Checkpoint VSX-1 3070 User manual

VSX-1
Getting Started Guide
VSX NGX R65
U-40, P-20
703522 February 2009
VSX_Appliance_GettingStarted.book Page 1 Thursday, February 5, 2009 3:56 PM

VSX_Appliance_GettingStarted.book Page 2 Thursday, February 5, 2009 3:56 PM

3
© 2003-2009 Check Point Software Technologies Ltd.
All rights reserved. This product and related documentation are protected by copyright and
distributed under licensing restricting their use, copying, distribution, and decompilation. No part of
this product or related documentation may be reproduced in any form or by any means without prior
written authorization of Check Point. While every precaution has been taken in the preparation of
this book, Check Point assumes no responsibility for errors or omissions. This publication and
features described herein are subject to change without notice.
RESTRICTED RIGHTS LEGEND:
Use, duplication, or disclosure by the government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS
252.227-7013 and FAR 52.227-19.
TRADEMARKS:
Please refer to http://www.checkpoint.com/copyright.html for a list of our trademarks.
For third party notices, see http://www.checkpoint.com/3rd_party_copyright.html.
VSX_Appliance_GettingStarted.book Page 3 Thursday, February 5, 2009 3:56 PM

4
VSX_Appliance_GettingStarted.book Page 4 Thursday, February 5, 2009 3:56 PM

Health and Safety Information
Read the following warnings before setting up or using the appliance.
To prevent damage to any system board, it is important to handle it with care. The
following measures are generally sufficient to protect your equipment from static
electricity discharge:
•When handling the board, to use a grounded wrist strap designed for static
discharge elimination.
•Touch a grounded metal object before removing the board from the antistatic bag.
•Handle the board by its edges only. Do not touch its components, peripheral chips,
memory modules or gold contacts.
•When handling processor chips or memory modules, avoid touching their pins or
gold edge fingers.
•Restore the communications appliance system board and peripherals back into the
antistatic bag when they are not in use or not installed in the chassis. Some
circuitry on the system board can continue operating even though the power is
switched off.
•Under no circumstances should the Lithium battery cell used to power the
real-time clock be allowed to short. The battery cell may heat up under these
conditions and present a burn hazard.
Warning - Do not block air vents. A minimum 1/2-inch clearance is
required.
Warning - This appliance does not contain any user-serviceable parts.
Do not remove any covers or attempt to gain access to the inside of the
product. Opening the device or modifying it in any way has the risk of
personal injury and will void your warranty. The following instructions
are for trained service personnel only.
Warning - DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS
VSX_Appliance_GettingStarted.book Page 5 Thursday, February 5, 2009 3:56 PM

•Disconnect the system board power supply from its power source before you
connect or disconnect cables or install or remove any system board components.
Failure to do this can result in personnel injury or equipment damage.
•Avoid short-circuiting the lithium battery; this can cause it to superheat and cause
burns if touched.
•Do not operate the processor without a thermal solution. Damage to the processor
can occur in seconds.
VSX_Appliance_GettingStarted.book Page 6 Thursday, February 5, 2009 3:56 PM

7
Contents
Chapter 1
Introduction
Welcome...................................................................................9
VSX-1 Overview .......................................................................11
Shipping Carton Contents .........................................................13
VSX-1 3070 ................................................................... 13
VSX-1 9070 ................................................................... 14
VSX-1 9090 ................................................................... 15
Terminology ............................................................................16
Chapter 2
Installation and Configuration
Installation and Configuration Workflow .....................................17
Installing and Setting Up VSX-1................................................18
Ear Mount Installation..................................................... 18
Installing VSX-1 in a Rack ............................................... 20
Connecting the Cables and Power On................................ 21
Initial Configuration .................................................................23
Logging in for the First Time ............................................ 23
Configuring the Management Interface.............................. 25
Setting Network and Time/Date Properties......................... 27
Selecting Cluster Options................................................. 27
Completing the Configuration........................................... 28
VSX Appliance Recovery ...........................................................29
Chapter 3
VSX-1 Hardware
Overview .................................................................................31
Front Panel Components.................................................. 32
VSX_Appliance_GettingStarted.book Page 7 Thursday, February 5, 2009 3:56 PM

8
Rear Panel Components................................................... 38
Customer Replaceable Parts......................................................40
Power Supply.................................................................. 40
Cooling Fan .................................................................... 42
Expansion Line Card........................................................ 43
Hard Disk Drive............................................................... 45
Chapter 4
Registration and Support
Registration.............................................................................47
Support...................................................................................48
Where To From Here? ...............................................................48
VSX_Appliance_GettingStarted.book Page 8 Thursday, February 5, 2009 3:56 PM

9
Chapter 1
Introduction
In This Chapter
Welcome
Thank you for choosing Check Point’s VSX-1 appliance. We
hope that you will be satisfied with this solution and our
support services. Check Point products provide your business
with the most up to date and secure solutions available today.
Check Point also delivers worldwide technical services
including educational, professional and support services
through a network of Authorized Training Centers, Certified
Support Partners and Check Point technical support personnel
to ensure that you get the most out of your security
investment.
Welcome page 9
VSX-1 Overview page 11
Shipping Carton Contents page 13
Terminology page 16
VSX_Appliance_GettingStarted.book Page 9 Thursday, February 5, 2009 3:56 PM

Welcome
10
For additional information on the NGX Internet Security Product Suite
and other security solutions, refer to: http://www.checkpoint.com or
call Check Point at 1(800) 429-4391. For additional technical
information, refer to: http://support.checkpoint.com.
Welcome to the Check Point family. We look forward to meeting all of
your current and future network, application and management
security needs.
VSX_Appliance_GettingStarted.book Page 10 Thursday, February 5, 2009 3:56 PM

VSX-1 Overview
Chapter 1 Introduction 11
VSX-1 Overview
The VSX-1 (Virtual System eXtension) appliance is a security and VPN
solution, designed to meet the demands of large-scale environments.
Based on the proven security of VPN-1, VSX provides comprehensive
protection for multiple networks or VLANs within complex
infrastructures. It securely connects them to shared resources such as
the Internet and DMZs, and allows them to safely interact with each
other. VSX is supported by SmartDefense™ Services, which provide
up-to-date preemptive security.
VSX incorporates the same patented Stateful Inspection and
Application Intelligence technologies used in the Check Point VPN-1
product line. It runs on high speed platforms (known as VSX
gateways) to deliver superior performance in high-bandwidth
environments. Administrators manage VSX via a SmartCenter server or
a Provider-1 Multi-Domain Server (MDS), delivering a unified
management architecture that supports enterprises and service
providers.
A VSX gateway contains a complete set of virtual devices that
function as physical network components, such as VPN-1 gateways
(firewalls), routers, switches, interfaces, and even network cables.
Centrally managed, and incorporating key network resources
internally, VSX allows businesses to deploy comprehensive firewall
and VPN functionality, while reducing hardware investment and
improving efficiency.
Key Features:
•Combines Virtual Firewall, VPN, and IPS
•Consolidates Up to 250 Security Gateways Onto a Single
Hardware Platform
•Includes Virtualized Networking Components- Virtual routers,
Virtual switches & Virtual cabling
•Wire-Speed Security for Gigabit Networks
•High Availability with Linear Growth Clustering
VSX_Appliance_GettingStarted.book Page 11 Thursday, February 5, 2009 3:56 PM

VSX-1 Overview
12
•Bridge Mode Support for Transparent Internal Firewalls
•Flexible Virtual Network Design
•SmartDefense Services Updates
•URL Filtering
This document provides:
•A brief overview of essential VSX-1 appliance concepts and
features
•A step by step guide to getting VSX-1 appliance up and running
VSX_Appliance_GettingStarted.book Page 12 Thursday, February 5, 2009 3:56 PM

Shipping Carton Contents
Chapter 1 Introduction 13
Shipping Carton Contents
This section describes the contents of the shipping carton.The
contents of the carton vary depending on your appliance model.
VSX-1 3070
Table 1-1 Contents of the VSX-1 3070 Shipping Carton
Item Description
Appliance A single VSX-1 3070 appliance
Rack Mounting Accessories Hardware mounting kit
Cables •1Powercable
• 1 Standard RJ-45 network cable
• 1 Serial console cable
• 1 RJ-45 loopback plug
2 CDs Includes the following:
•CD1: VSX-1 Installation
•CD2: VSX-1 Getting Started Guide
VSX NGX R65 documentation
Certifications, Regulations,
and Documentation
Certification data sheet and user license
agreement
VSX_Appliance_GettingStarted.book Page 13 Thursday, February 5, 2009 3:56 PM

Shipping Carton Contents
14
VSX-1 9070
Table 1-2 Contents of the VSX-1 9070 Shipping Carton
Item Description
Appliance A single VSX-1 9070 appliance
Rack Mounting Accessories Hardware mounting kit
Cables • 2 Power cables
• 1 Standard RJ-45 network cable
• 1 Serial console cable
• 1 RJ-45 loopback plug
2 CDs Includes the following:
•CD1: VSX-1 Installation
•CD2: VSX-1 Getting Started Guide
VSX NGX R65 documentation
Certifications, Regulations,
and Documentation
Certification data sheet and user license
agreement
VSX_Appliance_GettingStarted.book Page 14 Thursday, February 5, 2009 3:56 PM

Shipping Carton Contents
Chapter 1 Introduction 15
VSX-1 9090
Table 1-3 Contents of the VSX-1 9090 Shipping Carton
Item Description
Appliance Two VSX-1 9070 appliances
Rack Mounting Accessories Hardware mounting kit
Cables •4Powercables
• 2 Standard RJ-45 network cable
• 2 Serial console cable
• 2 RJ-45 loopback plug
2 CDs Includes the following:
•CD1: VSX-1 Installation
•CD2: VSX-1 Getting Started Guide
VSX NGX R65 documentation
Certifications, Regulations,
and Documentation
Certification data sheet and user license
agreement
VSX_Appliance_GettingStarted.book Page 15 Thursday, February 5, 2009 3:56 PM

Terminology
16
Terminology
The following VSX terms are used throughout this chapter:
• Gateway: The VPN-1 engine that enforces the organization’s
security policy and acts as a security enforcement point.
• Security Policy: The policy created by the system administrator
that regulates the flow of incoming and outgoing
communication.
• SmartCenter Server: The server used by the system administrator
to manage the security policy. The organization’s databases and
security policies are stored on the SmartCenter server and
downloaded to the gateway.
• SmartConsole: GUI applications that are used to manage various
aspects of security policy enforcement. For example, SmartView
Tracker is a SmartConsole application that manages logs.
• SmartDashboard: A SmartConsole GUI application that is used
by the system administrator to create and manage the security
policy.
• Centrally Managed Deployment: When the gateway and the
SmartCenter server are installed on separate machines.
• Virtual Routers: Independent routing domains within a VSX
Gateway that function like physical routers.
•Virtual System: A routing and security domain featuring firewall
and VPN capabilities supported by a standard Check Point
Gateway. Multiple Virtual Systems can run concurrently on a
single VSX Gateway, isolated from one another by their use of
separate system resources and data storage.
•VSX Clustering: The connection of two or more VSX Gateways in
such a way that if one fails, another immediately takes its place.
A single VSX Gateway contains multiple Virtual Routers and
Virtual Systems.
VSX_Appliance_GettingStarted.book Page 16 Thursday, February 5, 2009 3:56 PM

17
Chapter 2
Installation and Configuration
In This Chapter:
This chapter covers installing and configuring the VSX-1
appliance.
Installation and Configuration
Workflow
Below is an overview of the steps needed to configure your
VSX-1 appliance. Each step is explained in detail further on.
To configure VSX-1:
1. Install VSX-1 by ear mount or in the rack.
2. Connect the cables and power on.
3. Log in and perform the initial configuration.
Installation and Configuration Workflow page 17
Installing and Setting Up VSX-1 page 18
Initial Configuration page 23
VSX Appliance Recovery page 29
Note - A SmartCenter or Provider-1 Server is not installed
locally on the VSX-1 appliance. VSX-1 appliance is only
supported in a centrally managed environment.
VSX_Appliance_GettingStarted.book Page 17 Thursday, February 5, 2009 3:56 PM

Installing and Setting Up VSX-1
18
Installing and Setting Up VSX-1
VSX-1 appliance can be installed by ear mount or in the rack.
Ear Mount Installation
The VSX-1 appliance ships with two ear mount kits, and screws
of the type shown in Figure 2-1:
Figure 2-1 Ear Mount Screws
One ear mount fits on each side of the chassis.
To assemble the ear mounts:
1. Take out the L shape ear mount kits.
2. Place the side with four holes against the chassis. The side
with two holes faces outward, as shown in Figure 2-2.
VSX_Appliance_GettingStarted.book Page 18 Thursday, February 5, 2009 3:56 PM

Installing and Setting Up VSX-1
Chapter 2 Installation and Configuration 19
Figure 2-2 Ear Mounts
3. Fasten the four retaining screws on each ear mount.
4. Fasten the two screws that connect the ear mount to the
handle.
Retaining
Screws
VSX_Appliance_GettingStarted.book Page 19 Thursday, February 5, 2009 3:56 PM

Installing and Setting Up VSX-1
20
Installing VSX-1 in a Rack
Install the system in the rack with the network ports facing the
front of the rack.
Figure 2-3 Installing VSX-1 9070
VSX_Appliance_GettingStarted.book Page 20 Thursday, February 5, 2009 3:56 PM
