Solplanet Ai-HB G2 Series User manual

Ai-HB 075A / Ai-HB 100A
Ai-HB 125A / Ai-HB 150A
Ai-HB 175A / Ai-HB 200A
Quick Installation Guide
Ai-HB G2 Series Battery
Android iosiOS

The product is a battery system for residential and works with the solar hybrid invert-
ers. It is a high voltage Li-ion battery storage system that has its own control unit. It
can be operated in on-grid, o-grid and backup modes with all the compatible
inverters.
The product is suitable for indoor and outdoor use.
The product must only be operated with the inverters which are claimed by AISWEI.
The inverters must be compatible with this product.
The battery system must only be used as stationary equipment.
Alterations to the product are not allowed unless the written permission of AiSWEI is
achieved. Unauthorized alterations will void the guarantee and warranty claims.
AiSWEI will not be held liable for any damage caused by such illegal changes.
The product is not suitable for supplying life-sustaining medical devices. Please
ensure that no personal injury would lead due to the power outage of the battery
system.
The product must only be used in countries for which it is approved or released by
AISWEI and the grid operator.
Use this product only in accordance with the information provided in this documen-
tation and with the locally applicable standards and directives. Any other application
may cause personal injury or property damage.
The type label must remain permanently attached to the product.
This document does not replace any regional, state, provincial, federal or national
This quick installation guide does not replace the description in the user manual.
The contents of this guide may be updated or revised due to product development.
The information in this guide is subject to change without notice. The latest version
of this document and the manual for installation, commissioning, conguration and
decommissioning are to be found in PDF format at www.solplanet.net.
2.1 I
ntended use
SAFETY
2
GENERAL INFORMATION
1
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
1

2.2 Important safety instructions
The product has been designed and tested in accordance with international safety
requirements. To prevent personal injury and property damage and to ensure
long-term operation of theproduct, read this section carefully and observe all safety
information at all times.
DANGER
！
Danger to life due to high voltages of the battery！
When the battery system connected to the inverter, and the circuit breaker is ON, the
batteries will generate a high DC voltage which will be present in the DC cable and
live components.
• Do not touch non-insulated parts or cables.
• Do not touch the DC conductors.
• Do not touch any live components of the product.
• Do not open the product.
•All work on the product must only be carried out by qualied personnel who have
read and fully understood all safety information contained in this document.
•Disconnect the product from voltage sources and ensure it cannot be reconnect-
ed before working on the product.
•Wear suitable personal protective equipment, in accordance with local regula-
tions, when working on the product.
laws, regulations or standards that apply to the installation, electrical safety and use
of the product.
WARNING
！
Danger to life due to electric shock from destruction of measurement
devices due to overvoltage！
Overvoltage can damage a measurement device and result in voltage being present
in the enclosure of the measurement device. Touching the live enclosure of the mea-
suring device results in death or lethal injuries due to electric shock.
• Only use measuring devices with a higher volatge range than the system battery
voltage.
2
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

NOTICE
Damage to the battery system due to electrostatic discharge!
Internal components of the battery system can be irreparably damaged by electro-
static discharge.
• Ground yourself before touching any component.
NOTICE
Damage to the BCU due to particles and water!
Particles such as dust and sand can damage the BCU and impair its functionality.
•Only open the BCU cover when the humidity is within the permitted range of the
product and the environment is free of dust and sand.
WARNING
！
Risk of injury due to weight of product！
Injuries may result if the product is lifted incorrectly or dropped while being trans-
ported or mounted.
• Lift and transport the product carefully.
•Wear suitable personal protective equipment, in accordance with local regula-
tions, when working on the product.
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
3

2.3 Symbols on the label
Beware of a danger zone!
This symbol indicates that the product must be additionally grounded if additional
grounding or equipotential bonding is required at the installation site.
Beware of high voltage and operating current！
The product operates at a high voltage and current. Work on the product must only be
carried out by skilled and authorized personnel.
Beware of explosion!
The battery is an electro chemical, and there is an explosion risk in extreme cases. Please
keep away of it when the danger occurs.
Beware of danger to children!
The battery must be inaccessable to children.
Beware Flammable
Keep the battery system away from open ames or ignition sources.of danger with am!
CE marking
The product complies with the requirements of the applicable EU directives.
Certication mark
The product has been tested by TÜV and obtained the quality certication mark.
CE marking
The product complies with the requirements of the applicable EU directives.
The battery is recyclable
The battery can be recycled by a professional recycling organization, please refer to the
relevant local regulations.
WEEE Designation
Do not dispose of the product together with household waste. Dispose the product in
accordance with local disposal regulations for electronic waste.
Observe the documentation
Read and understand all documentation supplied with the product.
4
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

PARALLEL SYSTEM WIRING DIAGRAM
3
Ai-HB 075A/100A/125A/150A/175A/200A
P+
P-
P+
P-
P+
P-
P- P+ COM
…
Terminal
resistor
12N
（1≤N≤4）
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
5

EU DECLARATION OF CONFORMITY
4
Within the scope of the EU directives:
-Electromagnetic compatibility directive 2014/30/EU
(L 96/79-106, March 29, 2014)(EMC)
-Low voltage directive 2014/35/EU (L 96/357-374, March 29, 2014)(LVD)
Restriction of the use of certain hazardous substances 2011/65/EU
(L 174/88, June 8, 2011) and 2015/863/EU (L 137/10, March 31,2015) (RoHS)
AISWEI New Energy Technology (Yangzhong) Co., Ltd. conrms herewith that the
products described in this document are in compliance with the fundamental
requirements and other relevant provisions of the above mentioned directives. The
entire EU Declaration of Conformity can be found at www.solplanet.net.
6
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

OVERVIEW
5
1
1LED指示灯 指示逆变器当前的工作状态
Object Description
3
2Battery Module
Battery control unit(BCU)
4
5
6
Base
LED indicator
Circuit breaker
7
9
8
Link port in
Link port out
10
11
P-
P+
On/O
1
2
3
5
6
10
11
9
7
8
4
Grounding
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
7

SCOPE OF DELIVERY
6
6.1 BCU and Base Package
6.2 Battery Module Package
BCU and Base ×1
Quick installation
guide ×1
Positive cable and
negative cable ×1
L-bracket ×2 M5X12 Screw ×2 Terminating resistor ×1
Battery Module×1 M5×25 Screw×2
M6×16
Hexagon screw ×1
Cable gland ×1
M8×40 Expansion
Anchor Bolt ×2
8
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

MOUNTING ENVIRONMENT
7
-20℃
+50℃
RH.+5%~+95% max.3000m
≥350mm
≥600mm
≥350mm
×××
√√√
40~50mm
IP65
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
9

DIMENSIONS
8
MOUNTING
9
Unit：mm
12
155
≥350mm ≥350mm ≥350mm ≥350mm
130
1250
55
540 390
M5
N.W: 15kg
10
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

(3≤N≤8）
90°
Φ8mm
50mm
M5
4N.m
…
1
2
N
N.W: 30.5kg
34
5 6
78
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
11

PROTECTIVE GROUNDING
10
1
2
M6
6N
· m
E
L=E+(2~3)mm L
M5
4N.m
M8
≥10mm²
copper wire
OK
3
4
5
910
12
11
12
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523

BATTERY CONNECTION
11
OK
P-
P+
OR
12
3
66
45
1
1
2
2
3
3
4
4
5
6
QG0048_Ai-HB 050-200A_EN_540-300266-02_V03_0523
13

Please contact our Service Department if you have any technical questions about our
products.
The following information is needed to provide necessary assistance:
——Battery model
——Battery control unit and module series number
——Fault code
——Installation location
EMEA
Service email: [e-mail]
APAC
Service email: [e-mail]
LATAM
Service email: service.LAT[email protected]
Aiswei Greater China
Service email: [e-mail]
Hotline: [phone]
Taiwan
Service email: [e-mail]
Hotline: [phone]
https://solplanet.net/contact-us
