cinaton iSense Touch free Intelligent Faucet User manual

Touch free Intelligent Faucet
Operation Manual
2013-08-10





















Features
Just like magic®

1
Opera�on Procedure
iSense System
Technical Data
1. Power supply: 110 ~ 240 AC, 4 AA backup battery.
2. Water supply presure: 8 - 100 psi, normal 60 psi.
3. Operating temperature: 37° F ~ 180° F
4. Aerator water flow: Kitchen - 2.2 GPM, Lavatory - 1.5 GPM.
5. Control Valve: Digital Controller included.
Cold Water
Hot Water
Digital Controller
iSense Touch Free Intelligent Faucet System
TM TM

C - Easy Sensor & LED
A - Hot Water
B - Cold Water
D - High Flow
E - Low Flow
1. Sense C for intermittent flow.
2. Sense A & B for continuous
flow and sense again to stop.
3. Sense D & E to save as default.
iSense Touch free Intelligent Faucet (TIF)
TM
2
How to ac�vate Touch-free sensors
1. Place a finger about 1” in front of the sensor
for ac�va�on.
2. Place your palm about 1” in front of 2 sensors
for simultaneous ac�va�on.
Sensor Zone & Distance
1. Place a finger about 1” in front of the side
sensor for ac�va�on. 7” ~ 9” for center
sensor.
1.5”
1.5”
7” ~ 9”
Sensing Zone
A
B
C & LED
E
D
Opera�on Procedure
7” ~ 9”
Work with Sensors


Start and adjust water temperature and flow





















































3

Opera�on Procedure
4
1. Start Preset 1 Setting
When no water flow,
place finger in front of
Sensor D to start
Preset 1 setting.
3. Adjust water temperature and flow
accordingly.
2. Start water flow with Preset 1 setting
Place hand in front of
Sensor A and B or
in front of Sensor C to
start water flow with
Preset 1 setting.
4. To save new Preset 1 setting.
Place hand in front of both
Sensor D and E to save
the current water
temperature and flow
setting as new
Preset 1 setting.
Faucet will reset to the Common Defaucet Setting
condition after 30 seconds without new operation
command.
6. Start Preset 2 Setting
Repeat same procedure
1- 5 but start with
Sensor E to activate
or save Preset 2
setting.
LED - Flashes green once.
LED - Flashes green once.
LED - Flashes green once.
5. Stop water flow
Place hand in front of Sensor A and B to
stop water flow.
1. To pause Sensor C (Easy Sensor)
When no water flow, place finger in front of
Sensor A to pause Sensor C for working in the
sink area.
3. To Reset Sensor C (Easy Sensor)
When no water flow, place finger in front of
Sensor A to reset Sensor C.
2. Working in the sink area
Sensor C was paused
to allow user to proceed
with housework
in the sink area.
4. Working with Sensor C (Easy Sensor)
LED - Flashes green once
and red once.
LED - Flashes green
two times.
Pause Sensor C
Preset and saving setting
7. Faucet Reset

P81002-13
14014 Gannet Street, Santa Fe Springs, CA 90670
Tel: [phone] Fax: [phone]
www.cinaton.com [e-mail]
