CHERVIN VOGEL SPS 2A29VDC BBFM User manual

USER MANUAL
RECHARGEABLE 29V BATTERY PACK
SPS 2A29VDC BBFM
OPERATING INSTRUCTIONS
1. Be sure the battery is fully charged before use. To conrm this, press the Test button on the side of the
unit. If the indicator light is green then the battery is ready to use. If the indicator light is red, plug it into
an outlet to charge.
2. To install, connect the cord with the female connector to the male 2-pin plug hard wired to the recline
motor. Be sure to position the battery pack in a location where the cord will not be damaged in the recline
mechanism.
3. Press the test button on the side of the battery pack to check the status of the battery while in use. If the
battery has enough power to properly operate the furniture the test button will activate a GREEN LED.
When the battery drops to 20% capacity, the test button will activate a RED LED. When this occurs, plug
the battery pack into a standard wall outlet to recharge.
4. During the charging process a LED light will constantly indicate the current status of the battery pack.
A RED LED indicates the charging process is not complete. A GREEN LED indicates the battery is fully
charged.
*You have the option of using the battery while it is charging but this will require a much longer charging time before the
battery is fully charged.
**Do not completely drain the battery as this may reduce the life of the battery.
***Once the battery is fully charged, unplug it from the wall outlet. Leaving the battery plugged into a wall outlet while
fully charged will cause the battery to drain more quickly during use.
Notes:
1. Do not dispose of electrical appliance as unsorted municipal waste, use proper collection facilities.
2. Contact your local government for information regarding the collection system available.
3. Use only a power supply cord, Type SPT-1, 22awg, two conductors, rated minimum 105°C, 300V, VW-1. One
end terminates in an attachment AC plug of 15A, 125V (NEMA 1-15P) or 15A, 250V (NEMA 2-15P), the other
end terminates in a molded on connector which mates with the Power appliance inlet. Minimum 2.3m in
length.

TROUBLESHOOTING GUIDE
PROBLEM: NO POWER
OUTPUT FROM BATTERY
PACK
BATTERY NOT HOLDING
A CHARGE
LED INDICATOR LIGHT
DOES NOT LIGHT UP
WHEN PLUGGED INTO
WALL OUTLET
Check the connection between
the battery pack and the
recline motor and check
Battery status by pressing the
Test button on side of unit.
The number of recline cycles
the battery can execute
depends on the size of the
occupant and the number of
accessories connected to the
system such as LED lighting or
USB chargers
Conrm the AC cord is
properly connected tot he wall
outlet and battery pack.
NO LED ON: plug the battery
pack into an outlet to
recharge. Wait 30 seconds and
the RED LED will illuminate
indicating it is charging.
Allow 5 hours to fully charge
the battery pack. It may
be benecial to disconnect
the battery pack from the
furniture during the charging
process.
Conrm outlet used for
charging is working properly.
RED LED: this indicates the
battery needs to be charged.
A fully charged battery pack
should provide over 200 uses,
dependent on the load and
accessories. The battery pack
will discharge when idle.
Verify circuit breakers in the
house are not tripped.
GREEN LED: indicates battery
is fully charged and ready for
use.
If the battery pack does not
hold a charge as indicated
then contact customer
service at [phone] or
customerservice@rael.com
If the battery pack does
not recharge as indicated
then contact customer
service at [phone] or
customerservice@rael.com

WARNINGS
1. Keep away from ammable material and heat sources.
2. For indoor use only.
3. Dry location only.
4. Do not short circuit the battery, over charge or over discharge.
5. Do not allow the battery pack to become crushed.
6. Do not drop the battery into water.
7. Do not reverse the polarity.
8. Do not disassemble or repair the battery.
9. Do not install near metallic parts that could cause a short circuit.
10. Do not deform the battery housing.
11. Do not touch a leaky battery.
12. Do not use this battery with other devices it is not intended for.
13. Keep out of the reach of children.
ONE YEAR LIMITED WARRANTY
Rael systems warrants its products against all defects in materials and workmanship for a period of one year form
the date of purchase, subject to the following terms and conditions.
This warranty applies only for normal use of the product, and shall not be eective for products or parts which
do not function properly due to misuse, alteration, improper installation, accident, negligence, misapplication,
modication, improper maintenance or commercial use, or if any product or part has been serviced or repaired by
other than Rael Systems.
This warranty is eective only if the product is operated in the country which the product was purchased. A product
that requires modications or adoption to enable it to operate in any other country than the country for which it was
designed, manufactured, approved and/or authorized, or repair of products damaged by these modications is not
covered under this warranty.
Liability of Rael Systems shall be limited to the repair or replacement of any defective product or part, which
option shall be the sole decision of Rael Systems. This warranty is eective only on behalf of the original owner
of the product and is not transferable. This warranty is eective only if the user manual instructions have been
followed.
THE WARRANTY PROVIDED HEREIN SHALL BE THE SOLE AN EXCLUSIVE WARRANTY. THERE SHALL BE NO OTHER
WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS OR ANY
OTHER OBLIGATION ON THE PART OF RAFFEL SYSTEMS WITH RESPECT TO PRODUCTS COVERED BY THIS WARRANTY.
RAFFEL SYSTEMS SHALL HAVE NO LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. IN NO
EVENT SHALL THIS WARRANTY REQUIRE MORE THAN THE REPAIR OR REPLACEMENT OF ANY PART OR PARTS WHICH
ARE FOUND TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE WARRANTY. NO REFUNDS WILL BE GIVEN. IF
REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE, RAFFEL SYSTEMS RESERVES THE RIGHT TO
MAKE PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR OR REPLACEMENT.
To obtain warranty service on this product, contact Rael Systems or mail the product and your dated receipt (as
proof of purchase), postpaid, to the following address:
Rael Systems Consumer Relations
N112W14600 Mequon Road
Germantown WI 53022
Phone: [phone]
No COD’s will be accepted.
