Changhong Electric LED32E2200ST2 User manual

TV
Operation Manual
Tel: [phone]
Fax: [phone]
Service E-mail: [email protected]
CHANGHONG EUROPE ELECTRIC S.R.O.
Argentinská 286/38, 170 00 Praha 7, Czech Republic
Http: //www.changhong.eu
FR
Z
I
EN
SK
T
C
DE C
H
AT/
()
()
ES
Model: LED32E2200ST2

Contents
Safety instructions…………………………………….....…………............................4
Main Unit Control....................................................................................................6
Getting Started………………………..……………...………………..….….................9
Remote Control.…………………………………………………................................10
Basic Operation....................................................................................................12
Turning on and off the TV.....................................................................................12
Choosing a TV channel.........................................................................................14
Changing the input source....................................................................................14
Channel menu.......................................................................................................15
Sound menu..........................................................................................................20
Picture menu.........................................................................................................19
Hotel mode............................................................................................................22
Lock menu.............................................................................................................21
Setup menu...........................................................................................................23
Screen menu.........................................................................................................24
Channel List..........................................................................................................28
Teletext...................................................................................................................29
Media Operation....................................................................................................24
7 Day TV GUIDE.........…………………………………………………………….......28
Favorite List...........................................................................................................28
Warning...........................…....................…………………...….....................….........1
Connection and Setup............................................................................................7
Using the Remote Control........…………………...........…………............................9
Installing Batteries in the Remote Control……..……………..……...........................9
Battery Replacement...........……………………………………….…….....................9
Volume adjustment................................................................................................14
Menu Operation.....................................................................................................15
How to Navigate Menus........................................................................................15
Time menu............................................................................................................20
Important Unique Buttons....................................................................................28
E
ngli
sh
First Time Installation............................................................................................12
Troubleshooting.....................................................................................................30
Troubleshooting Guide……..………..............................………………..…..…......30
Maintenance..........................................................................................................31

Warning
DEAR CUSTOMER:
Before operating, please read all these safety and operating instructions completely and
then retain this manual for future reference.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
REGULATORY INFORMATION
This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
a. Relocate the receiving antenna.
b. Increase the separation between the equipment and receiver.
c. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
d. Consult the dealer or experienced radio/TV technician for help.
CAUTION
※DO not attempt to modify this product in any way without written authorization
from supplier. Unauthorized modification could void the user's authority to operate
this product.
※Figures and illustrations in this User Manual are provided for reference only and
may differ from actual product appearance. Product design and specifications may be
changed without notice.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sufficient magnitude to constitute
a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
E
nglish
1

Warning
IMPORTANT WARNINGS AND CAUTIONS!
Electrical energy can perform many useful functions, but it can also cause
personal injuries and property damage if improperly handled. This product has
been engineered and manufactured with the highest priority on safety. BUT
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order to prevent potential danger, please observe the following
instructions when installing, operating and cleaning the product.
1. Attachments---Only use attachments/accessories specified by the manufacturer. Do
not use attachments not recommended by the manufacturer. Use of improper
attachments can result in accidents.
2. Water---Apparatus should not be exposed to dripping or splashing, and objects filled
with liquids, such as vases, should not be placed on the apparatus.
To reduce the risk of fire and electric shock, do not expose this product to rain or
moisture.
3. Fire or explosion---Do not use or store flammable or combustible materials near the
unit. Doing so may result in fire or explosion. Do not place any naked flame sources,
such as lit candles, cigarettes or incense sticks on top of the TV set.
4. Ventilation---When you install your TV, maintain a distance of at least 4 inches
between the TV and other objects (walls, cabinet sides, etc.) to ensure proper
ventilation. Failing to maintain proper ventilation may result in a fire or a problem with
the product caused by an increase in its internal temperature.
5.
This equipment is a Class Ⅱor double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
6. Power source---This product is intended to be supplied by a listed power supply
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company.
7. Overloading---Do not overload wall outlets, extension cables, or convenience
receptacles on other equipment as this can result in a risk of fire or electric shock.
8. Voltage---Before installing this TV set, make sure your outlet voltage corresponds to
the voltage stated on the appliance rating label.
9. Power plug --- Do not defeat the safety purpose of the polarized or grounding-type
plug. Most appliances recommend they be placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that appliance and has no additional outlets or
branch circuits.
E
ngli
sh
2

Warning
11. Wall mounting---When mounting the product on a wall, be sure to install the product
according to the method recommended by the manufacturer. This is a safety feature.
12. Stand--- Do not place the product on an unstable trolley, stand, tripod or table. Placing
the product on an unstable base can cause the product to fall, resulting in serious
personal injuries as well as damage to the product.
Always place the TV on furniture that can safely support the TV. Make sure the ends of
the TV do not overhang the edge of the supporting furniture.
13. Entering of objects and liquids---Never insert an object into the product through
vents or openings. High voltage flows in the product, and inserting an object can cause
electric shock and/or short internal parts. For the same reason, do not spill water or
liquid on the product.
14. Damage requiring service--- This unit should only be serviced by an authorized and
properly trained technician. Opening the cover or other attempts by the user to service
this unit may result in serious injury or death from electrical shock, and may increase
the risk of fire.
15. Replacement parts---In case the product needs replacement parts, make sure that the
service person uses replacement parts specified by the manufacturer, or those with the
same characteristics and performance as the original parts. Use of unauthorized parts
can result in fire, electric shock and/or other danger.
16. Safety checks---Upon completion of service or repair work, request the service
technician to perform safety checks to ensure that the product is in proper operating
condition.
17. Children ---Do not allow young children to play with the plastic bag that came with the
television when you unpacked it. Failure to do so can result in suffocation, causing
injury.
18. Batteries---The batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
19. Antenna ---Install the antenna away from high-voltage power lines and communication
cables and make sure it is installed securely. If the antenna touches a power line,
contact with the antenna could result in fire, electric shock or serious injury.
20. Panel protection--- The panel used in this product is made of glass. Therefore, it can
break when the product is dropped or impacted upon by other objects. Be careful not to
be injured by broken glass pieces in case the panel breaks.
21. Operating Temperature: 5℃to 35℃Operating Humidity: ≤80%
Storage Temperature: -15℃to 45℃Storage Humidity: ≤90%
10. The MAINS plug of the apparatus is used as the disconnect device, the disconnect
device shall remain readily operable.
E
nglish
3

Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
7. Do not block any ventilation
openings. Ventilation should not be
impeded by covering the ventilation
openings with items such as
newspapers, table-cloths, curtains
etc.
5. Do not use this apparatus near water.
8. Do not install near any heat source
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
6. Clean only with a dry cloth. Unplug this
product from the wall outlet before
cleaning. Do not use liquid cleaners or
aerosol cleaners.
9. Do not defeat the safety purpose of
the polarized or grounding type plug.
A polarized plug has two blades with
one wider than other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong is provided for your
safety. When the provided plug does
not fit into your outlet, consult an
electrician for replacement of the
obsolete outlet.
E
ngli
sh
4

Safety Instructions
NOTE:
※Disposal of this product must be carried out in accordance to the regulations of
your local authority. Do not dispose of this product with general household
waste disposal.
※Occasionally, a few non-active pixels may appear on the screen as a fixed
point of blue, green or red. Please note that this does not affect the
performance of your product.
※Avoid touching the screen or holding your finger(s) against it for long periods of
time. Doing so may produce some temporary distortion effect on the screen.
※It is not recommended to keep a certain still image displayed on the screen for
a long time as well as displaying extremely bright images on screen, reduce the
„brightness‟ and „contrast‟ when displaying still images.
10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles,
and the point where they exit from
the apparatus.
13. For added protection for this
product during a lightning storm, or
when it is left unattended and
unused for long periods of time,
unplug it from the wall outlet and
disconnect the cable system.
11. Educate children about the dangers
of climbing on furniture to reach TV
controls.
14. Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such as
power supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
12. When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from
tip-over. Sudden stops, excessive
force and uneven floor surfaces can
cause the product to fall from the
trolley.
E
nglish
5

Main Unit Control
Rear & Sides Panel
Front Panel
Power Indicator
Infrared sensor /
Adjust the volume level.
:
:
: It turns on and off the TV. / Opens and closes the menu.
:
/
Change channels.
The navigation key; It turns on the TV.
E
ngli
sh
7
8
9
10
SCART
PC PC AUDIO
COMMON INTERFACE
AV/YPbPr_R/L
DIGITAL
1 2 4
3
5
6
4
AUDIO
OUT
HDMI1(ARC)
ANT2 ANT1
6

E
nglish
Connection and Setup
Connection Installation
antenna signals or closed circuit TV signals.
DVD player, digital TV set, etc.).HDMI is also called as high definition multimedia
interface, and it can transmit digital audio and video signal with one cable.
NOTE:
While connecting the HDMI, please aim at carefully, do not insert overexertedly,
for fear the pin might be broken.
equipment via the Digital Audio Output port.
the TV through AV cable.
connected with the COMPONENT(YPbPr) input port of the TV through AV cable.
NOTE:
Both Audio signals of AV and COMPONENT are input from "R - Audio - L".
If COMPONENT (YPbPr) and AV works as mini terminal, and shared same audio,
Please choose to use a one-to-three audio &video cable.
:Connect it to your headphone or other audio equipment.
NOTE:
The range of power input for the TV is 100-240V~ 50/60Hz; Do not connect the
TV power input port with the power cable out of the above range.
other end of the VGA cable with the VGA port on the TV, and tighten the bolts
clockwise on the each end of VGA cable.
NOTE:
While connecting the 15-pin VGA, please do not insert the plug overexerted, for
fear the pin might be broken.
jacks.
7
1. PC: Connect one end of the VGA cable with the VGA port on computer, connect the
2. SCART: Connect SCART socket input or output from an external device to these
3. ANT(1,2): Used to connect the antenna or the cable TV network, and receive outdoor
4. HDMI(1,2,3): Support AV devices with an HDMI connector (such as set top box,
5. DIGITAL AUDIO OUT: Sending the TV's digital audio signal to external audio
6.AV IN: The output AV terminal of DVD can be connected with the AV input port of
7. COMPONENT(YPbPr):The output COMPONENT(YPbPr) terminal of DVD can be
8. CI: Please insert CI card into the PCMCIA slot according to the arrow on the CI card.
9. USB: USB port, used to connect USB devices, such as USB Disk.
10.
11.Connect the power cable with 100-240V~ power supply.

Connection and Setup
Connection Suggestions
NOTE:
※Before connecting to an external device, please firstly make sure that the TV
set and the external device have been turned off. When connecting, please
make reference to the interface name and the interface color to connect the
signal cable.
※Please hold the insulated part of the plug when you are unplugging the power
cable, do not touch directly the metallic part of the cable.
E
ngli
sh
Computer
SPDIF
The equipment with
HDMI output function
Earphone
RF Coaxial
Wire(75 ohm)
USB Drive
The equipment with
HDMI output function
The equipment with
Component
output function
The equipment with
AV output function
(such as VCR, DVD,
set-topboxes ,etc.)
Video
Audio L
Audio R
Yellow
White
Red
Red
Blue
Green
Pr/Cr
Pb/Cb
Y
Audio L
White
Audio R
Red
COMMON INTERFACE
CI
Dispositivo con
DVD, video game
ecc.)
presa SCART
(esempio VCR,
Satellite
PC AUDIO HDMI1(ARC)
OUT
DIGITAL
AUDIO
AV/YPbPr_R/L
8

Getting Started
When using the remote control, aim it at remote sensor on the television. If there is an
object between the remote control and the remote sensor on the unit, the unit may not
operate.
Point the remote control at the REMOTE SENSOR located on the television.
When using this television in a very brightly lit area, the infrared REMOTE CONTROL
SENSOR may not work properly.
The recommended effective distance for using the remote control is about 7 meters.
1. Open the cover at the back of the remote control.
2. Install two AAA size batteries. Make sure to match
the “+”and “-”ends of the batteries with the
diagram inside the compartment.
3. Replace the cover.
You will need to install the batteries into the remote control to make it operate following
the instruction below.
When the batteries become weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the batteries.
Notes on Using Batteries:
The use of the wrong type of batteries may cause chemical leakage and/or explosion.
Please note the following:
Always ensure that the batteries are inserted with the + and - terminals in the correct
direction as shown in the battery compartment.
Different types of batteries have different characteristics. Do not mix different types.
Do not mix old and new batteries. Mixing old and new batteries will shorten battery
life and/or cause chemical leakage.
Replace batteries as soon as they do not work.
Chemicals which leak from batteries may cause skin irritation. If any chemical matter
seeps out of the batteries, wipe it up immediately with a dry cloth.
The batteries may have a shorter life expectancy due to storage conditions. Remove
the batteries whenever you anticipate that the remote control will not be used for an
extended period.
The batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
CAUTION:
It may result in an explosion if batteries are replaced incorrectly.
Only replace batteries with the same or equivalent type.
Installing Batteries in the Remote Control
Battery Replacement
Using the Remote Control
E
nglish
9

Remote Control
The buttons of the original remote control are as following:
Definition of the buttons on remote control:
1. :Power, switch on or off TV set.
2. INFO: display the current program
information on the screen. :Go to the
index page.
3. :Mute or restore sound.
4. NUMBER BUTTONS: Choose channels
or password importation.
5. SOURCE: Press to select signal source.
:Reveal the hidden information of
some teletext pages.
6. AUDIO(∞I/II): The button can be used to
switch between NICAM DUALⅠ/ NICAM
DUALⅡ/ DUALⅠ+Ⅱ/MONO and switch
audio language in DTV mode.
7.
8.
9. ▲/▼/◄/►: To select the direction.
10. ENTER: Select or confirm menu item.
11.
12.
LIST: Press to call up the channel list.
Press again to exit it.
13.
CH+/CH-: Press to select channels in
ascending or descending order.
14.
VOL+/VOL-: Press to adjust the volume
level up or down.
15.
SLEEP: Press to set the sleep timer.
When the preset length of time has
passed, the TV set enters standby mode.
16.
17.
EPG: Electronic Program Guide, use in
the DTV mode.
:Return to last viewed program.
MENU: Press to enter the menu screen
for various optional adjustable settings.
EXIT: Exit OSD Menu.
:Switch on/off the favorite programs
list.
E
ngli
sh
0
25
10

NOTE:
※The buttons not mentioned here are not used.
※All pictures in this manual are examples, only for reference, actual product may
differ from the pictures.
Remote Control
18. COLOR BUTTONS: Red/green/yellow/
blue key navigation link.
:Fast reverse (in Media mode)
:Fast forward (in Media mode)
:Previous (in Media mode)
: Next (in Media mode)
19.
:Hold the teletext page on display,
press again to release.
20.:Enter the Teletext, press again for MIX
mode, press this button again to exit.
:Play / Pause (in Media mode).
21. RADIO: Press to interchange Radio and
22.
:Change size of teletext screen in
display mode.
23. SUBTITLE: Enter the subtitle menu.
:Enter subtitle mode or subpage.
24.:Cancel the teletext but not to exit
teletext, press again to exit.
25. DMP: Press to switch to the Media source.
STILL: Press to hold the picture.
: Stop (in Media/PVR mode).
DTV program when there is Radio
program (in DTV mode).
:Press to select different images sizes.
E
nglish
0
25
11

Basic Operation
•Turn on the TV
Connect the TV to your mains socket.
If TV has a power switch, turn it on firstly. In standby mode, press Power button on
the remote to turn on the TV.
•Turn off the TV
Press the button on the remote control to enter standby mode.
Do not leave your TV in standby mode for long periods of time. It is best to unplug the
power cord.
NOTE:
If there is an accident power off, the TV will be in standby mode automatically after
re-supply the power. To ensure the normal use of the TV, the frequent turning on and
off is forbidden, when there is an accident power off, it is recommended to unplug the
power cable from the power socket.
•No signal
When the TV is working in RF receiving mode, the TV will enter standby mode
automatically 10 minutes after there is no any signal (such as the programs are
stopped by TV station). In PC mode, the TV set will automatically turn off in 90
seconds if no signal. When VGA cable is connected, the TV turns on automatically.
If this is the first time you run the TV, the Initial Setup Menu will appear in the picture,
and the items of this menu also exist in other menus, so you are able to change the
values after you set them up.
Tips: Make sure that the antenna connection is made.
■Set you desired language
Press ◄/►buttons to select the language to be used for menus and message.
■Set you desired Country
Press◄/►buttons to select the country you want to.
■Tuning Setup
Turning on and off the TV
Tune Type: Press the◄/►buttons to select: DTV+ATV, DTV, ATV.
Digital Type: DVB-T.
Start: Press the ENTER button to start the auto searching.
■Select your TV Environment.
E
ngli
sh
Signal Type is DVB-T:
First Time Installation
Press◄/►buttons to select the store mode or home mode.
12

Basic Operation
Signal Type is DVB-C:
Tune Type: Press the ◄/► buttons to select: DTV+ATV,DTV,ATV.
Scan Type: Press the◄/►button to select scan type: Full, Network Scan.
Network ID: Press the◄/►button to select Network ID: Auto or enter digital numbers.
Frequency: Press the◄/►button to select Frequency: Auto or enter digital numbers.
Symbol Rate: Press the◄/►button to select Symbol Rate: Auto or enter digital
numbers.
Signal Type is Satellite:
Satellite: Press the ◄/► buttons to select current satellite .
Scan Mode: Press the ◄/► buttons to select Scan Mode: Default, Blind Scan,
Network.
Channel Type: Press the◄/►button to select channel type: Scramble,
Free+Scramble, Free.
Service Type: Press the◄/►button to select Service Type: All, DTV, Radio.
Press the ENTER button to start the auto searching.
First tuning ATV, press Menu and left arrow button to skip ATV tuning,
Second tuning DTV, press Menu and left arrow button to skip DTV tuning.
Start: Press the ENTER button to start the auto searching.
Start: Press the ENTER button to start the auto searching.
E
nglish
■Channel Tuning
Press the OK/◄/►button to select the operator .
Operador:
13

Basic Operation
•Using the CH+/CH- on the panel of TV or on the remote control.
Press CH+ to increase channel number.
Press CH - to decrease channel number.
•Using 0-9 digital buttons.
You can select the channel number by pressing 0 to 9.
Additionally, when TV is in some mode, the TV will work in TV mode and play the
corresponding channel if any number button is pressed.
•Example
To select - channel (e.g. Channel 5): Press 5.
To select -- channel (e.g. Channel 20): Press 2 and 0 in a short time.
•Press the VOL+/- button to adjust the volume.
•If you want to switch the sound OFF, press the
.
•You can release mute by pressing the
or increase the volume.
You can select the input source by pressing the SOURCE button on the remote control.
Press the▲/▼buttons to cycle through the input source, and press the ENTER button
to confirm your choice.
Changing the Input Source
Volume Adjustment
Choosing
a TV channel
E
ngli
sh
14

Menu Operation
Before using the TV follow the steps below to learn how to navigate the menu in order
to select and adjust different functions. The access step may differ depending on the
selected menu.
1. Press MENU button to display the main menu.
2. Press ◄/►button to cycle through the main menu.
3. Press the▲/▼button to select the desired sub item.
4. Press the ENTER button to access the submenu.
5. Press the ▲/▼/◄/► buttons to select the desired value. The adjustment in the
OSD may differ depending on the selected menu.
6. Press the MENU button to return to the previous menu.
7. Press the EXIT button exit from the menu.
NOTE:
When an item in MENU is displayed gray, it means that the item is not available or
cannot be adjusted.
Some items in the menus may be hidden depending on modes or signal sources
used.
Buttons on the TV have the same function as corresponding buttons on the remote
control. If your remote control is lost or couldn‟t work, you may use the buttons on
the TV to select menus. This manual focuses on operation of the remote control.
Channel Menu
How to Navigate Menus
Signal Type is DVB-T:
■Auto Tuning
Press the ENTER/►button to enter sub-menu.
Country: Press ◄/►buttons to select the country you want to.
Tune Type: Press the◄/►buttons to select: DTV+ATV, DTV, ATV.
Start: Press the ENTER button to start the auto searching.
■ATV Manual Tuning: Manual store for ATV channels.
Current CH: Set the channel number.
Color system: Select the color system.
Sound System: Select the sound system.
E
nglish
15

Menu Operation
Signal Type is DVB-C:
■Auto Tuning
Press the ENTER/►button to enter sub-menu.
Country: Press ◄/►buttons to select the country you want to.
Tune Type: Press the◄/►buttons to select: DTV+ATV, DTV, ATV.
Digital Type: DVB-T.
Scan Type: Press the◄/►button to select scan type: Full, Network Scan.
Network ID: Press the◄/►button to select Network ID: Auto or enter digital
numbers.
Frequency: Press the◄/►button to select Frequency: Auto or enter digital
numbers.
Symbol Rate: Press the◄/►button to select Symbol Rate: Auto or enter digital
numbers.
Start: Press the ENTER button to start the auto searching.
■ATV Manual Tuning: Manual store for ATV channels.
Current CH: Set the channel number.
Sound System: Select the sound system.
Search: Press the ◄ button to search down from the current frequency, and press
the ► button to search up.
■
Press ▲/▼buttons to select the DTV Manual Tuning, then press the ENTER
button to enter sub-menu.
Press the◄/►buttons to select channel number, then press the ENTER button
search program.
■DTV Manual Tuning: Manual store for DTV channels.
Press ▲/▼buttons to select the DTV Manual Tuning, then press the ENTER
button to enter sub-menu.
Press the◄/►buttons to select channel number, then press the ENTER button
search program.
Fine-Tune: Adjust the frequency of the channel finely.
Color System: Select the color system.
CADTV Manual Tuning: Manual store for DTV channels.
Search: Press the ◄ button to search down from the current frequency, and press
the ► button to search up.
Fine-Tune: Adjust the frequency of the channel finely.
E
ngli
sh
16

Menu Operation
Signal Type is Satellite:
■Auto Tuning
Press the ENTER/►button to enter sub-menu.
Country: Press the◄/►button to select country.
Satellite: Press the ◄/► buttons to select current satellite.
Scan Mode: Press the ◄/► buttons to select Scan Mode: Default, Blind Scan,
Network.
Channel Type: Press the◄/►button to select channel type: Scramble,
Free+Scramble, Free.
Service Type: Press the◄/►button to select Service Type: All, DTV, Radio.
Start: Press the ENTER button to start the auto searching.
Dish Setup(only in satellite mode)
- Satellite/Transponder: Press the ▲/▼button to select the Satellite. press the
EPG button to select the transponder.
Press the ▲/▼button to select the satellite/transponder from the list.
Delete: Press the red button to delete the current satellite/transponder.
Edit: Press the green button to edit the current satellite/transponder.
Add: Press the yellow button to add a new satellite/transponder.
Scan: Press the blue button to enter sub-menu.
• Scan Mode: Press the ◄/► buttons to select Scan Mode: Default, Blind Scan,
Network.
• Channel Type: Press the◄/►button to select channel type: Scramble,
Free+Scramble, Free.
• Service Type: Press the◄/►button to select Service Type: All, DTV, Radio.
-LNB Type: Select the LBN type.
-LNB Power: Select the power supply type for the LBN.
-Toneburst: You can choose one of two satellites. Used to choose proper device.
-DiSEqC1.0: You can choose one of four satellites. Used to choose proper
device.
-DiSEqC1.1: You can choose one of sixteen satellites. Used to choose proper
■
-22KHz: 22KHz SWITCH. Select the mode: On, Off, Auto.
E
nglish
17

Menu Operation
When motor is set to DiSEqC1.2 :
-Set Limit: Press the red button to set Limits to the scope of satellite Antenna
rotation.
•Move Continue: Rotates the antenna until the rotation has been completed or
stopped manually.
•Move Step: Rotates the antenna in accordance with the step value. Enables the
antenna make a fine Adjustment.
•Set West Limit: Set the west limit value.
•Set East Limit: Set the East limit value.
•Goto Reference: Drive antenna to zero position.
•Disable Limit: Delete Limit settings. Allows the antenna to rotate over the full arc.
Cancel east limit and west limit.
- Set position: Press the yellow button to set position.
•Move Auto: Rotates the antenna automatically.
•Move Continue: Rotates the antenna until the rotation has been completed or
stopped manually.
•Move Step: Rotates the antenna in accordance with the step value. Enables the
antenna make a finer adjustment.
•Store Position: Store current position as the selected positioner limit.
•Goto Position: Rotates the antenna to the stored satellite position.
•Goto Reference: Drive antenna to zero position.
When Motor is set to DiSEqC1.3 :
-Set Location: Press the green button to set Location .
•Location: Manual,Abuzaby,Alger,Beirut,Berlin,Budapest,Cairo,Casablanka,ect.
can be adjusted When the Location is set to Manual.
•Longitude Direction: Sets the Longitude direction for the location.
•Longitude Angle: Sets the Longitude angle for the location.
•Latitude Direction: Sets the Latitude direction for the location.
•Latitude Angle: Sets the Latitude angle for the location.
■Programme Edit
Press the▲/▼ buttons select the Programme Edit, then
ENTER button to enter sub-menu.press the
First press the▲/▼buttons to highlight the channel you
Press the RED button to delete the channel.
Press the GREEN button to rename the channel. (In ATV mode)
Press the YELLOW button to set the channel to moving
▲/▼buttons to move it to the position
Press the BLUE button to skip the select channel. (Your TV
Press the
state, then press the
you want to put.
set will skip the channel automatically when using CH+/- to view the channels.)
button to set the favorite channel.
E
ngli
sh
want to delete, skip, rename or move, then:
18
