Chevrolet 2007 TrailBlazer Assembly instructions

DRIVER INFORMATION
Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Instrument Panel Cluster . . . . . . . . . . . . . . . . . . . . . .3
Driver Information Center . . . . . . . . . . . . . . . . . . . . .4
SAFETY & SECURITY
Programmable Automatic Door Locks . . . . . . . . . . .5
Remote Lock/Unlock Feedback . . . . . . . . . . . . . . . . .6
OnStar
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Remote Keyless Entry System . . . . . . . . . . . . . . . . .7
Content Theft-Deterrent System . . . . . . . . . . . . . . . .8
COMFORT
Manual Dual-Zone Climate Controls . . . . . . . . . . . . .8
Automatic Dual-Zone Climate Controls . . . . . . . . . .9
Electric Adjustable Pedals . . . . . . . . . . . . . . . . . . . .10
Heated Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Memory Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ENTERTAINMENT
AM/FM Stereo with CD and RDS . . . . . . . . . . . . . . .11
AM/FM Stereo with Six-Disc CD . . . . . . . . . . . . . . .12
Touch Screen Navigation
Entertainment System . . . . . . . . . . . . . . . . . . . . . . .13
CONVENIENCE
Headlamp Controls . . . . . . . . . . . . . . . . . . . . . . . . . .13
Automatic Lamp Control . . . . . . . . . . . . . . . . . . . . .14
Dome Lamp Override . . . . . . . . . . . . . . . . . . . . . . . .14
Outside Rearview Mirrors . . . . . . . . . . . . . . . . . . . .15
Universal Home Remote . . . . . . . . . . . . . . . . . . . . .15
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Luggage Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
PERFORMANCE & MAINTENANCE
Malfunction Indicator Lamp . . . . . . . . . . . . . . . . . . .17
Four-Wheel Drive . . . . . . . . . . . . . . . . . . . . . . . . . . .17
StabiliTrak
®
– Stability Control System . . . . . . . . .17
Tire Pressure Monitor . . . . . . . . . . . . . . . . . . . . . . . .18
OWNER INFORMATION
Roadside Assistance . . . . . . . . . . . . . . . . . . . . . . . .20
My GMLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Congratulations on your purchase of a Chevrolet TrailBlazer. Please read this information and your Owner
Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the
features described in this booklet. Keep this booklet with your Owner Manual for easy reference.

A. Exterior Lamp Controls
B. Air Outlets
C. Turn Signal/Multifunction Lever
D. Instrument Panel Cluster
E. Ignition Switch
F. Transfer Case Controls or Traction
Control Button (if equipped)
G. Rear Window Washer/Wiper
H. Audio System
I. Climate Controls
J. Hood Release
K. Ashtray (if equipped)
L. Shift Lever
M.Lighter (if equipped)
N. Accessory Power Outlet
O. Rear Window Defogger
(if equipped)
P. Glove Box
Getting to Know Your TrailBlazer
2
See Section 3 of your Owner Manual.
Instrument Panel
DRIVER INFORMATION

3
See Section 3 of your Owner Manual.
A
BCD
E
F
Instrument Panel Cluster
Your vehicle’s instrument panel is
equipped with this cluster or one very
similar to it. The instrument panel
cluster includes these key features:
A. Tachometer
B. Speedometer
C. Engine Oil Pressure Gauge
D. Fuel Gauge
E. Voltmeter
F. Engine Coolant Temperature
Gauge
Note: The instrument panel cluster is
designed to inform you about many
important aspects of your vehicle’s
operation. It is important to read your
Owner Manual and become familiar
with the information being relayed to
you by the lights, gauges and indicators,
as well as what action can be taken to
ensure safety and to prevent damage
to your vehicle.

Getting to Know Your TrailBlazer
4
Reset fuel information
• Press the reset stem located on the
DIC cluster or the reset button on the
steering wheel.
Customize vehicle settings
• Press once and current-driver
preferences will be displayed. Any
changes made at this time affect only
the displayed driver.
• Press again to scroll through and
customize menu features.
Use Reset button
•When you find the choice you want,
press to select it and move on to
the next feature.
Reset all customization features to
their default settings
•Press and hold the Trip Information
button ( ) and the Customization
button ( ) for four seconds.
Recall driver preferences
•Press memory button #1 or #2
located on the driver’s door.
Driver Information Center (DIC)
(if equipped)
The DIC display is located above the
steering wheel on the instrument cluster,
and can be programmed in three lan-
guages. The controls are located on the
steering wheel:
Access trip information
• Press to access each of the
odometer, Trip A, Trip B and Timer
functions.
Reset trip odometers to zero
•Press the reset stem located on the
DIC cluster or use the reset button
( ) on the steering wheel.
Access fuel information
•Press to view range, average fuel
used and the GM Oil Life SystemTM
status.

5
Available Customization Features
Depending on the equipment ordered
on your vehicle, you could customize a
wide variety of preferences on the DIC.
Only the features included on your vehi-
cle will be displayed by the DIC.
Customization features can include:
• Alarm Warning Type
• Automatic Locking and Unlocking
• Perimeter Lighting
• Remote Lock and Unlock Feedback
• Headlamps On at Exit
• Mirror Curb View Assist
• Easy Exit Driver Seat
• Display Units (English/Metric)
• Display Language
See Section 3 of your Owner Manual.
Programmable Automatic
Door Locks
Your vehicle includes an automatic door
lock/unlock system with a choice of four
features, as well as automatic door lock-
out prevention to prevent locking the
keys in the vehicle. In the event the
power door lock switch is activated
when a door is open and the key is in
the ignition, the driver door will unlock.
Locking options: The default setting
for the programmable automatic door
locks is to lock automatically when the
transmission is shifted into gear. Locking
options include:
Mode 1: All doors lock when the trans-
mission is shifted into gear
Mode 2: All doors lock when vehicle
speed is over 8 mph (13 kph)
Unlocking options: Choose one of the
following options before personalizing
your unlocking preference:
Mode 1: Driver’s door unlocks when the
transmission is placed into Park
Mode 2: All doors unlock when the
transmission is shifted into Park
Mode 3: All doors unlock when the key
is removed from the ignition
Mode 4: No automatic door unlock
SAFETY & SECURITY

Getting to Know Your TrailBlazer
6
Remote Lock/Unlock Feedback
(if equipped)
Program Remote Keyless Entry
System lock/unlock feedback (horn,
parking lamps, both or neither)
• Press the Personalization button
( ) on your steering wheel until
LOCK FEEDBACK (or UNLOCK
FEEDBACK, as desired) appears on
the display.
• Press the Select button ( ) to scroll
through the menu of choices. To
program the lock/unlock feedback
feature, press when the desired
menu option is displayed.
See Section 3 of your Owner Manual.
Select and program functions
(if vehicle is equipped with a Driver
Information Center)
• Press the personalization button
( ) on the Driver Information Center
until LOCKS appears on the display.
Press the Select button ( ) until the
desired setting appears on the dis-
play and press to select it.
Select and program functions (if not
equipped with DIC)
1. With ignition off, pull the turn
signal/multifunction stalk toward you
and hold it there while performing the
next step.
2. Turn the ignition key to Run and Lock
twice, ending in the Lock position,
and release the turn signal stalk; the
lock switch locks/unlocks, the horn
chirps twice and a 30-second timer
begins.
3. To cycle through the locking/unlock-
ing choices, press the power door
lock switch to the Lock position to set
locking preference and the Unlock
position to set unlocking preference.
When the lock switch locks/unlocks
and the horn chirps twice, you have
left programming mode; if more time
is needed, repeat the process above.
4. To exit the program mode manually,
turn the ignition key to Run.
See Section 2 of your Owner Manual.

7
If your vehicle is OnStar-equipped, the
OnStar system provides in-vehicle safe-
ty, security, and phone services, avail-
able 24 hours a day, 7 days a week.
These services are easily accessed
through the three OnStar buttons in
your vehicle.
• Press the blue OnStar button to
connect to an OnStar Advisor for
services such as OnStar Vehicle
Diagnostics or driving directions
and location assistance.*
• Press the white Phone button to
make phone calls using OnStar
Hands-Free Calling.**
• Press the red Emergency button to
connect to an OnStar Advisor who
can contact a nearby emergency
services provider to request emer-
gency services be dispatched to
your location.
For more information about OnStar
features, refer to the OnStar Owner’s
Guide and enclosed audio CD located in
your glove box.
* Routing and location assistance may require service
upgrade
**Available in most markets
See Section 2 of your Owner Manual.
OnStar®(if equipped) Remote Keyless Entry System
(if equipped)
On equipped vehicles, the RKE system
locks and unlocks the doors and liftglass
from a range of three to 30 feet. At times
the range may be shorter than usual,
which is normal. If the transmitter does
not seem to be working properly:
• Ensure that you are within transmitter
range of the vehicle. Rainy and
snowy weather can reduce transmit-
ter range.
• Check to see whether other vehicles
or obstacles are blocking the trans-
mitter signal by stepping a few feet
to the left or right, and holding the
transmitter higher when pressing
the button(s).
• Consider the length of time that
the transmitter battery has been in
service and replace it if necessary
(the DIC will display RFA BAT # LOW
if the battery needs replacing). Use
CR 2032 battery or equivalent.
See Section 2 of your Owner Manual.

COMFORT
Getting to Know Your TrailBlazer
8
Manual Dual-Zone Climate
Controls (if equipped)
Content Theft-Deterrent System
(if equipped)
This feature has a Security light ( )
located in the instrument panel cluster.
After closing all vehicle doors, the
system can be activated in two ways:
• Press the Lock button on the Remote
Keyless Entry key fob, or
• Press the power door Lock switch
with the door open.
The alarm is not armed until the
security light turns off (after a delay of
approximately 30 seconds).
If the alarm is tripped, the horn sounds
for 30 seconds, and the headlamps and
parking lamps also flash for two minutes
to get visual attention. The alarm sounds
whenever a locked door is opened
without the key or Remote Keyless
Entry transmitter.
See Section 2 of your Owner Manual.
( ) Instrument panel vents
( ) Instrument panel vents and
floor vents
( ) Floor vents
( ) Floor, windshield and side
window vents
( ) Windshield and side window
vents
Raise or lower fan speed
• Turn the fan control knob ( ) on the
left of the climate control panel.
Adjust the dual temperature controls
• Use the lever on the left-hand side of
the climate control panel to adjust the
temperature on the driver’s side of
the vehicle.
• Use the right-hand lever to adjust the
temperature on the front passenger’s
side of the vehicle and the tempera-
ture for the second row.
Cool the vehicle interior more quickly
on very hot days
• Open the windows just long enough
to let the hot air escape.
• Choose the coolest temperature
setting.
• Activate the Recirculate ( ) and
A/C ( ) buttons.
• Place the A/C mode knob in the ( )
Vent mode.
Recirculate interior air and prevent
outside air from entering your vehicle
• Press the Recirculate ( ) button.
This feature can be activated while in
the Vent or Bi-Level mode, but not in
Defog, Defrost or Floor mode.
Select airflow source
• Turn the Mode knob on the right of
the climate control panel to the
desired setting:

9
Automatic Dual-Zone Climate
Controls (if equipped)
Turn on the rear window defogger
• Press the rear window defogger
(REAR) button.
• The indicator light on the button will
come on to let you know the rear
window defogger is active.
See Section 3 of your Owner Manual.
Manually select desired airflow source
• Press and release the Mode ( )
button until the desired source is
indicated on the display. Mode selec-
tions include Vent, Bi-Level, Floor
and Defog.
Manually raise or lower fan speed
• Press the upper or lower portion of
the fan control ( ) button.
Manually adjust the dual temperature
controls
•Use the knob on the left-hand side of
the climate control panel to adjust the
temperature on the driver’s side of
the vehicle. Use the right-hand knob
to adjust the temperature on the pas-
senger’s side of the vehicle as well
as the second row.
• To match and link the passenger-side
temperature to the driver’s, press and
hold the AUTO button for three seconds.
Recirculate interior air and prevent
outside air from entering your vehicle
• Press the Recirculate ( ) button.
This feature can be activated while in
the Vent or Bi-Level mode, but not in
Defog, Defrost or Floor mode.
Clear the windshield and front side
windows of fog or frost more quickly
• Press the button and adjust the
fan speed.
Clear the rear glass of fog or frost
more quickly, and activate the heated
outside rearview mirrors (if equipped)
• Press the Rear button.
• The indicator light on the button will
come on to let you know the rear
window defogger is active.
Automatic Operation
In the automatic mode, the system
will automatically control the inside
temperature, air delivery mode and
the fan speed to achieve your set
temperature as quickly as possible.
1. Press the AUTO button.
2. Set the driver’s and passenger’s
temperatures.
Rear Seat Controls (if equipped)
Rear seat comfort controls are located
on the rear seat audio system display.
When the front climate control MODE
button is set to Defrost, the rear controls
do not function.
See Section 3 of your Owner Manual.

Getting to Know Your TrailBlazer
10
Heated Seats (if equipped)
Activate heat for the seatback only
•Press the vertical switch located on
the front door armrest until the switch
light indicates the desired setting.
Memory Seats (if equipped)
The memory seat controls are located
on the driver door. They program and
recall driver seat position and outside
mirror settings for up to two drivers.
Store the driver seat and mirror
settings
1. Adjust the seat and outside mirrors to
the desired position.
2. Press and hold memory button #1 for
three seconds until a chime sounds
to indicate that the seat position is
now stored.
Repeat the sequence using memory
button #2 for a second driver.
See Section 2 of your Owner Manual.
Electric Adjustable Pedals
(if equipped)
Adjust brake and accelerator pedals
to a comfortable setting
• Operate the pedal adjustment switch
located on the steering column.
See Section 2 of your Owner Manual.
Note: The pedals cannot be positioned
farther away from the driver than they
are in their standard position. This fea-
ture can be programmed to work with
the memory function (if equipped) on
your vehicle. Adjustment of the powered
pedals requires that the vehicle be in
Park and the key be out of the ignition.
Activate heat for seatback and seat
cushion
• Press the horizontal switch located on
the front door armrest until the switch
light indicates the desired setting.
See Section 1 of your Owner Manual.
Note: The engine must be running for
the heated seat feature to work.
