Cheyenne BE1058-ORB-COM User manual

ASSEMBLY INSTRUCTIONS
Page 1
CHEYENNE PRODUCTS
**
**
Item# BE1058-ORB-COM/BE1058-WHT-COM/BE1058-GLD-COM/
BE1058-NKL-COM
UPC# 05027699528-9/05027699529-6/05027699530-2/05027699531-9
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER
In the unlikely event that you should have a problem with your merchandise, o
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
r you are missing
parts or tools, Please contact our dedicated customer service team at 1-800-737-5267 or email
[email protected] to request parts, tools, or assistance with your
merchandise. Our offices are open Monday through Friday between 8:00 AM and 6:00 PM -
(Eastern Time Zone) - excluding major holidays. Our customer service representatives are
committed to resolving your problem as quickly as possible.

Page 2
1) BOLT (14 PCS)
1/4” x 1 3/16”L
A) LEFT SIDE BOTTOM
FRAME (1 PC)
B) RIGHT SIDE BOTTOM
FRAME (1 PC)
C) LEFT SIDE UPPER
FRAME (1 PC)
D) RIGHT SIDE UPPER
FRAME (1 PC)
2) MOUNTING SCREW (2 PCS) 3) PLASTIC ANCHOR (2 PCS)
4) ALLEN WRENCH (1 PC) 5) Cap (4 PCS) 6) SCREW (2 PCS)
NOTE: Phillips head screwdriver required
but not provided.
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER.
Please contact our dedicated customer service team at 1-800-737-5267 or email
[email protected] to request parts or assistance with your
merchandise. Office hours: Monday - Friday from 8:00 AM - 6:00 PM - (Eastern Time Zone)
Assemble on soft surface to prevent damage to the product finish.
Carefully remove all parts and tools from the box and make sure that no parts or tools
listed on the assembly instructions are missing.
Cheyenne products is committed to helping save the environment for future
generations. We encourage you to reuse or recycle all of the materials used in
the packaging of this product.
DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT.
To ensure proper assembly, use only the parts included and use only the tools that are
included or specifically described in these assembly instructions.
**
**
**
**
LOT NUMBER:
DATE OF PURCHASE:

F) LOWER BACK
FRAME (2 PCS)
E) UPPER BACK
FRAME (1 PC)
G) METAL SHELF
(3 PCS)
H) BOTTOM SUPPORT
BAR (1 PC)
I) BACK EXTRA
4 3/16” TUBE (2 PCS)
J) FRONT EXTRA
4 3/16” TUBE (2 PCS)
Page 3
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER.
Please contact our dedicated customer service team at 1-800-737-5267 or email
[email protected] to request parts or assistance with your
merchandise. Office hours: Monday - Friday from 8:00 AM - 6:00 PM - (Eastern Time Zone)
Step 1:
Insert left and right side bottom frames (A+B) into left and right
side upper frames (C+D).
B
D
A
C

Page 4
Step 2 :
Step 3 :
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER.
Please contact our dedicated customer service team at 1-800-737-5267 or email
[email protected] to request parts or assistance with your
merchandise. Office hours: Monday - Friday from 8:00 AM - 6:00 PM - (Eastern Time Zone)
Attach the metal shelves (G) x3
to the side frames (B+D) using
bolts (1) x6. Only tighten bolts halfway.
Insert upper and lower back frames (E+F) into left
and right side upper frames (C+D) as shown.
Fully tighten all bolts from steps 1 - 3 .
Attach the left side frames (A+C) to the metal shelves (G)
using bolts (1)x6. Leave the bolts very loose.
1 (x6 )
1 (x6)
G
G
G
D
B
D
B
CF
F
E
A

H
Due to variations in bathroom styles, this
Space Saver is height adjustable.
For a shorter Space Saver:
Attach the bottom support bar (H) to the
space saver frame using bolts (1) x2. Only
tighten bolts halfway.
Insert the four foot caps (5)x4 to right and
left bottom sideframe (A+B) .
Now fully tighten all the bolts from step 1~4.
For a taller Space Saver:
Insert the Front Extra Tubes (J)x2 into the
front left and right side of frame (A+B) and
fasten with screws (6)x2.
Insert the Back Extra Tubes (I)x2 into the
back left and right side of frame (A+B).
To secure the Back Extra Tubes (I)x2 to the
frame (A+B), use bolts (1)x2 to connect
Support Bar (H) as shown.
Fully tighten all the bolts from steps 1~4.
Step 4 :
Option 1:
Option 2:
H
AB
C
(1) x 2
(6) x 2
(1) x 2
A
B
C
I
J
