Cisco − WIC−1T One−Port Serial WAN Interface Card Cable Specifications
i

WIC−1T One−Port Serial WAN Interface Card Cable
Specifications
Document ID: 46793
Introduction
Prerequisites
Requirements
Components Used
Conventions
Overview
Cisco 5−in−1 Cables
Related Information
Introduction
This document provides cable specifications for the WIC−1T one−port WAN interface card.
Prerequisites
Requirements
There are no specific requirements for this document.
Components Used
This document is not restricted to specific software and hardware versions.
The information in this document was created from the devices in a specific lab environment. All of the
devices used in this document started with a cleared (default) configuration. If your network is live, make sure
that you understand the potential impact of any command.
Conventions
For more information on document conventions, see the Cisco Technical Tips Conventions.
Overview
The WIC−1T features the Cisco 5−in−1 connector which supports several serial protocols (V.35, X.21,
RS−232, RS−449, RS−530) when used with the appropriate transition cable. This facilitates easy
configuration and re−configuration as network requirements change without the need to purchase a different
serial interface card.
Cisco − WIC−1T One−Port Serial WAN Interface Card Cable Specifications

Note: When used in Cisco 1720 and 1600 Series Routers, the WIC−1T may also be operated in asynchronous
mode. The WIC−1T is not supported in asynchronous mode when used in Cisco 2600 and 3600 Series
Routers.
Cisco 5−in−1 Cables
Cisco 5−in−1 (DB−60 pin) cable support includes the following:
CAB−V35 MT/FC• CAB−232 MT/FC• CAB−449 MT/FC• CAB−X21 MT/FC• CAB−530 MT•
Related Information
Technical Support − Cisco Systems•
All contents are Copyright © 1992−2005 Cisco Systems, Inc. All rights reserved. Important Notices and Privacy Statement.
Updated: Jun 26, 2005 Document ID: 46793
