Chesney's Optimyst User manual

1
Electric Fire Basket &
Electric Stove User Manual
CHESNEY’S
Issue 04
powered by

Thank you for choosing this Chesney’s electric fire. Please
read this information guide carefully to be able to safely
install, use and maintain your product.
Front cover upper image shows Chesney’s Electric Fire with Universal Basket and Spherical Fire Dogs.
Lower image shows the Beaumont Electric Stove in yellow paint finish

1
CHESNEY’S
Contents
1. Important Safety Advice 2
2. General Information 4
3. Installation Instructions 5
4. Operating the Fire 7
5. Maintenance 10
6. Troubleshooting 20
7. Additional Information 22
8. Warranty Registration 25
powered by

2
1. Important Safety Advice
WHEN USING ELECTRICAL APPLIANCES, BASIC
PRECAUTIONS SHOULD ALWAYS BE FOLLOWEDTO
REDUCETHE RISK OF FIRE, ELECTRICAL SHOCK AND
INJURYTO PERSONS, INCLUDINGTHE FOLLOWING:
1. OVERHEATING
WARNING: IN ORDERTO AVOID OVERHEATING, DO
NOT COVERTHE HEATER. DO NOT PLACE MATERIAL OR
GARMENTS ON, OR OBSTRUCTTHE AIR CIRCULATION
AROUNDTHE APPLIANCE.THE HEATER CARRIES A DO NOT
COVER WARNING.
2. DAMAGE
IFTHE APPLIANCE IS DAMAGED, CHECK WITHTHE
SUPPLIER BEFORE INSTALLATION AND OPERATION.
IFTHE SUPPLY CORD IS DAMAGED IT MUST BE REPLACED
BYTHE MANUFACTURER OR SERVICE AGENT OR A
SIMILARLY QUALIFIED PERSON IN ORDERTO AVOID A
HAZARD.
3. LOCATION
DO NOT USE OUTDOORS.
DO NOT USE INTHE IMMEDIATE SURROUNDINGS OF A
BATH, SHOWER OR SWIMMING POOL.
DO NOT LOCATETHE FIRE IMMEDIATELY BELOW A FIXED
SOCKET OUTLET OR CONNECTION BOX.
ENSURETHAT FURNITURE, CURTAINS OR OTHER
COMBUSTIBLE MATERIAL ARE POSITIONED NO CLOSER
THAN 1 METRE FROMTHE APPLIANCE.
ALTHOUGHTHIS HEATER CONFORMS WITH SAFETY
STANDARDS, WE DO NOT RECOMMEND ITS USE ON DEEP
PILE CARPETS OR ON LONG HAIRTYPE OF RUGS.
4. PLUG POSITIONING
THE APPLIANCE MUST BE POSITIONED SOTHATTHE PLUG
IS ACCESSIBLE.
KEEPTHE SUPPLY CORD AWAY FROMTHE FRONT OFTHE
APPLIANCE.
5. USE OF OTHER CONTROLS
DO NOT USETHIS HEATER IN SERIES WITH ATHERMAL
CONTROL, A PROGRAM CONTROLLER, ATIMER OR
ANY OTHER DEVICETHAT SWITCHES ONTHE HEAT

3
AUTOMATICALLY, SINCE A FIRE RISK EXISTS WHENTHE
HEATER IS ACCIDENTALLY COVERED OR DISPLACED.
6. UNPLUGGING
INTHE EVENT OF A FAULT UNPLUGTHE DEVICE.
UNPLUGTHE DEVICE WHEN NOT REQUIRED FOR LONG
PERIODS.
7. OWNER/USER
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FORM
8YEARS AND ABOVE AND PERSONS WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK
OF EXPERIENCE AND KNOWLEDGE IFTHEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE
OFTHE APPLIANCE IN A SAFE WAY AND UNDERSTANDTHE
HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY WITH
THE APPLIANCE.
CLEANING AND USER MAINTENANCE SHALL NOT BE
MADE BY CHILDREN WITHOUT SUPERVISION.
CHILDREN OF LESSTHAN 3YEARS SHOULD BE KEPT AWAY
UNLESS CONTINUOUSLY SUPERVISED. CHILDREN AGED
FROM 3YEARS AND LESSTHAN 8YEARS SHALL ONLY
SWITCH ON/OFFTHE APPLIANCE PROVIDEDTHAT IT HAS
BEEN PLACED OR INSTALLED IN ITS INTENDED NORMAL
OPERATING POSITION ANDTHEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF
THE APPLIANCE IN A SAFE WAY AND UNDERSTANDINGTHE
HAZARDS INVOLVED. CHILDREN AGED FROM 3YEARS AND
LESSTHAN 8YEARS SHALL NOT PLUG IN,
REGULATE AND CLEANTHE APPLIANCE OR PERFORM USER
MAINTENANCE.
CAUTION - SOME PARTS OFTHIS PRODUCT CAN BECOME
VERY HOT AND CAUSE BURNS. PARTICULAR ATTENTION
HAS TO BE GIVEN WHERE CHILDREN AND VULNERABLE
PEOPLE ARE PRESENT.
8. ELECTRICITY
WARNING –THIS APPLIANCE MUST BE EARTHED.
THIS APPLIANCE MUST BE USED ON AN AC ~ SUPPLY ONLY
ANDTHE VOLTAGE MARKED ONTHE APPLIANCE MUST
CORRESPONDTOTHE SUPPLY VOLTAGE.
BEFORE SWITCHING ON, PLEASE READTHE SAFETY
ADVICE AND OPERATING INSTRUCTIONS.

4
2. General Information
Only use filtered water in this appliance.
This model is designed to be free standing and is normally positioned
near a wall, on a non combustible surface.
Always ensure the appliance is sitting on a level, non-combustible
surface.
Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the flame effect.This is normal and should not be a cause for concern.
If this product experiences a power surge for whatever reason the
product may cut-out.This is a normal safety feature and the product will
resume operation after 30 seconds.
Once installed, never move this appliance or lay on its back, without
draining the water from sump and water tank.
If you intend not using the appliance for longer than 2 weeks, drain the
water from sump and water tank and dry the sump.
The water tank, sump, sump lid, tank cap and air filters must be cleaned
once every two weeks, particularly in hard water areas.
The appliance should never be operated if the lamps are not working.
The lamps should be regularly inspected as described under
‘Maintenance’ and ‘Changing lamps’.

5
3. Installation Instructions
This section describes how to set up your fire.
BEFORE YOU START
1. Ensure that all packing items are removed (read any warning labels
carefully) and retain all packing for possible future use e.g. in the event of
moving house or returning the appliance to your supplier.
2. Before connecting to the mains supply, check that the supply voltage is
the same as that stated on the appliance.
INSTALLATION
Electric Fire Baskets: Place the appliance against a wall.
Connect the power cable to the appropriate power connector at the back
of the appliance and plug the power cable into a 13amp/240volt outlet.
Do not yet switch the appliance on.
Electric Stoves: Place the stove in to position allowing a minimum of
125mm all around the stove for ventilation.
Connect the power cable to the appropriate power connector at the back
of the fire and plug the power cable into a 13amp/240volt outlet.
Do not yet switch the appliance on.
Connecting theTransducer Unit + Lamps
1. Release the two red tabs by turning them by 90 degrees (see Fig.1).
2. Lift out the Sump Nozzle (Fig.2).
3. Insert lamps into lamp holders (Fig.3), carefully locating the pins into
the holes (Fig.4).
4. Push lamps firmly into place.
5. Place theTransducer Unit into the sump and join the cable to the
connector on the sump (Fig 5).
6.To ensure that theTransducer Unit is correctly placed in the sump, the
tab on theTransducer Unit should be lined up with the moulded recess in
the sump (Fig 5a).
7. Ensure that the cable is not placed above the disc on theTransducer
Unit (Fig 5b).To prevent the cable becoming pinched between the nozzle
and the sump, place the cable in the slot in the wall of the sump.
8. Replace the Sump Nozzle and secure it by turning the two red tabs
by 90 degrees (Fig 6).

6
Filling the WaterTank
9. Place WaterTank in sink and remove cap (turn anti-clockwise to open)
(Fig 7).
10. Fill WaterTank with filtered tap water only.This is necessary to pro-
long the life of the flame and smoke effect producing unit.The water
should be filtered through a conventional domestic water filter unit and
the filter should be replaced regularly. Distilled water must not be used.
11. Screw the cap back on – do not overtighten.
12. Place the WaterTank in the Sump, with the tank cap facing down and
the flat side of the tank facing outward (Fig 8).
Assembling the fire
13. Place the Fuelbed on top of the WaterTank.
The appliance is now ready for use.

7
4. Operating the Fire
This section describes how to activate your fire using either the manual
controls or remote control.
MANUAL CONTROLS
The manual controls are located beneath the hinged flap. (See Fig.9 for
Manual Control lay out).
Switch ‘A’:- Controls the electricity supply to the Fire.
Note:This switch must be in the ‘ON’ ( I ) position for the Fire to operate.
Switch ‘B’:- Press once to turn on the flame effect.This will be
indicated by an audible beep. Although the main lights operate
immediately it will take a further 30 seconds before the flame effect
starts.
(Electric Stove models only)
Press again to give flame effect and half heat.This will be
indicated by two beeps.
Press again to give flame effect and full heat.This will be
indicated by three beeps.
Press again to return to flame effect only.This will be
indicated by one beep.
Press to put fire in to standby mode.This will be indicated by one
beep.
Control Knob ‘C’:- Controls theThermostat setting. (Electric Stove Models only).
Turning the control knob to the left will decrease the temperature setting,
turning the control knob to the right will increase the temperature setting.
Control Knob ‘D’:- Controls the intensity of the flame effect.
Turning the control knob to the left increases the flame effect, turning the
control knob to the right will decrease the flame effect.

8
SETTING THE THERMOSTAT (Electric Stove models only)
Ensure the fire is plugged in and switch it on to the full heat setting.Turn
the Control Knob ‘C’ fully to the right (max temperature setting) to warm
the room rapidly. When the room temperature has reached the desired
level, turn the thermostat knob back slowly until you hear the thermostat
just click off.The heater will then maintain the room temperature at the
chosen level.
Note: Should your heater fail to come on when the thermostat is at a low
setting, this may be due to the room temperature being higher then the
thermostat setting.
THERMAL SAFETY CUT-OUT (Electric Stove models only)
A thermal safety cut-out is incorporated in the fan heater to prevent
damage due to overheating.This can happen if the heat outlet was
restricted in any way. If the cut-out operates, unplug the heater from the
socket outlet and allow approximately 10 minutes before reconnecting.
Before switching the heater back on remove any obstruction that may be
restricting the heat outlet, then continue normal operation.
Caution: In order to avoid a hazard due to inadvertent resetting of the
thermal cutout, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a switch that is
regularly switched on and off by the utility.
GETTING THE DESIRED FLAME EFFECT
1.The flame control knob ‘D’ (Fig.9) may be turned up or down to give a
more realistic effect.
2. Generally the flames appear more realistic when the flame control is
turned down.
3. Give the flame generator time to react to changes you may make.
4.The appliance will use less water if the flame effect is set to a lower
level (control knob ‘D’).
5. Do not tilt or move the appliance while there is water in the tank or
sump.
6. Make sure that the appliance is on a level floor.

9
Press once to turn on Flame effect only.
This will be indicated by one beep.
(Electric Stove models only)
Press once to turn on Half Heat and Flame Effect.
This will be indicated by two beeps.
Press again to turn on Full Heat and Flame Effect.
This will be indicated by three beeps.
To switch from Half or Full Heat to Flame Effect only, press
followed by
Standby.
This will be indicated by one beep.
REMOTE CONTROL OPERATION
On the control panel, Switch A (see Fig. 9) must be in the ‘ON’ ( I)
position in order for the remote control to operate.
There are 3 buttons on the remote control. (See Fig.11)To operate
correctly the remote must be pointed towards the front of the grate. (See
Fig 16).The remote control functions are as follows:

10
5. Maintenance
GENERAL TIPS
Only use filtered tap water in this appliance.
Always ensure that the appliance is sitting on a level surface.
If you intend not using the appliance for longer than 2 weeks, remove
and empty the sump and water tank.
Once installed, never move this appliance or lay on its back, without
draining the water from sump and water tank.
The appliance should never be operated if the lamps are not working.
The lamps should be regularly inspected as described under ‘Changing
lamps’.
FILLING THE WATER TANK
When the water tank is empty, the flame and smoke effect shuts off and
you will hear 2 audible beeps, follow these steps.
1. Press Switch ‘A’ to (0) (See Fig.9).
2. Gently lift out the fuelbed and carefully set aside.
3. Remove the water tank by lifting upwards and outwards.
4. Place the water tank in sink and remove cap, Anti-clockwise to open
(Fig 7).
5. Fill tank with filtered tap water only.This is necessary to prolong the
life of the flame and smoke producing unit.
The water should be filtered through a conventional domestic water filter
unit and the filter should be replaced regularly.
6. Screw the cap back on, do not over tighten.
7. Return the tank to the sump, with the tank cap facing down and the flat
side of the tank facing outward (Fig 8).
8. Gently place the fuelbed back into position.
9. Press Switch ‘A’ to ‘ON’ (I) position (See Fig.9).
CHANGING LAMPS
If the flame and smoke effect appears grey or colourless it may be that
one or more lamps have failed.
You can check for lamp failure as follows.
1. Leaving the flame effect on, lift out the fuelbed and water tank.
2. It should be possible to view the lamps with the nozzle in place and
observe which one needs to be changed.
3. Put Switch ‘A’ in the ‘OFF’ (0) position, and unplug the fire from the
mains.

11
4. Leave the appliance for 20 minutes to allow the lamps to cool down
before removing them.
5. Remove the sump as described in the Cleaning Section.
6. Remove the defective lamp, by gently lifting vertically and disengaging
the pins from the lamp holder,
(See Fig.3 and 4).
Replace with a Dimplex OPTIMYST, 12V / 45W, Gu5.3 base, 8º beam an-
gle, coloured lamp (Purchased from the website:
http://spares.dimplex.co.uk).
7. Carefully insert the two pins of the new lamp into the two holes in the
lamp holder. Push firmly in place.
(See Fig.3 and 4).
8. Replace the sump, nozzle, water tank and fuelbed.
CLEANING
Warning – Always press Switch ‘A’ to the ‘OFF’ (0) position (See Fig.9) and
disconnect from the power supply before cleaning the fire.
We recommend cleaning the following components once every 2 weeks,
particularly in hard water areas:-
WaterTank, Sump, Nozzle,Tank cap and seal, Air filter.
For general cleaning use a soft clean duster – never use abrasive clean-
ers.
To remove any accumulation of dust or fluff, the soft brush attachment of
a vacuum cleaner should occasionally be used.
Water tank
1. Remove water tank, as described earlier, put into sink and empty water.
2. Using the supplied brush gently rub the inside surfaces of the cap
paying particular attention to the rubber ring in the outer groove and the
centre rubber seal.
3. Put a small quantity of washing up liquid into the tank, refit the cap and
shake well, rinse out until all traces of washing up liquid are gone.
4. Refill with filtered tap water only, replace the cap, do not overtighten.
Sump
1. Press Switch ‘A’ to the ‘OFF’ (0) position.
2. Gently lift out the fuelbed and place carefully on the ground.
3. Remove the water tank by lifting upwards.
4. Disconnect the electrical connector, located on the right side of the
sump (See Fig.5).

12
5. Release the right sump locking tabs by turning 90º.This allows the
sump to be lifted completely from its location.
6. Gently lift up the sump, taking care to keep level so as not to spill any
water. Sit the assembly in the sink.
7. Release the left sump locking tabs by turning 90º, then lift off the Nozzle
(See Fig.2).
8. Lift out the transducer and carefully tilt, as shown, so that the liquid
drains out of the sump (See Fig.12).
9. Put a small amount of washing up liquid into the sump, and using the
supplied brush, gently clean all surfaces in the sump and gently clean the
transducer including the metal discs located in the top grooved surface
(See Fig.13).
10. When cleaned, thoroughly rinse the sump with clean water to remove
all traces of washing up liquid.
11. Clean the Nozzle with the brush and flush out thoroughly with water
(See Fig.14).
12. Reverse the above steps to reassemble.
Air filter
1. Gently lift out the fuelbed and place carefully on the ground.
2. Gently slide the air filter upwards out of its plastic holder (See Fig.15).
3. Gently rinse with water in the sink and dry with fabric towel before
returning.
4. Replace the filter making sure that the coarse black filter is facing the
front of the fire.
5. Replace the fuelbed.

13
Fig.1 Fig.2
Fig.3 Fig.4

14
Fig.5 Fig.5a
Fig.5b Fig.6

15
(Electric Stove models)
Fig.7 Fig.8
Fig.9

16
Fig.11
Fig.12 Fig.13
Fig.10

17
Fig.14
Fig.15

18
Fig.16
REMOTE CONTROL SENSOR
REMOTE CONTROL SENSOR
Electric Fire Basket
(model shown: Universal Freestanding Basket)
Electric Stove
(model shown: Salisbury)
