X-Trax VATA2024 Operational manual

Product User Manual
IP-Gateway
Model: VATA2024
Version：V1.0.90.1

Safety Notices
Please read the following safety notices before installing or using this gateway.
They are crucial for the safe and reliable operation of the device.
Please use the external power supply that is included in the package. Other
powers supplies may cause damage to the device, affect the behavior or
induce noise.
Before using the external power supply in the package, please check with
home power voltage. Inaccurate power voltage may cause fire and damage.
Please do not damage the power cord. If power cord or plug is impaired, do
not use it, it may cause fire or electric shock.
The plug-socket combination must be accessible at all times because it serves
as the main disconnecting device.
Do not drop, knock or shake it. Rough handling can break internal circuit
boards.
Do not install the device in places where there is direct sunlight. Also do not
put the device on carpets or cushions. It may cause fire or breakdown.
Avoid exposure the gateway to high temperature, below 0℃ or high humidity.
Avoid wetting the unit with any liquid.
Do not attempt to open it. Non-expert handling of the device could damage it.
Consult your authorized dealer for help, or else it may cause fire, electric
shock and breakdown.
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
it. Wipe it with a soft cloth that has been slightly dampened in a mild soap and
water solution.
When lightning, do not touch power plug or device line, it may cause an
electric shock.
Do not install this device in an ill-ventilated place.
You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be
familiar with standard practices for preventing accidents.

Table of Content
1. WELCOME TO THE VATA2024 TWO-PORT GATEWAY .................................................................................. 4
1.1. Package Contents ....................................................................................................................... 4
2 UNDERSTANDING OF VATA2024 TWO-PORT GATEWAY ................................................................................ 5
2.1. The positive of VATA2024 two-port gateway ............................................................................. 6
2.2. In icator signs ............................................................................................................................ 6
2.3. Connector escription ................................................................................................................ 6
3. GETTING STARTED ................................................................................................................................. 8
3.1. Connect the power an network ................................................................................................. 8
3.1.1. Co ect the etwork .......................................................................................................................... 8
3.1.2. Co ect the power ............................................................................................................................. 9
4. BASIC PHONE OPERATION OF VATA2024 TWO-PORT GATEWAY ................................................................... 10
4.1. Call transfer ............................................................................................................................. 10
4.2. Call hol ................................................................................................................................... 10
5. WEB CONFIGURATION ........................................................................................................................... 11
5.1. Intro uction of configuration ................................................................................................... 11
5.1.1. Ways to co figure ............................................................................................................................ 11
5.1.2. Password Co figuratio ................................................................................................................... 11
5.2. Setting via web browser ........................................................................................................... 12
5.3. Configuration via WEB ........................................................................................................... 12
5.3.1. BASIC ............................................................................................................................................. 12
5.3.2. Network .......................................................................................................................................... 14
5.3.3. VOIP ................................................................................................................................................ 21
5.3.4. Pho e ............................................................................................................................................... 29
5.3.5. Mai te a ce .................................................................................................................................... 33
5.3.6. Security ............................................................................................................................................ 37
5.3.7. Logout ............................................................................................................................................. 42
6. APPENDIX ........................................................................................................................................... 43
6.1. SPECIFICATION ................................................................................................................................. 43
6.1.1. HARDWARE .................................................................................................................................. 43
6.1.2. VOICE FEATURES ........................................................................................................................... 43
6.1.3. NETWORK FEATURES ...................................................................................................................... 43
6.1.4. MAINTENANCE AND MANAGEMENT ................................................................................................... 44
6.2. PARTICULARLY SUITABLE FOR VATA2024 TWO-PORT GATEWAY .............................................................. 44
6.3. COMMON PROBLEMS ......................................................................................................................... 44

1. Welcome to the VATA2024 two-port gateway
1.1. Package Contents
Please check your product packaging，it includes:
1. One VATA2024 two-port gateway
2. A group of cable
3. A power adapter
NOTE: if you use the non-VATA2024 two-port gateway comes with a power adapter,
two-port gateway may cause damage or other injury. Specifications for the power
adapter may different between the different shipment areas. If the power adapter
provided with the product can not be used locally, please consult your local dealer.
4. User manual

2 Understanding of VATA2024 two-port gateway
VATA2024 two-port gateway IP-based voice media access device is designed for
operators, enterprises, residential users, and residential VoIP solution to provide
network equipment. VATA2024 two- port gateway into the analog voice information
transmitted over IP networks, which use IP networks to transmit voice. It is full
compliance with the SIP protocol standard, with the market most other SIP
compliant devices and server-side.
The gateway will play Internet network (either public network or private network)
connecting with the public telephone network bridge. It provides two FXS analog
voice interfaces, used for ordinary small business PBX or gateway (PBX).
This site using the most advanced voice processing technologies, such as
advanced voice compression standards, echo cancellation, dynamic voice
detection, silence detection, ensuring Quality of Service (QoS), and voice quality
comparable to regular PSTN phone.
In addition, VATA2024 two-port gateway also integrates a small router function.
WEB comes through the gateway configuration page, simply configure the
network parameters, can achieve multiple computers and network equipment,
broadband access, ideal for small office and home users.
Because this site has a wealth of features and related detailed configuration
options, in your call to enjoy a stress free before you know your VATA2024 two-
port gateway.

2.1. The positive of VATA2024 two-port gateway
2.2. Indicator signs
Name Meaning Description
POWE
R
Power LED Always light, has power, you
can start using the VATA 0 4
two-port gateway.
FXS1 Phone work
status lights
Show the status of the phone
under the port 1. No phone or
hang up: Off; pick up: always.
FXS Phone work
status lights
Show the status of the phone
under the port . No phone or
hang up: Off; Pick up: always.
WAN WAN network
interface lights
Indicator light, WAN port
connected to the network.
Flashing: Data transfer.
LAN LAN network
interface lights
Indicator light, LAN port
connected to the network.
Flashing: Data transfer.
2.3. Connector description
Name Meaning Description
POWE
R
Power switch Output:1 VDC
， 500mA 。
FXS1 FXS1 Interface Ordinary telephone connection,
or switch into the line.
FXS FXS Interface Ordinary telephone connection,
or switch into the line.
LAN Network Interface 10/100M Adaptive connected PC.
WAN Network Interface 10/100M Adaptive connected to

the RJ45 port of Internet 。
VATA2024 two-port gateway with two network interface itself: WAN port and LAN
port, you can use the Internet connection into the WAN port or LAN port. Read the
manual carefully of “Safety” before inserting the power

3. Getting Started
Before you start using the VATA2024 two-port gateway, please install the following:
3.1. Connect the power and network
3.1.1. Connect the network
During this step, make sure your environment already have broadband Internet
access capability.
1. Broadband Router
Direct network connection—by this method, you need at least one available
Ethernet port in your workspace. Use the Ethernet cable in the package to connect
WAN port of VATA2024 two-port gateway to the Ethernet port in your workspace.
Since this gateway has router functionality, whether you have a broadband router
or not, you can make direct network connect. The following two figures are for
your reference.
2. as a broadband router
Use this method if you have a single Ethernet port in your workspace with your
desktop computer already connected to it. First, disconnect the Ethernet cable
from the computer and attach it to the WAN port of gateway. Next, use the Ethernet
cable in the package to connect LAN port of gateway to your desktop computer.
Your IP Phone now shares a network connection with your computer. The
following figure is for your reference.

3.1.2. Connect the power
During this step, make sure your power supply connector and VATA2024 two-port
gateway outlet match, while VATA2024 is also in line voltage and current required
for a two-port gateway.
1. The transformer connected to the DC port on the back of VATA2024 two-port
gateway POWER jack.
2. The AC adapter plug to an electrical outlet, VATA2024 two-port gateway boot.
3. At this point all of your lights (except the POWER indicator) will flash together.
After booting, you will hear popping sounds, and then the indicator light is lit
according to your current configuration corresponding light. (If your light is not
normal, you need to further configure your network connection mode).
4. If you login on the gateway server, then you can start calling.

4. Basic phone operation of VATA2024 two-port
gateway
Since there are two FXS interfaces on the VATA2024 two-port gateway, and the two
interfaces are independent, so the phones under the FXS1 and FXS2 have the
same operation. The phones under the two ports can be used as two separate
telephones at the same time. The following operations are applicable to the
phones under the FXS1 and FXS2.
4.1. Call transfer
Blind Transfer
During a call, press FLASH (Flash) key, enter the number to be transferred【*】add
and press 【#】 key to confirm, you can transfer the current call to third parties. (To
use this feature, you must enable the gateway of the Call Waiting and Call Transfer
function)
Attended Transfer
During a call, press FLASH (Flash) key, enter the number waiting to be transferred
connected, directly hang up, you can transfer successfully. (To use this feature,
you must enable the gateway of the Call Waiting and Call Transfer function)
NOTE:1, Call Transfer must call in two cases all the way is free for operation;
2, Gateway (transfer side) and the establishment of phone A calls phone C gateway
and then create a call, hang up the phone A, this time the gateway can also initiate
the transfer.
3, your VoIP traffic services providers need to support (RFC3515), this feature to
work correctly.
4.2. Call hold
Call Hold and set aside
During a call you can press FLASH (FLASH) button and enter the number to dial
and press 【#】 key to ensure
Recognition, can retain the current state of the call with third-party calls. If you
press the FLASH (Flash) key, you can switch back. You also can send and receive
on one side, then the party can not be retained to hear your conversation, the
speaker you can not. During a call if you press 【*】 operation, will enter the three-
