Chipsee CS12102F170P-C111 User manual
www.chipsee.com
www.chipsee.com
Chipsee Products Naming Rules
CS12102F170P-C111
CS Chipsee Product Abbreviations
www.chipsee.com
www.chipsee.com
12
Horizontal Resolution
80 Means 800 Pixel
10 Means 1024 Pixel
12 Means 1280 Pixel
14 Means 1440 Pixel
19 Means 1920 Pixel
102
Vertical Resolution
480 Means 480 Pixel
600 Means 600 Pixel
768 Means 768 Pixel
800 Means 800 Pixel
900 Means 900 Pixel
102 Means 1024 Pixel
108 Means 1080 Pixel
F(T) Product based on Freescale (TI) CPU
170
LCD Dimension
050 Means 5.0 Inch
070 Means 7.0 Inch
080 Means 8.0 Inch
097 Means 9.7 Inch
101 Means 10.1 Inch
104 Means 10.4 Inch
120 Means 12.0 Inch
150 Means 15.0 Inch
170 Means 17.0 Inch
190 Means 19.0 Inch
215 Means 21.5 Inch
www.chipsee.com
www.chipsee.com
P
Means Embedded PC or Panel PC
E Means Embedded PC without Case
P Means Panel PC with Case
C
Means Touch Type
R Means Resistive Touch
C Means Capacitive Touch
1
Means LCD Brightness
1 Means Common Brightness
2 Means High Brightness
1PCB Version
Baseboard PCB Version Number
1PCB Version
SOM Module PCB Version Number
Hardware Features
Key Features:
CPU iMX6Q, Quad-A9, 1GHz
RAM 2GB DDR3
eMMC 8GB
Storage TF card supports up to 32GB SDHC
Display 17 Inch LCD, 1280*1024 Pixel Resolution,
4:3
Touch Ten-Point Capacitive Touch
USB 4 x USB 2.0 Host, 1 USB OTG
www.chipsee.com
www.chipsee.com
LAN 1 Channel 1000M LAN
Audio 3.5mm Audio In/Out Connector, 2W Speaker
Internal
Buzzer 1
RTC Yes
RS232 4 Channels
RS485 Optional
CAN Optional
WiFi/BT On-Board WIFI/BT
HDMI 1 Channel
SATA II 1 Channel
4G/LTE Optional
Power Input 15~36V DC
Current @ 15V 2000 mA max
Power Consumption 20W Typical
Working Temperature -20°C to +70°C
OS Android, Ubuntu, Linux
Dimension 392*330*62mm
Weight 5200g
* This product has 5 channels of UART in total. One UART
channel is used for Bluetooth. The default setting is
4*RS232+Bluetooth. The UART can be easily changed between
RS232 and RS485. If you need different settings, please
contact us.
www.chipsee.com
www.chipsee.com
CS12102F170P-
C111
Figure 1: Front View (Android)
www.chipsee.com
www.chipsee.com
Figure 2: Back View
Power Input Connector
The product CS12102F170P-C111 uses a wide-range power input DC
15~36V. The total power consumption is normally about 20W. The
Power Input Connector is 3 Pin 3.81mm Screw Terminal Connector
as Figure 3 shows.
www.chipsee.com
www.chipsee.com
A detailed description of the power input connector pins is
provided in Table 1.
Figure 3: Power Input Connector
Table 1
Power Input Pin Definition:
Pin Number Definition Description
Pin 1 Positive Input Connect to DC Power Positive
Terminal
Pin 2 Negative Input Connect to DC Power Negative
Terminal
Pin 3 Ground Connect to Power System Ground
ATTENTION:
The system ground “GND” has been connected to power
negative “-” on board.
Capacitive Touch
www.chipsee.com
www.chipsee.com
The product CS12102F170P-C111 uses a ten-point capacitive
touch.
ATTENTION:
Capacitive touch is very sensitive to power noise. Ripple
voltage/current from the power adapter will cause the LCD
ripples and also the capacitive touch to malfunction. If you
use the APK Multi-Touch under Android to test, you can find
the touchpoint float. There are several ways to solve this
problem:
1) Use a high-quality power adapter, or a battery to provide
power like a cell phone or tablet PC.
2) If the power adapter isn’t good enough, make sure the
CS12102F170P-C111 power input connector Pin 3 is connected to
the Ground. This method can eliminate the problem totally. You
can test it by touching the GND of CS12102F170P-C111 with one
hand, while the other hand operates on the capacitive touch
screen. In this case, the user’s body acts as the Power System
Ground.
DB9 Connector
The product CS12102F170P-C111 has 4*DB9 connectors configured
as RS232 by default as shown in Figure 4. COM3/COM4 can be
configured as RS485. If you need other settings different from
the default one, please contact us.
www.chipsee.com
www.chipsee.com
Figure 4: DB9 Connector
USB HOST Connector
There are two dual USB ports, as Figure 5 shows. Each USB port
can provide a current of 500mA.
Figure 5: USB HOST Connector
USB OTG Connector
The product CS12102F170P-C111 has one USB OTG connector, shown
in Figure 6, that works as a slave by default. It can be used
to establish a connection with the host PC.
www.chipsee.com
www.chipsee.com
Figure 6: USB OTG Connector
LAN Connector
The product CS12102F170P-C111 has one channel 1000Mbit
Ethernet Connector, as Figure 7 shows.
Figure 7: LAN Connector
Audio Connector
There is one Audio Input (“Line-in”) and one Audio Output
(“Line-out”), as Figure 8 shows. As well as an internal 2W
speaker.
www.chipsee.com
www.chipsee.com
Figure 8: Audio Connector
ATTENTION:
The TF card slot doesn’t come with a TF card by default.
WiFi+BT
The product CS12102F170P-C111 has one WiFi+BT. It uses
Realtech RTL8723 which integrates WiFi and BT. There is a
connector on the backside case that is used to connect the
external WiFi/BT Antenna, as Figure 9 shows.
Figure 9: WiFi+BT Antenna
HDMI Connector
www.chipsee.com
www.chipsee.com
The product CS12102F170P-C111 has one HDMI connector as shown
in Figure 10. The HDMI output resolution can be configured by
software.
Figure 10: HDMI Connector
Boot Switch
The product CS12102F170P-C111 has a boot switch, shown in
Figure 11, used to change the boot sequence. For more details
on the boot switch configuration, please refer to Table 2.
Figure 11: Boot Switch
www.chipsee.com
www.chipsee.com
Table 2
Boot Config Select:
Mode 1 2 3 4
TF Card 1 0 0 0
eMMC 1 1 01
Download 01 1 0
Expansion Connector
The product CS12102F170P-C111 has one Expansion
Connector, as Figure 12 shows. This connector is labeled as
P28 on the PCB and is connected to CPU GPIO/I2C signals. As
for the definition of every pin, please refer to Table 3.
Figure 12: Expansion Connector
Table 3
GPIO Connector Definition
Pin Number Definition
Pin 1 INPUT4
Pin 2 INPUT3
Pin 3 INPUT2
www.chipsee.com
www.chipsee.com
Pin 4 INPUT1
Pin 5 OUTPUT4
Pin 6 OUTPUT3
Pin 7 OUTPUT2
Pin 8 OUTPUT1
Pin 9 GND_ISO
Pin 10 VCC_ISO
ATTENTION:
All signals are optocoupler isolated. VCC_ISO supports 5V ~
24V input.
Dimensions and Mounting
Dimensions
The dimensions of CS12102F170P-C111 are 392*330*62mm.
Mounting Method
This product CS12102F170P-C111 can be mounted by VESA mounting
method (100x100cm or 75x75cm), as Figure 13 shows. Please make
sure the display is not exposed to high pressure when mounting
into an enclosure.
www.chipsee.com
www.chipsee.com
Figure 13: Mounting Method
How to Get Support
Please feel free to contact us with any questions, queries or
suggestions.
If your question is about technical support or troubleshooting
for one of our products, we kindly ask you to first check our
documentation for a possible solution.
www.chipsee.com
www.chipsee.com
If you cannot find the solution you are looking for then
details.
