Chicago Electric 94748 Parts list manual

BELT SANDER
3” X 21”
94748
ASSEMBLY AND OPERATION INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND
ALL WARNINGS AND INSTRUCTIONS BEFORE USE.
Copyright©2006 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 2
PRODUCT SPECIFICATIONS
Motor 120 VAC / 60 Hz / 6 Amps / 2,625 RPM Motor
Double Insulated
Power Cord 6 Ft. x 18 Gauge with 2-Prong Plug
Trigger 2-Finger ON/OFF
Sandpaper Size 3” Wide x 21” Long
Features 1 to 6 Variable Speed Dial (1,025 to 2,625 speed range)
3-Position Adjustable Front Handle
Built-In Dust Collection
All Ball Bearing Construction
Quick Belt Change with Quick Release Tension Lever
Accessories Vacuum Bag / 80 Grit Sanding Belt
Overall Dimensions 13” Long x 6-1/4” Wide x 6-5/8” High
Unit Weight 7 Pounds
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, oper-
ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as in the pres-
ence of flammable liquids, gases, or dust. Power tools create sparks which may
ignite the dust or fumes.
Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
1.
2.
3.
E194601

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 3
ELECTRICAL SAFETY
Grounded tools must be plugged into an outlet properly installed and grounded
in accordance with all codes and ordinances. Never remove the grounding
prong or modify the plug in any way. Do not use any adapter plugs. Check with
a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. If the tools should electrically malfunction or break down, grounding
provides a low resistance path to carry electricity away from the user.
Double insulated tools are equipped with a polarized plug (one blade is wider
than the other). This plug will fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician to install a polarized outlet. Do not change the plug
in any way. Double insulation eliminates the need for the three wire grounded
power cord and grounded power supply system.
Avoid body contact with grounded surfaces such as pipes, radiators, ranges,
and refrigerators. There is an increased risk of electric shock if your body is
grounded.
Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
Do not abuse the Power Cord. Never use the Power Cord to carry the tools or
pull the Plug from an outlet. Keep the Power Cord away from heat, oil, sharp
edges, or moving parts. Replace damaged Power Cords immediately. Dam-
aged Power Cords increase the risk of electric shock.
When operating a power tool outside, use an outdoor extension cord marked
“W-A” or “W”. These extension cords are rated for outdoor use, and reduce the
risk of electric shock.
PERSONAL SAFETY
Stay alert. Watch what you are doing, and use common sense when operat-
ing a power tool. Do not use a power tool while tired or under the influence
of drugs, alcohol, or medication. A moment of inattention while operating power
tools may result in serious personal injury.
Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
Avoid accidental starting. Be sure the Power Switch is off before plugging
in. Carrying power tools with your finger on the Power Switch, or plugging in power
tools with the Power Switch on, invites accidents.
Remove adjusting keys or wrenches before turning the power tool on. A
wrench or a key that is left attached to a rotating part of the power tool may result
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 4
in personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing
and balance enables better control of the power tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid safety
shoes, hard hat, or hearing protection must be used for appropriate conditions.
TOOL USE AND CARE
Use clamps (not included) or other practical ways to secure and support the
workpiece to a stable platform. Holding the work by hand or against your body
is unstable and may lead to loss of control.
Do not force the tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
Do not use the power tool if the Power Switch does not turn it on or off. Any
tool that cannot be controlled with the Power Switch is dangerous and must be
replaced.
Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
Maintain tools with care. Keep cutting tools sharp and clean. Properly main-
tained tools with a sharp cutting edge are less likely to bind and are easier to control.
Do not use a damaged tool. Tag damaged tools “Do not use” until repaired.
Check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the tool’s operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool.
SERVICE
Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instruc-
tions in the “Inspection, Maintenance, And Cleaning” section of this manual.
Use of unauthorized parts or failure to follow maintenance instructions may create
a risk of electric shock or injury.
5.
6.
1.
2.
3.
4.
5.
6.
7.
8.
1.
2.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 5
SPECIFIC SAFETY RULES
Hold tool by insulated gripping surfaces when performing an operation where
the cutting tool may contact hidden wiring or its own cord. Contact with a “live”
wire will make exposed metal parts of the tool “live” and shock the operator.
Maintain labels and nameplates on the Belt Sander. These carry important infor-
mation. If unreadable or missing, contact Harbor Freight Tools for a replacement.
Always wear ANSI-approved safety impact eye goggles and heavy work gloves
when using the Belt Sander. Using personal safety devices reduce the risk for
injury. Safety impact eye goggles and heavy work gloves are available from Harbor
Freight Tools.
Maintain a safe working environment. Keep the work area well lit. Make sure
there is adequate surrounding workspace. Always keep the work area free of ob-
structions, grease, oil, trash, and other debris. Do not use a power tool in areas
near flammable chemicals, dusts, and vapors. Do not use this product in a damp
or wet location.
Never leave the Belt Sander unattended when it is plugged into an electrical
outlet. Turn off the tool, and unplug it from its electrical outlet before leaving.
Industrial applications must follow OSHA guidelines.
Use clamps or a vise to secure and support the workpiece to a stable platform.
Holding the workpiece by hand or against your body is unstable and may lead to
loss of control.
When sanding a large workpiece, make sure its entire length is properly sup-
ported. If necessary, use a roller stand (not included).
When using the Belt Sander, always maintain a firm grip on the tool with both
hands.
Do not use the Belt Sander if it has been dropped, damaged, left outdoors, or
immersed in liquid.
To avoid electrical shock, do not handle the Belt Sander or its Power Cord
Plug with wet hands.
Make sure the workpiece is free from nails and any other foreign objects which
can damage the tool and/or sandpaper.
Allow the tool to run up to full speed before placing its sandpaper onto a
workpiece. When turning off the Belt Sander, allow the tool to stop on its own.
Always unplug the Belt Sander from its electrical outlet before performing
any inspection, maintenance, or cleaning procedures.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 6
WARNING! Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contain chemicals known (to the State of Califor-
nia) to cause cancer, birth defects or other reproductive harm. Some examples of
these chemicals are: lead from lead-based paints, crystalline silica from bricks and
cement or other masonry products, arsenic and chromium from chemically treated
lumber. Your risk from these exposures varies, depending on how often you do this
type of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
(California Health & Safety Code § 25249.5, et seq.)
WARNING! People with pacemakers should consult their physician(s) before
using this product. Electromagnetic fields in close proximity to a heart pacemaker
could cause interference to or failure of the pacemaker.
Exposure to aluminum oxide (a dust generated from material removing pro-
cesses) can result in eye, skin and breathing irritation. Always use a NIOSH-
approved respirator and safety goggles. Avoid skin exposure. Proper ventilation of
the work area is required.
WARNING! The warnings and cautions discussed in this manual cannot cover
all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric shock.
Check with a qualified electrician if you are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord plug provided with the tool.
Never remove the grounding prong from the plug. Do not use the tool if the
power cord or plug is damaged. If damaged, have it repaired by a service facil-
ity before use. If the plug will not fit the outlet, have a proper outlet installed by
a qualified electrician.
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If
the tool should electrically malfunction or break down, grounding provides a low
15.
16.
17.
18.
1.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 7
resistance path to carry electricity away from the user, reducing the risk of electric
shock. (See Figure A.)
The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached to
an electrically “live” terminal. (See Figure A.)
Your tool must be plugged into an appropriate outlet, properly installed and grounded
in accordance with all codes and ordinances. The plug and outlet should look like
those in the following illustration. (See Figure A.)
FIGURE A FIGURE B
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard
Association, and the National Electrical Code. (See Figure B.)
Double insulated tools may be used in either of the 120 volt outlets shown in the
preceding illustration. (See Figure B.)
EXTENSION CORDS
Grounded tools require a three wire extension cord. Double Insulated tools can
use either a two or three wire extension cord.
As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a seri-
ous drop in voltage, resulting in loss of power and possible tool damage.
(See Figure C, next page.)
The smaller the gauge number of the wire, the greater the capacity of the cord. For
example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
When using more than one extension cord to make up the total length, make sure
each cord contains at least the minimum wire size required. (See Figure C.)
2.
3.
1.
2.
1.
2.
3.
4.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 8
If you are using one extension cord for more than one tool, add the nameplate am-
peres and use the sum to determine the required minimum cord size.
(See Figure C.)
If you are using an extension cord outdoors, make sure it is marked with the suffix
“W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified electri-
cian before using it.
Protect your extension cords from sharp objects, excessive heat, and damp or wet
areas.
RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*
(120 OR 240 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD LENGTH
25 Feet 50 Feet 75 Feet 100 Feet 150 Feet
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
FIGURE C * Based on limiting the line voltage drop to five volts at 150% of the rated amperes.
SYMBOLOGY
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~ Volts Alternating Current
AAmperes
n0xxxx/min. No Load Revolutions per Minute (RPM)
5.
6.
7.
8.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 9
UNPACKING
When unpacking, check to make sure that the item is intact and undamaged. If any
parts are missing or broken, please call Harbor Freight Tools at the number shown on the
cover of this manual as soon as possible.
PRODUCT FEATURES
FIGURE E
POWER CORD/PLUG
(15)
LEVER
(39)
POWER SWITCH
(27)
LOCK BUTTON
(14)
SPEED ADJUSTER
(56)
LOCK KNOB
(55)
FRONT HANDLE
(31)
ADJUSTING
KNOB
(54)
VACUUM BAG
(65)
SANDING BELT
(66)
Power Switch (27): The two-finger Power Switch is a simple “ON/OFF” switch that
when pressed and held turns on the Belt Sander. To turn off the Sander, release
pressure on the Power Switch and the switch will automatically return up to its “OFF”
position. (See Figure E.)
Lock Button (14): The Belt Sander features a Lock Button that allows continu-
ous operation without constantly holding the Power Switch (27). To lock the Power
Switch to its “ON” position, squeeze the Power Switch, depress the Lock Button,
and release the Power Switch. To unlock the Power Switch, squeeze the Power
Switch, and then release the Power Switch without depressing the Lock Button.
(See Figure E.)
Power Cord/Plug (15): The Power Cord/Plug must only be connected to a 120
volt, grounded, electrical outlet. Do not pull on the Cord to remove the Plug from
its electrical outlet. (See Figure E.)
1.
2.
3.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 10
Speed Adjuster (56): The Speed Adjuster features settings from “1 to 6”, with
“1” being the lowest speed at approximately 1,800 RPM and “6” being the highest
speed at approximately 2,650 RPM. Rotate the Speed Adjuster to select the desired
speed at which the Belt Sander will run. (See Figure E.)
Front Handle (31) and Lock Knob (55): The Front Handle may be adjusted to
three different positions. To do so, loosen the Lock Knob. Move the Front Handle
to the desired position. Then, retighten the Lock Knob. (See Figure E.)
Adjusting Knob (54): When the Sanding Belt (66) is properly tracking, the Belt
will remain centered and will run smoothly over the rollers of the tool. To adjust
the tracking of the Sanding Belt, rotate the Adjusting Knob clockwise or counter
clockwise. The Sanding Belt is properly tracking if, when turned on, the Belt does
not slip off the rollers. (See Figure E.)
Sanding Belt (66): The Sanding Belt should always be kept clean of sanding de-
bris and properly installed in the Belt Sander. Using dull Sanding Belts will place
an excessive load on the Belt Sander and increases the possibility of burning the
workpiece.
To install the Sanding Belt:
Unplug the Belt Sander from its electrical outlet.
Lay the Belt Sander down on its side with its Lever (39) facing upward.
(See Figure E.)
Pull out on the Lever (39). (See Figure E.)
Insert the Sanding Belt (66) around both rollers, making sure the arrow on the
inside of the Belt is pointing in the direction of rotation as indicated on the hous-
ing of the tool. (See Figure E.)
Center the Sanding Belt (66) over the rollers and bottom plate of the Belt Sander.
Then move the Lever (39) back in its original position to restore belt tension.
(See Figure E.)
To remove the Sanding Belt:
Place the Belt Sander on its side with its Lever (39) facing upward.
(See Figure E.)
Pull out on the Lever (39). Then, remove the Sanding Belt (66).
(See Figure E.)
Vacuum Bag (65): To install the Vacuum Bag, insert the Bag securely onto the dust
port of the Belt Sander. To empty the Vacuum Bag, unzip the Bag at its bottom, and
shake the sanding debris into a proper waste container.
(See Figure E.)
4.
5.
6.
7.
a.
b.
c.
d.
e.
a.
b.
8.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 11
OPERATING INSTRUCTIONS
CAUTION! Always use safety equipment. Wear ANSI-approved safety impact
eye goggles and heavy duty work gloves when operating the Belt Sander. Also, a
dust mask and hearing protection must be used for appropriate conditions.
CAUTION! Always secure the workpiece in place, using a vise or clamps (not
included).
Make sure the Power Switch (27) is in its “OFF” position. Then, plug the Power
Cord/Plug (15) into the nearest 120 volt, grounded, electrical outlet.
(See Figure E.)
Keep the Belt Sander off the work surface. Then, squeeze the Power Switch (27)
to start the tool. If desired, use the Lock Button (14) to lock the Power Switch in its
continuous run mode. (See Figure E.)
Place the heel of the Belt Sander on the work surface first. Then with a forward
motion, begin sanding as the tool is lowered onto the work surface.
Move the Belt Sander slowly back and forth across the work surface, using short,
overlapping strokes.
Do not apply excessive pressure on the Belt Sander. Too much pressure will over-
load the motor and reduce Sanding Belt (66) speed. Avoid tilting or rocking the Belt
Sander or sanding in one spot for too long.
Begin sanding with a coarser grit Sandpaper and gradually use finer grits until the
desired finish on the work surface is achieved.
When finished sanding, lift the Belt Sander off the work surface. Squeeze the Power
Switch (27) to disengage the Lock Button (14) and turn off the Sander.
Allow the Belt Sander to come to a complete stop before setting the tool down.
Unplug the Power Cord/Plug (15) from its electrical outlet.
Make sure to store the Belt Sander in a clean, dry, safe location out of reach of
children and other unauthorized people.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 12
INSPECTION, MAINTENANCE, AND CLEANING
WARNING! Make sure the Power Switch (27) of the Belt Sander is in its “OFF”
position and the tool is unplugged from its electrical outlet before performing any
inspection, maintenance, or cleaning procedures. (See Figure E.)
Before each use: Inspect the general condition of the Belt Sander. Check for loose
screws, misalignment or binding of moving parts, damaged electrical wiring, and
any other condition that may affect its safe operation. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Do not use damaged equipment.
Before each use: Inspect the Sanding Belt (66). Using dull Sanding Belts will cause
excessive wear on the motor of the Belt Sander and will not produce satisfactory
sanding results. Replace with a new Sanding Belt when needed.
(See Figure E.)
To clean the exterior parts of the Belt Sander: Use only a clean cloth and mild
detergent. Then dry. Do not immerse any electrical part of the tool in any liq-
uids.
CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
1.
2.
3.
4.
5.
TROUBLESHOOTING
Problem Possible Solution
Belt Sander will not turn on. Make sure to firmly squeeze the Power Switch.
Make sure the Power Cord/Plug is connected to a
working, 120 volt, grounded, electrical outlet.
Discontinue using the Belt Sander, and have a quali-
fied service technician check out the tool.
1.
2.
3.
Belt Sanding not removing material adequately
from the workpiece. Do not apply excessive downward pressure on the
Belt Sander.
Increase the speed of the Belt Sander.
Make sure the Sanding Belt is not dull or clogged with
excessive debris.
Use a coarser grit Sanding Belt.
1.
2.
3.
4.
Gashes and hollows occur in the workpiece
when sanding. Avoid tilting or rocking the Belt Sander or sanding in one
spot too long.
Sanding Belt slips off rollers of tool while in use. Adjust the tracking of the Sanding Belt.
Power Switch will not turn the Belt Sander off. Unplug the Belt Sander from its electrical outlet. Discon-
tinue using the Belt Sander, and have a qualified service
technician check out the tool.

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 13
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDEDTHE PARTS LIST AND
ASSEMBLY DIAGRAM INTHIS MANUAL AS A REFERENCETOOL ONLY. NEITHERTHE
MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY
OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO REPLACE ANY
PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY
THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT
PARTS THERETO.
PARTS LIST
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description Qty.
1 Washer (C) 2
2 Wave Washer 1
3 Ball Bearing 1
4 Ball Bearing 2
5 Tapping Screw 2
6 Tapping Screw 3
7 Tapping Screw 2
8 Tapping Screw 2
9 Tapping Screw 4
10 Carbon Brush 2
11 Brush Holder 2
12 Epoxy Board 2
13 Plain Washer 1
14 Lock Button 1
15 Power Cord/Plug 1
16 Bearing Holder 1
17 Small Belt Pulley 1
18 Plain Washer 1
19 Plain Washer 1
20 Cord Anchor 1
21 E-Type Ring 1
22 Spring 1
23 Spring 1
24 Spring 1
25 Hex Nut 1
26 Cord Guard 1
27 Power Switch 1
28 Belt Control Plate 1
29 Right Housing 1
30 Front Handle Cover 1
31 Front Handle 1
32 Left Housing 1
33 Mounting Plate 1
Part Description Qty.
34 Fan Baffle 1
35 Mounting Cover 1
36 Washer (A) 1
37 Plain Washer 3
38 Rivet 1
39 Lever 1
40 Needle Bearing 4
41 Front Pulley Shaft 1
42 Front Pulley 1
43 Rubber Bushing 1
44 Spring 1
45 Ball Bearing 1
46 Gear 1
47 Rear Pulley Shaft 1
48 Large Belt Pulley 1
49 Gear Shaft 1
50 Timing Belt 1
51 Belt Cover 1
52 Middle Housing 1
53 Rotor 1
54 Adjusting Knob 1
55 Lock Knob 1
56 Speed Adjuster 1
57 Bracket Assembly 1
58 Rear Pulley 1
59 Mounting 1
60 Stator 1
61 Internal Wire Assembly 2
63 Internal Wire Assembly 1
64 Tapping Screw 15
65 Vacuum Bag 1
66 Sanding Belt (80 Grit) 1

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 14
ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
65: Vacuum Bag not shown. 66: Sanding Belt not shown.
64
29
27
14
44
56
6
28
52
20
5
26
15
61 63
35
16
183
9
11
10
12
53
33
13
17
7
60
34
32
49
42
48
50
8
51
54 22 121
43
58
37
23
36
57
39
38
30
2531
2419
55
41
40 42
59
4547
46

SKU 94748 For technical questions, please call 1-800-444-3353 PAGE 15
LIMITED 90 DAY WARRANTY
Harbor FreightTools Co.makes every effort to assure that its products meet high quality and
durability standards, and warrants to the original purchaser that this product is free from defects in
materials and workmanship for the period of 90 days from the date of purchase.This warranty does
not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs
or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or
to lack of maintenance. We shall in no event be liable for death, injuries to persons or property, or
for incidental, contingent, special or consequential damages arising from the use of our product.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation of exclusion may not apply to you.THIS WARRANTY IS EXPRESSLY IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with trans-
portation charges prepaid. Proof of purchase date and an explanation of the complaint must
accompany the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily and
quickly provide you with a replacement. We will return repaired products at our expense, but if we
determine there is no defect, or that the defect resulted from causes not within the scope of our
warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]

PONCEUSE DE CEINTURE
3” X 21”
94748
MONTAGE ET INSTRUCTIONS D’OPÉRATION
En raison des améliorations continuantes, le produit réel peut différer légèrement du produit décrit ici.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visitez notre site Internet à : http://www.harborfreight.com
POUR ÉVITER LA BLESSURE SÉRIEUSE,LISEZ ET COMPRENEZTOUS
LES AVERTISSEMENTS ET LES INSTRUCTIONS AVANT L’UTILISATION.
Le Copyright © 2006 par le Harbor Freight Tools ®.Tous droits réservés. Aucune portion
de ce manuel ou de n’importe quel travail d’art contenu ici ne peut être reproduite dans
aucun forme ou manière sans le consentement écrit explicite de Harbor Freight Tools.
Pour les questions techniques ou les pièces détachées,
appelez-vous s’il vous plaît 1-800-444-3353.
IMPORTANT!
Cette édition de langue
française est une traduction
du manuel anglais original
accompagnant ce produit. Si
une partie du manuel anglais
original est inconsistante
avec cette traduction, le
manuel anglais original
gouvernera.

MODÈLE Pour les questions techniques, appelez-vous s’il vous plaît 1-800-444-3353. Français
94748 Page 2
SPÉCIFICATIONS DE PRODUIT
Moteur 120 V~ / 60 Hz / 6.0 Ampères / le Moteur de 2,625 tr-min
Double Isolé
Cordon de Pouvoir 6 pieds x 18 Calibre avec la Prise de courant de 2 dents
Manette 2 Doigt Allumez ou Éteindre
Grandeur de Papier de verre 3” Larges x 21” Long
Caractéristiques 1 à 6 Bouton de Vitesse Variable (1,025 à 2,625 variété
de vitesse)
Poignée Première Ajustable de 3 positions
Collection de Poussière intégrée
Toute la Construction de Roulement à billes
Changement de Ceinture Rapide avec le Levier de
Tension de Déclenchement Rapide
Accessoires Le Sac À vide / 80 Sable Érodant la Ceinture
Dimensions Générales 13” Long x 6-1/4” Large x 6-5/8” Haut
Poids d’Unité 7 livres
SAUVEZ CE MANUEL
Vous aurez besoin de ce manuel pour les avertissements de sécurité et les précau-
tions, le montage, le fait de faire marcher, l’inspection, la maintenance et le nettoyage des
procédures, la liste de pièces et le diagramme de montage. Gardez votre facture avec ce
manuel. Écrivez le nombre de facture sur l’intérieur de la couverture première. Gardez ce
manuel et facture dans un coffre-fort et un endroit sec pour la référence future.
RÈGLES RÉPANDUES DE SÉCURITÉ
AVERTISSEMENT!
LISEZ ET COMPRENEZ TOUTES LES INSTRUCTIONS
L’échec de suivre toutes les instructions énumérées peut ci-dessous
s’ensuivre dans le décharge électrique, le feu, et-ou la blessure sérieuse.
SAUVEZ CES INSTRUCTIONS
RÉGION DE TRAVAIL
Gardez votre région de travail propre et bien éclairé. Les bancs encombrés et
les régions sombres invitent des accidents.
Ne faites pas marcher d’instruments de pouvoir dans les atmosphères ex-
plosives, comme en présence des liquides inflammables, les gaz, ou la pous-
sière. Les instruments de pouvoir créent des étincelles qui peuvent enflammer la
poussière ou les exhalaisons.
Gardez des spectateurs, des enfants et des visiteurs loin en faisant marcher
un instrument de pouvoir. Les distractions peuvent vous faire perdre le contrôle.
1.
2.
3.
E194601

MODÈLE Pour les questions techniques, appelez-vous s’il vous plaît 1-800-444-3353. Français
94748 Page 3
Protégez d’autres dans la région de travail des débris comme les frites et les étin-
celles. Fournissez des barrières ou des protecteurs comme nécessaire.
SÉCURITÉ ÉLECTRIQUE
Les instruments mis à la terre doivent être branchés à une prise de courant
murale correctement installée et mise à la terre conformément à tous les
codes et aux ordonnances. N’enlevez jamais la dent d’installer à la terre ou
modifiez la prise de courant de toute façon. N’utilisez pas n’importe quelles
prises de courant d’adaptateur. Vérifiez avec un électricien qualifié si vous
êtes douteux quant à si la prise de courant murale est correctement mise
à la terre. Si les instruments devraient électriquement mal fonctionner ou se dé-
composer, installer à la terre fournit un sentier de résistance faible pour emporter
l’électricité de l’utilisateur.
Les instruments isolés doubles sont équipés avec une prise de courant polari-
sée (une lame est plus large que l’autre). Cette prise de courant correspondra
dans une prise de courant murale polarisée seulement à une voie. Si la prise
de courant ne va pas complètement dans la prise de courant murale, inverse
la prise de courant. S’il ne va pas toujours, contactez un électricien qualifié
pour installer une prise de courant murale polarisée. Ne changez pas la prise
de courant de toute façon. L’isolation double élimine le besoin pour le trois fil a
mis le cordon de pouvoir à la terre et a mis le système d’alimentation électrique à
la terre.
Évitez le contact de corps avec les surfaces mises à la terre comme les tuyaux,
les radiateurs, les variétés et les réfrigérateurs. Il y a un risque augmenté de
décharge électrique si votre corps est mis à la terre.
Ne permettez pas de contacter d’instruments de pouvoir pour pleuvoir ou les
conditions mouillées. L’eau entrant dans un instrument de pouvoir augmentera le
risque de décharge électrique.
N’abusez pas du Cordon de Pouvoir. N’utilisez jamais le Cordon de Pouvoir
pour porter les instruments ou tirer la Prise de courant d’une prise de cou-
rant murale. Tenez le Cordon de Pouvoir à distance de la chaleur, les bords
de pétrole, pointus, ou les pièces bougeantes. Remplacez des Cordons de
Pouvoir faits tort immédiatement. Les Cordons de Pouvoir Faits tort augmentent
le risque de décharge électrique.
En faisant marcher un instrument de pouvoir à l’extérieur, utilisez «W-A»
marqué d’un cordon d’extension en plein air ou “W”. Ces cordons d’extension
sont estimés pour l’utilisation en plein air et réduisent le risque de décharge élec-
trique.
1.
2.
3.
4.
5.
6.

MODÈLE Pour les questions techniques, appelez-vous s’il vous plaît 1-800-444-3353. Français
94748 Page 4
SÉCURITÉ PERSONNALISÉE
Séjour vigilant. La surveillance que vous faites et utilisez le sens commun
en faisant marcher un instrument de pouvoir. N’utilisez pas un instrument de
pouvoir pendant que fatigué ou sous l’influence de drogues, alcool, ou mé-
dication. Un moment d’inattention en faisant marcher des instruments de pouvoir
peut s’ensuivre dans la blessure personnalisée sérieuse.
Robe correctement. Ne portez pas de vêtements desserrés ou de bijouterie.
Contenez de longs cheveux. Gardez vos cheveux, vêtements et gants loin de
déplacer des pièces. Les vêtements desserrés, la bijouterie, ou les longs cheveux
peuvent être attrapés dans les pièces bougeantes.
Évitez le commencement accidentel. Soyez sûrs que l’Interrupteur de Pouvoir
est éteint avant le fait de brancher. Le fait de porter des instruments de pouvoir
avec votre doigt sur l’Interrupteur de Pouvoir, ou en branchant des instruments de
pouvoir avec l’Interrupteur de Pouvoir sur, invite des accidents.
Enlevez des clés s’adaptant ou des tourne-à-gauche avant le fait d’allumer
l’instrument de pouvoir. Un tourne-à-gauche ou une clé qui est laissée attachée à
une pièce tournante de l’instrument de pouvoir peuvent s’ensuivre dans la blessure
personnalisée.
Ne pencher pas. Gardez la position nécessaire et l’équilibre à tous moments. La
position nécessaire et l’équilibre permettent le meilleur contrôle de l’instrument de
pouvoir dans les situations inattendues.
Utilisez l’équipement de sécurité. Portez toujours la protection d’oeil. Le mas-
que de filtre, les chaussures de sécurité antidérapantes, le chapeau dur, ou l’ouïe
de la protection doivent être utilisés pour les conditions appropriées.
UTILISATION D’INSTRUMENT ET SOIN
Utilisez des attaches (non inclus) ou d’autres façons pratiques de stabiliser et
soutenir la pièce de fabrication à une plate-forme ferme. La possession du travail
à la main ou contre votre corps est instable et peut causer la perte de contrôle.
Ne forcez pas l’instrument. Utilisez l’instrument correct de votre application.
L’instrument correct fera le travail mieux et plus sûr au taux auquel il est conçu.
N’utilisez pas l’instrument de pouvoir si l’Interrupteur de Pouvoir ne l’allume
pas ou éteint. N’importe quel instrument qui ne peut pas être contrôlé avec l’Inter-
rupteur de Pouvoir est dangereux et doit être remplacé.
Débranchez la Prise de courant de Cordon de Pouvoir de la source de pou-
voir avant le fait de faire n’importe quels ajustages, accessoires changeants,
ou le fait de conserver l’instrument. De telles mesures de sécurité préventives
réduisent le risque de commencer l’instrument par hasard.
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.

MODÈLE Pour les questions techniques, appelez-vous s’il vous plaît 1-800-444-3353. Français
94748 Page 5
Le magasin les instruments à l’arrêt hors de portée des enfants et d’autres
personnes sans formation. Les instruments sont dangereux dans les mains d’uti-
lisateurs sans formation.
Maintenez des instruments avec le soin. Continuez à couper des instruments
pointus et propres. Les instruments correctement maintenus avec un tranchant
pointu attacheront moins probablement et sont plus faciles de contrôler. N’utilisez
pas un instrument fait tort. Les instruments faits tort d’étiquette «N’utilisent pas»
jusqu’à ne réparé.
Vérifiez pour le défaut d’alignement ou le fait d’attacher de pièces bougeantes,
la fracture de pièces et d’autre condition qui peut affecter l’opération de l’ins-
trument. Si fait tort, faites assurer l’entretien de l’instrument avant l’utilisation.
Beaucoup d’accidents sont causés par les instruments pauvrement maintenus.
Utilisez seulement des accessoires qui sont recommandés par le fabricant
pour votre modèle. Les accessoires qui peuvent être convenables pour un instru-
ment peuvent devenir les hasardeux quand utilisé sur un autre instrument.
ENTRETIEN
L’entretien d’instrument doit être exécuté seulement par le personnel de répa-
ration qualifié. Entretien ou la maintenance exécutée par le personnel disqualifié
pourrait s’ensuivre dans un risque de blessure.
En assurant l’entretien d’un instrument, utilisez des pièces détachées seule-
ment identiques. Suivez des instructions dans «L’inspection, la Maintenance
et le Nettoyage» section de ce manuel. L’utilisation de pièces faites sans autori-
sation ou d’échec de suivre les instructions de maintenance peut créer un risque
de décharge électrique ou de blessure.
RÈGLES DE SÉCURITÉ SPÉCIFIQUES
Tenez l’instrument par les surfaces de captage isolées en exécutant une opé-
ration où l’instrument coupant peut contacter des circuits électriques cachés
ou son propre cordon. Contact avec un fil “électriquement stimulé” fera des pièces
en métal dévoilées de l’instrument “vivre” et choquer l’opérateur.
Maintenez des étiquettes et des plaques sur la Ponceuse de Ceinture. Ceux-ci
portent des renseignements importants.Si illisible ou l’absence, contactez le Harbor
Freight Tools pour un remplacement.
Portez toujours des lunettes de protection d’oeil d’impact de sécurité approu-
vées d’ANSI et de lourds gants de travail en utilisant la Ponceuse de Ceinture.
L’utilisation les artifices de sécurité personnalisés réduit le risque pour la blessure.
Les lunettes de protection d’oeil d’impact de sécurité et les lourds gants de travail
sont en vente du Harbor Freight Tools.
5.
6.
7.
8.
1.
2.
1.
2.
3.
