirely by its springs.
2. Raise and lower the door to see if there is any
binding or sticking.
If your door binds, sticks, or is out of balance, call a
trained door systems technician.
WARNING
CAUTION WARNING
WARNING
WARNING
CAUTION
WARNING
WARNING
Sectional Door
One-Piece Door Tools needed
During assembly, installation and adjustment of the
opener, instructions will call for hand tools as
illustrated below.
Pliers
Wire Cutters
Claw Hammer
Hack Saw
Screwdriver Adjustable End Wrench
/2" and 7/ 6" Sockets
and Wrench
Drill
Tape Measure
2
Stepladder
Pencil
3/ 6", 5/ 6" and
5/32" Drill Bits
Carpenter's
Level

Safety
Reversing Sensor
Horizontal and vertical reinforcement
is needed for lightweight garage doors
(fiberglass, steel, aluminum, door with
glass panels, etc.). See page 20 for details.
FINISHED CEILING
Support bracket &
fastening hardware
is required.
See page 6.
— — — — — — — —
Door
Center
Header Wall
Safety
Reversing Sensor
Extension Spring
OR Torsion Spring
Motor unit
Wall-mounted
Door Control
Rail
Access Door
Gap between floor
and bottom of door must not exceed /4"
4
SECTIONAL DOOR INSTALLATION
Planning
Identify the type and height of your garage door. Survey your garage area to see if any of the conditions below
apply to your installation. Additional materials may be required. You may find it helpful to refer back to this page
and the accompanying illustrations as you proceed with the installation of your opener.
Safety Reversing Sensor
FINISHED CEILING
Support bracket &
fastening hardware
is required. See page 6.
Safety Reversing
Sensor
Header Wall
Access Door
Gap between floor
and bottom of door must not exceed /4"
Motor unit
Wall-mounted
Door Control
Rail
ONE-PIECE DOOR WITHOUT TRACK
Access
Door
Safety
Reversing Sensor
Safety
Reversing Sensor
Gap between floor
and bottom of door must not exceed /4"
ONE-PIECE DOOR WITH TRACK

5
Straight Door
Arm Section
Curved Door
Arm Section
Safety Labels
and
Literature
Header Bracket
UP
CEILING MOUNT ONLY
2 Conductor Bell Wire
White & White/Red
Remote Control
Transmitter Visor Clip
Door Bracket
SECURITY✚
3-Channel Remote Control
Multi-Function
Door Control Panel
LOCK
LIGHT
(2) Safety Reversing Sensors
( Sending Eye and Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
Safety Sensor
Bracket (2)
Lighted
Door Control Button
SECURITY✚
Single-Function Remote Control
Rail
Rail Brackets
Light Lens
Sprocket Coupling
Trolley
Models 2220, 2220-267 Model 2 0 Model 2 0 ( )
Models 2220 ( ), 2220-267 (2)
SECURITY✚ Keyless Entry
Model 2220-267 only
Your garage door opener is packaged in two cartons
which contain the motor unit and all parts illustrated
below. Accessories will depend on the model
purchased. If anything is missing, carefully check the
packing material. Parts may be stuck in the foam.
Hardware for installation is also listed below.
Carton Inventory
RAIL ASSEMBLY
Coupling Sleeve ( )
Hex Bolt /4"-20 x 5/8" (4)
Nut /4" - 20 (4)
INSTALLATION HARDWARE
Hex Bolt 5/ 6"- 8x7/8" (4)
Lag Screw 5/ 6"-9x -5/8" (2)
Lag Screw 5/ 6"- 8x -7/8" (2)
Clevis Pin 5/ 6"x2-3/4" ( )
Clevis Pin 5/ 6"x - /4" ( )
Clevis Pin 5/ 6"x " ( )
Nut 5/ 6"- 8 (4)
Lock Washer 5/ 6" (4)
Screw 6ABx - /4" (2)
Screw 6-32x " (2)
Self-Threading Screw /4"- 4x5/8" (2)
Insulated Staples (30)
Ring Fastener (3)
Dry Wall Anchors (2)
Carriage Bolt /4"-20x /2" (2)
Wing Nut /4”-20 (2)
Rope
Handle

6
ASSEMBLY STEP 1
Fasten the Rail to the Motor Unit
To avoid installation difficulties, do not run the
ara e door opener until instructed to do so.
• Working on a level surface, align the rail assembly
with the motor unit, as shown.
• Slip the coupling over the rail sprocket.
• Slide the rail through the motor unit bracket until
the coupling fits securely over the motor unit
sprocket.
• Align the two bolt holes in the rail with those in the
motor unit bracket. Insert two /4"-20x5/8" hex
bolts and lock nuts. Tighten securely with a 7/ 6"
socket wrench.
ASSEMBLY STEP 2
Install the Trolley
• Slide the trolley onto and along the bottom of the
rail until it snaps firmly in place. Be certain to
install it facin correctly: the trolley release
arm must be horizontal (lock position), with its
arrow pointed away from the motor unit.
Rail
Sprocket
Rail
Assembly
Trolley
Coupling
Motor Unit
Bracket
Lock Nuts
/4"-20
Motor Unit
Sprocket
Foam Packaging
Hex Bolts
/4"-20x5/8"
Release arm
Arrow must point
toward garage door
Lock Nut
/4" - 20
Hex Bolt
/4" - 20 x 5/8"
HARDWARE SHOWN ACTUAL SIZE

7
ASSEMBLY STEP 3
Attach the Rail Brackets
• Align rail brackets to end of rail assembly, as
shown.
• Insert two /4"-20 x 5/8" hex bolts and lock nuts.
Tighten securely with a 7/ 6" socket.
You have now finished assembling your garage
door opener. Please read the following warnings
before proceeding to the installation section.
Rail
Brackets
Rail
Lock Nuts
/4"-20
Hex
Bolts
/4"-20x5/8
IMPORTANT INSTALLATION INSTRUCTIONS
. READ AND FOLLOW ALL INSTALLATION WARNINGS
AND INSTRUCTIONS.
2. Install garage door opener only on properly balanced
and lubricated garage door. An improperly balanced
door may not reverse when required and could result in
SEVERE INJURY or DEATH.
3. All repairs to cables, spring assemblies and other
hardware MUST be made by a trained door systems
technician before installing opener.
4. Disable all locks and remove all ropes connected to
garage door before installing opener to avoid
entanglement.
5. Install garage door opener 7 feet or more above floor.
6. Mount emergency release handle 6 feet above floor.
7. NEVER connect garage door opener to power source
until instructed to do so.
8. NEVER wear watches, rings or loose clothing while
installing or servicing opener. They could be caught in
garage door or opener mechanisms.
9. Install wall-mounted garage door control:
• within sight of the garage door
• out of reach of children at minimum height of 5 feet
• away from all moving parts of the door.
0. Place entrapment warning label on wall next to garage
door control.
. Place manual release/safety reverse test label in plain
view on inside of garage door.
2. Upon completion of installation, test safety reversal
system. Door MUST reverse on contact with a one-
inch high object (or a 2x4 laid flat) on the floor.
To reduce the risk of severe injury or death:
WARNING
CAUTION WARNING
WARNING
INSTALLATION
Lock Nut
/4" - 20
Hex Bolt
/4" - 20 x 5/8"
HARDWARE SHOWN ACTUAL SIZE

8
INSTALLATION STEP 1
Determine the Header Bracket
Location
Installation procedures vary according to garage door
types. Follow the instructions which apply to your
door.
SECTIONAL DOOR
AND ONE-PIECE DOOR WITH TRACK
. Close the door and mark the inside vertical
centerline of the garage door.
2. Extend the line onto the header wall above the
door.
You can fasten the header bracket within 4 feet
of the left or ri ht of the door center only if a
torsion sprin or center bearin plate is in the
way; or you can attach it to the ceilin (see
pa e 10) when clearance is minimal. (It may be
mounted on the wall upside down if necessary,
to ain approximately 1/2".)
If you need to install the header bracket on a 2x4
(on wall or ceiling), use lag screws (not provided)
to securely fasten the 2x4 to structural supports as
shown here and on page 9.
3. Open your door to the highest point of travel as
shown. Draw an intersecting horizontal line on the
header wall 3" above the high point. This height
will provide travel clearance for the top edge of the
door.
Proceed to Step , page 10. One-piece
door with
horizontal
track
To prevent possible SERIOUS INJURY or DEATH:
• Header bracket MUST be RIGIDLY fastened to
structural support on header wall or ceiling, otherwise
garage door might not reverse when required. DO NOT
install header bracket over drywall.
• Concrete anchors MUST be used if mounting header
bracket or 2x4 into masonry.
• NEVER try to loosen, move or adjust garage door,
springs, cables, pulleys, brackets, or their hardware, all
of which are under EXTREME tension.
• ALWAYS call a trained door systems technician if
garage door binds, sticks, or is out of balance. An
unbalanced garage door might not reverse when
required.
Header Wall
Ceiling
Track
Highest Point
of Travel
Door
3"
Sectional door
with curved
track
Door
Track
Header Wall
Highest Point
of Travel
3"
Finished
Ceiling
Vertical
Centerline
Header
Wall 2x4 Structural
Supports
Vertical
Centerline
WARNING
CAUTION WARNING
WARNING

9
Header Wall Vertical
Centerline
Vertical
Centerline
of Garage
Door
2x4
Unfinished
Ceiling
2x4
OPTIONAL
CEILING MOUNT
FOR
HEADER BRACKET
Structural
Supports
ONE-PIECE DOOR WITHOUT TRACK
. Close the door and mark the inside vertical
centerline of your garage door. Extend the line
onto the header wall above door, as shown.
If headroom clearance is minimal, you can install
the header bracket on the ceiling. See page 0.
If you need to install the header bracket on a 2x4
(on wall or ceiling), use lag screws (not provided)
to securely fasten the 2x4 to structural supports
as shown.
2. Open your door to the highest point of travel as
shown. Measure the distance from the top of the
door to the floor. Subtract the actual height of the
door. Add 8" to the remainder. (See Example).
3. Close the door and draw an intersecting horizontal
line on the header wall at the determined height.
NOTE: If the total number of inches exceeds the
height available in your garage, use the maximum
height possible, or refer to page 10 for ceiling
installation.
Door
Highest Point
of Travel
Header Wall
Pivot
Distance
Floor
One-piece door without track:
pivot hardware
Header Wall
Highest Point
of Travel
Door
Floor
Distance
Jamb
Hardware
One-piece door without track:
jamb hardware
EXAMPLE
Distance from top of door
(at highest point of travel) to floor ...................... 92"
Actual height of door .......................................... -88"
Remainder.......................................................... 4"
Add..................................................................... +8"
Bracket height on header wall............................ = 2"
(Measure UP from top of CLOSED door.)
Proceed to Step , page 10.

0
INSTALLATION STEP 2
Install the Header Bracket
You can attach the header bracket either to the wall
above the garage door, or to the ceiling. Follow the
instructions which will work best for your particular
requirements. Do not install the header bracket
over drywall. If installin into masonry, use
concrete anchors (not provided).
WALL HEADER BRACKET INSTALLATION
• Center the bracket on the vertical centerline with
the bottom edge of the bracket on the horizontal
line as shown (with the arrow pointing toward the
ceiling).
• Mark the vertical set of bracket holes (do not use
the holes designated for ceiling mount). Drill 3/ 6"
pilot holes and fasten the bracket securely to a
structural support with the hardware provided.
Lag Screw
5/ 6"-9 x -5/8"
HARDWARE SHOWN ACTUAL SIZE
Lag Screws
5/ 6"-9x -5/8"
Highest Point of
Garage Door Travel
Vertical
Centerline
Header
Wall
Garage
Door
UP
CEILING MOUNT ONLY
Wall Mounting Holes
Optional
Wall Mounting Holes
The nail hole is for
positioning only.
You must use lag screws
to mount the header bracket.
UP
CEILING MOUNT ONLY
Door Spring
Header
Bracket
2x4
Structural
Support
Vertical
Centerline
UP
CEILING MOUNT ONLY
Ceiling Mounting Holes
The nail hole is for
positioning only.
You must use lag screws
to mount the header bracket.
UP
Lag Screws
5/ 6"-9x -5/8"
Garage Door
Vertical Centerline
Header Wall
– Finished Ceilin –
Header
Bracket
6" Maximum
Vertical
Centerline
Door
Spring
CEILING HEADER BRACKET INSTALLATION
• Extend the vertical centerline onto the ceiling as
shown.
• Center the bracket on the vertical mark, no more
than 6" from the wall. Make sure the arrow is
pointing toward the wall. The bracket can be
mounted flush against the ceiling when clearance
is minimal.
• Mark the side holes. Drill 3/ 6" pilot holes and
fasten bracket securely to a structural support with
the hardware provided.

Clevis Pin
5/16"x2-3/4" Ring Fastener
11
INSTALLATION STEP 3
Attach the Rail to the Header
Bracket
• Position the opener on the garage floor belo the
header bracket. Use packing material as a
protective base. NOTE: If the door spring is in the
way you’ll need help. Have someone hold the
opener securely on a temporary support to allow
the rail to clear the spring.
• Position the rail bracket against the header
bracket.
• Align the bracket holes and join ith a clevis pin
as sho n.
• Insert a ring fastener to secure.
Header Bracket
Rail Bracket
Temporary
Support
Header Wall
Garage
Door
Rail
Clevis Pin
5/16"x2-3/4 "
Ring Fastener
Header Bracket
Rail
Bracket
Rail
HARDWARE SHOWN ACTUAL SIZE

12
Invisible Light Beam
Protection Area
Sensor Beam
6" max.
above floor
Sensor Beam
6" max.
above floor
Facing the door from inside the garage
INSTALLATION STEP 4
Install The Protector System®
The safet reversing sensor must be connected
and aligned correctl before the garage door
opener will move in the down direction.
IMPORTANT INFORMATION ABOUT
THE SAFETY REVERSING SENSOR
When properly connected and aligned, the sensor
ill detect an obstacle in the path of its electronic
beam. The sending eye ( ith an orange indicator
light) transmits an invisible light beam to the
receiving eye ( ith a green indicator light). If an
obstruction breaks the light beam hile the door is
closing, the door ill stop and reverse to full open
position, and the opener lights ill flash 10 times.
The units must be installed inside the garage so that
the sending and receiving eyes face each other
across the door, no more than 6" above the floor.
Either can be installed on the left or right of the door
as long as the sun never shines directly into the
receiving eye lens.
The mounting brackets are designed to clip onto the
track of sectional garage doors ithout additional
hard are.
If it is necessary to mount the units on the all, the
brackets must be securely fastened to a solid
surface such as the all framing. Extension brackets
(see accessories) are available if needed. If
installing in masonry construction, add a piece of
ood at each location to avoid drilling extra holes in
masonry if repositioning is necessary.
The invisible light beam path must be unobstructed.
No part of the garage door (or door tracks, springs,
hinges, rollers or other hard are) may interrupt the
beam hile the door is closing.
• Be sure power is not connected to the garage door
opener BEFORE installing the safety reversing sensor.
• To prevent SERIOUS I JURY or DEATH from a closing
garage door:
– Correctly connect and align the safety reversing
sensor. This required safety device MUST OT be
disabled.
– Install the safety reversing sensor so beam is O
HIGHER than 6" above garage floor.
WARNING
CAUTION WARNING
WARNING

13
FLOOR MOUNT (RIGHT SIDE)
WALL MOUNT (RIGHT SIDE)
DOOR TRACK MOUNT (RIGHT SIDE)
Indicator
light
Lens
Lip
Sensor
Bracket
Door
Track
Sensor
Bracket
Extension
Bracket
(See Accessories)
Lens
Indicator
light
Attach ith
concrete anchors
(not provided)
Inside
Garage
Wall
Indicator
light
Sensor
Bracket
Lens
Extension
Bracket
(See Accessories)
Inside
Garage
Wall
(Provided ith
Extension
Bracket)
(Provided ith
Extension Bracket)
(Provided ith
Extension
Bracket)
(Provided ith
Extension Bracket)
Figure 3
Figure 1
Figure 2
INSTALLING THE BRACKETS
Be sure power to the opener is disconnected.
Install and align the brackets so the sensors ill face
each other across the garage door, ith the beam no
higher than 6" above the floor. They may be installed
in one of three ays, as follo s:
Garage door track installation (preferred):
• Slip the curved arms over the rounded edge of
each door track, ith the curved arms facing the
door. Snap into place against the side of the track.
It should lie flush, ith the lip hugging the back
edge of the track, as sho n in Figure 1.
If your door track ill not support the bracket
securely, all installation is recommended.
Wall installation:
• Place the bracket against the all ith curved
arms facing the door. Be sure there is enough
clearance for the sensor beam to be unobstructed.
• If additional depth is needed, an extension bracket
(see Accessories) or ood blocks can be used.
• Use bracket mounting holes as a template to
locate and drill (2) 3/16" diameter pilot holes on
the all at each side of the door, no higher than 6"
above the floor.
• Attach brackets to all ith lag scre s
(not provided).
• If using extension brackets or ood blocks, adjust
right and left assemblies to the same distance out
from the mounting surface. Make sure all door
hard are obstructions are cleared.
Floor installation:
• Use ood blocks or extension brackets (see
Accessories) to elevate sensor brackets so the
lenses ill be no higher than 6" above the floor.
• Carefully measure and place right and left
assemblies at the same distance out from the all.
Be sure all door hard are obstructions are
cleared.
• Fasten to the floor ith concrete anchors as
sho n.

14
Carriage bolt
1/4"-20x1/2" Lens
Wing nut
Figure 4
MOUNTING AND WIRING THE SAFETY
SENSORS
• Slide a 1/4"-20x1/2" carriage bolt head into the
slot on each sensor. Use ing nuts to fasten
sensors to brackets, ith lenses pointing to ard
each other across the door. Be sure the lens is not
obstructed by a bracket extension (Figure 4).
• Finger tighten the ing nuts.
Recommended Wire Routing
1. Using insulated staples, run the ires from both
sensors to the rail at the door header (Figure 5).
2. Cross and t ist the t o ires here they meet
the rail (see inset A). Run the ires inside the
channels at the top of the rail, along each side,
to the motor unit. Do not use the lower (trolle )
channels. Use a scre driver tip to tuck the ires
snugly into the channels.
NOTE: If your access door is near the garage
door, you may choose to install the door control at
this time and run the door control wire along the
rail with the sensor wires. Use one rail channel for
the door control wire and the other channel for
both sensor wires. If you choose this option, follow
instructions 1-3 on page 1 now.
3. Pull ires taut across the top of the chassis and
insert into the opening above the terminal block
(see inset B). You ill complete the iring in
Installation Step 7.
Wing Nut Staples
Carriage Bolt
1/4"-20x1/2"
HARDWARE SHOWN ACTUAL SIZE
Invisible Light Beam
Protection Area Sensor
Sensor
Bell Wire
Header
Bracket
Header
Wall
Sensor
Wire
T ist
Wires
Sensor
Wire
Rail
Channel
2. Run wires along channels
to motor unit. Use screwdrive blade
to tuck snugl into channels.
1. Run wires from sensors to end of rail
at the door header. Cross & twist here to
help contain wires in channels on top of rail.
3. Pull wires taut across top of chassis
and insert into opening above
terminal block.
Figure 5
A
B

15
ONE-PIECE DOOR WITHOUT TRACK
• With the door fully open and parallel to the floor,
measure the distance from the floor to the top of
the door.
• Using a stepladder as a support, raise the top of
the opener to this height.
• The top of the door should be level ith the top of
the motor unit. Do not position the opener more
than 3" above this point.
INSTALLATION STEP 5
Position the Opener
Follo instructions hich apply to your door type as
illustrated.
SECTIONAL DOOR OR ONE-PIECE DOOR WITH
TRACK
A 2x4 laid flat is convenient for setting an ideal door-
to-rail distance.
• Raise the opener onto a stepladder. You ill need
help at this point if the ladder is not tall enough.
• Open the door all the ay and place a 2x4 laid flat
on the top section beneath the rail.
• If the top section or panel hits the trolley hen you
raise the door, pull do n on the trolley release arm
to disconnect inner and outer sections. Slide the
outer trolley to ard the motor unit. The trolley can
remain disconnected until Installation Step 13
is completed.
2x4
laid flat
Door
Header
Bracket
ENGAGED RELEASED
Trolley
Release Arm
To prevent damage to garage door, rest garage door
opener rail on 2x4 placed on top section of door.
WARNING
CAUTION
WARNING
WARNING
Header
Bracket
Top of Door
Top of Motor Unit

16
INSTALLATION STEP 6
Hang the Opener
T o representative installations are sho n. Yours
may be different. Hanging brackets should be angled
(Figure 1) to provide rigid support. On finished
ceilings (Figure 2), attach a sturdy metal bracket to
structural supports before installing the opener. This
bracket and fastening hard are are not provided.
Existing brackets from a previous installation may be
fastened to the sides of the motor unit as in Figures
1 and 2, or to the mounting tabs as sho n in
Figure 3. Then continue ith step 5 belo .
1. Remove foam packaging. Measure the distance
from each side of the motor unit to the structural
support.
2. Cut both pieces of the hanging bracket to required
lengths.
3. Drill 3/16" pilot holes in the structural supports.
4. Attach one end of each bracket to a support ith
5/16"-18x1-7/8" lag scre s.
5. Fasten the opener to the hanging brackets ith
5/16"-18x7/8" hex bolts, lock ashers and nuts.
If you ish to utilize the t o center mounting tabs,
you must triangulate the vertical brackets for
additional stability (Figure 3).
6. Check to make sure the rail is centered over the
door (or in line ith the header bracket if the
bracket is not centered above the door).
7. Remove the 2x4. Operate the door manually. If the
door hits the rail, raise the header bracket.
To avoid possible SERIOUS I JURY from a falling
garage door opener, fasten it SECURELY to structural
supports of the garage. Concrete anchors MUST be used
if installing A Y brackets into masonry.
Lag Scre 5/16"-18x1-7/8"
Hex Bolt
5/16"-18x7/8" Nut 5/16"-18 Lock Washer 5/16"
HARDWARE SHOWN ACTUAL SIZE
Measure
Distance
Lag Scre s
5/16"- 18x1-7/8"
Bracket
(Not Provided)
Lag Scre s
5/16"-18x1-7/8"
(Not Provided)
Bolt 5/16"-18x7/8"
Lock Washer 5/16"
Nut 5/16"-18
— FINISHED CEILING —
Hex Bolts
5/16"-18x7/8"
Lock Washers 5/16"
Nuts 5/16"-18
Hidden
Support
Bolt 5/16"-18x7/8"
Lock Washer 5/16"
Nut 5/16"-18
Structural
Supports
Preferred range of
bracket placement
Preferred range of
bracket placement
Top Mounting Tabs
Utilizing existing top mount installation
Existing Brackets
Bracket
(Provided)
Figure 1
Figure 2
WARNING
CAUTION WARNING
WARNING
Figure 3

To release ire, push in tab
ith scre driver tip
Door Control
Connections
7/16"
Strip ire 7/16"
Red Grey
White
17
INSTALLATION STEP 7
Install the Door Control
Locate door control ithin sight of the door at a minimum
height of 5 feet here small children cannot reach, and
a ay from moving parts of the door and door hard are.
The installation surface must be smooth and flat. If
installing into dry all (Figure 1), drill 5/32" holes and use
anchors provided. For pre- ired installations (as in ne
home construction), it may be mounted to a single gang
box (Figure 2). NOTE: After installation, a green indicator
light behind the cover will indicate proper connection. If not
lit, the Lock and Light features will not function (reverse
wires to correct).
1. Strip 7/16" of insulation from one end of bell ire and
connect to the t o scre terminals on back of door
control by color: hite ire to 2 and hite/red ire to
the 1 (Figure 3).
2. Lighted door control: Fasten to all ith 6ABx1-1/2"
self-threading scre s.
Multi-function: Remove hite cover by gently prying at
slot in top of the cover ith a small flat head scre driver.
Fasten ith 6ABx1-1/4"self-threading scre s (dry all
installation) or 6-32x1" machine scre s (into gang box)
as follo s:
• Drill and install bottom scre , allo ing 1/8" to protrude
above all surface.
• Position bottom of door control on scre head and
slide do n to secure. Adjust scre for snug fit.
• Install top scre ith care to avoid cracking plastic
housing. Do not overtighten.
• Insert bottom tabs and snap on cover.
NOTE: The push bar may stick if the door control is not
mounted on a smooth surface. If a click is not heard when
pressing the push bar, loosen the two mounting screws or
relocate the door control to a smoother surface.
3. (Standard installation only) Run bell ire up all and
across ceiling to motor unit. Use insulated staples to
secure ire in several places. Do not pierce ire ith a
staple, creating a short or open circuit. If your access
door is near the garage door, you may run this ire ith
the Safety Reversing Sensor ires along the top of the
rail. See page 14.
4. Insert all ires through the opening on top of motor unit
above the terminal block on the back panel (Figure 4).
5. Strip 7/16" of insulation from each set of ires. Insert
door control ire into quick-connect terminals by color:
hite ire to hite, hite/red ire to red.
Separate hite and hite/black ires sufficiently to
connect to the opener quick-connect terminals. T ist like
colored ires together. Insert ires into quick-connect
holes: hite to hite and hite/black to grey (Figure 4).
NOTE: When connecting multiple door controls to the
opener, twist same color wires together. Insert wires into
quick-connect holes: white to white and red/white to red.
6. Use tacks or staples to permanently attach entrapment
arning label to all near door control, and manual
release/safety reverse test label in a prominent location
on inside of garage door.
NOTE: DO NOT connect the power and operate the
opener at this time. The trolley will travel to the full open
position but will not return to the close position until the
sensor beam is connected and properly aligned. See
Step 11 on page 19.
Figure 2
To Replace
Insert Bottom Tabs First
PRE-WIRED
INSTALLATION
24 Volt
Bell Wire
LOCK
LIGHT
LOCK
LIGHT
To Replace
Insert Bottom Tabs First
Figure 1 STANDARD
INSTALLATION
Single
Gang Box
Figure 3
To prevent possible SERIOUS I JURY or DEATH from
electrocution:
• Be sure power is not connected BEFORE installing door
control.
• Connect O LY to 24 VOLT low voltage wires.
To prevent possible SERIOUS I JURY or DEATH from a
closing garage door:
• Install door control within sight of garage door, out of
reach of children at a minimum height of 5 feet, and
away from all moving parts of door.
• EVER permit children to operate or play with door
control push buttons or remote control transmitters.
• Activate door O LY when it can be seen clearly, is
properly adjusted, and there are no obstructions to door
travel.
• ALWAYS keep garage door in sight until completely
closed. EVER permit anyone to cross path of closing
garage door.
WARNING
CAUTION
WARNING
WARNING
Figure 4
To
Door
Control
To
Sensors
Quick-
Connect
Terminal
Lighted Door Control Button
6ABx1-1/2" Scre
Dry Wall
Anchors
Insulated
Staples
Multi-function (std installation)
6AB x 1-1/4" Scre Multi-function (pre- ired)
6-32 x 1" Scre
HARDWARE SHOWN ACTUAL SIZE
Multi-function
Wall Control
Lighted
Door Control
Terminal
Scre s

18
INSTALLATION STEP 8
Install the Lights
• Install up to a 100 att maximum light bulb in each
socket. The lights ill turn ON and remain lit for
approximately 4-1/2 minutes hen po er is
connected. Then the lights ill turn OFF.
• Insert bottom lens tabs into slots on chassis. Tilt
to ards chassis to engage top tabs, then drop
do n gently into place.
• To remove, depress both top lens tabs. Tilt lens
slightly out ard and do n, then pull out to clear
bulbs. Use care to avoid snapping off bottom lens
tabs.
• Reverse the procedure to close the lens.
• If the bulbs burn out prematurely due to vibration,
replace ith a Garage Door Opener bulb.
NOTE: Use only standard light bulbs. The use of
short neck or speciality light bulbs may overheat the
endpanel or light socket.
INSTALLATION STEP 9
Attach the Emergency Release
Rope and Handle
• Thread one end of the rope through the hole in the
top of the red handle so "NOTICE" reads right side
up as sho n. Secure ith an overhand knot at
least 1" from the end of the rope to prevent
slipping.
• Thread the other end of the rope through the hole
in the release arm of the outer trolley.
• Adjust rope length so the handle is 6 feet above
the floor. Secure ith an overhand knot.
NOTE: If it is necessary to cut the rope, heat seal
the cut end with a match or lighter to prevent
unraveling.
• To prevent possible SERIOUS I JURY or DEATH from
a falling garage door:
– If possible, use emergency release handle to
disengage trolley O LY when garage door is
CLOSED. Weak or broken springs or unbalanced
door could result in an open door falling rapidly
and/or unexpectedly.
– EVER use emergency release handle unless garage
doorway is clear of persons and obstructions.
• EVER use handle to pull door open or closed. If rope
knot becomes untied, you could fall.
Bottom
Chassis Slots
Top Lens Tab
Bottom
Lens Tab
Bottom
Chassis Slot Insert Bottom
Lens Tabs First
Top
Chassis Slot
Top
Lens Tab
Lens
Lens
Top
Chassis
Slot
NOTICE
Emergency
Release Handle
Overhand
Knot
Trolley
Release Arm
WARNING
CAUTION WARNING
WARNING

19
INSTALLATION STEP 10
Electrical Requirements
To avoid installation difficulties, do not run the
opener at this time.
To reduce the risk of electric shock, your garage door
opener has a grounding type plug ith a third
grounding pin. This plug ill only fit into a grounding
type outlet. If the plug doesn't fit into the outlet you
have, contact a qualified electrician to install the
proper outlet.
If permanent wiring is required b our local
code, refer to the following procedure.
To make a permanent connection through the 7/8"
hole in the top of the motor unit:
• Remove the motor unit cover scre s and set the
cover aside.
• Remove the attached 3-prong cord.
• Connect the black (line) ire to the scre on the
brass terminal; the hite (neutral) ire to the
scre on the silver terminal; and the ground ire
to the green ground scre . The opener must be
grounded.
• Reinstall the cover.
To avoid installation difficulties, do not run the
opener until Step 11 below.
RIGHT WRONG
To prevent possible SERIOUS I JURY or DEATH from
electrocution or fire:
• Be sure power is not connected to the opener, and
disconnect power to circuit BEFORE removing cover to
establish permanent wiring connection.
• Garage door installation and wiring MUST be in
compliance with all local electrical and building codes.
• EVER use an extension cord, 2-wire adapter, or
change plug in any way to make it fit outlet. Be sure
the opener is grounded.
Ground Tab
Green
Ground Scre
Ground Wire
Black Wire
PERMANENT WIRING
CONNECTION
White Wire
Black
Wire
WARNING
CAUTION WARNING
WARNING
INSTALLATION STEP 11
Complete Safety Reversing Sensor
Installation
ALIGNING THE SAFETY SENSORS
Plug in the opener. The indicator lights in both the
sending and receiving eyes ill glo steadily if
iring connections and alignment are correct.
The sending eye orange indicator light ill glo
regardless of alignment or obstruction. If the green
indicator light in the receiving eye is off, dim, or
flickering (and the invisible light beam path is not
obstructed), alignment is required.
• Loosen the sending eye ing nut and readjust,
aiming directly at the receiving eye. Lock in place.
• Loosen the receiving eye ing nut and adjust the
sensor vertically and/or horizontally until it
receives the sender’s beam. When the green
indicator light glo s steadily, tighten the ing nut.
TROUBLESHOOTING THE SAFETY SENSORS
1. If the sending eye indicator light does not glo
steadily after installation, check for:
• Electric po er to the opener.
• A short in the hite or hite/black ires. These
can occur at staples, or at opener connections.
• Incorrect iring bet een sensors and opener.
• A broken ire.
2. If the sending eye indicator light glo s steadily but
the receiving eye indicator light doesn't:
• Check alignment.
• Check for an open ire to the receiving eye.
3. If the receiving eye indicator light is dim, realign
either sensor.
NOTE: When the invisible beam path is obstructed
or misaligned while the door is closing, the door will
reverse. If the door is already open, it will not close.
The opener lights will blink 10 times. (If bulbs are not
installed, 10 clicks can be heard.) See page 12.

20
INSTALLATION STEP 12
Fasten the Door Bracket
Follo instructions hich apply to your door type
as illustrated belo or on the follo ing page.
A horizontal reinforcement brace should be long
enough to be secured to two or three vertical
supports. A vertical reinforcement brace should
cover the height of the top panel.
Figure 1 sho s one piece of angle iron as the
horizontal brace. For the vertical brace, 2 pieces of
angle iron are used to create a U-shaped support.
The best solution is to check ith your garage door
manufacturer for an opener installation door
reinforcement kit.
NOTE: Many door reinforcement kits provide for
direct attachment of the clevis pin and door arm. In
this case you will not need the door bracket; proceed
to Step 13.
SECTIONAL DOORS
1. Center the door bracket on the previously marked
vertical centerline used for the header bracket
installation. Note correct UP placement, as
stamped inside the bracket.
2. Position the top edge of the bracket 2"-4" belo
the top edge of the door, OR directly belo any
structural support across the top of the door.
3. Mark, drill holes and install as follo s, depending
on your door’s construction:
etal or light weight doors using a vertical angle
iron brace between the door panel support and
the door bracket:
• Drill 3/16" fastening holes. Secure the door bracket
using the t o 1/4"-14x5/8" self-threading scre s.
(Figure 2A)
• Alternately, use t o 5/16" bolts, lock ashers and
nuts (not provided). (Figure 2B)
etal, insulated or light weight factory reinforced
doors:
• Drill 3/16" fastening holes. Secure the door bracket
using the self-threading scre s (Figure 3).
Wood Doors:
• Use top and bottom or side to side door bracket
holes. Drill 5/16" holes through the door and
secure bracket ith 5/16"x2" carriage bolts, lock
ashers and nuts (not provided). (Figure 4)
NOTE: The 1/4"-14x5/8"
self-threading screws are
not intended for use on
wood doors.
To prevent damage to garage door, reinforce inside of
door with angle iron both vertically and horizontally.
WARNING
CAUTION
WARNING
WARNING
Vertical
Centerline
Door
Bracket
Location
Header
Bracket
HORIZONTAL AND VERTICAL
REINFORCEMENT IS NEEDED
FOR LIGHTWEIGHT GARAGE
DOORS (FIBERGLASS,
ALUMINUM, STEEL, DOORS
WITH GLASS PANEL, ETC).
(NOT PROVIDED)
Door
Bracket
Vertical
Centerline
UP
Vertical
Reinforcement
Self-Threading
Scre
1/4"-14x5/8"
Door
Bracket
Nut
5/16"-18
Bolt
5/16"-18x2"
Lock Washer
5/16"
Vertical
Centerline
UP
Vertical
Reinforcement
(Not Provided)
UP
Vertical
Centerline
Self-Threading
Scre
1/4"-14x5/8"
UP
Inside Edge
of Door or
Reinforcement Board
Bolt
5/16"x2"
Vertical
Centerline
(Not Provided)
Figure 1
Figure 2A
Figure 2B
Figure 3
Figure 4
Self-Threading
Scre
1/4"-14x5/8"
HARDWARE
SHOWN
ACTUAL SIZE
