Channel Vision DVR-HD080 User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
product with new or rebuilt parts, free of charge in the USA, for two
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
proof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-170 rev A
DVR-HD080
DVR-HD200
DVR-HD320
Hard Drives for camera DVR
QUICK START GUIDE
6
xx GB

2
Channel Vision’s and are 80, 200,
and 320GB Hard Drives for use with Digital Video Recorders. These are
standard IDE computer Hard Drives that have been selected to work well
with Channel Vision’s DVRs. This general quick start guide is intended to
help you through the Hard Drive installation process.
DVR-HD080, DVR-HD200, DVR-HD320
1. Review your Hard Drive and look for the following features.
40-Pin IDE connector
Configuration Jumper Pins
(see diagram on label)
Rectangle indicates the jumper
is placed over these pins
No rectangle indicates that there is no
jumper in this configuration
You will find a diagram on the Hard Drive that looks
similar to the one shown here. This diagram shows
where to place the jumpers for various applications.
You will see the following terms:
- means you have only one Hard
Drive installed.
- means this is the master Hard
Drive, but there is also a slave drive.
- means this is the slave Hard Drive and there
is another Hard Drive installed that is configured as
the master.
Master or Single
Master w/ Slave
Slave
Power Connector
xx GB
3
Connections
Attach IDE cable as shown here
Attach power cable as shown here
Note: The power connector and IDE connector
are notched to ensure the correct orientation.
The cables will only go in the correct way.
IDE Cable
Slave
Connector
Master
Connector
(at the end of cable)
xx GB
