Fuji Electric FRENIC-Multi User manual

Fuji Electric Systems Co. Ltd FFECA-TE-121
Fuji Electric Corp. of America 09/2011
Instruction Manual
High Performance Compact Inverter
Addendum
This is an update to the Instruction Manual publication number INR-S147-1204-E.
New or revised information is highlighted for easy identification.

1
Standard Models
1) Three-phase 230V class series
Item
Specifications
Type (FRN□□□E1S-2U)
F12
F25
F50
001
002
003
005
007
010
015
020
Applicable motor rating for 3 phase
input[HP] *1
1/8
1/4
1/2
1
2
3
5
7.5
10
15
20
Applicable motor rating for single
phase input [HP] *1a
--------
1/8
1/4
1/2
1
1.5
2
3
5
7.5
7.5
Output ratings for three phase input
Rated capacity(kVA ) *2a
0.3
0.6
1.2
2.0
3.2
4.4
6.8
10
13
19
24
Rated voltage(V) *3
Three-phase, 200V to 240V (With AVR function )
Rated current(A) *4
0.8
(0.7)
1.5
(14)
3.0
(2.5).
5.0
(4.2)
8.0
(7.0)
11
(10)
17
(16.5)
25
(23.5)
33
(31)
47
(44)
60
(57)
Overload capability *5
150% of rated current for 1min, 200% - 0.5 s
Rated frequency (Hz)
50, 60Hz
Input power
For three phase input
Phases, voltage,
frequency
Three-phase,200 to 240V, 50/60Hz
Voltage/frequency variations
Voltage: +10 to -15% (Voltage unbalance: 2% or less *6), Frequency: +5 to -5%
Rated
current *7
[A]
with DCR
0.6
0.9
1.6
3.0
5.7
8.3
14.0
21.1
28.8
42.2
57.6
without
DCR
1.1
1.8
3.1
5.3
9.5
13.2
22.2
31.5
42.7
60.7
80.0
Required power
supply capacity[kVA *8
0.2
0.3
0.6
1.1
2.0
2.9
4.9
7.4
10
15
20
Output ratings for
single phase input
(a)
Rated capacity[kVA] *2a
--------
0.3
0.7
1.1
1.8
2.6
3.9
5.6
7.6
10.4
10.8
Rated current[A] *4
--------
0.8
1.7
2.8
4.6
6.6
9.7
b)
14
19
26
b)
27
Input power for
single phase input
(a)
Phases, voltage,
frequency
SIngle-phase,200 to 240V, 50/60Hz
Voltage/frequency variations
Voltage: +10 to -10%, Frequency: +5 to -5%
Rated
current *7
[A]
with DCR
--------
1.2
2.1
3.6
6.6
9.5
17.3
25.1
33.1
41.8
56.0
without DCR
--------
1.8
3.1
5.3
9.5
13.2
22.2
31.5
42.7
60.7
80.0
Required power
supply capacity[kVA] *8
--------
0.3
0.5
0.9
1.6
2.3
4.1
5.9
7.7
9.7
13.0
Braking
Torque(%) *9
150
100
70
40
20
Torque(%) *10
150
DC braking
Starting frequency: 0.1 to 60.0Hz, Braking time: 0.0 to 30.0s, Braking level: 0 to 100% of
rated current
Braking transistor
Built in
Applicable safety standards
UL508C, C22.2 No.14, EN50178:1997
Enclosure(IEC60529)
IP20 / UL open type
Cooling method
Natural Cooling
Fan Cooling
Weight/Mass lbs.
(kg)]
1.3
(0.6)
1.3
(0.6)
1.5
(0.7)
1.8
(0.8)
3.7
(1.7)
3.7
(1.7)
5.1
(2.3)
7.5
(3.4)
7.9
(3.6)
13.4
(6.1)
15.7
(7.1)

2
2) Three-phase 460V class series
Item
Specifications
Type (FRN□□□E1S-2U)
F50
001
002
003
005
007
010
015
020
Applicable motor rating for 3 phase
input[HP] *1
1/2
1
2
3
5
7.5
10
15
20
Applicable motor rating for single
phase input [HP] *1a
1/4
1/2
1
1.5
3
3
5
7.5
10
Output ratings for three phase input
Rated capacity(kVA ) *2a
1.2
2.0
2.9
4.4
7.2
10
14
19
24
Rated voltage(V) *3
Three-phase, 380V to 480V (With AVR function )
Rated current(A) *4
1.5
2.5
3.7
5.5
9.0
13
18
24
30
Overload capability *5
150% of rated current for 1min, 200% - 0.5 s
Rated frequency (Hz)
50, 60Hz
Input power
For three phase input
Phases, voltage,
frequency
Three-phase,380 to 480V, 50/60Hz
Voltage/frequency variations
Voltage: +10 to -15% (Voltage unbalance: 2% or less *6), Frequency: +5
to -5%
Rated
current *7
[A]
with DCR
0.85
1.6
3.0
4.4
7.3
10.6
14.4
21.1
28.8
without
DCR
1.7
3.1
5.9
8.2
13.0
17.3
23.2
33.0
43.8
Required power
supply capacity[kVA *8
0.6
1.1
2.0
2.9
4.9
7.4
10
15
20
Output ratings for
single phase input
(a)
Rated capacity[kVA] *2b
0.7
1.3
1.9
2.5
4.6
5.8
8.1
11.2
12.8
Rated current[A] *4
0.9
1.5
2.3
3.0
5.6
7.2
10
14
16
Input power for
single phase input
(a)
Phases, voltage,
frequency
SIngle-phase,380 to 480V, 50/60Hz
Voltage/frequency variations
Voltage: +10 to -10%, Frequency: +5 to -5%
Rated
current *7
[A]
with DCR
1.1
1.9
3.6
4.9
7.5
11.4
15.8
24.0
29.0
without DCR
1.7
3.1
5.9
8.2
13.0
17.3
23.2
33.0
43.8
Required power
supply capacity[kVA] *8
0.5
0.9
1.7
2.3
3.5
5.3
7.3
11.0
13.4
Braking
Torque(%) *9
100
70
40
20
Torque(%) *10
150
DC braking
Starting frequency: 0.1 to 60.0Hz, Braking time: 0.0 to 30.0s, Braking
level: 0 to 100% of rated current
Braking transistor
Built in
Applicable safety standards
UL508C, C22.2 No.14, EN50178:1997
Enclosure(IEC60529)
IP20 / UL open type
Cooling method
Natural Cooling
Fan Cooling
Weight/Mass lbs.
(kg)]
2.4
(1.1)
2.8
(1.2)
3.7
(1.7)
3.7
(1.7)
5.1
(2.3)
7.5
(3.4)
7.9
3.6)
13.4
(6.1)
15.7
(7.1)

3
Notes:
*1 Standard 4-pole motor
*1a-When utilized on a single phase application the drive’s output voltage may be lower than the nominal rated voltage
*2a Rated capacity is calculated by assuming the output rated voltage as 230V for three-phase & single-phase input.
*2b Rated capacity is calculated by assuming the output rated voltage as 460V for three-phase & single-phase input.
*3 Output voltage cannot exceed the power supply voltage.
*4 Use the inverter at the current enclosed with () or below when the carrier frequency is set to 4KH or above (F26) and the
inverter continuously runs at 100% load.
*5 In the case of inverters with a capacity of 20 HP at an ambient temperature of 45degree C (113 degree F) or above, this
overload capability is assured, provided that the inverter has run continuously with 85% of the rated current.
*6
3(5.2.3))(IEC6180067
[V]voltageaveragephase-Three
[V]voltageMin.[V]voltageMax.
unbalanceVoltage 


If this value is 2 to 3%, use an AC reactor (ACR).
*7 The value is calculated assuming that the inverter is connected with a power supply with the capacity of 500 kVA(or 10 times
the inverter capacity if the inverter capacity exceeds 50 kVA) and %X is 5%
*8 Obtained when a DC reactor (DCR) is used.
*9 Average braking torque obtained when reducing the speed from 60 Hz with AVR control OFF (It varies with the efficiency of the
motor.
10)Average braking torque obtained by use of an external braking resistor (standard type available as option)
