CineRAID EditPro T4 4 Bay User manual

1. Welcome:
Thank you for choosing CineRAID
Thank you for your CineRAID EditPRO purchase. The EditPRO is a professional
high performance storage solution to meet your high resolution digital media and
storage requirements.
2. What’s in the box?
Carefully unpack your EditPRO and inventory what is inside with the items list
below. Confirm that everything that is correct before moving on to the next step.
If anything is missing please contact your dealer or CineRAID.
CineRAID EditPRO T04 – 1 Qty
HDD Trays – 4 Qty PCI-e or PCI-X RAID Card – 1 Qty
User Manual – 1 Qty Installation CD – 1 Qty
HDD Mounting Screws – 16 Qty I2C Cable – 1 Qty Data Cable – 1 Qty Standard Power Cable – 1 Qty
EditPro 4 Bay
Missing Parts?
Please contact your dealer or CineRAID if your recived a package missing any of the
above parts.
Tel: [phone] Fax: [phone]
www.CineRAID.com [email protected]
3. Disk Tray Mounting
Confirm that all bays are secured by pushing the tray into its bay with the locking
lever open until the tray sits flush with the EditPRO. Then lock the lever in place
to secure the tray into the enclosure.
4. RAID Controller Installation
1. Touch the metal PCI slot covers on the back of your
computer to discharge any static electricity.
2. Unplug ALL cables from your computer and
remove the side access panel according to your
system type.
3. Apple G5 users must first remove the deflector
cover and place it in a clean and safe surface.
NOTE: Remember to replace the air deflector after
you have finished installing your RAID controller
card.
WARNING: Allow a few minutes for the computer
internals to cool down before opening your computer.
[email protected]
www.CineRAID.com
CineRAID
2861 Saturn St. #B
Brea, CA 92821 USA

3. Remove the PCI slot cover plate from an available
PCI slot. Consult your HBA or video capture card for
recommended slot positions.
4. Install & secure your PCI controller card into the
slot and firmly press the card into place.
5. Close and replace the system panel
WARNING: To minimize the chance of electrical shock,
always follow proper safety rules when working with
electrical componets.
1. Power on your system
2. Insert the Areca MRAID Installation CD
3. After the CD mounts, open the MAC driver folder
4. Choose either the MAC or MACPro installer according to your system.
5. The MRAID window, click on the lock to continue. (You may be prompted to enter your
administrator password)
6. Introduction – Read and make appropriate changes if necessary. Click next to continue.
7. Choose Install Folder – Default is inside “Applications” on local disk. Click next to continue.
* Slot4 is recommend to obtain
the maxium performance for
MAC PRO systems*
[email protected]
www.CineRAID.com
5. MAC OS Driver Installation

8. Choose Install Set – Here you will choose “MRAID With Driver”. Click next to continue.
9. Choose Alias Folder – Default setting is “On the Desktop”. Click next to continue.
10. Pre-Installation Summary – Verify Settings. Click next to continue.
11. Install Complete – Congratulations! MRAID has been successfully installed. Click next to
continue.
12. Click Done and reboot the system for the changes to take affect. Your system is now
configured to be used with your CineRAID EditPRO.
6. Connecting Your EditPRO to Your System
Your EditPRO is equipped with 2 industry standard SFF-8088 Multi-Lane interface
ports. Connect cable from the raid conrtoller to the EditPRO. You will receive
SFF-8470 to SFF-8088 cables for the PCI-X solution or SFF-8088 to SFF-8088 cables
for the PCI-e solution. Ensure that both connectors are properly secured and
fastened. Most common issues are poor cable connections.
SFF8470 SFF8088
Note: Do NOT over tighten thumbscrews
[email protected]
www.CineRAID.com

7. Finished
Ensure all connections are secure on the EditPRO and your system. Power your
EditPRO first, then power your host computer. Your array is now ready for RAID
configuration. To learn more about RAID configuration, please refer to your RAID
controller’s documentation.
NOTE: Always have your EditPRO be the
first to power on and last to power off.
Power Switch
Three (3) Year Limited Warranty
WARRANTY COVERAGE
CineRAID’s warranty obligations are limited to the terms set forth below:
CineRAID, as defined below, warrants this hardware product against defects in materials and workmanship under normal use for the period of THREE (3)
YEARS from the date of retail purchase by the original en-user purchaser. If a hardware defect arises and a valid claim is received within the Warranty
Period, at its option, CineRAID will either (1) repair the hardware defect at no charge, using new or refurbished replacement parts, or (2) exchange the
product with a product that is new or which has been manufactured from a new serviceable used parts and is at least functionally equivalent to the
original product, or (3) refund the purchase price of the product. CineRAID may request that you replace defective parts with new or refurbished
user-installable parts that CineRAID provides in fulfillment of its warranty obligation. A replacement product or part, including a user-installable part
that has been in accordance with instructions provided by CineRAID, assumes the remaining warranty of the original product of ninety (90) days from
the date of replacement or repair, whichever provides longer coverage for you. When a product or part is exchanged, any replacement item becomes
your property and the replaced item becomes CineRAID property. Parts provided by CineRAID in fulfillment of its warranty obligation must be used in
products for which warranty service is claimed. When a refund is given, the product for which the refund is provided must be returned to CineRAID and
becomes CineRAID’s property.
EXCLUSTIONS AND LIMITATIONS
This Limited Warranty applies only to hardware products manufactured by or for CineRAID that can be identified by the “CineRAID” trademark, trade
name, or logo affixed to them. The Limited Warranty does not apply to any non- CineRAID hardware products or any software, even if packaged or sold
with CineRAID hardware. Manufactures, suppliers, or publishers, other than CineRAID, may provide their own warranties to the end user purchaser, but
CineRAID, in so far as permitted by law, provides their products “as is”. Software distributed by CineRAID with or without the CineRAID brand name
(including, but not limited to system software) is not covered under this Limited Warranty. Refer to the licensing agreement accompanying the software
for details of your rights with respect to its use.
CineRAID does not warrant that the operation of the product will be uninterrupted or error-free. CineRAID is not responsible for damage arising from
failure to follow instructions relating to the product’s use.
This warranty does not apply: (a) to damage caused by use with non- CineRAID products; (b) to damage caused by accident, abuse, misuse, flood, fire,
earthquake or other external causes; (c) to damage caused by operating the product outside the permitted or intended uses described by CineRAID; (d)
to damage caused by service (including upgrades and expansions) performed by anyone who is not a representative of CineRAID or an CineRAID
Authorized Service Provider; (e) to a product or part that has been modified to significantly alter functionality or capability without the written
permission of CineRAID; (f) to consumables parts such as batteries, unless damage has occurred due to a defect in materials or workmanship; (g) or if
any CineRAID serial numbers have been removed or defaced.
To the extent permitted by the law, this warranty and remedies set forth above are exclusive and in lieu of all other warranties, remedies and
conditions, whether oral or written, statutory, express or implied. As permitted by applicable law, CineRAID specifically disclaims any and all statutory
or implied warranties, including, without limitation, warranties of merchantability. Fitness for a particular purpose and warranties against hidden or
latent defects. If CineRAID cannot lawfully disclaim statutory or impled warranties then to the extent permitted by law, all such warranties shall be
limited in duration to the duration of this express warranty and to repair or replace service as determined by CineRAID in its sole discretion. No
CineRAID reseller, agents, or employee is authorized to make any modification, extension, or addition to this warranty.
Except as provided in this warranty and to the extent permitted by law, CineRAID is not responsible for direct, special, incidental or consequential
damage resulting from any breach of warranty or conditions, or under any other legal theory, including but not limited to loss of use; loss of revenue;
loss of actual or anticipated profits (including loss of profits on contracts); loss of the use of money; loss of anticipated savings; loss of business; loss of
opportunity; loss of goodwill; loss of reputation; loss of damage to or corruption of data; or any indirect or consequential loss or damage howsoever
caused including the replacement of equipment and property, any costs of recovering, programming, or reproducing any program or data stored or used
with CineRAID products and any failure to maintain the confidentiality of data stored on the product. The foregoing limitation shall not apply to death
or personal injury claims. CineRAID disclaims any representation that it will be able to repair any product under this warranty or make a product
exchange without risk to or loss of the programs or data.
CONSUMER PROTECTION LAWS
For consumers who are covered by consumer protection laws or regulations in their country of purchase or, if different, their country of residence.
The benefits conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations. Some
countries, states and provinces do not allow the exclusion or limitation of incidental or consequential damages or exclusions or limitations on the
duration of the implied warranties or conditions, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights, and you may also have others rights that vary by country, state or province.
This Limited Warranty is governed by and construed under laws of the country in which the product purchase took place. CineRAID, the warrantor
under this Limited Warranty, is identified at the end of this document according to the country or region in which the product purchase took place.
9. Warranty
Please carefully read your warranty
8. Troubleshooting
This section covers some common support questions. If you are experiencing an
urgent issue, please contact us with your questions or concerns.
Connection Problems:
Always double check for loose cable connections or improperly seated disks if you experience
problems where a disk or volume does not appear in your computer, or you receive an error
message stating a disk is missing when you have the drives configured as a RAID set.
1. Disconnect the data cables and reconnect each cable one at a time ensuring each connector
is screwed in securely on your EditPRO
2. Make sure the connector is properly secured on your HBA
3. Check you EditPRO’s drive presence LED’s, located on each HDD tray. If the LED’s are not lit,
remove the disk and reinsert it back into the EditPRO.
SFF-8088
(Mini SAS)
I2C
SFF8088 connected to the EditPRO
Power Cable
