TE110DS manual override switch
In some cases, customers may require a manual button or switch that allows them to activate their doorstrike
without using the TE110DS. The diagram below shows one possible wiring schematic to accomplish this.
Use a standard pushbutton or any device that will provide a
momentary contact closure and wire it across the ‘Strike’
terminals on the TE110DS. When the button is pressed, power
will be delivered to the strike mechanism causing it to activate
White Paper
TE110DS
Door strike
power supply
(NOT SOLD BY CHANNEL VISION)
Door strike
Mechanism
(NOT SOLD BY CHANNEL VISION)
TE110
Telephone
Service
Provider
House
Telephones
Strike duration
Seconds S1 S2 S3
3
5
8
15
20
40
120
240
off
on
off off
on
off
on
off
on
off
off
on
on
off
off
on
on
off
off
off
on
on
on
on
On
Off
# of rings
2x3 ring
patern
Key on
phone
Yes
No
#
*
S4 S5 S6
3
5
Power Line
Tel Intercom
House
Intercom
Strike
Standard push button
provides momentary
contact closure
