Westfire WF36 Technical Document

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
1
DANSK INGENIØRKUNST
WF36 WF37
DK: INSTALLATIONS- OG BRUGSVEJLEDNING
UK: INSTALLATION MANUAL AND OPERATING INSTRUCTIONS
D: INSTALLATIONS- UND GEBRAUCHSANWEISUNG
FR: NOTICE D’INSTALLATION ET D’UTILISATION
NL: INSTALLATIEHANDLEIDING EN GEBRUIKSAANWIJZING

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
2 3
DK: INSTALLATIONS- OG BRUGSVEJLEDNING ...................................4
UK: INSTALLATION MANUAL AND OPERATING INSTRUCTIONS .......9
D: INSTALLATIONS- UND GEBRAUCHSANWEISUNG .....................21
FR: NOTICE D’INSTALLATION ET D’UTILISATION ..............................24
NL: INSTALLATIEHANDLEIDING EN GEBRUIKSAANWIJZING ...........27
WF36 WF37
WF36 WF37
WESTFIRE 2020 | WF36 WF37
Fabrikat
Producent
Hersteller
Fabricant
Westfire
Model
Model
Modell
Modèle
Westfire 36
Westfire 37
Energi effektivitets klasse
Energy Efficiency Class
Energieeffizienzklasse
Classe d´efficacité énergétique
A
Varmeydelse
Nominal Heat Output to Room
Wärmeleistung
Puissance thermique
7.2 kW
Indirekte varmeydelse
Nominal Heat Output to Water
Indirekte Wärmeabgabe
Production de chaleur indirecte
0 kW
Energieffektivitetsindeks (EEI)
Seasonal Space Efficiency ( EEI )
Energieeffizienz –Index (EEI)
l’efficacité énergétique Index (EEI)
104
Virkningsgrad v/norminel varmeydelse
Net Efficiency
Wirkungsgrad bei Nennheizleistung
Rendement à puissance nominale
78%
Særlige forholdsregler ved installation eller vedligeholdelse
Specific precautions when installed or maintained
Besondere Vorsichtsmaßnahmen bei der Installation oder Wartung
Précautions spécifiques lors de l’installation ou de la maintenance
Se brugsvejledning
See the Instructions manual
Siehe Bedienungsanleitung
Voir le manuel d’instructions
DATABLAD / PRODUCT SHEET / PRODUKTDATENBLATT / FICHE PRODUCT
Datablad iht. Reglement (EU) 2015/1186
Energy Labelling Directive – ( EU ) 2015/1186 for Solid Fuel Boilers and Packages of Solid Fuel Boilers,
Supplementary Heaters, Temperature Controls and Solar Devices
Gemäss Verordnung (EU) 2015/1186
Fiche de produit conformément au réglement (EU) 2015/1186

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
4 5
DK: INSTALLATIONS- OG BRUGSVEJLEDNING
WESTFIRE WF36 · WESTFIRE WF36 med sokkel
WESTFIRE WF37 · WESTFIRE WF37 med sokkel
Vi ønsker Dem tillykke med Deres nye brændeovn fra Westfire. For at De kan få størst mulig glæde af Deres
nye brændeovn og for at der ikke skal opstå problemer, beder vi Dem gennemlæse denne vejledning.
Vi henviser til at, ”alle lokale forordninger, inklusive dem der henviser til nationale og europæiske standarder,
skal overholdes ved installation af anordningen”.
Ønskes der flere oplysninger om installering og fyring med pejse eller brændeovne, kan vi henvise til pjecerne
”Bygningsreglement” i det pågældende land som WF36/ WF36 med sokkel og WF37/ WF37 med sokkel
er godkendt i og ”Korrekt fyring”, der begge udgives af Byggestyrelsen og som kan rekvireres hos Deres
brændeovnsforhandler eller skorstensfejer.
Norge:
Henvisning til norsk regelverk angående installasjon av ildsted.
”Nye regler for installasjon av ildsteder pr. 2000-01-01”
”Installasjon av nye ildsteder skal meldes til de lokale bygningsmyndigheter. Huseier står selv ansvarlig for at
alle krav til sikkerhet er ivaretatt på en forskriftsmessig måte og er forpliktet til å få installasjonen inspisert og
sikkerheten bekreftet av en kvalifisert kontrollør. Lokalt feiervesen må informeres dersom installasjonen medfører
endret feiebehov.”
OPSTILLINGSVEJLEDNING/INSTALLERING
Ved installering af Deres brændeovn er der en række love og bestemmelser i Bygningsreglementet, der skal
overholdes. Disse bestemmelser kan man læse i Bygningsreglementet. Bygningsreglementet siger, at ved lukkede
ildsteder skal brændbare gulve dækkes mindst 30 cm foran fyringsåbningen og mindst 15 cm til hver side.
Underlaget skal være af ikke brændbar materiale f.eks. stålplade, glasplader, klinker eller kunstskiferplade.
Anbring ikke brandbart materiale i brændeovnens strålingszone – risiko for brandfare.
Norge:
Under platen av ubrennbart materiale skal brennbart gulvbelegg fjernes
Gulvene som brændeovnene skal installeres på, skal have en tilstrækkelig bæreevne.
Afstande til brændbart materiale som angivet på EN 13240 skiltet bag på brændeovnen.
Til ikke brændbar væg er der ingen regler om afstand, men vi anbefaler 10 cm bag ovnen pga. rengøring.
Norge:
En ikke brennbar vegg er en mur- eller betongvegg uten, brennbare matterialer på modsatt side. Ved bruk av
forskriftsmessig oppsett brannmur som beskyttelse av brennbar vegg skal ovnenes oppstillingsavstand være minst
5 cm bak og 40 cm til side.
Forbrændingen kræver luft og der skal derfor være frisk lufttilførelse til rummet, hvor ovnen er opstillet, disse skal
være placeret således at de ikke kan blokeres. Det kan være i form af en ventil (ventilen skal være åben og have
tilstrækkelig kapacitet når ovnen er tændt) eller et friskluftsystem koblet til ovnen.
Alle brændeovne fra Westfire er forsynet med en røgvenderplade, der sørger for, at røgvandringen bliver lang nok.
DK
Bag (cm) Siden (cm)
Hjørneopstilling (cm )
Møbleringsafstand
Foran (cm)
WF36 / WF36 med sokkel 17,5 cm 45 cm
15 cm
115 cm
WF37 / WF37 med sokkel 10 cm 60 cm
37,5 cm
82,5 cm
DK
Norge:
En ikke brennbar vegg er en mur- eller betongvegg uten, brennbare materialer på modsatt side. Ved bruk av
forskriftsmessig oppsett brannmur som beskyttelse av brennbar vegg skal ovnenes oppstillingsavstand være
minst 10 cm bak og 20 cm til side.
Alle mål er i cm.
Mod brandvæg (uden brandmur)
17,5
10
45
15
15
17,5
20
10
10
10
80 55
80
50
Z
Z
Z
10
Z
20
10
Z
Z
10
Z Z
10
Z Z
17,5 17,5
95
856070
Med brandmur i væg (indbygget brandmur)
Z skal altid være større end 30 cm
70
Med brandmur uden på væg
Z skal altid være større end 30 cm
90
WESTFIRE WF36 · WESTFIRE WF36 med sokkel

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
6 7
Norge:
En ikke brennbar vegg er en mur- eller betongvegg uten, brennbare materialer på modsatt side. Ved bruk av
forskriftsmessig oppsett brannmur som beskyttelse av brennbar vegg skal ovnenes oppstillingsavstand være
minst 5 cm bak og 40 cm til side.
Alle mål er i cm.
Mod brandvæg (uden brandmur)
10
5
60
37,5
37,5
10
40
5
5
5
80 50
80
50
Z
Z
Z
5
Z
40
5
Z
Z
5
Z Z
5
Z Z
10 10
115
1007075
Med brandmur i væg (indbygget brandmur)
Z skal altid være større end 30 cm
75
Med brandmur uden på væg
Z skal altid være større end 30 cm
95
DKDK
WESTFIRE WF37 · WESTFIRE WF37 med sokkel SKORSTENSTILSLUTNING
Der skal altid anvendes en skorsten med en diameter på min. 15 cm, svarende til en lysning på 175 cm2.
Skorstenen skal have en sådan højde, at trækforholdene er i orden, at røgen ikke generer omgivelserne og
skorstenen skal være forsynet med er let tilgængelig renselem.
WF36 / WF37: Er godkendt efter europæiske standard (EN 13240). Den nominelle varmeydelse er 7,2 kW.
WF36 / WF37: Har en afprøvningsvægt på 90 kg.
WF36 med sokkel / WF37 med sokkel: Har en afprøvningsvægt på 95 kg.
Minimumsrøgtrækket: Ovnen er afprøvet med et røgtræk på 12 Pa. Max røgtræk 25 Pa.
Røggasmasseflowet er 7,0 g/sek.
Røggastemperaturen er målt til 303° C.
Middel røggastemperatur i ovens røgstuds er målt til 363° C
WF36/ WF36 med sokkel og WF37/ WF37 med sokkel har både top og bagudgang.
Skorstenen kan forsynes med et reguleringsspjæld i ovnens røgrør, så skorstenstrækket kan reguleres på dage med
kraftig blæst. Spjældet må ikke kunne lukkes helt til, men skal have et friareal på mindst 20 cm2 af rørets totale
lysningsareal.
Der kan også anvendes andre former for trækbegrænsere fx ved at slippe luft ind i skorstenen uden om ovnen.
WF36 og WF37 kan tilsluttes skorsten hvor der også er tilsluttede andre anordninger.
Gasfyrede anordninger skal altid have deres egen skorsten hvor der ikke må være tilsluttede andre anordninger.
Norge:
Henvisning til skorsteinsleverandørens spesifikasjoner og anvisning for korrekt røkinnføring i elementskorsteiner.
For teglskorsteiner skal ovnens røkrør føres inn i en røkstuss som er murs fast i skorsteinen.
BETJENINGSVEJLEDNING
Første gang De fyrer i brændeovnen, vil den varmebestandige maling hærde, hvilket bevirker, at der opstår en del
lugt og røg. Sørg derfor for en god udluftning.
De bør ligeledes holde lågen lidt åben under de første par påfyringer og først lukke, når ovnen er kold, så undgår
De at paksnoren klæber sig fast til ovnen og går løs. Når den varmebestandige maling er hærdet, skal lågen holdes
lukket, undtagen under optænding, brændselspåfyldning og fjernelse af restmaterialer, for at forhindre udslip af røggas.
Inden optænding åbnes luftsystemet ved at trække luftstangen helt til højre og åbne for opstartsanordring.
Man tænder bedst op i ovnen med optændingsblokke. Brug aldrig sprit, benzin eller andre brandfarlige væsker til
optænding! Læg nogle mindre stykker træ på tværs i ovnen, optændingsbriketterne lægges ovenpå træet.
Når der er godt ild i brændet ilægges der 3 stykker træ på ca. 22 cm med en samlet vægt på ca. 2,1 kg. Maksimal
påfyldningshøjde er til underkant af de tatiære lufthuller.
Efter ca. 3 min lukkes opstartsanordring og efter ca. 3 min lukkes den sekundære luftstang ca. 38%.
Brændselspåfyldningsintervaller ved nominel varmeydelse er ca. 1 gang pr. time. Ønskes der en langsom for-
brændning kan det sekundære luftspjæld lukkes mere end de 38% men det er vigtigt at der forsat er ild I brændet.
WF36/ WF36 med sokkel og WF37/ WF37 med sokkel ovne er beregnet til intermitterende forbrænding (der skal
ilægges træ ofte og ovnen er ikke fremstillet til døgnkontinuerlig opvarming).
WF36/ WF36 med sokkel og WF37/ WF37 med sokkel er forsynet med en reguleringsventil til sekundærluft der skal
sikre ilt til forbrændingen.
Ved fyring i brændeovnen vil alle overflader blive varme og der skal udvises fornøden forsigtighed. Ved betjening af
spjæld og håndtag, skal der bruges hanske. I tilfælde af skorstensbrand: Luk for luftspjældet og lågen, derefter ring
112 eller det lokale Brandvæsen.
Sekundær luft
WF36 / WF36 med sokkel 62% åben
WF37 / WF37 med sokkel 62% åben

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
8 9
DK UK
GRUNDINDSTILLING AF SPJÆLDENE UNDER DRIFT:
Det er nødvendigt at gøre sine egne erfaringer med hensyn til indstilling af sekundærluft, da f.eks skorstenskvalitet,
skorstenshøjde, brændselskvalitet og de ydreforhold spiller en stor rolle, men man kan se om forbrændingen sker
på den rigtige måde. Hvis Deres ovn indvendig får en belægning af hård blank sod, er der tegn på en ufuldstændig
forbrænding, i så fald skal der tilføres mere sekundærluft.
Det er vigtig at man inden fyring kontroller trækforholdene, det kan fx gøres ved at krølle et stykke avispapir
sammen, ligge det i brændkammeret og antænde det, hvis røgen trækker fint ud gennem skorsten er
trækforholdende i orden.
BRÆNDSEL
Brug aldrig giftigt træ såsom spånplader, malet eller imprægneret træ. Brug altid tørt træ. Det er ikke tilladt at
brænde affald eller nogen form for flydende brændsel. Træets tørhedsgrad spiller en særdeles stor rolle, idet det
foruden dårlig fyringsøkonomi også giver anledning til løbesod.
Nyfældet træ indeholder 60-70% vand, hvilket gør det fuldstændig uegnet til fyring.
Man skal regne med at nyfældet træ skal stå stakket til vindtørring, under et halvtag i 2 år, før det er egnet til fyring.
VEDLIGEHOLDELSE
Asken bør tages ud med jævne mellemrum.
Rengøring af ovnen bør kun foretages når ovnen er kold. Ovnen rengøres udvendig med en tør klud. En gang
årligt bør ovnens indre rengøres. Dette gøres ved at rengøre brandkammeret for aske og evt. sod og tjærerester.
Røgvenderpladen bør tages ud, da snavs og sod vil lægge sig bag på pladen. Pakninger i lågen vil efter længere tids
brug blive slidt og bør tjekkes.
Regelmæssig bør ovnen, røggasforbindelsestykket og skorsten efterses af kvalificeret montør, efter længere
stilstandsperiode, skal skorstenen kontrolleres for blokeringer inden genoptænding.
På udsatte steder kan lakken nedslides p.g.a. overophedning, dette kan ligesom andre lakskader repareres med en
speciel senothermlak på spraydåse, som kan købes i alle pejseforretninger.
Norge:
Aske skal kun oppbevares i ubrennbar beholder og skal ikke blandes med annet brennbart avfall.
Der er monteret skamolplader i brandkammeret. Disse plader vil med tiden blive nedslidte og skal udskiftes.
Det samme gælder røgvenderpladen.
Hvis De kommer til at kaste et brændestykke for hårdt ind i ovnen, kan dette indebære, at en skamolplade revner.
Dette har ingen betydning for forbrændingen (gælder ikke røgvender pladen). Først når skamolpladerne er så
nedslidte, at disse ikke mere er hele, skal pladerne udskiftes, dette gælder også hvis skamolpladerne har flere
revner.
Ved overophedning af brændeovnen skal luftspjældet og lågen være lukket.
DRIFTFORSTYRRELSER
Hvis glasset soder til, skyldes det højst sandsynligt vådt træ eller at bålet får for lidt sekundærluft.
Brænder træet for hurtigt, kan det skyldes at skorstenstrækket er for kraftigt eller utæthed ved lågen.
Varmer ovnen for lidt, kan det skyldes fyring med vådt træ.
Røg eller lugtgener kan skyldes dårligt skorstenstræk. Kontrollér om røgrør/skorsten er tilstoppet og skorstenens
højde i forhold til omgivelserne. Tilsodning af skorsten kan skyldes brug af vådt træ eller at forbrændingen får for
lidt sekundærluft.
GARANTI
Der ydes 5 års garanti på fabrikationsfejl på Deres nye ovn. Deres købsfaktura gælder som dokumentation for
købsdato. Garantien gælder ikke skader, som følge af forkert betjening, f.eks. overophedning, forkert tilslutning,
eller skader der er opstået p.g.a. ydre påvirkning af fysisk karakter.
Garantien omfatter ikke skader på udskiftelige dele, transportomkostninger i forbindelse med garantireparationer
eller montering/demontering ved garantireparationer.
Der advares mod enhver uautoriseret ændring af anordningen.
Ved reparation brug alene reservedele anbefalet af Westfire.
UK: INSTALLATION MANUAL AND OPERATING INSTRUCTIONS
WESTFIRE WF UNIQ36 · WESTFIRE WF UNIQ36 PEDESTAL
WESTFIRE WF UNIQ37 · WESTFIRE WF UNIQ37 PEDESTAL
This manual refers to the stove type listed above, which has been tested in accordance with EN 13240.
Congratulations on your purchase of a new wood burning stove from Westfire. Please read this manual carefully in
order to ensure that you get maximum enjoyment from your new stove and to prevent any problems. Please note
that “all local regulations, including those referring to national and European Standards, need to be complied with
when installing this appliance”.
For further information on installing and using fireplaces and wood burning stoves, please see the relevant building
regulations that apply to the country in which UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal has been
approved, as well as the relevant documents on the correct use of wood burning stoves available from your local
stove supplier or your Chimney sweep.
These instructions cover the basic principles to ensure the satisfactory installation of the UNIQ36/ WF36 Pedestal
and UNIQ37/ WF37 Pedestal wood stoves, although detail may need slight modification to suit particular local site
conditions. In all cases the installation must comply with current Building Regulations, Local Authority Byelaws and
other specifications or regulations as they affect the installation of the stove.
It should be noted that the Building Regulations requirements may be met by adopting the relevant recommen-
dations given in British Standards BS 8303, BE EN15287-1:2007 design, installation and commissioning of chimneys.
HEALTH AND SAFETY PRECAUTIONS
Special care must be taken when installing the stove such that the requirements of the Health and Safety at Work
Act are met.
Handling
Adequate facilities must be available for loading, unloading and site handling.
Fire Cement
Some types of fire cement are caustic and should not be allowed to come into contact with the skin. In case of
contact, wash immediately with plenty of water.
Asbestos
This stove contains no asbestos. If there is a possibility of disturbing any asbestos in the course of installation then
please seek specialist guidance and use appropriate protective equipment.
Metal Parts
When installing or servicing this stove care should be taken to avoid the possibility of personal injury.
CO Alarms
Building regulations require that whenever a new or replacement fixed solid fuel or wood/biomass appliance
is installed in a dwelling a carbon monoxide alarm must be fitted in the same room as the appliance. Further
guidance on the installation of the carbon monoxide alarm is available in BS EN 50292:2002 and from the alarm
manufacturer’s instructions. Provision of an alarm must not be considered a substitute for either installing the
appliance correctly or ensuring regular servicing and maintenance of the appliance and chimney system.
Stove paint aerosols
Paint aerosols are flammable and therefore dangerous to use around a lit stove. Be sure to allow aerosol spray
paints to dry and ventilate the room well before lighting the stove. The use of any aerosol around lit stove is
dangerous and care must be take in handling aerosols.

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
10 11
UK
UNIQ 36 and UNIQ36 PEDESTAL dimensions / UNIQ37 and UNIQ37 PEDESTAL dimensions
Stove model Weight Nominal heat output
Wood Smokeless fuels
UNIQ36 / UNIQ37 90 kg 7.2 KW N/A
UNIQ36 Pedestal /UNIQ37 Pedestal 95 kg 7.2 KW N/A
UNIQ37 Large 100 kg 7.2 KW N/A
UNIQ36 / UNIQ37 UNIQ36 Pedestal / UNIQ37 Pedestal UNIQ37 Large
Height 980 mm Pedestal 1: 1150 mm / Pedestal 2: 1070 mm 1310 mm
Width 505 mm 505 mm 505 mm
Depth 445 mm 445 mm 445 mm
Closed combustion option Order specific closed combustion option
STOVE PERFORMANCE & TESTING
Westfire UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal have been approved in accordance with EN 13240.
PREPARATORY WORK AND SAFETY CHECKS
IMPORTANT WARNING
This stove must not be installed into a chimney that serves any other heating appliance. There must not be an
extractor fan fitted in the same room as the stove as this can cause the stove to emit fumes into the room.
CHIMNEY
Chimney Connection
Flue Diameter 125 mm
IMPORTANT: Once the stove is unpacked and checked it is necessary to remove the central bar from the flue collar of
the stove before installation. To remove unbolt collar remove bar and replace collar.
When installing your stove with a 125 mm /5” flue please ensure to fill drain hole at rear of cast collar with fire
cement so to prevent any potential leakage of flue gases. Use a proprietary brand of heat resistant fire cement and
ensure that enough cement is used to completely fill the area.
In order for the stove to perform satisfactorily the chimney height must be sufficient to ensure an adequate
draught so as to clear the products of combustion and prevent smoke problems into the room.
Minimum draft: UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal stoves has been tested with a draft of
12 Pa. Maximum draft 25 Pa.
Flue gas flow 7.0 g/sec.
Flue gas temperature 303°C. approximately 12 Pa.
NOTE: A chimney height of not less than 4.5 metres measured vertically from the outlet of the stove to the top of
the chimney should be satisfactory. Alternatively the calculation procedure given in BS 5854:1980 may be used as
the basis for deciding whether a particular chimney design will provide sufficient draught.
The outlet from the chimney should be above the roof of the building in accordance with the provisions of Building
Regulations Approved Document J.
If installation is into an existing chimney then it must be sound and have no cracks or other faults which might allow
fumes into the house. Older properties, especially, may have chimney faults or the cross section may be too large
i.e. more than 160 mm x 160 mm. Remedial action should be taken, if required, seeking expert advice, if necessary.
If it is found necessary to line the chimney then a flue liner suitable for solid fuel must be used in accordance with
Building Regulations Approved Document J.
Any existing chimney must be clear of obstruction and have been swept clean immediately before installation of the
stove. If the stove is fitted in place of an open fire then the chimney should be swept one month after installation to
UK
clear any soot falls which may have occurred due to the difference in combustion between the stove and the open fire.
If there is no existing chimney then either a prefabricated block chimney in accordance with Building Regulations
Approved Document J or a twin walled insulated stainless steel flue to BS 4543 can be used. These chimneys must
be fitted in accordance with the manufacturer’s instructions and Building Regulations.
A single wall metal fluepipe is suitable for connecting the stove to the chimney but is not suitable for using for the
complete chimney. The chimney and connecting fluepipe must have a minimum diameter of 150 mm and its
dimension should be not less than the size of the outlet socket of the stove.
Any bend in the chimney or connecting fluepipe should not exceed 45°. 90° bends should not be used.
If it is found that there is excessive draught in the chimney then either an adjustable flue damper or alternatively a
draught stabiliser should be fitted. The adjustable flue damper should not close off the flue entirely but should in its
closed position leave a minimum continuous opening free area of at least 20% of the total cross sectional area of
the flue or fluepipe.
Adequate provision e.g. easily accessible soot door or doors must be provided for sweeping the chimney and
connecting flue pipe.
Distance to Combustible materials
Combustible materials should not be located where the heat dissipating through the walls of fireplaces or flues could
ignite it. Therefore when installing the stove in the presence of combustible materials due account must be taken of
the guidance on the separation of combustible material given in Building Regulations Approved Document J and also
in these stove instructions.
UNIQ36 /
UNIQ36 Pedestal
UNIQ37 /
UNIQ37 Pedestal / UNIQ37 Large
Distance to combustible materials rear 175 mm 100 mm
Distance to combustible materials side 450 mm 600 mm
Distances to flammable materials/furnitures 1150 mm 825 mm
Hearth
The hearth should be able to accommodate the weight of the stove and its chimney if the chimney is not
independently supported.
The Westfire UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal wood stoves has been tested and is suitable to
be installed on a 12 mm non combustible plate such as Westfire 12 mm glass plates or 20 mm slate plates. Installa-
tion of all hearths should comply in size and construction so that it is in accordance with the provisions of the current
Building Regulations Approved Document J.
The clearance distances to combustible material beneath, surrounding or upon the hearth and walls adjacent to the
hearth should comply with the guidance on the separation of combustible material given in Building Regulations
Approved Document J and also in these stove instructions.
If the stove is to be installed on a wooden floor, it must be covered with a non-combustible material at least 12 mm
thick, in accordance with Building Regulations Approved Document J, to a distance of 30 cm in front of the stove and
15 cm to each side measuring from the door of the combustion chamber.
Combustion air supply
In order for the stove to perform efficiently and safely there should be an adequate air supply into the room in which
the stove is installed to provide combustion air. This is particularly necessary if the room is double-glazed or a flue
draught stabiliser is operating in the same room as the appliance. The provision of air supply to the stove must be in
accordance with current Building Regulations Approved Document J. An opening window is not appropriate for this
purpose. Air inlets must be positioned in such a way that they cannot be blocked. An air inlet may be a vent (the vent
must be open and the capacity of the vent sufficient when the stove is lit) or a fresh air system linked to the stove.
There are no European rules regarding the minimum distance to non-flammable walls, Westfire recommend leaving
a gap of at least 10 cm behind and to sides of stove.

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
12 13
UK UK
Westfire Insulated chambers
The Westfire UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal wood burning stoves is lined with heat deflection
panels and baffles, these panels are designed to ensure the maximum efficiency and are an integral part of the
clean burn process of the stove. These baffles should not be removed apart from for cleaning the stove. Any defec-
tive panels should be replaced.
Connection to chimney
Westfire UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal wood stoves has both rear and top flue connector
that allows connection to either a masonry chimney or a prefabricated factory made insulated metal chimney in
accordance with the instructions for “Connection to chimney” given in the instruction booklet.
Commissioning and handover
Ensure loose parts are fitted in accordance with the instructions, page 16. ‘Vermiculite fire brick installation
sequence’ before handover. Operation of primary and secondary air control sliders must be fully explained.
On completion of the installation allow a suitable period of time for any fire cement and mortar to dry out, when
a small fire may be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and
emitted safely to atmosphere. Do not run at full output for at least 24 hours.
On completion of the installation and commissioning ensure that the operating instructions for the stove are left
with the customer. Ensure to advise the customer on the correct use of the appliance with the fuels likely to be
used on the stove and warn them to use only the recommended fuels for the stove.
Advise the user what to do should smoke or fumes be emitted from the stove. The customer should be warned to
use a fireguard to BS EN 8423:2002 in the presence of children, aged and/or infirm persons.
Secondary Air Control
Right = Open / Left = Closed
Primary Air Control
Right = Open / Left = Closed
Operating your stove – WF36/ WF36 Pedestal and WF37/ WF37 Pedestal
WARNING; CO Alarm
Your installer should have fitted a CO alarm in the same room as the appliance. If the alarm sounds unexpectedly,
follow the instructions given under “Warning Note” above.
Use a fireguard in the presence of children, and old and/or infirm people. The fireguard should be manufactured in
accordance with BS 8423:2002, Fireguards for use with solid fuel appliances.
Initial lighting
The heat-resistant paint on your stove will cure and harden the first time you light your appliance. The curing process
produces a good deal of smoke and odour, it is therefore important that the first time you light your stove the room
should be well ventilated. During the process it is important to open and close the stove door periodically (every
30 mins) during the first couple of firings therefore preventing the door seal cord around the door from sticking and
coming away from the door. Once the Heat-resistant paint has hardened; the stove door must be kept closed except
when lighting the stove, adding firewood or removing ash in order to prevent flue gas from escaping.
Lighting your appliance
Quality Firelighters should be used when lighting the stove. (Never use mentholated spirit, petrol or other
flammable liquids). Lighting your stove with fire lighters will be more reliable and easier than paper.
To light your stove
1. Place a few smaller pieces of dry wood (kindling) in the stove on top of the non toxic firelighters.
2. Open Secondary air by sliding lever above the door to the right and open primary air lever by sliding to
the right.
3. Light the firelighters close the door.
4. Once the fire has caught, add three pieces of wood measuring approx 22 cm with a combined weight of approx
2.1 kg and close the door.
5. After approximately 3 minutes when the fire is burning brightly shut the primary air lever.
6. After approximately another 3 minutes close the secondary air slider by 38%, for the stove to burn cleanly
plenty of secondary air is needed, do not be tempted to shut the fire down too early as this may cause smoke.
At nominal heat output, expect to refuel your stove approximately once an hour.
WF36 / WF37 models are all equipped with air control levers for secondary and primary air and they are
designed to ensure a plentiful supply of oxygen during firing. When lit, the stove will get very hot and due care
must therefore be exercised. Please use a glove when operating handles and air control levers.
RE-FUELING
To re-fuel in the cleanest way. Before refuelling open secondary air lever fully, also open primary air lever fully
and leave for 5 minutes. Open door gently, add three pieces of wood measuring approx 22 cm with a combined
weight of approx 2.1 kg and close the door. Leave the air lever open for 3 minutes to allow the fire to reach a
good temperature. Then close primary air lever and slide secondary air lever by 38%.
In the event of a chimney fire: Close the primary and secondary air sliders and the stove door, and call 999 or
your local fire department. If your stove is over heating close the Primary and secondary air sliders and
ensure door is firmly closed, and left until the stove has return to nominal temperatures’.
Basic Positions of air sliders during Operation
You will need to become familiar with your stove in order to be able to regulate the secondary air intake correctly,
as factors such as the quality and height of your chimney, the quality of your fuel and the external conditions play a
large role in your stove performance. It is easy to see whether the stove is functioning correctly; however incomplete
combustion may lead to a build-up of hard, shiny soot on the inside of your stove and glass.
To prevent sooting of the chamber and glass introduce secondary air, also check that your wood is dry.
It is important to check the draft conditions before lighting your stove. This may be done, for instance, by crumpling
a piece of newspaper, placing it in the combustion chamber and lighting it. The draft conditions are good if the
smoke is drawn away through the chimney.

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
14 15
UK UK
Operational Position of air sliders during operation and in adverse conditions
You need to become familiar with your stove in order to be able to regulate the air controls (sliders) correctly, as
outside factors such as the quality and height of your chimney, the quality of your fuel and the external weather
conditions can alter the stoves operational settings and performance.
Very damp weather can affect the draw of the stove and therefor more secondary air may be needed to adjust.
Very still cold clear days induce more draught and the setting for secondary air may be less than nominal settings.
Such accommodations will become normal once you are familiar with your stove.
It is easy to see whether the stove is functioning correctly; incomplete combustion will be shown by
1) The inside of the fire chamber firebricks having a black dusty build up,
2) A build-up of hard shiny soot on the inside of the glass
3) Smoking chimney
To prevent sooting of the chamber and glass introduce more secondary air, also check that your wood is dry.
CONTROLS ON WESTFIRE UNIQ36/ UNIQ36 Pedestal and UNIQ37/ WF37 Pedestal
Door operation
When opening the door of your Westfire stove always wear the glove that is provided to protect your hand from
possible heat. The handle pulls out right away from the fire. When shutting the door push the door closed and push
the handle until the handle firmly closes.
WOOD FUEL
IMPORTANT: Never use toxic wood such as chipboard, impregnated or painted wood.
Good quality wood is the most important factor in your stove working efficiently and cleanly. Always use dry
firewood. The dryness of the firewood plays an important role since the use of wet wood results in poor fuel
economy and may cause a tarry sooty film on the internals of the stove.
Newly cut wood contains 60-70% water, making it totally unsuitable for use as firewood.
Newly cut wood should be stacked and air dried under cover for two years before being used as firewood.
SMOKELESS COAL, HOUSE COAL AND PETROLEUM COKE ARE NOT SUITABLE FOR USE ON THIS STOVE; ITS USE WILL
INVALIDATE THE GUARANTEE
SOLID SMOKELESS FUELS – WESTFIRE UNIQ 36 & 37 models are NOT suitable for use with smokeless fuels and have
not been tested to the relevant European standard. Only use wood for these stoves.
PETROLEUM COKE IS NOT SUITABLE FOR USE ON THIS STOVE; ITS USE WILL INVALIDATE THE GUARANTEE
Overnight burning
Westfire stoves are wood stoves, wood burns more efficiently and cleanly if is burnt hotter. Westfire do not
recommend that their stoves are burnt overnight for this reason.
As a night time regime we recommend that the fire is loaded when hot and burnt for five minutes with the
secondary air valve fully open until the new wood has taken and is burning, then close the secondary air valve to
its operational position.
On returning to the stove in the morning the fire will have burn out, reload with some paper or firelighter and some
kindling and open all the values fully open and the stove will relight quickly. Beware as the ash bed will have hot
embers.
Use of operating tools
Always use the operating tools provided when handling parts likely to be hot when the stove is in use.
Maintenance
UNIQ36/ WF36 Pedestal and UNIQ37/ WF37 Pedestal wood stoves needs to have the ash removed from the stove
at regular intervals. Make sure the stove is completely cold before cleaning out ash (embers can remain hot for over
24 hours). To clean the outside of the stove use a dry cloth.
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a
smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed
boiler if located in a designated smoke control area. It is also an offence to acquire an “unauthorised fuel” for
use within a smoke control area unless it is used in an “exempt” appliance (“exempted” from the controls which
generally apply in the smoke control area).
In England appliances are exempted by publication on a list by the Secretary of State in accordance with changes
made to sections 20 and 21 of the Clean Air Act 1993 by section 15 of the Deregulation Act 2015. In Scotland
appliances are exempted by publication on a list by Scottish Ministers under section 50 of the Regulatory Reform
(Scotland) Act 2014. Similarly, In Northern Ireland appliances are exempted by publication on a list by the
Department of Agriculture, Environment and Rural Affairs under Section 16 of the Environmental Better regulation
Act (Northern Ireland) 2016. In Wales appliances are exempted by regulations made by Welsh Ministers.
Further information on the requirements of the Clean Air Act can be found here:
https://www.gov.uk/smoke-control-area-rules
Your local authority is responsible for implementing the Clean Air Act 1993 including designation and supervision
of smoke control areas and you can contact them for details of Clean Air Act requirements.
The WESTFIRE UNIQ 36 & 37 SE stoves have been recommended as suitable for use in smoke control areas when
burning wood logs. The appliances have been fitted with a modification to fix the air controls at 40% open for
WESTFIRE UNIQ 36 & 37 model in its minimum position.
Only specific SE models are suitable for smoke control areas, alterations should not be attempted.
Westfire smoke control stoves should not be burnt with the door left open.
The refuelling procedure : - allow the newly charged fuel to burn with the secondary air control set at maximum
for up 3 to 4 minutes. After this period, with flames from the logs fully established, close the secondary air supply
to the low output setting. When operating at high output (secondary air set fully open) the new refuel charge
does not require any boost air to establish combustion.
RE-FUELLING WHEN BURNING WOOD
BURNING WOOD IN A SMOKE CONTROL AREA
To re-fuel your stove in the cleanest way only refuel your stove when flames have died down and you have
glowing embers. Before refuelling, open air controls fully and slide. Unlatch door to equalise pressure with the
room. Open door gently, add one piece of wood WESTFIRE UNIQ 36 & 37 and close the door. Once the flames from
the logs are fully established move air control to nominal position. The stove
is only suitable for intermittent use only: do not run overnight or for long periods unattended.
Experience will determine the settings that produce best results. Use a flue thermostat to check the stove is not
overheating. Flue thermostats should be placed directly above collar of the stove on a non insulated section of
pipe. (efficient operating temperature range is between 200c and 400c?)
SE MODELS – smoke exemption modification
Smoke exempt models are factory fitted with a air stop on the air control slider:
Refuelling on to a low fire bed
If there is insufficient burning material in the firebed to light a new fuel charge, excessive smoke emission can
occur. Refuelling must be carried out onto a sufficient quantity of glowing embers and ash that the new fuel
charge will ignite in a reasonable period. If there are too few embers in the fire bed, add suitable kindling to
prevent excessive smoke.
Stove Log length & weight
WF 36 3 pieces approx 22 cm, 2.1 kg
WF 37 3 pieces approx 22 cm, 2.1 kg

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
16 17
UK UK
Operation with door left open
Operation with the door open can cause excess smoke. The appliance must not be operated with the appliance
door left open except as directed in the instructions.
Dampers left open
Operation with the air controls or appliance dampers open can cause excess smoke. The appliance must not be
operated with air controls, appliance dampers or door left open except as directed in the instructions.
Fuel Overloading
The maximum amount of fuel specified in this manual should not be exceeded, overloading can cause excess
smoke.
Annual service
The inside of the stove should be serviced /cleaned once a year. To clean the inside, remove all ash, soot and tar
residue from the combustion chamber. Remove insulated chamber panels and baffle, dirt and soot will collect
behind it and this must be cleaned out. Insulated panels may crack if hit too hard by a piece of firewood. This has no
effect on the function of the stove (this is not the case with the smoke plate). The Insulated panels will only need to
be replaced once they become very worn and are no longer whole, or if they crack in several places. Check glass is
correctly positioned, replace stove door rope cord in the door. Check glass is correctly positioned.
The stove, the flue pipe connection and the chimney should be checked regularly by a qualified engineer. The
chimney should also be checked for blockages before relighting the stove if it has not been used for an extended
period of time.
The paint/ lacquer can wear thin in exposed places due to overheating. This, and other lacquer damage, may be
repaired using a Westfire Senotherm paint/lacquer spray available from your Westfire dealer.
Ash must be stored in a non-combustible container and must not be mixed with other combustible waste.
TROUBLE SHOOTING, CHECK THE FOLLOWING:
1. Fire Will Not Burn
a) the air inlet is not obstructed in any way,
b) that chimneys and flueways are clear,
c) that a suitable fuel is being used,
d) that there is an adequate air supply into the room,
e) that an extractor fan is not fitted in the same room as the fire.
2. Fire Blazing Out Of Control
a) the doors are tightly closed,
b) the air control is turned down to the minimum setting,
c) the air inlet damper is closed and that it is not prevented from closing completely by a piece of ash,
d) a suitable fuel is being used,
e) the door seals are in good condition.
f) the chimney draft may be too strong
g) check ash pan seal and
h) check for ash below ash pan causing pan to not seat correctly and clean out.
3. Soot forms on the window
a) The firewood may be too wet
b) the intake of secondary air may be insufficient
c) fire not hot enough
4. The stove fails to heat fully
a) The firewood may be too wet
b) the intake of secondary air may be insufficient
5. Smoke or odour
a) Weak chimney draft
b) check for blockages in the flue pipe/chimney
c) check the height of the chimney in relation to the surroundings
6. Soot in the chimney
a) The firewood may be too wet
b) intake of secondary air may be insufficient
Chimney Fires
If the chimney is thoroughly and regularly swept, chimney fires should not occur. However, if a chimney fire does
occur turn the air control setting to the minimum, and tightly close the doors of the stove. This should cause the
chimney fire to go out in which case the control should be kept at the minimum setting until the fire in the stove has
gone out. The chimney and flueways should then be cleaned. If the chimney fire does not go out when the above
action is taken then the fire brigade should be called immediately.
After a chimney fire the chimney should be carefully examined for any damage. Expert advice should be sought if
necessary.
Permanent air vent
The stove requires a permanent and adequate air supply in order for it to operate safely and efficiently.
In accordance with current Building Regulations the installer may have fitted a permanent air supply vent into the
room in which the stove is installed to provide combustion air. This air vent should not under any circumstances be
shut off or sealed.
WARNING NOTE
Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from
de ashing and re fuelling may occur. However, persistent fume emission is potentially dangerous and must not be
tolerated. If fume emission does persist, then the following immediate action should be taken:
(a) Open doors and windows to ventilate room
(b) Let the fire out or eject and safely dispose of fuel from the appliance
(c) Check for flue or chimney blockage and clean if required
(d) Do not attempt to relight the fire until the cause of the fume emission has been identified and corrected.
If necessary seek expert advice.
The most common cause of fume emission is flueway or chimney blockage. For your own safety these must be kept
clean at all times.
IMPORTANT NOTES
General
Before lighting the stove check with the installer that the installation work and commissioning checks described in
the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and
free from any obstructions. As part of the stoves’ commissioning and handover the installer should have shown you
how to operate the stove correctly.
Use of fireguard
When using the stove in situations where children, aged and/or infirm persons are present a fireguard must
be used to prevent accidental contact with the stove. The fireguard should be manufactured in accordance with
BS EN 8423: 2002.
Chimney cleaning
The chimney should be swept at least once a year for smokeless fuels and a minimum of twice a year for wood and
other fuels. It is important that the flue connection and chimney are swept prior to lighting up after a prolonged
shutdown period.

WESTFIRE · WF36 WF37 WESTFIRE · WF36 WF37
18 19
GEWICHTNORMASTKBENENNUNG
NÁZOVČÍSLO/NUMMER
POS
53,709 kg1
ZVARENEC KRBU
550-9-37-01-100-11
1,345 kg1
POPOLNÍK
550-0-37-00-019-119
0,232 kg1
RÁMIK ROŠTU ZVARENEC
550-9-60-07-100-110
2,076 kg1ROST
ROŠT PEVNÝ
550-0-16-00-015-112
0,150 kg 1
BEŽEC PRIMÁRU
550-0-37-00-013-113
0,026 kg 2
GLASSCHEIBEDICHTUNG
TESNENIE BOČNÉHO SKLA
550-0-37-00-041-141
0,711 kg 2
SKLO BOČNÉ
550-0-37-00-027-127
0,010 kg 4
TESNENIE PRÍCHYTKY BOČNÉHO SKLA
550-0-37-00-040-140
0,183 kg 2
PRÍCHYTKA SKLA ZADNÁ
550-0-37-00-018-118
1,427 kg 1RAUCHSTUTZ
DYMOVOD
541-0-05-00-008-1
28
0,009 kg 1RAUCHSTUTZDICHTUNG
TESNENIE DYMOVODU
550-0-03-01-328-1
29
10,239 kg 1
DVERE MONTÁŽ
550-9-37-03-000-1
3
0,024 kg1
KONZOLA VALČEKA DOLNÁ ZVARENEC
550-9-37-09-100-19
0,024 kg1
KONZOLA VALČEKA HORNÁ ZVARENEC
550-9-37-08-100-18
0,001 kgDIN 12510
DIN 125 - A 6,4
56
0,005 kgDIN 9338DIN 933 - M6 x 1251
0,003 kg
ANSI
B18.16.3M
3
ANSI B18.16.3M -
Třída vlastností 5 a
10 - Metrický M6 x 1
Typ kovu
55
3,811 kg1
SPODNÉ DVERE MONTÁŽ
551-9-37-07-000-17
0,001 kgDIN 1371 DIN 137 - B859
0,003 kgDIN 9021
5
DIN 9021 - 6,458
5,062 kg 1
HORNÝ KRYT ZVARENEC
550-9-37-02-100-12
2,020 kg 1Vermiculit - Rückwand
OBKLAD ZADNÝ
550-0-37-00-035-11
0,467 kg 1Vermiculit - Seitenstein rechts
OBKLAD BOČNÝ PRAVÝ
550-0-37-00-030-22
0,098 kg
2
Vermiculit - Seitenstein rechts
OBKLAD BOČNÝ DOLNÝ
550-0-37-00-032-1
4
0,460 kg 1Vermiculit - Oberes
OBKLAD SPODNÝ BOČNÝ PRAVÝ
550-0-37-00-036-1
5
0,070 kg
2
THERMAX - BODENSTEIN HINTEN
OBKLAD SPODNÝ PRIEČNY
550-0-37-00-038-1
7
0,467 kg1
OBKLAD BOČNÝ ĽAVÝ
550-0-37-00-031-23
7,220 kg1
OBKLAD SPODNÝ BOČNÝ ĽAVÝ
550-0-37-00-037-16
1,140 kg1
OBKLAD NADOHNISKOVÝ
550-0-37-00-034-28
0,044 kg1
MOSTÍK DYMOVODU
550-0-16-00-013-123
0,002 kg2
PODLOŽKA 6,4x15
BN 73557
0,008 kgDIN 9332DIN 933 - M6 x 2553
0,003 kgDIN 9346DIN 934 - M654
1,067 kg1
OBKLAD HORNÝ
550-0-37-00-033-29
0,164 kg2
PRÍCHYTKA SKLA PREDNÁ
550-0-37-00-017-117
0,040 kg2
KONZOLA ZÁVESU
550-0-37-00-020-120
0,003 kgISO 738012 Skrutka M6 x 6ISO 7380 - M6 x 650
0,777 kg 1
TIENIACI PLECH BOČNY PRAVÝ
ZVARENEC
550-9-37-11-100-111
0,231 kg 1
LAMELA HRADLA
550-0-37-00-014-111
0,777 kg 1
TIENIACI PLECH BOČNY ĽAVÝ
ZVARENEC
550-9-37-12-100-112
0,179 kg 1
BEŽEC SEKUNDÁRU
550-0-37-00-015-115
WF 37
8
1
2
3
4
6
5
10
11
7
12
9
Number Code Description
1 W93700-02-03-99-00 Rear fire brick
2 W93700-02-24-99-00 Right side rear brick Part brick set
3 Left side rear brick
4 Side bricks front x 2
5 W93700-02-22-99-00 Base right brick Part brick set
6 Base left brick
7 Base front and rear brick
8 W93700-02-04-99-00 Lower baffle brick
9 W93700-02-05-99-00 Upper baffle brick
10 W92300-05-07-00-00 Grate support
11 W93700-04-02-00-00 Log retainer x 2
12 Cast iron grate
If the stove is fitted in place of an open fire then the chimney should be swept one month after installation to clear
any soot falls which may have occurred due to the difference in combustion between the stove and the open fire.
In situations where it is not possible to sweep through the stove the installer will have provided alternative means,
such as a soot door. After sweeping the chimney the stove flue outlet and the flue pipe connecting the stove to the
chimney must be cleaned with a flue brush.
HETAS Ltd Approval
This appliance has obtained HETAS Ltd approval on a safe and fit for purpose level (single tick approval) for burning
wood logs only as detailed in list of recommended fuels. Approval does not cover the use of other fuels either alone
or mixed, nor does it cover instructions for the use of other fuels.
GUARANTEE
Your new stove is covered by a five year guarantee against manufacturing defects. Your receipt documents the date
of purchase. The guarantee does not cover damage caused by faulty operation such as overheating or the stove
being incorrectly connected, or damage which occurs as a result of external physical force.
The guarantee does not cover damage to replaceable parts, transport costs associated with repairs under warranty
or the installation/dismantling of the stove in connection with repairs under warranty.
Warning! Any unauthorised modification of the appliance is forbidden.
Only replacement parts recommended by Westfire should be used for repairs.
UK UK
