chinavasion CVSH-I168-2GEN User manual

distortion
SNR 46dB
Receiving
Sensitivity -96dBm@BER=1e-3
Night vision range 2-3 meters
Operating
Humidity 20--\OVo RH
Operating
Temperature 0L --60r
z.ilG Wireless
Digital Golor
LCD Baby tonitor Kit
Signal lndicator:
Signal Strength lndicator Description
Y,lll Perfect Signal
Yrl Low Signal
YNo Signal
t6

:
Note,
1:Please do not operate in high temperature,high magnetic field and
strong light field.
2:Use the designated power adaptor and battery in case any serious
damage of this product
3:Do not put this product in those places which the temperature is
extremely low or high.
4:Please turn off the power when you do not use this product.
S:Please avoid water and dust.
6:Please do not use thinner or other chemicals to wipe this product
7:This product is designed for baby,please try to use it in interior.And
it will reduce the display effect under strong light.
8:The AC adaptor is for indoor use only.
Main Function
oAdopt 2.4GHz Frenquency transmission , accord with FCC,CE
Standard;
.With hich resolution 2.4" LCD display screen ;
oHave operation text menu display function i
oSupport one receiver can connect 4 transmitters ;
olong-distance transmission:Up to 200-300m in the open air;
oClear night vision function,24 hours real-time monitoring i
oHalf-duplex Voice Transmission ,clear voice, volume of sound (0-10)
is adjustable i
rVox Alarm function , when the volume of the baby side over the fixed

:: r:i a:e tolume,it tr'ill alarm the LCD monitor (screen will trrrn off
::: : aaricall] .and then turn on u-ith sound) , to remind parents to pay more
:::::::on to the status of the baby.
el,l:nitor irith TV Out function,support TV display;
el.l:ritor rrith real time function,and dispiay real time information;
oianera and monitor use lithium batteries, it is convenient for
; :::abilitl'.
o',1:th pairing code function: make pairing through the pairing code key
:: :te monitor and camera:
rReceiver with belt buckle clip, eas1. to carry.
Long press to switch
on/ofishort press to
enter the sleep mode
ded after after after
after
DC 5Vpower input
indicator
Channel Switch Key
Volume Decrease
LCD Screen
Sound Volume
lndicator
Shot press to
two-way talk;long
press for 3 seconds to
amplify the image
Channel Switch
TV output, Plug in &A/ line to
switch to TV display
automatiGlly, pull out AV line to
sw switch to LCD display
Charge
5V DC Power
Work/Pairing
Switch
Function lntroduction
2..lGHz Wireless Camera Illustration
2.-l Inch LCD baby monitor tttustration:
Pair Key,press this key 10 begin paring
code after switch on; Long press about 3
seconds io begin parlng,LCD monitor will
display the image from the camera after
successful
Bra.ket

2.4GHz Wireless Camera
rew
I PCS Wireless Cmera 2 pCS powerAdaDre^
I PcswiretesslcDRecerer I pcs AV cabh I PCS lirhium banery lol
1 pcs Mmml hsm"tinn camera use
display the image from the camera after successful.
In the preview mode,press up/down key to adjust the volume of
LCD receiver and press left/right to switch the channels.
Menu
the
Standad Package Contents
a 5V DC Power adapter
O 2.4G Wireless LCD Baby Receiver
O 2.4G Wireless Camera
O Manual Instauction
O AV Cable
O Lithium battery for camera
Operating Instructions
2PCS
lPCS
lPCS
lPCS
lPCS
LPCS
In the preview mode, short click OK key to enter the
main menu display
a Babyvol
Baby Vol Mode
The camera and receiver use external power supply or lithium battery,
short press the Power/pair key of the camera to switch on, work
indicator light is on;After switching on, long press the power key of the
receiver for 3 seconds,appear switch-on scene,then enter to preview
scene. Press the Power/pair key to make paring code,and the LCD
monitor will have paring prompt.Also,the work indicator Iight beside
rhe power jack flash,then long press the camera, s power/pair key for
3 seconds,work indicator flash and make paring,the LCD monitor will
In the preview mode, short press OK key to enter the main menu display,the
options box stops in the "Baby Vol' option,this mode is to adjust the volume
of the camera and to adjust the volume of the LCD monitor when pressrng
up/down key in the preview mode.Press OK key to enter the volume
adjustment, press left and right key to adjust the volume . volume level is
vary from 0 100 (f0 volume level in total ).Press OK Key lo confirm and
Effect Mode
.;.'E ':t :i i
-2 1
:* .::_
*..:+.:a' 'ii
7 e. ?;."r,a..:'
,',,'ae'7e
'?'Z-:
:
6

t'i:**?*, lE Eri
1'ffi.,,'i."'
.,:i1.:,2*&.+ t* Err
1: Brightness Mode
In the preview mode, short press OK button to enter the main menu
display , hen press up/down key to move to the Effect position,and
press OK to enter at the same time.Press up/down key to move to
brightness mode ,press left/right key to modify the parameters,the
brightness level is vary from 0-100 (10 brightness level in total )
Press OK Key to return to main menu mode after set up the
brightness.Press up/down key to move to exit positon and press OK
key to exit main menu and back to preview mode.
Note: The brightness can be adjusted usefully only after receiving the
image of camera,and the brightness is the camera's,not the LCD's.
2: Vertical Mode
In the preview mode, short press OK key to enter the main menu
display,then press up/down key to move to Effect position and press
OK to enter.Press up/down key to move to Vertical,press leftlright key
to modify and check whether ihe image is the same as the ON/OFI;
ON:Display image normally
OFF:UP/Down image display
Press OK Key to back to main menu,press up/down key to move to
Exit position,and press OK key to exit the main menu and back to
preview mode.
3: Horizontal Mode
In the preview mode,short press OK key to enter the main menu
display,then press up/down key to move to Effect position and press
OK key to enter.Press up/down key to move to Horizontal,press
left/right key to modify and check whether the image is the same as
ON/OFF.
ON:Display image normally
OFF:LeftlRight image display
Press OK Key to back to main menu,press up/down key to move to
Exit position and press OK key to exit main menu and back to preview
mode.
4: Contrast Mode
In the preview mode,short press OK key to enter the main menu
display,then press up/down key to move to Effect position and press
OK key to enter. Press up/down key to move to contrast
position,press left/rieht key to modify the parameters,the contrast
level is vary from 0-100 (10 contrast level in total)
Note:The contrast can be adjusted usefully only after receiving the
image of camera.
5: Saturation Mode
In the preview mode, short press OK key to enter the main menu
display , then press up/down key to move to Effect position and press
?
I
r
t
*
k*

OK key to enter. Press up/down key to move to Saturation
position,press leftlright key to modify the parameters,the saturation
level is vary from 0-100 (10 saturation Ievel in total)
Press OK Key to back to main menu after set up the saturation
parementers.Press up/down key to move to Exit postion and press OK
key to exit main menu and back to preview mode.
Note: The saturation can be adjusted usefully only after receiving the
image of camera,and it is to adjust the camera's contrast,the
saturation of this camera is fixed, so the parameter won't change when
adjusting.
Setup Mode
LO:VOX low sensitivity,when the LCD enter to sleep mode,the voice
of the camera is more than 60 dB , the LCD will open automatically, and
the screen display "VOX " mark.
HL VOX high sensitivity,when the LCD enter to sleep mode,the voice
of the camera is more than 56 dB ,and the LCD will open automatically,
and the screen display "VOX " mark.
2: Auto Sleep Mode
In the preview mode, short press OK key to enter the main menu
display , then press up/down key to move to Setup position and press
OK to enter.Press up/down key to move to Auto Sleep,and press
leftlriSht key to modify the parameters.
OFF: When auto sleep mode is off,short press POWER button to enter
the auto sleep mode.
305/1M/3M/5M/10M : screen-off time selection,the LCD monitor will
enter auto sleep mode actording to the setup time-When the LOIHI of
vox mode is on, the voice volume of the camera is more than the
set-up volume,the LCD will light on automatically.
3: TV OUTMode
In the preview mode, short press OK button to enter the main menu
display , then press up/down key to move to Setup position and press
OK key to enter.Press up/down key to move to TV OUT TV system
output mode,press left/right key to modify the parameters,
PAL-M/NTSC-3.58 / PAL/NTSC-4.43 four TV systems for
selection.
t
t
I
I
.:E v..i
::1i.1:#:
tz *,
?'r:@,1,
a,lt,*,bj*. i3ll ?,ii
;'*.
i+
1: VOX Mode
In the preview mode, short press OK key to enter the main menu
display,then press up/down key to move to Setup position and press
OK to key to enter.Press up/dowl key to move to VOX Mode,press
Ieft/right key to modify the parameters.There are OFF/LOIHI 3
selection, it will display t- - -l if there is no image.
OFF:close VOX function, VOX function is useless
t
I
,i
i
ll
L
10

iil&a" i3E Yri
%*t
*,
;4
-,;&',
ZOOM Mode
,$= ffi Srt
::
'*
4
In the preview mode,long press rel-UzOOrraExey for 3 seconds,a
magnifier icon is displayed on the LCD,press up/down/left/right key to
move the image display area, then short press TALL/ZOOM Key to
exilZoom mode display.
TIME Set
In the preview mode,long press OK Key for 3 seconds to enter into
time setup,Press up/down key to set up the parameters,and set up the
hour first and then press OK key to skip to minute setup ,press
up/down key to modify the parameters,after setup,press OK key to
exit time setup.
Pair Process
LCD Monitor with power and switch on,and camera should be with power and
switch on also;
l:Choosing the camera code which is going to pair by Left and Right
Key of the Monitor,such as CH1;
2:Press Power/Pair key of Monitor for 3 seconds to make pairing,
POWER licht will flash ,LCD display ' t # baby Pairing... '
3:Press the Power/Pair key of camera for 3 secons,Green light flash
h
t2 13
I*
and enter into pairing code;
4:After pairing successful,Monitor will display the image from the
camera and Power led is on all the time and enter to work status.
I{ can not pair code, it returns to original code and back to origital state
after 15 seconds,
Repeat Step 2 - Step 5 to make pairing code of Camera2,3,4.
Note:Different cameras should choose different channel to code,
otherwise, it will override other cameras in this chmel to code.
Problems & Solutions
1:There are screaming voice if the distance betl'een the camera and
monitor is near
Answer: This phenomenon is caused by the acoustical feedback,the
audio signal of microphone is gleaned by receiver' s speaker and then
the microphone pick up the signal again and transmit them together
with camera' s voice,the receiver will have louder voice than
before.Therefore,it can cause the formation of self-excited osci[ation
round and round ,and result in the screaming voice.However,you can
solve this problem by turn down the speaker volume or insert the
headset into the receiver.
2:No response
Answer:Check whether the battery is with electricity,and confirm
whether the device can switch on a{ter connecting the power
adaptor.Also,check whether charge LED is on or not.
3: LCD can't disphy after switch on

Answer:Please Check whether the AV line is connected to TV set ,
whether short press the POWER key so that it has entered to auto
sleep mode,then short press the POWER key again to check whether
the LCD monitor can display or not.
Parameters
a: Function
Function Description
Frame Rate 15-25 Frame , Signal strong,frame high
Signal strength
indication
6 grade
Voice Volume 10 grade
Talkback Two-way talk, half-duplex
vox Switch on automatically when there js voice
One monitor with 4
tra nsmitters
One receiver with 4 cameras,switch CH
display
Realtime clock Yes,24 hours system
LCD Size 2.4inch 960*240 RGB color LCD
Transmission
safety
Use after pair code
b: Electrical parameters
LCD Receiver
Voltage
DC: 5V/1000MAi Battery: Built-in
3.6V/7001\4AH lilhium bailer).
Camera Voltage DC : 5V/1000MAi Battery:External
t4
3.6V/700MAH lirhium battery
Frequency 2.4GHz ISM Band
Wireless Work
Method FHSS
Transmission
Power 19dBm@CW mode
Transmission rate 3Mbps
Operating Range Open field : 200-300 meter
Work cunent
(Transmitter and
receiver)
TX:400mA MAX,RX:4@mA MAX(Not
include charge curent)
Charge current 120-200MA (Transmitter and Receiver
are the same)
Work current for
Auto sleep
TX:35mA (once every O.Ss) RX:2OmA
(once every 0.5s)
Audio rate 16K
Audio range ).ZOHz-3KHz
VOX Power *56/-60dB@ MIC Input
Camera resolution 0.3 Mega
Picture resolution 320*240QVGA
AV OUT function 5-15 frame VGA from AV Output
Video Rate 15-2sFPS
Total harmonic <5.OVo
