Champion D-HBM5 Manual

Door-type
Dishwasher
D-HBM5
High Temperature with
Built-in Booster Heater
Champion Industries, INC.
3765 Champion Boulevard, Winston-Sale, NC 27105
P.O. Box 4149 Winston-Salem, NC 27115-4149
1-800 232-8591 Fax: [phone]
Installation/Operation Manual with Service Replacement Parts
Issued 5.26.10
Manual P/N 113491 rev. J
For machines beginning with S/N D3694 and above
Models:
D-H1M5
High Temperature
Printed in U.S.A.
2674 N. Service Road, Jordan Station
Ontario, Canada L0R 1S0
1-800 263-5798 Fax: [phone]
www.championindustries.com
D-LFM5
Low Temperature

COPYRIGHT © 2010 All rights reserved Printed in the USA
For future reference, record your dishwasher information in the box below.
Model Number__________________________ Serial Number_______________________
Voltage________________Hertz_____________ Phase__________________
Service Agent __________________________________ Tel:______________________
Parts Distributor _________________________________ Tel:______________________
ATTENTION:
The model no., serial no., voltage, Hz
and phase are needed to identify your
machine and to answer questions.
The machine data plate is located
on the front panel of the machine
Please have this information ready
if you call for service assistance.
National Service Department
In Canada: In the USA:
Toll-free: 800/ 263-5798 Toll-free: 800/ 858-4477
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
email: [email protected] email: [email protected]
The USGBC and the CaGBC Member Logos are trademarks owned by the U.S. Green Building Council and The Canadian Green
Building Council, respectively, and are used by permission. The logos signify only that Champion Industries and Moyer Diebel
are a USGBC member and a CaGBC member respectively. USGBC and CaGBC do not review, certify nor endorse the products
or services offered by its members.

ATTENTION:
Complete the back of the POSTAGE PAID WARRANTY CARD below, then cut along
the dashed lines and mail immediately to make sure that your machine warranty is validated.
USE CANADIAN WARRANTY CARD IN CANADA AND USA WARRANTY CARD IN THE UNITED STATES.
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO. 2101 WINSTON-SALEM, NC
POSTAGE WILL BE PAID BY ADDRESSEE
CHAMPION INDUSTRIES INC
PO BOX 4149
WINSTON-SALEM, NC 27119-0981

IMPORTANT IMPORTANT
Model Serial #
Date of Installation:
Company Name:
Telephone #: ( ) ---
Contact:
Address:
Address:
Telephone #:
Contact:
Installation Company:
(Street) State or Province Zip Code
This Card Must Be Returned to Validate Machine Warranty:
WARRANTY REGISTRATION CARD
IMPORTANT IMPORTANT
Model Serial #
Date of Installation:
Company Name:
Telephone #: ( ) ---
Contact:
Address:
Address:
Telephone #:
Contact:
Installation Company:
(Street) State or Province Zip Code
This Card Must Be Returned to Validate Machine Warranty:
WARRANTY REGISTRATION CARD

i
Revision Date Pages Serial No. Effectivity Description
Revision History
Revision History
6.1.02 All D3694 ReleaseofFirstEdition
10.18.02 11 D3858 Revisedcycletimes
10.18.02 36,37 D3858 RevisedrinsearmbearingP/N's
   Bearing112164replacedby
   113514,0707453replacedby
   414111.
10.18.02 37 D3858 AddednewrinsearmP/N414110
   forDHB/DH1and414111forDLF.
10.18.02 39 D3851 AddedwaterdeectorP/N327283.
10.24.02 47 D3700 AddedbushingP/N100171.
10.24.02 55 D3858 Addednewtimerbd.P/N113547.
12.18.02 55 D3858 Addedtimerbd.kitP/N900911
   toconvertbds.toP/N113597.
2.5.03 27 _____ ReplacedP/N108391w/113622.
2.5.03 55 _____ Vendorchangeforoverloads
   SquareDinplaceofSiemans.
2.3.04 44-45 D4237 AddedPRVandlinestrainer
3.5.04 68 D4410 UpdateschematictoRev.I
3.5.04 55 D4410 Changeddoorsafetyswitch
   P/N112659toP/N113721.
6.21.04 35 -------- Addedrinsesupportbracket
   P/N0309149.
Arevisionmightbeapartnumberchange,newinstructions,orinformationthatwasnotavailable
atthetimeofprinting.Wereservetherighttomakechangestothismanualwithoutnoticeand
withoutincurringanyliabilitybymakingchanges.Dishwasherownersmayrequestarevised
manualatnochargebycalling(800)858-4477intheUSAor(800)263-5798inCanada.
7.22.03 27 _____ ReplacedP/N112090with113644
   &112086with113662.
7.22.03 43 D3982 Replaced110562with113604.
7.22.03 47,51 ---------- ReplacedplasticV.BrkwithBronze.
