Cisco D9477-1 Operating instructions

78-717866-01 Rev D
MQAM Modulator Models
D9477-1, D9477-2, and D9477-3
Installation and Operation Guide

Please Read
Important
Please read this entire guide. If this guide provides installation or operation
instructions, give particular attention to all safety statements included in this guide.

Notices
TrademarkAcknowledgments
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its
affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found
at www.cisco.com/go/trademarks.
Third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between
Cisco and any other company. (1110R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Copyright
© 2007, 2013 Cisco and/or its affiliates. All rights reserved. Printed in the United States of
America.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.

78-717866-01 Rev D iii
Contents
Safety Precautions vii
Read, Retain, and Follow These Instructions....................................................... vii
Warning and Caution Icons ................................................................................... vii
Heed All Warnings.................................................................................................. vii
Avoid Electric Shock ............................................................................................... vii
Servicing................................................................................................................... viii
Cleaning, Water, Moisture, Open Flame............................................................. viii
Ventilation................................................................................................................ viii
Placement................................................................................................................. viii
Fuse .............................................................................................................................. ix
Grounding This Product (U.S.A. and Canada Only)............................................ix
FCC Compliance xi
United States FCC Compliance................................................................................xi
Canada EMI Regulation............................................................................................xi
About This Guide xiii
Introduction..............................................................................................................xiii
Scope..........................................................................................................................xiii
Audience ...................................................................................................................xiii
Related Publications ................................................................................................xiv
Document Version ...................................................................................................xiv
Chapter 1 Introducing the MQAM 1
System Overview ..................................................................................................................... 2
Features ........................................................................................................................ 2
Input/Output Process............................................................................................................. 4
Back Panel Components ............................................................................................ 4
Input/Output Diagram.............................................................................................. 6
Input/Output Stage/Description Table.................................................................. 6
Front Panel Overview ............................................................................................................. 7
Front Panel Diagram .................................................................................................. 7
Back Panel Overview............................................................................................................... 9
Back Panel Diagram ................................................................................................... 9
Back Panel Indicator Lights..................................................................................... 10

Contents
iv 78-717866-01 Rev D
Chapter 2 Installing the MQAM 11
Installation Process Summary.............................................................................................. 12
Before You Begin....................................................................................................... 12
MQAM Installation Processes................................................................................. 12
Unpack and Inspect the MQAM.......................................................................................... 14
Carrier’s Responsibility............................................................................................ 14
Unpacking and Inspecting Procedure ................................................................... 14
Install the Modulator Into a Rack ........................................................................................ 15
Installing the Modulator into a Rack ..................................................................... 15
Connect Power Sources......................................................................................................... 16
Connecting an Earth Ground .................................................................................. 16
Connecting a DC Power Source.............................................................................. 16
Connecting an AC Power Source ........................................................................... 17
Record the MAC Address..................................................................................................... 18
Recording the MAC Address.................................................................................. 18
Connect the RF OUT Ports ................................................................................................... 20
Location of RF OUT Ports........................................................................................ 20
Connecting the RF OUT Ports................................................................................. 21
Connect the DVB ASI Input Ports ....................................................................................... 22
Location of DVB ASI Input Ports............................................................................ 22
Connecting the DVB ASI Ports ............................................................................... 23
Connect the CA SYNC Port.................................................................................................. 24
Location of CA SYNC Port ...................................................................................... 24
Guidelines for Connecting the CA SYNC Port..................................................... 24
Connecting the CA SYNC Port ............................................................................... 25
Connect the 10/100BaseT Ethernet Port............................................................................. 26
Description................................................................................................................. 26
Location of 10/100BaseT Ethernet Port ................................................................. 26
Connecting the 10/100BaseT Ethernet Port.......................................................... 27
Chapter 3 Provision the MQAM 29
Overview................................................................................................................................. 30
Basic Parameters Tab............................................................................................................. 31
Advanced Parameters Tab.................................................................................................... 33
File Selection Dialog Window................................................................................. 34
Connectivity Tab.................................................................................................................... 36
Provisioning the MQAM on the DNCS.............................................................................. 38

Contents
78-717866-01 Rev D v
Chapter 4 Operating the Modulator 41
Understand the Boot Process ............................................................................................... 42
Initial Boot Screens ................................................................................................... 43
Code Download Messages ...................................................................................... 44
Change the Boot Mode.......................................................................................................... 45
Boot Modes ................................................................................................................ 45
Changing the Boot Mode......................................................................................... 46
Read the Default Status Screen ............................................................................................ 47
Reading the Default Status Screen.......................................................................... 47
Use the Front Panel Keys to Change Configuration Settings.......................................... 48
Diagram of MQAM Menu Structure...................................................................... 48
Accessing the MQAM Menus ................................................................................. 49
Navigating Within a Menu or Changing a Screen Value.................................... 49
Saving Changes to Configuration Settings............................................................ 49
Adjust the Frequencies of a Selected Carrier ..................................................................... 50
Adjusting the Output Frequency............................................................................ 50
Adjust the RF Output Level of a Selected RF Module...................................................... 51
LEVEL Button Menu Flow ...................................................................................... 51
Adjusting the RF Output Level............................................................................... 51
Mute the RF Output of a Selected RF Module................................................................... 52
Enabling or Disabling a Muting Option ................................................................ 52
Change the Carrier Mode of a Selected RF Module.......................................................... 53
Selecting Modulated or Continuous Wave Carrier Mode .................................. 53
Monitor Setup Options.......................................................................................................... 54
OPTIONS Menu ........................................................................................................ 54
Displaying Alarm Status.......................................................................................... 55
Viewing the Session Count...................................................................................... 55
Viewing the Program Count ................................................................................... 55
Viewing the Encryption Mode................................................................................ 56
Viewing the MAC Address ..................................................................................... 56
Viewing the Netmask Screen .................................................................................. 56
Viewing the IP Address ........................................................................................... 56
Viewing the I/O Board Software Revision Level................................................. 57
Viewing the RF Module Revision Numbers ......................................................... 57
Checking the Temp of an RF Module .................................................................... 57
Viewing the Hardware Revision String................................................................. 58
Setting the Modulation Type................................................................................... 58
ITUB Interleave Screen............................................................................................. 59
Adjusting the LCD Contrast.................................................................................... 59
Resetting the MQAM ............................................................................................... 59
Inspect the Modulator ........................................................................................................... 60
Select an RF Module .............................................................................................................. 61
Selecting an RF Module ........................................................................................... 61

Contents
vi 78-717866-01 Rev D
Inspect the MQAM ................................................................................................................ 62
Quarterly Inspection................................................................................................. 62
Replace the Fuse..................................................................................................................... 63
Replacing the Fuse.................................................................................................... 63
Diagnose the Fan.................................................................................................................... 65
Diagnosing the Fan................................................................................................... 65
Replace the Fan ...................................................................................................................... 66
When Can I Perform This Procedure? ................................................................... 66
Location of Fans ........................................................................................................ 66
Replacing the Fan...................................................................................................... 67
Chapter 5 Troubleshooting the MQAM 69
Alarm Conditions .................................................................................................................. 70
Purpose and Severity Levels of MQAM Alarms.................................................. 70
LCD Alarm Display.................................................................................................. 71
Reading the Display ................................................................................................. 71
Troubleshooting Alarm Messages....................................................................................... 72
Front Panel LCD Alarm Messages ......................................................................... 72
Troubleshooting Boot Screen Error Messages ................................................................... 79
Booting Error Messages ........................................................................................... 79
Chapter 6 Customer Information 83
Appendix A Technical Specifications 85
Installation and Operation Requirements .......................................................................... 86
Power Requirements Table...................................................................................... 86
Rack Requirements Table ........................................................................................ 86
Environmental Requirements Table....................................................................... 87
RF Specifications .................................................................................................................... 88
ASI Input Specifications........................................................................................................ 89
Modulation Specifications .................................................................................................... 90
Modulation Specifications Table ............................................................................ 90
Digital I/O Performance Specifications.............................................................................. 91
Digital I/O Performance Specifications Table...................................................... 91
Connector Type...................................................................................................................... 92
Connector Type Table .............................................................................................. 92
Factory Default Settings........................................................................................................ 93
Factory Default Settings Table ................................................................................ 93
Standard Output Frequencies .............................................................................................. 94
Index 95

Safety Precautions
78-717866-01 Rev D vii
Safety Precautions
Read, Retain, and FollowThese Instructions
Carefully read all safety and operating instructions before operating this product. Follow all
operating instructions that accompany this product. Retain the instructions for future use.
Give particular attention to all safety precautions.
Warning and Caution Icons
WARNING:
Avoid personal injury and product damage! Do not proceed beyond any icon
until you fully understand the indicated conditions.
The following icons alert you to important information about the safe operation of this
product:
You will find this icon in the literature that accompanies this product. This icon
indicates important operating or maintenance instructions.
You may find this icon affixed to this product and in this document to alert you of
electrical safety hazards. On this product, this icon indicates a live terminal; the
arrowhead points to the terminal device.
You may find this icon affixed to this product. This icon indicates a protective earth
terminal.
You may find this icon affixed to this product. This icon indicates excessive or
dangerous heat.
You may find this symbol affixed to this product and in this document. This symbol
indicates an infrared laser that transmits intensity-modulated light and emits
invisible laser radiation and an LED that transmits intensity-modulated light.
HeedAll Warnings
Adhere to all warnings on the product and in the operating instructions.
Avoid Electric Shock
Follow the instructions in this warning.
WARNING:
To reduce risk of electric shock, perform only the instructions that are
included in the operating instructions. Refer all servicing to qualified service
personnel.

Safety Precautions
viii 78-717866-01 Rev D
Servicing
WARNING:
Avoid electric shock! Opening or removing the cover may expose you to
dangerous voltages.
Do not open the cover of this product and attempt service unless instructed to do so in the
operating instructions. Refer all servicing to qualified personnel only.
Cleaning, Water, Moisture, Open Flame
To protect this product against damage from moisture and open flames, do the following:
Before cleaning, unplug this product from the AC outlet. Do not use liquid or aerosol
cleaners. Use a dry cloth for cleaning.
Do not expose this product to moisture.
Do not place this product on a wet surface or spill liquids on or near this product.
Do not place or use candles or other open flames near or on this product.
Ventilation
To protect this product against damage from overheating, do the following:
This product has openings for ventilation to protect it from overheating. To ensure
product reliability, do not block or cover these openings.
Do not open this product unless otherwise instructed to do so.
Do not push objects through openings in the product or enclosure.
Placement
To protect this product against damage from breakage, do the following:
Place this product close enough to a mains AC outlet to accommodate the length of the
product power cord.
Route all power supply cords so that people cannot walk on, or place objects on, or lean
objects against them. This can pinch or damage the cords. Pay particular attention to
cords at plugs, outlets, and the points where the cords exit the product.
Make sure the mounting surface or rack is stable and can support the size and weight of
this product.
WARNING:
Avoid personal injury and damage to this product! An unstable surface may
cause this product to fall.

Safety Precautions
78-717866-01 Rev D ix
When moving a cart that contains this product, check for any of the following possible
hazards:
Move the cart slowly and carefully. If the cart does not move easily, this condition may
indicate obstructions or cables that you may need to disconnect before moving this cart
to another location.
Avoid quick stops and starts when moving the cart.
Check for uneven floor surfaces such as cracks or cables and cords.
WARNING:
Avoid personal injury and damage to this product! Move any appliance and
cart combination with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart to overturn.
Fuse
When replacing a fuse, heed the following warnings.
WARNING:
Avoid electric shock! Always disconnect all power cables before you change a
fuse.
WARNING:
Avoid product damage! Always use a fuse that has the correct type and rating.
The correct type and rating are indicated on this product.
Grounding This Product (U.S.A. and Canada Only)
Safety Plugs
If this product is equipped with either a three-prong (grounding pin) safety plug or a two-
prong (polarized) safety plug, do not defeat the safety purpose of the polarized or
grounding-type plug. Follow these safety guidelines to properly ground this product:
For a 3-prong plug (consists of two blades and a third grounding prong), insert the plug
into a grounded mains, 3-prong outlet.
Note: This plug fits only one way. The grounding prong is provided for your safety. If
you are unable to insert this plug fully into the outlet, contact your electrician to replace
your obsolete outlet.
For a 2-prong plug (consists of one wide blade and one narrow blade), insert the plug
into a polarized mains, 2-prong outlet in which one socket is wider than the other.
Note: If you are unable to insert this plug fully into the outlet, try reversing the plug. The
wide blade is provided for your safety. If the plug still fails to fit, contact an electrician to
replace your obsolete outlet.

Safety Precautions
x 78-717866-01 Rev D
Grounding Terminal
If this product is equipped with an external grounding terminal, attach one end of an 18-
gauge wire (or larger) to the grounding terminal; then, attach the other end of the wire to an
earth ground, such as an equipment rack that is grounded.
20050727 Headend/Rack

FCC Compliance
78-717866-01 Rev D xi
FCC Compliance
Where this equipment is subject to U.S.A. FCC and/or Industry Canada rules, the following
statements apply.
United States FCC Compliance
This device has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against such interference when this equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy, and if not installed
and used in accordance with the instruction manual may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case users will be required to correct the interference at their own
expense.
Canada EMI Regulation
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class A est conforme à la norme NMB-003 du Canada.
20061110 FCC HE

About This Guide
78-717866-01 Rev D xiii
About This Guide
Introduction
This guide describes the following Multiple Quadrature Amplitude Modulation
(MQAM) modulator models and includes installation and operation procedures.
Model D9477-1 120 V AC (part number 592800)
Model D9477-2 48 V DC (part number 714330)
Model D9477-3 230 V AC (part number 4000833)
Scope
This guide includes the following topics:
Descriptions of MQAM modulator functions
Descriptions of MQAM modulator components
Installation procedures
Operation procedures
Troubleshooting guidelines
Customer support information
MQAM modulator technical specifications for installation
Audience
This guide is written for the system administrator of the Digital Broadband Delivery
System (DBDS), operators of the Digital Network Control System (DNCS), call center
personnel, and system operators who are responsible for installing and operating the
MQAM modulator.

About This Guide
xiv 78-717866-01 Rev D
Related Publications
You may find the following publications useful as resources when you implement
the procedures in this document.
DBDS Utilities Version 5.1 Installation Instructions and DNCS Utilities User’s Guide
(part number 740020)
DBDS Utilities Version 6.1 Installation Instructions and DNCS Utilities User’s Guide
(part number 4020695)
MQAM Modulator Software Version 2.4.10 Release Notes and Installation Instructions
(part number 732583)
MQAM Software Version 2.6.10 Release Notes and Installation Instructions (part
number 745250)
For more information, refer to the following publication: ITU-T Recommendation J.83.
April 1997. Digital multi-programme systems for television, sound and data services for
cable distribution. Telecommunication Standardization Sector of the International
Telecommunication Union, available from the ITU.
Document Version
This is the fourth release of this guide. In addition to minor text and graphic
changes, the following table provides the technical changes to this guide.
Description See Topic
Updated all safety information Throughout document
Removed all references to locking the
MQAM front panel
Throughout document

78-717866-01 Rev D 1
Introduction
This chapter illustrates how the Multiple Amplitude Modulation modulator
(MQAM) functions within the Digital Broadband Delivery System (DBDS),
describes MQAM processing, and describes the front and back panel of the
MQAM.
1Chapter 1
Introducing the MQAM
In This Chapter
System Overview.................................................................................... 2
Input/Output Process............................................................................ 4
Front Panel Overview ............................................................................ 7
 Back Panel Overview ............................................................................. 9

Chapter 1 Introducing the MQAM
2 78-717866-01 Rev D
System Overview
The MQAM delivers compressed and encoded, multi-program Moving Picture
Expert Group (MPEG) transport streams of interleaved voice, video, and data in the
RF spectrum to Digital Home Communications Terminals (DHCTs). The MQAM
performs the following functions within the DBDS:
Uses two ASI inputs to allow:
-MPEG stream multiplexing of two MPEG data sources
-Use of the second input as a redundant port
Allows direct input from a variety of MPEG data sources at various rates, such as
video-on-demand (VOD) servers, SONET-to-ASI converters, Grooming BIGs,
and Multiple Decryption Receivers (MDR)
Processes an MPEG transport stream (TS) at various rates
Allows Stream Encryption and Management
Contains four, independent RF Output channels, allowing the MQAM to use
only one unit of rack space for the MQAM hardware and one unit of rack space
for ventilation while replacing the RF output capabilities of four D9476 QAM
Modulators
Features
The MQAM provides many digital broadcast features and innovations for your
system. The following table describes these features and innovations.
Feature Function
Dual ASI Inputs Supports maximum ASI data rate at both inputs (216 Mbps
each)
Multiplexing
Functionality
Program and Packet Identifier (PID) remapping and filtering
Full routability of MPEG programs. The MQAM can route any
MPEG program from both of its inputs to any combination of
outputs.
Single programs can be sent to any combination of the four RF
outputs simultaneously (multicast).

System Overview
78-717866-01 Rev D 3
Feature Function
MPEG Stream
Management
Program Clock Reference Timestamp Correction
Program Specific Information Reconstruction
MPEG Packet Insertion: System Information (SI), Entitlement
Control Messages (ECMs), Program Map Tables (PMTs)
Transport Stream Monitoring

Adaptive Insertion Rate Control
Stream Encryption,
Conditional Access,
and Management
Encryption Mode: PowerKEY® Conditional Access
PowerKEY Book One ECM Handling

Supports broadcast clear-to-air and encrypted PowerKEY data
Four 16/64/256-QAM
RF Output Channels
Separate physical connector for each output
Independent control of frequency and level
Electronically tunable output center frequency range of 91 to
867 MHz ITU-T J.83 Annex-A and Annex-B standards
RF output level monitor
Switched filter bank for superior broadband combined noise
performance
Spectral Inversion can be turned on or off
Variable Symbol Rate can be set for ITU-T J.83 Annex-A
(DVB/DAVIC) modulation modes

Chapter 1 Introducing the MQAM
4 78-717866-01 Rev D
Input/Output Process
This section describes how the MQAMs modulate, encrypt, and transmit the signals
they receive from external sources.
Back Panel Components
The following table describes the back panel components.
Item Component Description
1 AC Unit: AC Power
Inlet
IEC 320-conductor grounded outlet
2 AC Unit: Power
Switch
On/off rocker-type power switch
3 DC Unit: DC Power
Inlet
Two-post terminal block DC power input connection
4 Fuse Holder (AC Unit) 2.0 A SLO BLO 250 V fuse (Cisco part
number 535391, International T2H)
(DC Unit) 2.5 A SLO BLO 250 V fuse (Cisco part
number 184428)
5 Cooling Fan Removes heat from the chassis
6 GND Ground screw for grounding the MQAM
7 RF OUT 4 F-connector for RF output, 75 Ω
8 RF OUT 3 F-connector for RF output, 75 Ω
9 RF OUT 2 F-connector for RF output, 75 Ω
10 RF OUT 1 F-connector for RF output, 75 Ω
11 Cooling Fan Removes heat from the chassis
12 DVB ASI INPUT 1 Female BNC, 75 Ωconnector. Allows for the input of
MPEG 2 TS data at a maximum rate of 216 Mbps
13 DVB ASI INPUT 2 Female BNC, 75 Ωconnector. Allows for the input of
MPEG 2 TS data at a maximum rate of 216 Mbps
14 CA SYNC RS-232 connection to a DB-9 9-pin port used for
diagnostics. Can be used either locally or in conjunction
with a VPN
15 10 BASE T Ethernet Port. Shares data with Digital Network Control
System Ethernet hub
