INSTALLATION MANUAL
MODEL #102006
AUTOMATIC TRANSFER SWITCH
WITH aXis CONTROLLERTM MODULE
REV 20201015 Champion Power Equipment, Inc., Santa Fe Springs, CA USA
or visit championpowerequipment.com
READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product. Failure to
do so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction...................................................3
Safety Definitions ..........................................3
Important Safety Instructions .......................4
Instructions for Champion Automatic Transfer Switch
with aXis ControllerTM Module ....................................4
Before Installation.................................................4
Safety Labels......................................................5
Safety Symbols....................................................5
Controls and Features ...................................6
Champion Automatic Transfer Switch
with aXis ControllerTM Module ....................................6
Panel Board Safety Information ....................7
Unpacking......................................................8
Location and Mounting ...........................................8
Electrical Grommet(s) .............................................8
Installation Wiring for ATS Utility Socket .........................9
Wiring the ATS ....................................................9
Installation .................................................. 10
Low Voltage Control Relays..................................... 10
Settings on the aXis ControllerTM Module ...................... 10
WIFI Setup Method...............................................11
ATS and HSB Status Using WIFI ................................ 12
Connecting the Load Management Systems................... 12
Teaching System ................................................ 12
Full System Check .............................................. 13
Specifications.............................................. 13
aXis ControllerTM Module Automatic Transfer Switch .......... 13
Technical Specifications ........................................ 13
Warranty...................................................... 13

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE INTRODUCTION
3
INTRODUCTION
Congratulations on your purchase of a Champion Power Equipment
(CPE) product. CPE designs, builds, and supports all of our
products to strict specifications and guidelines. With proper
product knowledge, safe use, and regular maintenance, this
product should bring years of satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the time of
publication, and we reserve the right to change, alter and/or
improve the product and this document at any time without prior
notice.
CPE highly values how our products are designed, manufactured,
operated, and serviced as well as providing safety to the operator
and those around the generator. Therefore, it is IMPORTANT to
review this product manual and other product materials thoroughly
and be fully aware and knowledgeable of the assembly, operation,
dangers and maintenance of the product before use. Fully
familiarize yourself, and make sure others who plan on operating
the product fully familiarize themselves too, with the proper safety
and operation procedures before each use. Please always exercise
common sense and always err on the side of caution when
operating the product to ensure no accident, property damage,
or injury occurs. We want you to continue to use and be satisfied
with your CPE product for years to come.
When contacting CPE about parts and/or service, you will need to
supply the complete model and serial numbers of your product.
Transcribe the information found on your product’s nameplate
label to the table below.
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
102006
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
DANGER
DANGER indicates a hazardous situation which,if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE indicates information considered important, but not
hazard-related (e.g., messages relating to property damage).

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Instructions for Champion Automatic
Transfer Switch with aXis ControllerTM
Module
THE CHAMPION AUTOMATIC TRANSFER SWITCH WITH aXis
CONTROLLERTM MODULE IS NOT FOR “DO-IT-YOURSELF”
INSTALLATION. It must be installed by a qualified electrician
thoroughly familiar with all applicable electrical and building
codes.
This manual has been prepared for familiarizing servicing dealer/
installer with the design, application, installation and servicing of
the equipment.
Read the manual carefully and comply with all instructions.
This manual or a copy of this manual should remain with the
switch. Every effort has been taken to make sure that the contents
of this manual are accurate and current.
The manufacturer reserves the right to change, alter or otherwise
improve this literature and the product at any time without prior
notice and without any obligation or liability whatsoever.
The manufacturer cannot anticipate every possible circumstance
that might involve a hazard.
The warnings in this manual, tags and decals affixed to the unit
are, therefore, not all-inclusive. If using a procedure, work method
or operating technique the manufacturer does not specifically
recommend follow all codes to ensure safety for personnel.
Many accidents are caused by failing to follow simple and
fundamental rules, codes and precautions. Before installing,
operating or servicing this equipment, read the SAFETY RULES
carefully.
The publications that cover the safe use of ATS and installation
are the following NFPA 70, NFPA 70E, UL 1008 and UL 67. It is
important to refer to the latest version of any standard/code to
ensure correct and current information. All installations must
comply with local municipal, state and national codes.
Before Installation
WARNING
Per OSHA 3120 Publication; “lockout/tagout” refers to
specific practices and procedures to safeguard individuals
from the unexpected energization or startup of machinery
and equipment, or the release of hazardous energy during
installation, service or maintenance activities.
WARNING
Be certain that the power from the utility is turned off and all
backup sources are locked out before starting this procedure.
Failure to do so could result in serious injury or death. Be
aware, automatic start generators will start upon loss of utility
mains power unless locked in the “off” position.
Consult the generator operator manual section to locate the
ATS CONTROL and ENGINE CONTROL modules to make sure
both switches are in the OFF position.
CAUTION
Consult with your Local municipal, State and National
electrical codes for proper mandatory wiring methods.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE IMPORTANT SAFETY INSTRUCTIONS
5
Safety Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
Read Installation Manual. To reduce the risk of injury, user must read and understand installation
manual before using this product.
Ground. Consult with local electrician to determine grounding requirements before operation.
Electric Shock. Improper connections can create an electrocution hazard.
Safety Labels
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.
HANGTAG/LABEL DESCRIPTION
1
1681-T- PR
ATTENTION
ALTERNATE POWER SOURCE AVAILABLE -
STANDBY GENERATOR ON PREMISES.
ATTENTION
AUTRE SOURCE DE COURANT DISPONIBLE -
GENERATEUR SUR SITE.
ATENCIÓN
FUENTE DE CORRIENTE ALTERNA DISPONIBLE -
GENERADOR DE RESERVA EN EL SITIO.
GENERATOR LOCATION:
UBICACIÓN DEL GENERADOR:
EMPLACEMENT DU GENERATEUR:
DO NOT REMOVE \ NO REMUEVA \ NE PAS ENLEVER
NW
W E
NNE
SW SSE
1681-T- PR
ATTENTION
ALTERNATE POWER SOURCE AVAILABLE -
STANDBY GENERATOR ON PREMISES.
ATTENTION
AUTRE SOURCE DE COURANT DISPONIBLE -
GENERATEUR SUR SITE.
ATENCIÓN
FUENTE DE CORRIENTE ALTERNA DISPONIBLE -
GENERADOR DE RESERVA EN EL SITIO.
GENERATOR LOCATION:
UBICACIÓN DEL GENERADOR:
EMPLACEMENT DU GENERATEUR:
DO NOT REMOVE \ NO REMUEVA \ NE PAS ENLEVER
NW
W E
NNE
SW SSE
FRONT BACK
K---------
ColorsLPN 168 1-T-O P
Rev --
Size 115 x 110 mm
Artwork Notes
2mm safe m argin; fron t and back; to be p rinted on
weather-resistant, white, synthetic substrate (PE/PP
mix)
Revision Changes
--
This artw ork belongs to Champio n Power Equipment. The c ontents are confi dential and privileg ed and shall not be disclo sed to or used by or for
outside par ties without the e xplicit consent of C hampion Power Equip ment.
152
Alternate Power Source
2
This switch will not transfer if overcurrent device
opens due to fault.
 CAUTION
Cet interrupteur ne sera pas transfere si le
dispositif a maximum de courant
s’ouvre par errur.
 MISE EN GARDE
Este interruptor no se transferira si el dispositivo
de sobrecorriente se abre debido a una falla.
 PRECAUCIÓN
1943-L-PR-A
K109 --- --- ---
ColorsLPN 1943-L-PR
Rev A
Size 70 x 26 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
---
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Caution. Overcurrent device.
3
Electrical shock hazard. May cause injury or death.
Disconnect all sources of supply before servicing.
Riesgo de descarga eléctrica. Puede causar lesión o la
muerte. Desconecte todas las fuentes de suministro
antes de realizar el servicio.
Risque d'électrocution. Peut causer des blessures ou la
mort. Débranchez toutes les sources d'alimentation
avant de procéder à l'entretien.
2458-L-PR-A
More than one live circuit - disconnect all sources of supply before servicing.
Más de un circuito en vivo - desconecte todas las fuentes de
suministro antes de dar servicio.
Plusieurs circuits sous tension - débranchez toutes les sources
d’alimentation avant de procéder àl’entredien.
WARNING ADVERTENCIA AVERTISSEMENT
DANGER PELIGRO DANGER
K485 152 --- ---
ColorsLPN 2458-L-PR
Rev A
Size 90 x 65 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
WHITE substrate.
Revision Changes
---
This ar twork belongs t o Champio n Power Equ ipment. T he conte nts are c onfidential and p rivileg ed and shall not be disc losed to o r used by or f or
outsid e parti es witho ut the exp licit con sent of Ch ampion Po wer Equipment.
Danger. Electrocution shock hazard.
Warning. More than one live circuit.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE CONTROLS AND FEATURES
6
CONTROLS AND FEATURES
Read this installation manual before installing your transfer switch. Familiarize yourself with the location and function of the controls and
features. Save this manual for future reference.
Champion Automatic Transfer Switch with aXis ControllerTM Module
1. aXis Controller
2. Antenna
3. Generator L1 and L2 Terminals
4. Battery Charger Fuse Block
5. Two Wire Sensing Fuse Block
6. Ground Bar
7. Neutral Bar
8. Neutral to Ground Bonding Wire
9. Load L1 and L2 Terminals
10. Utility L1 and L2 Terminals
11. Mounting Holes
12. Front Cover
13. Dead Front
1
5 6 7
12 13
2
3
4
11
11 11
8
11
9
10

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE PANEL BOARD SAFETY INFORMATION
7
PANEL BOARD SAFETY INFORMATION
As of January 1, 2017, enhanced UL 67 safety requirements took
effect, applying to all panel boards and load centers with service
equipment applications in accordance with the National Electrical
Code, NFPA 70.
To comply, any single service disconnect panel board or load
center must have provisions such that, when the service
disconnect is opened, no person in the field servicing the
equipment load side can make accidental contact to live circuit
parts. Barriers to protect against unintended contact shall be
constructed in such a way that they are easily installable and
removable without contacting or damaging bare or insulated live
parts. The barrier could be installed on the ARM, panel board or
load center.
The battery(s) might be discharged to a level that is too low to re-
charged with this charger (battery voltage below 6V). If this is the
case, the batteries will need to be charged individually. Remove
all battery cables from the batteries and follow the battery
manufacturers’ instructions on properly servicing/charging the
batteries.
Be careful to avoid corrosion on the battery post(s). Corrosion
can have the effect of creating an insulation between the post(s)
and the cable(s), this will severely affect the performance of the
battery. Follow battery manufacturers’ instructions on proper
maintenance, service or replacement. The correct wire lands are
read left to right, 6 land points;
1. Wire land #1 Ground G (GREEN)
2. Wire land #2 L1 P (PINK)
3. Wire land #3 N W (WHITE)
4. Wire land #4 NOT CONNECTED EMPTY
5. Wire land #5 B- B (BLACK)
6. Wire land #6 B+ R (RED)
A 120VAC circuit must be installed for battery charging. From ATS
fuse block or distribution panel install L1 and N to Wire land # 2
and #3 respectively.
Automatic Transfer Switch (ATS) Service Entrance models
Refer to the Champion ATS instruction guide enclosed with each
unit for information related to installation, operation, service,
trouble shooting and warranty.
The most reliable and convenient method to transfer power is with
an automatic transfer switch (ATS). The ATS will automatically
disconnect the home from the utility power prior to the HSB
functioning (see NEC 700, 701 and 702). Failure to disconnect the
home from the utility with an approved UL listed ATS can result
in damage to the HSB and can also cause injury or death to utility
power workers who may receive electrical back-feed from the
HSB.
ATS includes sensors to detect when a power failure (utility lost)
occurs. These sensors trigger the ATS to disengage the home from
the utility power. When the HSB reaches the proper voltage and
frequency, the ATS will automatically transfer generator power to
the home.
The ATS module continues to monitor the utility source for the
return of utility power. When the utility power returns, the ATS
disengages the home from generator power and re-transfers the
home to utility power. The HSB is now off line and will shut down-
-returning to the standby mode.
NEMA 3R – This type of enclosed ATS is similar to the indoor box,
except that it is a weatherproof enclosure and required for exterior
installations by code. The enclosure has knockouts on the bottom
and side, and requires water tight connections when installed
outside per code. This enclosure can also be used inside.
The HSB Generator Exercise mode allows for automatic
operation at specific times (set by the installer or owner).

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE UNPACKING
8
UNPACKING
1. Use care when unpacking to avoid damaging transfer switch
components.
2. Allow the ATS to acclimate to room temperature for
a minimum of 24 hours before unpacking to prevent
condensation on the electrical apparatus.
3. Use a wet/dry vacuum cleaner or a dry cloth to remove dirt
and packing material that may have accumulated in the
transfer switch or any of its components during storage.
4. Do not use compressed air to clean the switch, cleaning with
compressed air can cause debris to lodge in the components
and damage the switch per the ATS manufacturers
specifications.
5. Retain the ATS manual with or near the ATS for future
reference.
TOOLS REQUIRED NOT INCLUDED
5/16 in. Hex Wrench Mounting Hardware
Line Voltage Wire
1/4 in. Flat Screwdriver Conduit
Fittings
Location and Mounting
Install the ATS as close as possible to utility meter socket. Wires
will run between the ATS and main distribution panel, proper
installation and conduit are required by code. Mount the ATS
vertically to a rigid supporting structure. To prevent the ATS or
enclosure box from distortion, level all mounting points; use
washers behind the mounting holes (outside the enclosure,
between enclosure and supporting structure), see following image.
The recommended fasteners are 1/4” lag screws. Always follow
local code.
16 in.
406.4 mm
24 in.
609.5 mm
Electrical Grommet(s)
Grommets can be used in any enclosure knockout for NEMA 1
installations. Grommets can only be used in the bottom enclosure
knockouts for NEMA 3R installations, when installed outside.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE UNPACKING
9
Installation Wiring for ATS Utility Socket
WARNING
The manufacturer recommends that a licensed electrician or
an individual with complete knowledge of electricity perform
these procedures.
Always be certain that the power from the main panel is
turned “OFF” and all backup sources are locked out prior to
removal of the cover or removal of any wiring of the utility
main electrical distribution panel.
Be aware, automatic start generators will start upon loss of
utility main power unless locked in the “OFF” position.
Failure to do so could result in serious injury or death.
CAUTION
Consult with your Local municipal, State and National
electrical codes for proper mandatory wiring methods.
Conductor sizes must be adequate to handle the maximum current
to which they will be subjected. The installation must comply fully
with all applicable codes, standards and regulations. Conductors
must be properly supported, of approved insulation materials,
protected by approved conduit and with the correct wire gauge
size in accordance with all applicable codes. Before connecting
wire cables to terminals, remove any surface oxides from the
cable ends with a wire brush. All power cables must enter the
enclosure through the enclosure knockouts.
1. Determine where the flexible, liquid tight conduit will pass
through the building from the inside to outside. When you
are certain that there is adequate clearance on each side of
the wall, drill a small pilot hole through the wall to mark the
location. Drill an appropriate sized hole through the sheathing
and siding.
2. In compliance with all local electrical codes, route the conduit
along ceiling/floor joists and wall studs to the location where
the conduit will pass through the wall to the exterior of the
house. Once the conduit is pulled through the wall and in
proper position to attach to the HSB generator, place silicone
caulk around the conduit on both side of the hole, inside and
outside.
3. Mount the ATS near the Utility meter socket.
Wiring the ATS
NOTICE
US ATS model shown for reference. For Canadian installation,
refer to ATS Installation Manual.
1. Have authorized utility personnel pull the utility meter from
the meter socket.
2. Remove door and deadfront of ATS.
3. Connect Utility (L1-L2) to ATS Utility side breaker. Torque to
275 in-lbs.
4. Connect Utility N to Neutral lug. Torque to 275 in-lbs.
5. Connect earth GROUND to GROUND bar. NOTE: GROUND and
NEUTRAL bonded in this panel.
6. Connect Generator L1-L2 to Generator side breaker. Torque to
45-50 in-lbs.
7. Connect Generator Neutral to neutral bar. Torque to
275 in-lbs.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE INSTALLATION
10
8. Connect Generator Ground to ground bar.
Torque to 35-45 in-lbs.
9. Connect Load bars L1 and L2 to distribution panel.
Torque to 275 in-lbs.
10. Pull NEUTRAL from ATS to distribution panel. Pull GROUND
from ATS to distribution panel.
CAUTION
Remove bond from distribution panel if installed.
INSTALLATION
Low Voltage Control Relays
The aXis ControllerTM ATS has two low voltage relays that can be
used to manage the load of air conditioners or other devices that
utilize low voltage controls. The ATS’s two low voltage relays are
called AC1 and AC2 and are found on the aXis control board as
shown in the picture below.
AC 2
Pin 1 Pin 2 Pin 3 Pin 1 Pin 2
AC 1
CONNECTING TO AC1 AND AC2
For air conditioner or other low voltage controls, route your low
voltage wiring into the ATS using code appropriate conduit and
fittings. Connect the wiring to pin 1 and pin 2 of either AC1 or AC2
as shown in the diagram above. Please note that AC2 has three
pins available. Pin 3 of AC2 is only used when this ATS is being
wired to a non-aXis ControllerTM HSB. In that scenario, Pin 1 and
Pin 3 of AC2 become the two-wire start signal for the non-axis
HSB and AC2 cannot be used to manage a load.
Settings on the aXis ControllerTM Module
1. On the aXis control board, set the two circular pots that
are located to the right of the DIP switches to match the
maximum power output of the generator for your fuel type.
1st pot (left pot) is 10’s value, 2nd pot (right pot) is 1’s value, do
not go over generator rating. If wattage rating of generator falls
between settings choose the next lower value; i.e. generator
rating is 12,500W, set pots to 1 and 2 for 12,000W.
NO
1 2 3 4 5 6 7 8 9 10 11 12
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE INSTALLATION
11
NOTICE
All DIP switches are set to ON by default from the factory.
2. Verify the DIP switches are set for your installation. Adjust as
needed.
DIP Switch Settings
Switch 1. Load Module 1 Lockout
–On= Load Module 1 is being managed. Load Module 1 is the
lowest priority of the 4 load modules. This load will be turned
off first as the ATS manages the home’s load.
–Off= Load module 1 will stay off during HSB power.
Switch 2. Load Module 2 Lockout
–On= Load Module 2 is being managed.
–Off= Load module 2 will stay off during HSB power.
Switch 3. Load Module 3 Lockout
–On= Load Module 3 is being managed.
–Off= Load module 3 will stay off during HSB power.
Switch 4. Load Module 4 Lockout
–On= Load Module 4 is being managed. Load Module 4 is the
highest priority of the 4 load modules. This load will be turned
off last as the ATS manages the homes load.
–Off= Load module 4 will stay off during HSB power.
Switch 5. Frequency Protection.
–On= All managed loads will be turned off when if the HSB
frequency drops below 58 Hz.
–Off= All managed loads will be turned off when if the HSB
frequency drops below 57 Hz.
Switch 6. Spare. Not used at this time. Switch position does not
matter.
Switch 7. Power Management
–On= ATS is managing the homes load.
–Off= ATS has disabled power management.
Switch 8. PLC vs. Two Wire Communication
–On= ATS will control HSB startup and shutdown through PLC.
This is the preferred method of communication however it
requires the HSB to be an aXis controlled HSB.
–Off= ATS will control the start of the HSB using the AC2 Relay.
In this setting the AC2 can not be used to manage a load. Pins
1 and 3 of the AC2 connector will be used for the HSB startup
signal.
Switch 9. Test HSB with Load
–On= Test occurs with load.
–Off= Test occurs without load.
Switch 10. Master/Slave
–On= This ATS is the primary or only ATS. <- most common.
–Off= This ATS is being controlled by a different aXis
controller™ ATS. Used for installations that require two ATS
boxes (i.e. 400A installations).
Switch 11. Exercise Test
–On= Exercise tests will occur per the schedule that is
programmed into the aXis controller.
–Off= Exercise tests are disabled.
Switch 12. Time delay for HSB to accept load.
–On= 45 seconds.
–Off= 7 seconds.
3. Have authorized utility personnel reconnect the utility meter
to the meter socket.
4. Verify voltage at utility circuit breaker.
5. Turn on utility circuit breaker.
6. ATS aXis ControllerTM module will begin boot up process.
Allow ATS aXis ControllerTM module to fully boot up
(approximately 6 minutes).
7. Home should be fully powered at this point.
WIFI Setup Method
1. Use a WiFi enabled device (laptop, smart phone, tablet, etc.)
in near proximity to the ATS.
2. Search and Connect to network name (SSID) “Champion
HSB”. The password for the network is located on a decal on
the deadfront of the ATS.
3. After connecting, open your device’s web browser. Many
times the Champion aXis ControllerTM Home Standby
Generator Settings Page will autoload however if that is not
the case, refresh the browser or change the web address to
anything.com. As your device attempts to reach the internet
the WiFi module in the ATS will redirect your browser to the
Champion aXis ControllerTM Home Standby Generator Settings
Page.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE INSTALLATION
12
4. On the Champion aXis ControllerTM Home Standby Generator
Settings Page, set the date and time. Use either the drop-
down boxes or the “USE THIS DEVICE’S DATE & TIME” button
to set the time and date. Confirm and Save the settings
before continuing.
5. Set the HSB exercise frequency and schedule. Confirm and
Save the settings before continuing.
6. Wireless network settings are not used at this time. The
default values (shown below) should not be adjusted.
7. The time, date, and exercise information have now been
setup for the aXis ATS and HSB. You can close your browser
and disconnect from the WIFI, or skip to step 2 in the next
section “ATS & HSB STATUS USING WIFI”.
ATS and HSB Status Using WIFI
1. Using a WIFI enabled device, connect to the “Champion HSB”
WIFI network following steps 1, 2, and 3 from WIFI Setup
Method.
2. After loading the Home Standby Generator Settings page,
locate and click the icon at the bottom right corner of the
page.
3. You are now viewing the ATS and HSB status page. Items
such as voltage, frequency, current, etc. can all be viewed
for both utility and HSB power. All of the information is
live. There are three tabs located at the top of the page.
ATS, GEN, and LMM. Each tab will display
the status for the Transfer Switch, Home Standby Generator,
or Load Management Module(s) respectively.
4. When finished viewing the status of the ATS, Generator, and
LMM, close your browser and disconnect from the WIFI.
Connecting the Load Management Systems
The following instructions pertain only to aXis ControllerTM Load
Management Modules (LMM) that use Power Line Carrier (PLC)
communication. If one or more LMM’s are being installed on the
home, install them per the installation instructions included with
the LMM before continuing.
Teaching System
After installation and wiring are complete teach the ATS which
loads are attached by the following procedure. Teaching the
system is only required if 1 or more LMM’s were installed OR if
AC1 OR if AC2 is being used to manage loads.
1. Turn Champion aXis ControllerTM ATS UTILITY circuit
breaker to the OFF position. Generator will start and run
automatically.
2. Confirm managed loads are all operating.
3. Press and hold the button marked “LEARN” for 8 seconds.
ATS will shutoff managed loads one at a time until all are OFF.
ATS will flash LED’s indicating function in process.
4. After ATS has learned all loads the LMM units will be returned
to normal operation.
5. Installation configuration is now held in memory and will not
be affected by power outage.

102006 - AUTOMATIC TRANSFER SWITCH WITH aXis CONTROLLER™ MODULE SPECIFICATIONS
13
6. Return UTILITY circuit breaker to the ON position. ATS will
transfer load back to utility and generator will cool down and
shut off.
7. Repeat this process if LMM units are added or removed from
the system.
NO
1 2 3 4 5 6 7 8 9 10 11 12
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
Full System Check
1. Open Utility breaker for full system test, close breaker after
confirming all systems working.
2. After Utility breaker opens engine will start automatically.
3. aXis ATS control panel will reboot on Generator power and
control switching of latching relays.
4. Home is now powered by Generator. If Load Management
modules (LMM) have been installed, they will become active
after 5 minutes.
5. Close Utility breaker
6. System is now fully functional.
7. Replace the deadfront by sliding it from the bottom up
into the cabinet; panel should index into the door latch
protrusions. Secure it to the deadfront bracket with included
nut and stud.
8. Replace the door and secure with included hardware. It is
recommended to secure the door with a lock.
9. Return to HSB and verify the controller is in “AUTO” mode.
Confirm icons indicate Utility power is active, Utility side relay
is closed, and home is receiving power.
10. Close and lock HSB hoods return keys to customer.
NEMA 1 – This type of enclosed ATS is for indoor installations
only.
NEMA 3R – This type of enclosed ATS is similar to the indoor box,
except that it is a weatherproof enclosure and required for exterior
installations by code. The enclosure only has knockouts on the
bottom side for the enclosure, requires water tight fasteners/
grommets when installed outside per code. This enclosure can
also be used inside.
SPECIFICATIONS
aXis ControllerTM Module Automatic
Transfer Switch
Model Number................................................................ 102006
Enclosure Style ...............................................NEMA 3R outdoor
Maximum Amps ................................................................... 200
Nominal Volts ................................................................ 120/240
Load Management Circuits ....................................................... 4
Weight................................................................ 43 lbs (19.6 kg)
Height .................................................................28 in. (710mm)
Width ..................................................................20 in. (507mm)
Depth .................................................................8.3 in. (210mm)
Technical Specifications
–22kAIC, no short-time current rating.
–Suitable for use in accordance with the National Electrical
Code, NFPA 70.
–Suitable for control of motors, electrical discharge lamps,
tungsten filament lamps, and electrical heating equipment,
where the sum of the motor full load ampere ratings and the
ampere ratings of the other loads does not exceed the ampere
rating of the switch, and the tungsten load does not exceed
30% of the switch rating.
–Continuous load not to exceed 80% of switch rating.
–Line voltage wiring: Cu or AL, min 60°C, min AWG 1 – max
AWG 000, torque to 250 in-lb.
–Signal or Com Wiring: Cu only, min AWG 22 – max AWG 12,
torque to 28-32 in-oz.
WARRANTY
Each Champion transfer switch or accessory is guaranteed against
mechanical or electrical failure due to manufacturing defects
for a period of 24 months following shipment from the factory.
The manufacturer’s responsibility during this warranty period
is limited to repair or replacement, free of charge, of products
proving defective under normal use or service when returned to
the factory, transportation charges prepaid. Guarantee is void
on products that have been subjected to improper installation,
misuse, alteration, abuse or unauthorized repair. The manufacturer
makes no warranty with respect to the fitness of any goods for
a user’s particular application and assumes no responsibility for
proper selection and installation of its products. This warranty is
in lieu of all other warranties, expressed or implied, and limits the
manufacturer’s liability for damages to the cost of the product.
This warranty gives you specific legal rights, and you may have
other rights, which vary from state to state.

WARRANTY*
CHAMPION POWER EQUIPMENT
2 YEAR LIMITED WARRANTY
Warranty Qualifications
To register your product for warranty and FREE lifetime call center
technical support please visit:
https://www.championpowerequipment.com/register
To complete registration you will need to include a copy of the
purchase receipt as proof of original purchase. Proof of purchase
is required for warranty service. Please register within ten (10)
days from date of purchase.
Repair/Replacement Warranty
CPE warrants to the original purchaser that the mechanical and
electrical components will be free of defects in material and
workmanship for a period of two years (parts and labor) from
the original date of purchase and 180 days (parts and labor) for
commercial and industrial use. Transportation charges on product
submitted for repair or replacement under this warranty are the
sole responsibility of the purchaser. This warranty only applies to
the original purchaser and is not transferable.
Do Not Return The Unit To The Place Of
Purchase
Contact CPE’s Technical Service and CPE will troubleshoot any
issue via phone or e-mail. If the problem is not corrected by
this method, CPE will, at its option, authorize evaluation, repair
or replacement of the defective part or component at a CPE
Service Center. CPE will provide you with a case number for
warranty service. Please keep it for future reference. Repairs or
replacements without prior authorization, or at an unauthorized
repair facility, will not be covered by this warranty.
Warranty Exclusions
This warranty does not cover the following repairs and equipment:
Normal Wear
Products with mechanical and electrical components need
periodic parts and service to perform well. This warranty does not
cover repair when normal use has exhausted the life of a part or
the equipment as a whole.
Installation, Use and Maintenance
This warranty will not apply to parts and/or labor if the product is
deemed to have been misused, neglected, involved in an accident,
abused, loaded beyond the product’s limits, modified, installed
improperly or connected incorrectly to any electrical component.
Normal maintenance is not covered by this warranty and is not
required to be performed at a facility or by a person authorized by
CPE.
Other Exclusions
This warranty excludes:
–Cosmetic defects such as paint, decals, etc.
–Wear items such as filter elements, o-rings, etc.
–Accessory parts such as storage covers.
–Failures due to acts of God and other force majeure events
beyond the manufacturer’s control.
–Problems caused by parts that are not original Champion
Power Equipment parts.
Limits of Implied Warranty and
Consequential Damage
Champion Power Equipment disclaims any obligation to cover
any loss of time, use of this product, freight, or any incidental
or consequential claim by anyone from using this product. THIS
WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
A unit provided as an exchange will be subject to the warranty
of the original unit. The length of the warranty governing the
exchanged unit will remain calculated by reference to the purchase
date of the original unit.
This warranty gives you certain legal rights which may change
from state to state or province to province. Your state or province
may also have other rights you may be entitled to that are not
listed within this warranty.
Contact Information
Address
Champion Power Equipment, Inc.
12039 Smith Ave.
Santa Fe Springs, CA 90670 USA
www.championpowerequipment.com
Customer Service
Toll Free: 1-877-338-0999
[e-mail]
Fax no.: 1-562-236-9429
Technical Service
Toll Free: 1-877-338-0999
[e-mail]
24/7 Tech Support: 1-562-204-1188
