Chigo HFR100W-BPA User manual

25kg
技 术要求
1、外形尺寸公差：长× 宽=(145×5 5)± 1mm;
2、题头采用"Arial"9号字体；机型号采用"黑体"7号字体; 其它均采用"Arial"7号字体;
3、图文清晰，正面为过塑处理； ；
4、反面为不干胶，要求粘性好；
5、耐久性要求应符合GB 4706.1的规定：要求用沾水的布擦拭15s，再用沾酒精的布擦拭
15s，标志应清晰易读、不易撕下、不易卷边；
6、有RoHS指令要求的物料应符合志高企业标准QZN-J11.002《产品中限制使用有害物质
的技术标准》。
50 mm
55 mm
Floor ceiling type air conditioner
Model of outdoor unit
Electric shock protection class
50Hz
18000 Btu/h
Rated voltage
Rated frequency
Rated cooling capacity
Rated heating capacity
Max. current input of the unit
Rated current input of indoor unit
18000 Btu/h
8.5A
0.2A
Model of indoor unit
220-240V~1N
I
Max. power input of the unit
1900W
Max.operating pressure of
indoor heat exchanger
CCA-18HVR1-C
Additional electrical heater power input
Additional electrical heater current input
Rated power input of indoor unit
Max. power input of indoor unit
Max. current input of indoor unit
Net weight of indoor unit
Manufacture number
Date of manufacture
4.2MPa
Indoor noise
32-42dB(A)
Indoor discharge air-flow
1250m³/h
Extemal static pressure
0Pa
COU-18HVR1-C
0.3A
-
-
45W
60W
-
-
140 mm
145 mm
S0001A-CE-KFR53Q-BPAY(DJ01)+7.PM-1A-005
CENTRAL AIR-CONDITIONING
1
CENTRAL AIR-CONDITIONING

Table of Contents
1 Safety Precautions 1
2 Construction Check Points ........................................................1
3 Installation of Outdoor Unit.......................................................2
4 Installation of Connecting Pipe ................................................5
5 Electrical Wiring...........................................................................8
6 Test Run ........................................................................................11
......................................................................
Appendix (Names and Content of Hazardous Substances in
Products)

-1-
!
Confirm that the drainage ditch can drain smoothly.
Check if the leakage protection switch is installed. The earth leakage protection switch must be installed. If it is not installed, it may cause
electric shock.
Do not install in a place where flammable gases are easily leaked. In the event of a flammable gas leak, it may cause a fire if it is trapped
around the indoor unit.
Confirm that the installation base and hoisting are firm and reliable. If the foundation and hoisting are not strong enough, it may fall and
cause an accident.
Connect the cables correctly. If the cables are not correctly connected, electrical parts may be damaged.
Exposing the unit to water or other moisture before installation may cause short-circuiting of electrical components. Do not store it in a wet
basement or expose it to rain or water.
If the refrigerant leaks during installation, immediately ventilate the room. If the refrigerant gas leaks out and comes into contact with the
fire, it may produce toxic gases.
After the installation is completed, check and confirm that the refrigerant is not leaked.
If the refrigerant gas enters the room and comes into contact with a fire source such as a heater, stove or rice cooker, it may produce toxic
gases.
Please install the lightning protection device according to the national laws and regulations, otherwise the machine may be damaged by
lightning.
!
2.1 Arrival of Goods(AOG) and Out of Box Audit(OOBA)
1) After receiving the machine, check for transport damage. If damage is found on the surface or inside, it should be
reported to the transportation company immediately in written form.
2) After receiving the machine, check whether the model, specification and quantity of the equipment are in accordance
with the contract.
3) When unpacking, please keep the operating instructions and check the accessories.
. Refrigerant piping
1) The refrigerant piping shall use pipeline with specified diameter and wall thickness.
2
2) When the copper tube is welded, it must be filled with nitrogen. Before welding, it is filled with 0.2 kgf /cm of nitrogen.
After the welding is completed, wait until the copper tube is completely cooled and stop the nitrogen supply.
3) The refrigerant piping must be insulated.
4) After the refrigerant piping is installed, the indoor unit cannot be energized until the airtightness test and vacuuming
are performed.
2.3 Air tightness test
2
After the refrigerant piping is installed, it is necessary to inject nitrogen at a pressure of 40 kgf/cm (4.0MPa) from the gas
side and the liquid side for a 1-hour air tightness test.
2.4 Vacuum treatment
After the air tightness test, vacuum treatment must be carried out simultaneously from both sides of the gas and liquid
(vacuum treatment should reach -0.1 MP a).
2.5 Refrigerant adding
1) Calculate the amount of refrigerant added based on the pipe diameter and length (solid length) of the liquid side piping
of the outdoor unit and the hydraulic module.
2) The amount of refrigerant added, the diameter of the liquid pipe, the length (actual length), and the difference between
the indoor and outdoor units shall be recorded in advance on the outdoor unit's use confirmation form (on the cover of
electrical control box) for later review.
2.6 Electrical wiring
1) Please select the power supply capacity and wire diameter according to the design manual. The power cord of the air
conditioner is thicker than the power cord of the general motor.
2) To prevent malfunction of the air conditioner, be careful not to make the power cords (220v) to be interleaved and
entangled with the connecting wire of indoor and outdoor unit (low voltage wiring).
3) After performing the airtightness test and vacuum pumping, energize the hydraulic module.
2.7 Trial run
Test run can only be performed after at least 3 hours preheating, otherwise the system will be damaged.
2 2
1 Safety Precautions
Warning
* This air conditioner is a comfortable air conditioner. Please do not use it in special places storing items like
computers, precision instruments, food, plants, animals or artware.
Please entrust a dealer or professional to install. The installer must have relevant professional knowledge. Do not install by yourself, the
improper installation will cause fire, electric shock, injury, water leakage and other accidents.
When installing in a small room, take appropriate measures to ensure that the concentration of refrigerant leakage in the room does not
exceed a critical level. Please consult your dealer for specific measures.
Observe the regulations of local electric companies when connecting power cables. According to the law, the ground wire must be well
connected. If the ground wire is not properly connected, it may cause electric shock.
When the air conditioner needs to be moved or reinstalled, please entrust the dealer or professional to operate. Improper installation will
result in fire, electric shock, injury, water leakage and other accidents.
Never modify or repair it yourself. Improper repairing may result in fire, electric shock, injury, water leakage, etc., and must be repaired by
a dealer or professional.
Attention
2 Construction Check Points

-2-
!
1328
40 0
900
360
585
994
1054
694
370 399
3 Installation of Outdoor Unit
Warning




Install the air conditioner in a firm place where the unit can be supported.
If the strength is not enough, the unit may fall and cause personal injury.
Perform specific installation work to prevent strong winds or earthquakes.
Incomplete installation can cause an accident due to the falling of the unit.
3.1 Installation location selection
1) Provide sufficient space for installation and maintenance.
2) The place shall ensure that the air inlet and outlet are unobstructed and not influenced by the strong wind.
3) Dry and ventilated place.
4) The supporting surface shall be flat and withstand the weight of the outdoor unit, and can be installed horizontally
without bringing more noise and vibration.
5) Operation noise and exhaust air shall not affect neighbors.
6) No flammable gas leaks.
7) Easy to install the connecting pipe and electrical connection.
3.2 Dimensions of outdoor unit (unit: mm)
1) Model HFR100w-BPA
Figure 3-1 Dimensions of outdoor unit
2) Model HFR140W-BPA/HFR160W-BPA
Figure 3-2 Dimensions of outdoor unit

-3-
>600
>600
>300
>300
3 Installation of Outdoor Unit
3.3 Hoisting of outdoor unit
1) A solid and proper foundation has the following effects:
① The outdoor unit will not sink.
The outdoor unit does not generate abnormal noise caused by the foundation.
2) Types of foundation
① Steel structure foundation.
Concrete foundation (refer to the following figure).
②
②
Air intake surface Maintenance line and pipe surface
Air blowing surface
Fixed with 4m 10 explosion bolts
Figure 3-3 Outdoor unit installation and maintenance space
Please entrust a dealer or professional to install. The installer must have relevant professional knowledge. If it is
wrongly installed by yourself, it may cause fire, electric shock, injury, water leakage and so on.
When installing in a small room, provide appropriate measures to ensure that the concentration of refrigerant leakage
in the room does not exceed a critical level. Please consult your dealer for specific measures.
Observe the regulations of the local electric companies when making power connection. According to the law, the
ground wire must be well connected. If the ground wire is not properly connected, it may cause electric shock.
When the air conditioner needs to be moved or reinstalled, please entrust the dealer or professional to operate.
Improper installation will result in fire, electric shock, injury, water leakage and other accidents.
Never modify or repair it by yourself. Improper repairing may result in fire, electric shock, injury, water leakage, etc.,
and must be repaired by a dealer or professional.
Knock out the sheet metal
opening for piping connection
Figure 3-4

-4-
Threaded connection
Liquid-side connecting pipe
Gas-side connecting pipe
Welding
Figure 3-5 Schematic diagram of pipeline connection of outdoor unit

-5-
!
Φ9.5
Φ15 9.
32 7~39 9 333~407 kgf cm). . ( •
61.8~75.4(630~770 kgf cm)•
A(mm)
12.4 12.0
Φ15.9 19.0 18.6
Φ9.5
4 Installation of Connecting Pipe
4.1 Refrigerant piping
1) Flaring
Cut the pipe with the pipe cutter, and flare with a pipe expander.
Oblique Coarse Burr
Figure 4-1 Cutting of the connecting tube
Table 4-1 Flaring size of connection tube
Outer
diameter
(mm) MAX MIN
2) Fastening nut
Align the connecting tube, screw the nut you're your hand and then tighten with a wrench.
Figure 4-2 Tightening
Table 4-2 Tightening torque
Piping size (mm) Tightening torque (N•m)
Attention
In order to prevent oxidation inside the copper tube during copper pipe welding, nitrogen filling must be taken.
Otherwise the scale will block the refrigeration system!
When the nut is tightened, too much force will break the bell mouth, and too little force will cause leakage. Please refer
to the tightening torque in the above table to tighten the nut!
4.2 Connection diagram of hydraulic module and outdoor unit
Hydraulic
Module
Figure 4-3

-6-
!
L＜30m
1L≥30m
1
Φ9.52 Φ15.88 Φ9.52 Φ15.88
HFR100W-BPA
Φ9.52 Φ15.88 Φ9.52 Φ19.05
HFR140W-BPA
HFR160W-BPA
4 Installation of Connecting Pipe
4.3 Determination of the main pipe diameter
Table 4-4 Pipe Diameter
Piping
Pipe dimensions (mm)
Model
Liquid pipe Liquid pipe
Gas pipe Gas pipe
4.4 Remove the foreign matter inside the pipe
1) When the refrigerant piping is installed, foreign matter inside the pipe must be removed with high pressure nitrogen.
2) The hydraulic module shall not be connected during cleaning.
3) It is not possible to replace nitrogen with flammable and toxic gases such as refrigerant or oxygen.
4.5 Air tightness test
2
1) After the refrigerant piping is installed and connected to the hydraulic module, the nitrogen with pressure of 40kgf/cm
(4.00 MPa) should be injected from the gas side and the liquid side before connecting the pipe between the indoor and
the outdoor to the outdoor unit valve. Mark the pressure value and perform 8-hour air tightness test.
2) If a pressure drop is found, re-examine the leakage of all interfaces and re-pressurize for 8 hours after completion.
3) The outdoor unit cannot be connected when holding pressure.
4.6 Vacuum pumping
1) A vacuum pump with a vacuum degree of -0.1μm or less and gas displacement of above 40 L/min shall be used.
2) The outdoor unit does not need to be vacuumed. Do not open the shut-off valve on the gas side or liquid side of the
outdoor unit.
3) Confirm that the vacuum pump can work below - 0. 1 MPa after running for more than 1 hour. If it cannot work below -
0.1 MPa after running for more than 2 hours, it indicates that there is moisture or gas leakage inside and needs to be
checked.
4) The vacuum pump must be equipped with a check valve.
Connect vacuum pump
Run the vacuum pump (more than 30 minutes)
After the complete vacuuming and the pressure reaches-
0.1MPa, the vacuum pump continues to run for 20 minutes.
Vacuum pump stops
Place in vacuuming state (more than 1 hour)
1. Close the valve of the pressure
gauge is;
2. Disconnect the pressure gauge
from the vacuum pump;
3. Turn off the vacuum pump.
Attention
Do not mix tools and measuring instruments used for different refrigerants and in direct contact with the refrigerant.
Never remove air with refrigerant gas.
When the vacuum degree cannot reach -0.1 MPa, please consider whether there is a possibility of leakage. Please
confirm again if there is any leakage. If there is no leak, run the vacuum pump for one or two more hours.

-7-
Φ9.52
!
≤5 0
Φ9.52 >5
4 Installation of Connecting Pipe
4.7 Adding amount of refrigerant
The calculation method of the adding amount of refrigerant is shown in the following table, based on the pipe diameter
and length of connection liquid-side piping of the outdoor unit and the hydraulic module.
Liquid measuring pipe
diameter (mm) Pipe length (m) Adding amount of
refrigerant (Kg)
Add 0.04 Kg for each
additional 1m
Table 4-7 Adding amount of refrigerant
Note: R 410A refrigerant must be charged in liquid form with fixed amount
measured by electronic scale, with a maximum length of 20 m.
4.8 Instructions for use of the shut-off valve
1) It shall be in OFF state when delivery.
2) Open or close the valve with a 6 mm hex wrench, counterclockwise turning for opening and clockwise
turning for closing.
3) The valve cover must be tightened after the operation.
4) The operation of vacuuming and refrigerant injection at the service port must be operated with the special
tool R410A. Inject the refrigerant at the gas side valve service port, and vacuum at the liquid side and the
gas side valve service port.
Maintenance port
Bonnet
Valve stem
Vacuuming Refrigerant injecting
Opening
Opening
Liquid-side Gas-side
Figure 4-4 Illustration of the shut-off valve
4.9 Pipe insulation treatment
1) Insulate the gas side and liquid side pipes separately.
2) Use closed-cell insulation material, with B1 flame retardant rating and 120℃high temperature resistance.
3) The outer diameter of the copper tube is φ 9 52, the thickness of the insulation cotton is not less than 15 mm; the outer
diameter of the copper tube is φ15 88 , and the thickness of the insulation cotton is not less than 20 mm.
4) The nut joint of the hydraulic module must also be insulated.
.
.
Attention
Please design the dedicated power supply for the hydraulic module and the outdoor unit.
The power supply uses a branch circuit and must be equipped with the leakage protector and manual switch.
Please arrange the connecting lines of hydraulic module and the refrigerant piping in a same system.
For indoor and outdoor communication lines, please use two-core or three-core shielded twisted pair to reduce
interference, instead of using ordinary multi-core cables.


Performed in accordance with the relevant national electrical standards.
The wiring of power supply must be performed by a professional electrician.

-8-
40/30
HFR100W-BPA
63/45
P Q E
L N
L N
P Q E
HFR140W-BPA
HFR160W-BPA
!
!
5 Electrical wiring
5.1 Hydraulic module wiring
Table 5-1 Hydraulic Module Wiring
Model Power supply Power cord
2
(mm )
Circuit breaker
/ fuse (a)
2
Hydraulic module/outdoor unit signal line (mm )
(weak signal line)
Single
phase
Single
phase
3-core shielded cable 3×1.0
(2-core shielded cable 2×1.0)
220V~50HZ
220V~50HZ
3×4.0
3×6.0
power
supply
power
supply
Switch/power
supply
Switch/power
supply
Outdoor unit
power cord
Hydraulic module
power cord
The
outdoor
unit
Hydraulic
module
Cable connecting
indoor and
outdoor units
Figure 5-1 Wiring and Control
Hydraulic module
Y/G
3-core
shielded
cable
Single-phase power supply 220V~ 50Hz
Y/G
Outdoor unit Single-phase power
supply 220V~50Hz
Figure 5-2 Electrical connection mode of single-phase outdoor unit
Attention
When using the 2-core shielded cableas the signal cable, connect the shielded mesh to "e" of the terminal block.
When using the 3-core shielded cable as the signal cable, the shielded mesh must be grounded.
It is absolutely forbidden to connect the power line (strong power) to the signal line (weak power) terminal block,
otherwise the electric control board will be burned out.
5.2 Power cables for hydraulic module
Attention
When the power cord is parallel to the signal line, place the wires in their respective conduits and leave a suitable line
spacing (10A or less: 300 mm, 50A or less: 500 mm).

-9-
1 2
O N DP
3
HFR100W BPA-
SW3
Sw6 HFR1 0W BPA4 -
HFR160W BPA-
1 2
O N DP
3
1 2
O N DP
3
1 2 3
O N D P
4
1 2 3
O N D P
4
SN Display content Remarks
0 Normal display Current f requency / number of indoor unit Display the number of units being started
1 1- Capacity of outdoor units 100/140/160
2 2- Total capacity of indoor units
3 3- Total capacity requirement af ter correction of outdoor unit
4 4- Operation mode 0: Shutdown; 2: Cooling; 3: Heating; 4: Forced cooling
5 5- Actual operating capacity of outdoor unit
6 6- Fan status 0-7
7 7- Tw-in heat exchanger inlet water temperature
8 8- Tw-out heat exchanger outlet temperature
9 9- T1 hydraulic module outlet temperature
10 10- T3 tube temperature
11 11- T4 ambient temperature
12 12- T5 exhaust temperature
13 13- Opening of electronic expansion v alve Actual v alue = Check display v alue × 8
14 14- High pressure
15 15- Primary current
16 16- Secondary current
17 17- Primary v oltage
18 18- Secondary v oltage Actual v alue = Check display v alue × 4
19 19- Last f ailure or protection code No protection or f ault display ---
20 20- Control parameter For dev elopers only
21 21- Control parameter For dev elopers only
22 22- --- End of check
5 Electrical Wiring
5.3 Main control board dial code setting
Table 5-2 Main Control Board Dial Code
Dialing content Switch number Dial code Set value
Start time setting
Ability setting
Start time 12
Start time 3
5.4 Outdoor unit check instructions
Table 5-3 Outdoor unitcheck instructions
Operating mode definition: 0 - Shutdown; 2 - Cooling; 3 - Heating; 4 - Forced cooling.

-10-
Display content Failure or protection def inition Remarks
E1 Three-phase supply phase-sequence f ault
E2 Communication f ailure between indoor unit and host Internal and external communication interrupted
f or 2 minutes or more
E4 Ambient temperature sensor f ailure
E6 Condenser tube temperature sensor f ailure
E9 AC ov erv oltage / underv oltage protection
E10 EEPROM f ailure
H0 Communication f ailure between the main control chip
and the module board
H1 Communication f ailure between the main control chip
and the communication chip
H4 3 p6 protections within 30 minutes It can only be restored by re-supply ing power.
H5 3 p2 protections within 30 minutes It can only be restored by re-supply ing power.
H6 3 p4 protections within 100 minutes It can only be restored by re-supply ing power.
H9 2 p9 protections within 10 minutes It can only be restored by re-supply ing power.
H8 High pressure sensor f ailure Exhaust pressure Pc<0.3MPa
H10 3 P3 or P14 protections within 60 minutes It can only be restored by re-supply ing power.
P1 High v oltage protection (high v oltage switch)
P2 Low v oltage protection 3 times P2 protection appears within 30
minutes and then reported H5
P3 Primary current ov ercurrent protection
P4 Exhaust temperature is too high protection 3 times P4 protection appears within 100
minutes and thenreported H6
P5 Tube temperature and high temperature protection
P6 Module protection 3 times P6 protection appearswithin 30 minutes
andthen reported H4
P9 DC f an f ailure 2 times P9 protection appears within 10
minutes and then reported H9
P10 Ty phoon protection
P12 The heating f an is in f ault state in the area A f or 5
minutes.
P14 Secondary current ov ercurrent protection
P15 High pressure protection (high pressure sensor)
L0 DC compressor module f ailure
L1 DC bus low v oltage protection
L2 DC bus high v oltage protection
L4 MCE f ault / sy nchronization / closed loop
L5 Zero speed protection
L7 Phase sequence error protection
L8 Protection f or speed change >15Hz at the prev ious
and last moments
L9 Protection f or set speed and actual running speed
dif f erence >15 Hz
d1 Ov er temperature protection
5 Electrical Wiring
Table 5-4 Outdoor unit fault codes

≤3
concentration limit: 0.3 [ kg/m ]
A [kg]
B [m³]
D
D
0A
-11-
6 Test run
6.1 Inspection before commissioning
1) Check and confirm that the cooling pipes and communication lines for the hydraulic module and the outdoor unit are
connected to the same refrigeration system. Otherwise, an operational failure will occur.
2) The power supply voltage is within ± 10% of the rated voltage.
3) Check and confirm that the power cable and control cable are wired correctly.
4) Before powering up, check and confirm that there is no short circuit in each line.
2
5) Check whether all units have passed the 24-hour nitrogen pressure maintaining test (40 kgf/cm ).
6) Check and confirm that the system to be commissioned has been vacuum dried and filled with refrigerant as required.
6.2 Preparation before commissioning
1) Calculate the amount of refrigerant to be added to each unit according to the length of the liquid pipe on site.
2) Prepare the required refrigerant.
3) Prepare the system plan, system piping diagram and control circuit diagram.
4) Record the set address code on the system plan.
5) Turn on the outdoor unit power switch in advance to ensure that it is turned on for more than 3 hours to heat the
compressor oil.
6) Fully open the gas pipe shut-off valve, liquid pipe shut-off valve and oil balance valve of the outdoor unit. If not fully
opened, the machine will be damaged.
7) Check if the power phase sequence of the outdoor unit is correct.
8) Check that all the DIP switches of the outdoor unit and hydraulic module have been set according to the product
technical requirements.
6.3 Precautions against refrigerant leakage
1) The refrigerant used for the air conditioner is a harmless and non-combustible safety refrigerant.
2) The air conditioner shall be placed in a room with sufficient space. Even if a refrigerant leak occurs, the limit of
concentration will not be exceeded. Necessary measures can be taken depending on the situation.
3
3) The concentration limit of the gas that does not cause harm to the human body is: 0.3 [kg/m ].
4) Confirm the concentration limit below and take the necessary measures.
a) Calculate the total filling amount of the refrigerant (A [kg] )
Total amount of refrigerant = the amount of refrigerant filled when delivery (see nameplate) + the
additional amount of refrigerant according to the length of the piping
3
b) Calculate the indoor volume (B[m ]) (calculated by the minimum volume)
c) Calculate the refrigerant concentration
5) Countermeasures when the concentration limit is exceeded
a) To reduce the concentration of the refrigerant below the concentration limit, please install a mechanical
ventilator(for frequent ventilating).
b) When it is not possible to change the air frequently, please install a leak detection alarm device interlocked with the
mechanical ventilator.
b. Leak detection alarm device interlocked with mechanical ventilator
Hydraulic
module
a. Ventilation opening
(The leak detection alarm device should be installed in a
place where the refrigerant is easily retained.)
Figure 6-1 Mechanical ventilator
6.4 Hand over to the customer
1) Be sure to give the “User Manual” of the hydraulic module and the “Installation Manual” of the outdoor unit to the
customer.
2) Explain the contents of the “Operation and Installation Manual” to the customer in detail.

× ×
×
× ×
× ×
×
×
○
○
○
○
○
○
○
○
○○
○
○
○
○
○ ○
○
○
○
○
○
○ ○ ○ ○
○○○
○
○
○
○
○
○
○
○
○○○○
○
○
○ ○
○
○ ○
○
○
○
○
○
○
○ ○
○○
○
○○
○ ○ ○
○ ○
○○ ○
○
○
○
○
○○
○
-12-
Part Name
Lead (Pb) Mercury (Hg) Cadmium (Cd)
Hexavalent
chromium
(Cr (VI))
Polybrominated
biphenyl (PBB)
Polybrominated
diphenyl ether
(PBDE)
Compressor and accessories
Heat exchanger
Pipe fittings and valves
Refrigerant
Motor
Control box and electrical
components
Power cords and cables
Fasteners such as screws
and gaskets
Rubber parts
Other metal parts
Other plastic parts
Printed parts
Foam pieces
Insulated cotton
The sheet is prepared in accordance with the specification of SJ/T 11364.
○: It indicates that the content of this hazardous substance in all homogeneous
materials of this part is below the limit specified by GB/T 26572.
: It indicates that the content of the hazardous substance in at least one of the
homogeneous materials of the part exceeds the limit specified by GB/T 26572. However,
it is temporarily impossible to realize that the product parts are completely free from the
above-mentioned hazardous substances under the existing technical conditions. The
above-mentioned harmful substances will be gradually reduced with the progress of
alternative technologies.
×
Appendix 1: Names and contents of hazardous substances in the product

C-SA-ZKRS01CHN-0
802000100260
C-SA-ZKRS01CHN-3
802000100454
Guangdong CHIGO HVAC Equipment Co., Ltd.
Address: Chigo Industrial Park, Lishui Town, Nanhai District,
Foshan City, Guangdong Province, China
Post Code: 528244
Tel: [phone]
Fax: [phone]
Service Hotline: [phone]
http://www.chigo-cac.com
