Chigo CSG-07HVR1-A User manual

DC Inverter Multi-split
System Technical Manual
- 50Hz/R410a
A/1/LCAC/2/TM/2.0

R410A DC Inverter Multi-split Technical Manual General Information
1
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Part 1. General Information........................................................................4
1. Features................................................................................................................4
2. Nomenclature.......................................................................................................6
3. Products Line-up ..................................................................................................8
4. External Appearance..........................................................................................10
5. Combination Table..............................................................................................12
Part 2. Indoor Units……...........................................................................15
Wall-Mounted Type……….…………….………………………………………15
1. Features ............................................................................................................15
2. Specifications....................................................................................................16
3. Dimensions........................................................................................................18
4. Service Space...................................................................................................19
5. Wiring Diagrams................................................................................................20
6. Capacity Table...................................................................................................22
7. Electric Characteristics......................................................................................30
8. Sound Level.......................................................................................................31
9. Exploded View...................................................................................................33
10.Accessories.......................................................................................................39
11.Troubleshooting.................................................................................................40
Duct Type………………………………….……………………………………..41
1. Features ............................................................................................................41
2. Specifications....................................................................................................43
3. Dimensions........................................................................................................44
4. Service Space...................................................................................................45
Contents

R410A DC Inverter Multi-split Technical Manual General Information
2
GD Chigo Heating & Ventilation Equipment Co., Ltd.
5. Wiring Diagrams................................................................................................46
6. Capacity Table...................................................................................................47
7. Electric Characteristics......................................................................................55
8. Sound Level.......................................................................................................56
9. Exploded View...................................................................................................57
10.Accessories.......................................................................................................59
11.Troubleshooting.................................................................................................60
4-way cassette Type .................................................................................61
1. Features ............................................................................................................61
2. Specifications....................................................................................................63
3. Dimensions........................................................................................................64
4. Service Space...................................................................................................65
5. Wiring Diagrams................................................................................................66
6. Capacity Table...................................................................................................67
7. Electric Characteristics......................................................................................75
8. Sound Level.......................................................................................................76
9. Exploded View...................................................................................................77
10. Accessories.....................................................................................................79
11.Troubleshooting.................................................................................................80
Part 3. Outdoor Units…………………………………………………………..81
1. Features ............................................................................................................81
3. Dimensions........................................................................................................85
4. Service Space ...................................................................................................86
5. Piping Diagrams................................................................................................ 87
6. Wiring Diagrams................................................................................................88
7. Combination Capacity Table ............................................................................. 90
8. Field Wiring......................................................................................................102
9. Electric Characteristics....................................................................................103
10. Operation Limits .............................................................................................104
11.Sound Levels...................................................................................................105

R410A DC Inverter Multi-split Technical Manual General Information
3
GD Chigo Heating & Ventilation Equipment Co., Ltd.
12.Exploded View.................................................................................................106
13.Troubleshooting............................................................................................... 110
Part 4. Installation ….. ........................................................................... 112
1. Selecting installation place............................................................................ 112
2. Rooftop installation........................................................................................ 113
3. REFRIGERANT PIPE CONNECTION.......................................................... 113
4. AIR PURGING............................................................................................... 117
5. Safety and leakage check.............................................................................121
6. Water Drainage..............................................................................................123
7. Insulation Work..............................................................................................124
Part 5. Test Running…...........................................................................127
1. Dialing setting of main control board.............................................................127
2. Outdoor unit spot-check instructions.............................................................128
3. Inspection and confirmation before debugging.............................................129
4. Preparation before debugging.......................................................................129
5. Filling of names of connecting systems ........................................................130
6. Precautions against refrigerant leak..............................................................130
Part 6. Controller…….........................................................................132
1. Wireless Remote Controller ..........................................................................132
2. Wired Controller.............................................................................................135

R410A DC Inverter Multi-split Technical Manual General Information
4
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Part 1. General Information
1. Features
1.1Compressor
1.1.1 180osine wave compressor control, higher efficiency and lower power consumption and noise.
1.1.2 Built-in high temp. protection, guarantee safety revolution.
1.2Operation range
High temperature and low temperature operation stability.cooling:10-46℃,heating:-15-24℃
1.3Electrical design
1.3.1 Total new design for the E-box. Optimizing design of the E-box, fresh air cooling down the
temperature of the inverter module.
1.3.2 Adopting high performance main chip of NEC for the electronic control, higher reliability and operation
speed.

R410A DC Inverter Multi-split Technical Manual General Information
5
GD Chigo Heating & Ventilation Equipment Co., Ltd.
1.4System design
1.4.1 Anticorrosive components design, leading to longer service live.
Plastic-coating EXV loop design.
1.4.2 Profit from EXV design, the system can control the refrigerant flow much more precisely, leading to
precise capacity output, make the users much more comfortable and save energy.
1.5Free match
1.5.1 Different indoor units for choice. You can choose different indoor units appearance for your favorite.
1.5.2 Much more indoor units for free combination, meeting for different requirement such as office, house
use, villa and etc.
1.5.3 One or more indoor units’ connection combination for your choice.

R410A DC Inverter Multi-split Technical Manual General Information
6
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2. Nomenclature
2.1 Indoor Units
C
T
CA
-
24
E
B
C:Chigo HVAC
E:Electrical auxiliary heater.
Working Condition
Omit:T1 condition; T:T3 condition.
Capacity,unit:kBtu/h
Design No
i
C
Function code
Omit:Match universal outdoor unit; i:match individual outdoor
Product series
CA:4-way cassette; CB:Compact 4-way Casssette
TA;Low ESP Duct; TB:Mid ESP Duct; TH:High ESP Duct;UA:Floor & Ceiling
SG:Multi Wall type;SC:Multi 4-way Cassette;ST:Multi Duct.
-
R1
Refrigerant
Omit:R22; R1:R410A
V:DC Inv.
Omit:Fixed speed.
V

R410A DC Inverter Multi-split Technical Manual General Information
7
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2.2 Outdoor Units
C
OU
3
-
24
C
B
C:Chigo HVAC
Function code
Product series
OU:Universal type; OT:Top-discharge; OW:Non-universal
Capacity,unit:kBtu/h
Design No
B:second design.
T
S
Power Code
Working Condition
Omit:T1 condition; T:T3 condition.
Match Code
Omit:unitary series; 2:Multi 1 drives 2; 3:Multi 1 drives 3; 4:Multi 1 drives 4;
5:Multi 1 drives 5
-
R1
Refrigerant
V:DC Inv.
Omit:Fixed speed.
V

R410A DC Inverter Multi-split Technical Manual General Information
8
GD Chigo Heating & Ventilation Equipment Co., Ltd.
3. Products Line-up
3.1 Indoor Units
Model name
Dimension (W×H×D)(mm)
Net/Gross weight (kg)
Power supply
Wall Mounted
CSG-07HVR1-A(J150)
878×290×227
8.5/10
220~240V/1Ph/50Hz
CSG-07HVR1-A(J155)
878×290×227
8.5/10.5
220~240V/1Ph/50Hz
CSG-07HVR1-A(J156)
878×290×227
8.5/11
220~240V/1Ph/50Hz
CSG-09HVR1-A(J150)
878×290×227
8.5/10
220~240V/1Ph/50Hz
CSG-09HVR1-A(J155)
878×290×227
8.5/10.5
220~240V/1Ph/50Hz
CSG-09HVR1-A(J156)
878×290×227
8.5/11
220~240V/1Ph/50Hz
CSG-12HVR1-A(J150)
878×290×227
8.5/10
220~240V/1Ph/50Hz
CSG-12HVR1-A(J155)
878×290×227
8.5/10.5
220~240V/1Ph/50Hz
CSG-12HVR1-A(J156)
878×290×227
8.5/11
220~240V/1Ph/50Hz
CSG-18HVR1-A(P150)
953×347×270
10.5/13
220~240V/1Ph/50Hz
CSG-18HVR1-A(P155)
953×347×270
10.5/13
220~240V/1Ph/50Hz
CSG-18HVR1-A(P156)
953×347×270
10.5/13.5
220~240V/1Ph/50Hz
CSG-24HVR1-A(W150)
1180×362×288
13.5/16
220~240V/1Ph/50Hz
CSG-24HVR1-A(W155)
1180×362×288
13.5/16.5
220~240V/1Ph/50Hz
CSG-24HVR1-A(W156)
1180×362×288
13.5/16.5
220~240V/1Ph/50Hz
Ducted unit
CST-07HVR1-A
814×210×467
17/19.5
220~240V/1Ph/50Hz
CST-09HVR1-A
814×210×467
17/19.5
220~240V/1Ph/50Hz
CST-12HVR1-A
814×210×467
17/19.5
220~240V/1Ph/50Hz
CST-18HVR1-A
1010×210×467
20.5/24
220~240V/1Ph/50Hz

R410A DC Inverter Multi-split Technical Manual General Information
9
GD Chigo Heating & Ventilation Equipment Co., Ltd.
3.2 Outdoor Units
Model name
Dimension (W×H×D) (mm)
Net/Gross weight (kg)
Power supply
DC Dual-split
C2OU-16HDR1-A
944×608×345
41/44
220~240V/1Ph/50Hz
C2OU-18HDR1-A
944×608×345
41/44
220~240V/1Ph/50Hz
DC Tri-split
C3OU-21HDR1-A
989×843×392
57/67
220~240V/1Ph/50Hz
C3OU-27HDR1-A
989×843×392
62/72
220~240V/1Ph/50Hz
DC Fourfold-split
C4OU-28HDR1-A
1090×997×399
87/98.5
220~240V/1Ph/50Hz
C4OU-36HDR1-A
1090×997×399
91/102.5
220~240V/1Ph/50Hz
DC Fivefold-split
C5OU-42HDR1-A
1090×997×399
91/102.5
380~415V/3Ph/50Hz

R410A DC Inverter Multi-split Technical Manual General Information
10
GD Chigo Heating & Ventilation Equipment Co., Ltd.
4. External Appearance
4.1 Indoor Units
Wall Mounted
Ducted Units
4-way Cassette
150
Series
155 Series
156 Series

R410A DC Inverter Multi-split Technical Manual General Information
11
GD Chigo Heating & Ventilation Equipment Co., Ltd.
4.2 Outdoor Units
DC Dual-split
DC Triple split
DC Fourfold &Fivefold split

R410A DC Inverter Multi-split Technical Manual General Information
12
GD Chigo Heating & Ventilation Equipment Co., Ltd.
5. Combination Table
Outdoor Unit
Qty. of indoor units
Combination Table (kBtu/h)
C2OU-16HDR1-A
1
7
1
9
1
12
1
18
2
7+7
2
7+9
2
7+12
2
9+9
2
9+12
2
12+12
C2OU-18HDR1-A
1
7
1
9
1
12
1
18
2
7+7
2
7+9
2
7+12
2
7+18
2
9+9
2
9+12
2
12+12
2
9+18
C3OU-21HDR1-A
2
7+7
2
7+9
2
7+12

R410A DC Inverter Multi-split Technical Manual General Information
13
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2
7+18
2
9+9
2
9+12
2
12+12
2
9+18
3
7+7+7
3
7+7+9
3
7+9+9
3
7+7+12
3
7+9+12
3
9+9+9
3
9+9+12
C3OU-27HDR1-A
2
7+7
2
7+9
2
7+12
2
7+18
2
7+24
2
9+9
2
9+12
2
12+12
2
9+18
2
9+24
2
12+18
3
7+7+7
3
7+7+9
3
7+7+12
3
7+7+18
3
7+9+9
3
7+9+12

R410A DC Inverter Multi-split Technical Manual General Information
14
GD Chigo Heating & Ventilation Equipment Co., Ltd.
3
7+9+18
3
7+12+12
3
9+9+9
3
9+9+12
3
9+12+12
3
9+9+18
3
12+12+12
C4OU-28HDR1-A
2
24+7
2
18+12
3
12+12+9
4
7+7+7+7
C4OU-36HDR1-A
2
24+12
2
18+18
3
12+12+12
4
9+9+9+9
C5OU-42HDR1-A
2
24+18
3
18+12+12
4
12+12+12+9
5
9+9+9+9+9

R410A DC Inverter Multi-split Technical Manual Indoor Units
15
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Part 2. Indoor Units
Wall-Mounted Type
1.Features
The wall-mounted indoor unit has several different types for your choice, such as 150 style, 155 style and 156
style. The different style panels can satisfy your different requirements. All the units have various functions,
such as the function of auto-restart, sleep mode are standard, golden fins and some filter for optional.

R410A DC Inverter Multi-split Technical Manual Indoor Units
16
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2.Specifications
Model name
CSG-07HVR1-A
CSG-09HVR1-A
CSG-12HVR1-A
Power supply
V-Ph-Hz
220~240-1-50
220~240-1-50
220~240-1-50
Electricity supplying type
Outdoor unit supply
Cooling
Capacity
Btu/h
7000
9000
12000
Input
W
40
40
40
Rated current
A
0.2
0.2
0.2
Heating
Capacity
Btu/h
8000
10000
13000
Input
W
40
40
40
Rated current
A
0.2
0.2
0.2
Indoor
fan
motor
Model
YDK-16-4 9
YDK-16-4 3
YDK-16-4 3
Type
AC
AC
AC
Brand
CHIGO
CHIGO
CHIGO
Input
W
26
26
26
Capacitor
μF
1
1
1
Speed (H/M/L)
r/min
900/800/740
1000/850/740
1100/900/760
Indoor
coil
Number of rows
2
2
2
Tube pitch × row pitch
mm
21×12.7
21×12.7
21×12.7
Fin spacing
mm
1.5
1.5
1.5
Fin type
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Tube outside diameter
mm
Ф7
Ф7
Ф7
Tube type
Inner screw
Inner screw
Inner screw
Number of circuits
2
2
2
Indoor air flow (H/M/L)
m3/h
400/350/320
500/400/320
550/400/330
Indoor noise level(H/M/L)
dB(A)
30/2724
33/28/24
36/30/25
Indoor
unit
Net Dimension (W×H ×D)
mm
878×290×227
878×290×227
878×290×227
PackingDimension(W×H×D)
mm
150
865×365×285
865×365×285
865×365×285
155
885×375×315
885×375×315
885×375×315
156
950×365×300
950×365×300
950×365×300
Net/Gross weight
kg
150
8.5/10
8.5/10
8.5/10
155
8.5/10.5
8.5/10.5
8.5/10.5
156
8.5/11
8.5/11
8.5/11
Refrigerant Type
R410A
R410A
R410A
Refrigerant pipe (Liquid side/ Gas side)
mm
Ф6.35/Ф9.52
Ф6.35/Ф9.52
Ф6.35/Ф9.52
Drainage water pipe diameter
mm
DN25
DN25
DN25
Controller(standard)
Remote Controller
(chigo)
Remote Controller
(chigo)
Remote Controller
(chigo)
Application area
m2
10-15
12-18
16-23

R410A DC Inverter Multi-split Technical Manual Indoor Units
17
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model name
CSG-18HVR1-A
CSG-24HVR1-A
Power supply
V-ph-Hz
220~240-1-50
220~240-1-50
Electricity Supplying type
Outdoor unit supply
Cooling
Capacity
Btu/h
18000
24000
Input
W
60
66
Rated current
A
0.27
0.3
Heating
Capacity
Btu/h
19000
25000
Input
W
60
66
Rated current
A
0.27
0.3
Indoor fan
motor
Model
YDK-23-4 A6
YDK-18-4 A7
Type
AC
AC
Brand
CHIGO
CHIGO
Input
W
36
33
Capacitor
μF
1.2
1.2
Speed (H/M/L)
r/min
1250/1050/950
1200/1090/850
Indoor coil
Number of rows
2
2
Tube pitch ×row pitch
mm
21×12.7
21×12.7
Fin spacing
mm
1.6
1.6
Fin type
Hydrophilic
Hydrophilic
Tube outside diameter
mm
Ф7
Ф7
Tube type
Inner screw
Inner screw
Number of circuits
4
5
Indoor air flow (H/M/L)
m3/h
750/580/500
1000/900/700
Indoor noise level (H/M/L)
dB(A)
44/40/36
45/42/38
Indoor unit
Net Dimension (W×H ×D)
mm
953×347×270
1180×362×288
Packing Dimension
(W×H×D)
mm
150
983×377×300
1145×392×318
155
990×395×325
1190×405×345
156
1075×380×310
1235×390×330
1235×390×330
1235×390×330
1235×390×330
1235×390×330
Net/Gross weight
kg
150
10.5/13
13.5/16
155
10.5/13
13.5/16.5
156
10.5/13.5
13.5/16.5
Refrigerant Type
R410A
R410A
Refrigerant pipe (Liquid side/ Gas side)
mm
Ф6.35/Ф12.7
Ф9.52/Ф15.88
Drainage water pipe diameter
mm
DN25
DN25
Controller(standard)
Remote Controller
(chigo)
Remote Controller
(chigo)
Application area
m2
23-34
34-51
Notes:
1. The cooling conditions: indoor side 27°C(80.6°F) DB, 19°C(60°F)WB outdoor side 35°C(95°F) DB.
2. The heating conditions: indoor side 20°C(68°F) DB, 15°C(44.6°F)WB outdoor side 7°C(42.8°F)DB.
3. Sound level: measured at a point 1 m in front of the unit at a height of 1.5 m. During actual operation, these values are normally somewhat
higher as a result of ambient conditions.
4. The above data may be changed without notice for future improvement on quality and performance.

R410A DC Inverter Multi-split Technical Manual Indoor Units
18
GD Chigo Heating & Ventilation Equipment Co., Ltd.
3.Dimensions
Unit: mm
Capacity
A
B
C
07/09/12k Btu/h
878
290
227
18k Btu/h
953
347
270
24k Btu/h
1180
362
288

R410A DC Inverter Multi-split Technical Manual Indoor Units
19
GD Chigo Heating & Ventilation Equipment Co., Ltd.
4.Service Space
A
40
90
40
45
65
Right rear side
refrigerant pipe hole
B
Installation plate
Indoor unit outline
150 mm or more to
ceiling
120 mm or
more to wall
Left rear side
refrigerant pipe hole
120 mm or
more to wall
65
Model
A(mm)
B(mm)
≤12000Btu/h
870
280
18000Btu/h
990
300
24000Btu/h
1200
310
