Champion EUCC4 User manual

STANDARD FEATURES
•Exclusive Dual Rinse Technology
• All-purpose 24”-wide peg belt
• Dish capacities up to 16,495 dishes per hour (NSF Listed)
• Automatic tank fill
• Chemical dispensing equipment
connection provisions
• Choice of tank heat: electric, steam
coils or direct steam injectors
• Common hot water connection
• Common drain connection
• Common electric connection
(separate connection required for
optional electric booster and blower-dryer)
• One piece stainless steel wash/rinse
manifold system, easy to remove
• Door safety switch
• Electric eye energy sentinel (idle pump shut-off)
• Easy-to-reach top-mounted controls
• Heavy-gauge stainless construction
• Low-water tank heat protection
• Push-button start-stop station – load end
• Recirculating flushing nozzles – load end with prewash
• Rinse saver device
• Conveyor shut-off shelf – unload end
• Stainless steel enclosure panels – front & ends
(3M) 6/07 Printed in U.S.A.
CH089
Upright 24” Conveyor
Dual Rinse Dishwashing Machine
EUCC SERIES
EUCC SERIES UPRIGHT CONVEYORS
SPECIFIER STATEMENT
Specified unit will be Champion model EUCC4,
EUCC6 or EUCC8 upright 24” conveyor water
saver dishwashing machine.
Features automatic tank fill, chemical dispensing
connection provisions, common water, drain and
electrical connections, door safety switch, low
water tank heat protection, rinse saver.
1 year parts and labor warranty.
A compact footprint that also reduces energy
consumption by more than 58%
Champion Industries, Inc.
P. O. Box 4149, Winston-Salem, NC 27115
Tel: [phone] Fax: [phone]
www.championindustries.com
2674 N. Service Road,
Jordan Station, Ontario, Canada L0R 1S0
Tel: [phone] Fax: [phone]
Project
Item No.
Quantity
The DualRinse feature offers the
Lowest Water/Utility/Chemical Consumption
as low as 113 GPH usage while circulating
as much as 410+ gallons of water for
Consistently Good Results

Upright 24” Conveyor
Dual Rinse
Dishwashing Machine
EUCC SERIES
Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: [phone]
Booster connections may vary. Contact the Factory.
Standard Voltages (Specify choice): 208/60/3, 240/60/3, and
480/60/3. Available in 3-phase only. For non-standard 3-phase voltages,
contact the Factory.
Plumbing Notes Because of the variation in house-supplied water
pressure, a water pressure regulating valve (PRV) is needed (water
PRV is standard). Steam PRV’s may be required for pressure higher
than 30 psi. The PRVs can either be purchased from Champion or
obtained locally.
Warning Plumbing and electrical connections should be made by
qualified personnel who will observe all the applicable plumbing,
sanitary, safety codes and the National Electrical Code.
Note Water Hammer Arrestor (meeting ASSE-1010 standard or
equivalent) to be supplied (by others) in common water supply line
at service connection.
Venting Notes
Fabricated duct size: 3-7/8” x 23-7/8” (outside dimensions)
Utilities EUCC4
1 Electrical
Contact factory for specific machine electrical requirements
NOTE: Electric booster connection – contact Factory
2 Hot Water
3/4” NPT 180°F hot water connection.
(For machine without built-in booster)
3 Drain
2” NPT connection
4 Vents
A Load end: 300 CFM 1/4” S.P.
B Unload end: 800 CFM 1/4” S.P. With blower-dryer,
increase room ventilation by 600 CFM.
Utilities EUCC6
1 Electrical
Contact factory for specific machine electrical requirements
NOTE: Electric booster connection – contact Factory
2 Hot Water
3/4” NPT 180°F hot water connection.
(For machine without built-in booster)
3 Drain
2” NPT connection
4 Vents
A Load end: 300 CFM 1/4” S.P.
B Unload end: 800 CFM 1/4” S.P. With blower-dryer,
increase room ventilation by 600 CFM.
Utilities EUCC8
1 Electrical
Contact factory for specific machine electrical requirements
NOTE: Electric booster connection – contact Factory
2 Hot Water
3/4” NPT 180°F hot water connection.
(For machine without built-in booster)
3 Drain
2” NPT connection
4 Vents
A Load end: 300 CFM 1/4” S.P.
B Unload end: 800 CFM 1/4” S.P. With blower-dryer,
increase room ventilation by 600 CFM.
SPECIFICATIONS
Capacities EUCC4 EUCC6 EUCC8
Dishes per hr. (NSF rated) 10,472 13,221 16,495
Conveyor speed (ft./min.) 8.0 10.1 12.6
Motor horsepower
Drive 1/2 Hp 1/2 Hp 1/2 Hp
Prewash 30” [762] 1 Hp 1 Hp 1 Hp
Prewash 48” [1219] 3 Hp 3 Hp 3 Hp
Wash 3 Hp 3 Hp 3 Hp
Power Rinse* N/A 3 Hp 3 Hp
Auxiliary Rinse 1/5 Hp 1/5 Hp 1/5 Hp
Water consumption
Gal. per hr. (max. use) 115 113 141
Temperatures °F
Wash (min.) 160 150 150
Power Rinse (min.)* N/A 160 160
Auxiliary Rinse (min.) 165 165 165
Final rinse (min.) 180 180 180
Heating
Tank heat Steam Electric
Wash tank 125 lbs./hr. 25 kW
Rinse tank * 100 lbs./hr. 20 kW
Auxiliary rinse 50 lbs./hr. 10 kW
Electric booster 15 15 16
(kW required for 40°F rise)
Electric booster 25 25 28
(kW required for 70°F rise)
Steam booster 75 75 80
(lbs./hr. required for 40°F rise)
Steam booster 125 125 135
(lbs./hr. required for 70°F rise)
Venting
Minimum cfm, load end 300
Minimum cfm, unload end 800
*EUCC4 has no power rinse tank
Shipping weight crated: 150 lbs./ft.[68kg./m.]
Height with doors up: 95”
Height to remove doors: 100”

4'
[102]
1'-10"
[559]
2'-1"
[635]
9'-4" CL-CL
[2845]
5'-8"
[1727]
33-5/8"
[854]
6-1/4" [159]
6" [152]
36" [914]
4'
[1219]
[102]
4"
5-1/2" [140]
1-5/8"
[41]
38" [965]
12" [305]
Plumbing
Clearance
100" [2540]
Door
Removal
95" [2413]
Doors Up
24" [610]
Clearance
Overall Length “C”
7" [179]
CL
CL
7" [179]
4"
"A"
Load
4'
Wash
“B”
Unload
19" [483]
Clearance
62" [2337]
Machine
Height
10-1/2"
[267]
16" [406]
9-3/8" [238]
32"
2'
[610] 2'-6" [762]
2
2
4A
3
1
4B
4B 4A
1
3
Start/Stop
HP
3 1
HP
HP
0.2
1/2 HP
Plumbing
Clearance
Wash PrewashFinal
Rinse
Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: [phone]
Upright 24” Conveyor
Dual Rinse
Dishwashing Machine
EUCC SERIES
EUCC4
MODULAR SECTIONS: Right to Left Operation
Notes:Load Section (A) Standard
5 ft , contains 30” Prewash
Prewash also available in a
48” HD section Non-standard
load section available in
12” increments
Minimum load length 5ft
(includes 30” prewash)
Unload Section (B)
Standard 5 ft contains 24” Aux.
Rinse available in 12” increments
Built in electric booster requires
a 5 ft minimum unload
Built in steam booster requires
a mininum 6 ft unload
Blow dryer section adds 4ft to
overall length of machine
TABLE B - Booster Connection
40°F/22°C Rise – 15 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 42 60 60
240/60/3 36 45 45
480/60/3 18 25 25
Machine Only - Electric Heat
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 119 150 150
240/60/3 102 150 150
480/60/3 52 70 70
TABLE A - Machine Connection
Machine-steam
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 21 25 25
240/60/3 18 25 25
480/60/3 10 15 15
70°F/39°C Rise – 25 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 70 90 90
240/60/3 60 80 80
480/60/3 30 40 40
Contact Factory for additional voltages.
Dimensions shown in inches and [millimeters]

Dimensions shown in inches and [millimeters]
Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: [phone]
Upright 24” Conveyor
Dual Rinse
Dishwashing Machine
EUCC SERIES
EUCC6
MODULAR SECTIONS: Right to Left Operation
4'
1'-10"
2'-1"
11'-4" CL-CL
[3454]
5'-8"
6-1/4
"
6"
4"
OVERALL LENGTH “C”
CL
CL
4"
“A”
Load
6' [1829]
Wash/Rinse
“B”
Unload
62" Machine
Height
12"
3'
[914]
33-5/8"
16"
24"
Clearance 32"
13-5/8"
1-5/8"
[41
3'
[914]
2'-6"
[762]
[610]
2'
Plumbing
Clearance
12" [305]
100" [2540]
Door
Removal
95" [2413]
Doors
Up
19" [483]
Clear
38" [965]
10-1/2"
[267]
36" [914]
7" [179] 7" [179]
5-1/2" [140]
[102] [102]
2
2
4A
3
1
4B
4B 4A
1
3
Start/Stop
HP
3
HP
3 1
HPHP
0.2
1/2 HP
Plumbing
Clearance
Power
Rinse Prewash
Final
Rinse Wash
Notes:Load Section (A) Standard
5 ft , contains 30” Prewash
Prewash also available
in a 48” HD section
Non-standard load section
available in 12” increments
Minimum load length 5ft
(includes 30” prewash)
Unload Section (B)
Standard 5 ft contains 24” Aux.
Rinse available in 12” increments
Built in electric booster requires
a 5 ft minimum unload
Built in steam booster requires
a mininum 6 ft unload
Blow dryer section adds 4ft to
overall length of machine
TABLE B - Booster Connection
40°F/22°C Rise – 15 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 42 60 60
240/60/3 36 45 45
480/60/3 18 25 25
Machine Only - Electric Heat
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 183 250 250
240/60/3 158 200 200
480/60/3 80 100 100
TABLE A - Machine Connection
Machine-steam
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 29 40 40
240/60/3 26 35 35
480/60/3 14 20 20
70°F/39°C Rise – 25 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 70 90 90
240/60/3 60 80 80
480/60/3 30 40 40
Contact Factory for additional voltages.

Due to an ongoing value analysis program at Champion, specifications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: [phone]
Upright 24” Conveyor
Dual Rinse
Dishwashing Machine
EUCC SERIES
EUCC8
MODULAR SECTIONS: Right to Left Operation
4'
[102]
1'-10"
[559]
2'-1"
[635]
13'-4" [4064] CL-CL
33-5/8"
[854]
6" [152]
36" [914]
4'4'
4"
[102][102] [1219][1219][610]
1-5/8"
[41]
38" [965]
Plumbing
Clearance
Plumbing
Clearance
12" [305]
100" [2540]
Door
Removal
95" [2413]
Doors
Up
92" [2337]
Machine
Height
24" [610]
Clear
Overall Length “C”
7" [179]7" [179]
CL
CL
4"
“A”
Load
8' [2438]
Wash/Rinse
“B”
Unload
19" [483]
Clear
10-1/2"
[267]
16" [406]
32"
2' 2'-6"
[762]
5-1/2" [140]
9-3/8" [238]
6-1/4" [159]
5'-8" [1727]
2
2
4A
3
1
4B
4B 4A
1
3
Start/Stop
HP
3
HP
31
HP
HP
0.2
1/2 HP
Wash Prewash
Final
Rinse Power Rinse
Notes:Load Section (A) Standard 5 ft ,
contains 30” Prewash
Prewash also available in a
48” HD section Non-standard
load section available in 12”
increments Minimum load
length 5ft (includes 30” prewash)
Unload Section (B)
Standard 5 ft contains 24” Aux.
Rinse available in 12” increments
Built in electric booster requires
a 5 ft minimum unload
Built in steam booster requires
a mininum 6 ft unload
Blow dryer section adds 4ft to
overall length of machine
Machine Only - Electric Heat
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 183 250 250
240/60/3 158 200 200
480/60/3 80 100 100
TABLE A - Machine Connection
TABLE B - Booster Connection
40°F/22°C Rise – 16 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 44 60 60
240/60/3 38 50 50
480/60/3 19 25 25
Machine-steam
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 29 40 40
240/60/3 26 35 35
480/60/3 14 20 20
70°F/39°C Rise – 28 kW
Electric built-in booster
Minimum Maximum
Supply Ckt. Overcurrent
Elec. Rated Conductor Protective
Specs. Amps Ampacity Device
208/60/3 77 100 100
240/60/3 67 90 90
480/60/3 34 45 45
Contact Factory for additional voltages.
Dimensions shown in inches and [millimeters]

Upright 24” Conveyor
Dual Rinse
Dishwashing Machine
EUCC SERIES
EUCC8 UPRIGHT CONVEYOR
Due to an ongoing value analysis program at Champion, specications contained in this catalog are subject to change without notice.
Champion Industries, Inc., P. O. Box 4149, Winston-Salem, NC 27115 • 336/661-1556 • Fax: [phone] • www.championindustries.com
2674 N. Service Road, Jordan Station, Ontario, Canada L0R 1S0 • 905/562-4195 • Fax: [phone]
OPTIONS & ACCESSORIES
Tank heat; choices of electric, steam coil or steam injectors
Booster Heaters – stainless steel
(completely inter-plumbed, controls are inter-wired)
Electric: (40°F rise or 70°F rise)
Steam: (40°F or 70°F rise)
Blower Dryer, electric or steam (add 4’ to overall length)
Belts: standard peg belt, at belt, thermal tray belt,
silverware belt, belts with upper cross rods, and other
select combination belts
Start/Stop station, unload end
Back panels, stainless steel
Conveyor, variable speed, electric
Cold water thermostat (for pre-wash)
External scrap bucket on 48” pre-wash
(standard on 30” pre-wash)
External scrap bucket on wash tank
Insulated hoods, lower panels
Motor pumps, 2 or 3 Hp optional in lieu of 1 Hp on pre-wash
Bumper rail, machine mounted
Steam pressure regulating valve (unmounted)
Drain water tempering kit (unmounted)
Vent fan control switch
Drain interlocks
Isolation switches for motors and/or electric tank heat
Fused disconnect switch for machine and/or booster
