User Manual

DATA STREAM 8
Data Stream 8 User Manual Rev. 1
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Unpacking Instructions.................................................................................. 1
Claims ............................................................................................................................ 1
Text Conventions .......................................................................................... 1
Symbols ........................................................................................................ 1
Disclaimer ..................................................................................................... 1
Product at a Glance ...................................................................................... 2
Safety Notes.................................................................................................. 2
2. Introduction ................................................................................ 3
Product Overview.......................................................................................... 3
Product Dimensions ...................................................................................... 4
3. Setup ........................................................................................... 5
AC Power ...................................................................................................... 5
Fuse Replacement ......................................................................................................... 5
Mounting ....................................................................................................... 6
Orientation...................................................................................................................... 6
Rigging ........................................................................................................................... 6
4. Operation .................................................................................... 7
Front Panel Operation................................................................................... 7
Configuration................................................................................................. 7
Power Indicator .............................................................................................................. 7
Signal Indicators............................................................................................................. 7
DMX Input Ports............................................................................................................. 7
Input Select Switch......................................................................................................... 7
5. Maintenance................................................................................ 8
Product Maintenance .................................................................................... 8
6. Technical Specifications ........................................................... 9
7. Returns ........................................................................................ 10
8. Contact Us .................................................................................. 11

Page 1 of 11
Data Stream 8 User Manual Rev. 1
BEFORE YOU BEGIN
1. BEFORE YOU BEGIN
What Is Included
Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Symbols
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetdj.com.
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2018 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo, and Data Stream 8 are registered trademarks or trademarks of Chauvet &
Sons LLC. (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company
and product names and logos referred to herein may be trademarks of their respective companies.
• Data Stream 8
• Power Cord
• Warranty Card
• Quick Reference Guide
CONVENTION MEANING
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
ON A value to be entered or selected
SYMBOL MEANING
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
!

Page 2 of 11
BEFORE YOU BEGIN
Data Stream 8 User Manual Rev. 1
Product at a Glance
Safety Notes
Use on Dimmer Auto Programs 
Outdoor Use Auto-ranging Power Supply 
Sound-Active Replaceable Fuse 
DMX User-Serviceable 
Master/Slave 
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Always disconnect the product from the power source before cleaning or replacing the
fuse.
• Make sure the power cord is not crimped or damaged.
• Never disconnect the product from power cord by pulling or tugging on the cord.
• If mounting the product overhead, always secure to a fastening device using a safety
cable.
• Make sure there are no flammable materials close to the product while operating.
• Do not touch the product’s housing when operating because it may be very hot.
• The product is not intended for permanent installation.
• Always make sure that the voltage of the outlet to which you are connecting the product
is within the range stated on the decal or rear panel of the product.
• The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose
the product to rain or moisture.
• Always install the product in a location with adequate ventilation, at least 20 in (50 cm)
from adjacent surfaces.
• Be sure that no ventilation slots on the product’s housing are blocked.
• Never connect the product to a dimmer.
• Make sure to replace the fuse with another of the same type and rating.
• Never carry the product from the power cord or any moving part.
• The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate the product at
higher temperatures.
• In the event of a serious operating problem, stop using the product immediately.
• Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Keep this User Manual for future use. If you sell the product to someone else, be sure that
they also receive this document.
!

Page 3 of 11
Data Stream 8 User Manual Rev. 1
INTRODUCTION
2. INTRODUCTION
Product Overview
DMX Input A
Power Fuse
DMX Input B
Power/
Signal
Indicators DMX Input
Switch
DMX Output Port
Assignment
Indicator
DMX Output Ports
DMX Output Port
Manual Assignment
Switch Bank
Safety Loop

Page 4 of 11
INTRODUCTION
Data Stream 8 User Manual Rev. 1
Product Dimensions
18.46 in
469 mm
1.26 in
32 mm
0.79 in
20 mm
8.70 in
221 mm
5.20 in
132 mm
8.70 in
221 mm
0.55 in
14 mm
0.79 in
20 mm
1.73 in
44 mm
5.59 in
142 mm
19.02 in
483 mm
0.43 in
11 mm
0.28 in
7 mm

Page 5 of 11
Data Stream 8 User Manual Rev. 1
SETUP
3. SETUP
AC Power
The Data Stream 8 has an auto-ranging power supply and it can work with an input voltage range of 100 to
240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s
specifications chart. The listed current rating indicates the product’s average current draw under normal
conditions.
Fuse Replacement
1. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
2. Pry the fuse holder out of the housing.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same type and rating.
4. Insert the fuse holder back in place and reconnect power.
• Always connect the product to a protected circuit (circuit breaker or fuse).
Make sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by
unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
Disconnect the product from the power outlet before replacing the fuse.
!
Safety cap
Spare fuse holder
(inside safety cap)
Installed fuse
(held by plastic clip)
!

Page 6 of 11
SETUP
Data Stream 8 User Manual Rev. 1
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
Orientation
The Data Stream 8 may be mounted in any position; however, make sure adequate ventilation is provided
around the product.
Rigging
• Before deciding on a location for the product, always make sure there is easy access to the product
for maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product’s
weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
Mounting Diagram
Mounting Hole M12
Safety Cable
(such as CH-05 from
Chauvet)
M
oun
ti
ng
Cl
amp
(such as CLP-15 or CLP-15N
from Chauvet)

Page 7 of 11
Data Stream 8 User Manual Rev. 1
OPERATION
4. OPERATION
Front Panel Operation
The Data Stream 8 is designed to distribute / boost 2 incoming DMX signals (A/B) into 8 separate output
ports. Each of the 8 output ports is electronically isolated from the others, and must be assigned to one of
the incoming DMX signals.
To control where each of the signals go, there are assignment switches located on the front panel. Please
refer to the Product Overview to see the Input Switch and DMX Output Port Manual Assignment Switch
Bank.
Configuration
The Data Stream 8 works with up to 2 DMX universes. Information about DMX is in the CHAUVET DMX
Primer, which is available from the Chauvet website www.chauvetdj.com.
Power Indicator
The power indicator is located on the left side of the panel and will illuminate red when the product has
power.
Signal Indicators
There are 2 signal indicators. Green indicates a signal from input A and Blue indicates a signal on input B.
DMX Input Ports
There are 2 DMX input ports A and B. Each port handles 1 universe of DMX.
Input Select Switch
This 3 way switch selects whether signal A is routed to all the output ports, signal B is routed to all the
output ports or if it gets routed to the DMX Output Port Manual Assignment Switch Bank.
DMX Output Ports
These ports are labeled with a number and have both a green and a blue indicator lights which identify
which DMX input signal the output port is assigned to.
DMX Output Port Manual Assignment Switch Bank
To use the DMX Output Port Manual Assignment Switch Bank., the Input Select Switch must be set to the
Manual position in the center between A and B. Each switch on the DMX Output Port Manual Assignment
Switch Bank has a number that corresponds with the numbers on each of the output ports. Each switch
can choose which Input is assigned to each of the individual output ports.
AB
POWER
SIGNAL
BA
12345678 A / B A / B
1
2
3
4
5
6
7
8
INPUT
SELECT
DMX INPUT
MANUAL
MANUAL

Page 8 of 11
MAINTENANCE
Data Stream 8 User Manual Rev. 1
5. MAINTENANCE
Product Maintenance
Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of
the light source’s life and/or mechanical wear. To maintain optimum performance and minimize wear, clean
your lighting products at least twice a month. However, be aware that usage and environmental conditions
could be contributing factors to increase the cleaning frequency.
To clean the product, follow the instructions below:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3. Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on the external
surface/vents.
4. Clean all transparent surfaces with a mild soap solution, ammonia-free glass cleaner, or isopropyl
alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
6. Softly drag any dirt or grime to the outside of the transparent surface.
7. Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.

Data Stream 8 User Manual Rev. 1
TECHNICAL
Page 9 of 11
6. TECHNICAL SPECIFICATIONS
Dimensions and Weight
Note: Dimensions in inches rounded to the nearest hundredth.
Power
Thermal
DMX
Ordering
LENGTH WIDTH HEIGHT WEIGHT
19 in (483 mm) 5.2 in (132 mm) 1.7 in (44 mm) 4.6 lb (2.0 kg)
POWER SUPPLY TYPE RANGE VOLTAGE SELECTION
Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging
PARAMETER 120 V, 60 HZ230 V, 50 HZ
Consumption 2 W 2 W
Operating Current 0.04 A 0.3 A
Fuse F 1 A, 250 V F 1 A, 250 V
POWER I/O U.S./CANADA WORLDWIDE
Power input connector IEC IEC
Power output connector Edison IEC
Power Cord plug Edison (U.S.) Local Plug
MAXIMUM EXTERNAL TEMPERATURE COOLING SYSTEM
104 °F (40 °C) Convection
I/O CONNECTOR
3-pin XLR
PRODUCT NAME ITEM CODE UPC NUMBER
Data Stream 8 09111451 781462217990

RETURNS
Data Stream 8 User Manual Rev. 1
Page 10 of 11
RETURNS
In case you need to get support or return a product:
• If you are located in the U.S., contact Chauvet World Headquarters.
• If you are located in the UK or Ireland, contact Chauvet Europe Ltd.
• If you are located in Mexico, contact Chauvet Mexico.
• If you are located in Benelux, contact Chauvet Europe BVBA.
• If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local
distributor. See www.chauvetdj.com for distributors outside the U.S., UK, Ireland, Mexico, or
Benelux.
Call the corresponding Chauvet Technical Support office and request a Return Merchandise Authorization
(RMA) number before shipping the product. Be prepared to provide the model number, serial number, and
a brief description of the cause for the return.
Send the merchandise prepaid, in its original box, and with its original packing and accessories. Chauvet
will not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product returned without an RMA
number.
Before sending the product, clearly write the following information on a piece of paper and place it inside
the box:
• Your name
• Your address
• Your phone number
• RMA number
• A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be
your responsibility. FedEx packing or double-boxing are recommended.
If you are located outside the U.S., UK, Ireland, Mexico, or Benelux, contact your
distributor of record and follow their instructions on how to return Chauvet products to
them. Visit our website www.chauvetdj.com for contact details.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
Chauvet reserves the right to use its own discretion to repair or replace returned
product(s).

Data Stream 8 User Manual Rev. 1
CONTACT US
Page 11 of 11
CONTACT US
Visit the applicable website above to verify our contact information and instructions to request support.
Outside the U.S., United Kingdom, Ireland, Mexico or Benelux, contact the dealer of record.
World Headquarters
General Information Technical Support
Address: 5200 NW 108th Ave. Voice: [phone]
Sunrise, FL 33351 Fax: [phone]
Voice: [phone] Email: [email protected]
Fax: [phone] Website
Toll Free: [phone] www.chauvetdj.com
EUROPE
General Information Technical Support
Address: Stokstraat 18 Email: [email protected]
9770 Kruishoutem Website
Belgium www.chauvetdj.eu
Voice: [phone]
General Information Technical Support
Address: Unit 1C Email: [email protected]
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK Website
NG16 6NT www.chauvetdj.eu
Voice: [phone]
Fax: [phone]
MEXICO
General Information Technical Support
Address: Av. de las Partidas 34, 3-B Email: [email protected]
(Entrance by Calle 2)
Zona Industrial Lerma
Lerma, Edo. de México, CP 52000 Website
Voice: [phone] www.chauvetdj.mx
