Cisco ASR 9000 Series User manual

Replacing Cisco ASR 9000 Series Router
Components
The router is equipped as ordered and is ready for installation and startup when it is shipped. As network
requirements change, you may need to upgrade the system by adding or changing components. This chapter
describes how to maintain router components.
•Prerequisites and Preparation, on page 1
•Replacing the Chassis Air Filter, on page 4
•Removing and Replacing the Fan Trays, on page 10
•Removing and Replacing Power System Components, on page 12
•Removing and Replacing Cards from the Chassis, on page 25
•Migrating from RP1 to RP2 Card, on page 27
•Migrating from RP2 to RP3 Card, on page 30
•Migrating from RSP440 to RSP880 or RSP880-LT Card , on page 33
•Migrating from RSP4-S to RSP880-LT Card (ASR 9906 Router), on page 36
•Migrating from RSP4/RSP4-S/RSP-L to RSP5 Card, on page 38
•Migrating from FC1 to FC2 Card, on page 41
•Migrating from A99-SFC2 to A99-SFC3 Card, on page 41
•Migrating from A99-SFC-S/A99-SFC-T to A99-SFC3-S/A99-SFC3-T Card, on page 42
•Removing a Chassis from the Equipment Rack, on page 43
•Installing a Replacement Chassis in the Equipment Rack, on page 44
•Packing a Chassis for Shipment, on page 44
Prerequisites and Preparation
Before you perform any of the procedures in this chapter, be sure that you:
• Review the b-asr9k-hardware-installation-guide_chapter1.pdf#nameddest=unique_8.
• Read the safety and ESD-prevention guidelines described in b-asr9k-hardware-installation-guide_
chapter1.pdf#nameddest=unique_10.
• Ensure that you have all the necessary tools and equipment before beginning the procedure.
Have access to the safety and compliance document during the installation, see:
http://www.cisco.com/en/US/docs/routers/asr9000/hardware/rcsi/regulatory/compliance/asr9krcsi.html
Replacing Cisco ASR 9000 Series Router Components
1

Field Replaceable Units
In the Cisco ASR 9006 Router, Cisco ASR 9010 Router, and Cisco ASR 9904 Router, the following components
are field replaceable units (FRU):
• All line cards
• RSP cards
• Power modules
• Fan trays
• Air filters
• Line card and RSP blank fillers
• Compact flash disk
• Gigabit Ethernet small form-factor pluggable (SFP) transceiver modules
• 10-Gigabit Ethernet small form-factor pluggable (SFP+) transceiver modules
• 10-Gigabit Ethernet small form-factor pluggable (XFP) transceiver modules
• Optional card cage doors (Cisco ASR 9010 Router only)
The backplane is not field-replaceable.
Note
In the Cisco ASR 9906 Router, Cisco ASR 9910 Router, Cisco ASR 9912 Router, and Cisco ASR 9922
Router, the following components are FRUs:
• All line cards
• RP cards
• RSP cards (only for Cisco ASR 9906 Router and Cisco ASR 9910 Router)
• Fabric cards
• Power modules
• Fan trays and covers
• Air filters
• Foam media (only for Cisco ASR 9922 Router, Cisco ASR 9912 Router)
• Blank line card fillers
• Gigabit Ethernet small form-factor pluggable (SFP) transceiver modules
• 10-Gigabit Ethernet small form-factor pluggable (SFP+) transceiver modules
• 100-Gigabit Ethernet small form-factor pluggable (CFP) transceiver modules
• Optional card cage doors
Replacing Cisco ASR 9000 Series Router Components
2
Replacing Cisco ASR 9000 Series Router Components
Field Replaceable Units

The backplane, midplane (only for Cisco ASR 9906 Router and Cisco ASR 9910 Router), PEM, and BPID
cards are not FRUs but are field serviceable.
Note
Online Insertion and Removal
Most Cisco ASR 9000 Series Routers FRUs can be removed and replaced with the power on and the system
operating. This is known as online insertion and removal (OIR). Power modules, fan trays, Route Switch
Processor (RSP) cards, Route Processor (RP) cards, Fabric Controller (FC) cards, Line Cards (LCs), shared
port adapter (SPA), and SPA interface processor (SIP) cards all support OIR. Unless otherwise noted, the
maintenance tasks described in this chapter can be performed while the router remains powered on.
Never unplug all the fan trays at the same time.
Caution
Although the power trays are not a true FRU because they do not support OIR, a procedure for replacing the
power trays in Cisco ASR 9000 Series Routers is included in this chapter if a replacement becomes necessary.
Note
OIR Monitoring
The BPID board monitors OIR by counting the number of card insertions for each slot and saving that
information in non-volatile memory. OIR monitoring is done for all fan trays, RSP cards, RP cards, FCs, and
LCs. A card insertion is determined by the CAN Bus Controller (CBC) of the inserted card booting up and
sending a CBC message which is intercepted by the BPID board. Note that a CBC reset or power cycle on a
card will also be interpreted as a card insertion.
A card with an OIR count that exceeds 175 will generate a minor alarm against that slot. If the card OIR count
exceeds 200, a major alarm is generated against that slot. Fan tray insertion counts are not checked against a
threshold. See the Release Notes for Cisco ASR 9000 Series Aggregation Services Routers for Cisco IOS XR
Software Release 3.9.1 for information about CLI commands for obtaining and resetting card insertion data.
Note
Powering Off the Router
Do not turn off the switch on the power tray to remove individual power modules. Power modules support
OIR, so they can be removed and replaced with the power on and the system operating.
Caution
If it becomes necessary to turn all power off to the router, follow these steps:
Replacing Cisco ASR 9000 Series Router Components
3
Replacing Cisco ASR 9000 Series Router Components
Online Insertion and Removal

Procedure
Step 1 Set the power switch on each power tray to the off (0) position.
Step 2 Power off all circuit breakers for the source power lines connected to the power trays.
Step 3 Verify that the Pwr OK indicator on each power module is off.
Step 4 Verify that the OK indicator on the fan tray is off.
Replacing the Chassis Air Filter
The Cisco ASR 9000 Series Routers are equipped with user-replaceable air filters that help prevent dust from
being drawn into the router. One time per month (or more often in dusty environments), examine the air filters
for damage and cleanliness.
In the Cisco ASR 9006 Router, Cisco ASR 9010 Router, Cisco ASR 9904 Router, Cisco ASR 9906 Router,
and Cisco ASR 9910 Router, the chassis air filter is not serviceable. We recommend that you replace the filter
at regular maintenance intervals. The interval may vary between 3 and 12 months depending on the environment.
Note
In the Cisco ASR 9922 Router and Cisco ASR 9912 Router, the three air filters (left, center, and right) contain
foam media which filters the air going into the chassis. The three air filters can be removed from the chassis
so that the foam media (Cisco PIDs 9922-CEN-FLTRMED= and 9922-LR-FLTRMED=) can be replaced on
a regular maintenance interval. The interval may vary between 3 and 12 months depending on the environment.
Note
Damage to the air filter can restrict the airflow, cause overheating in the router, and degrade electromagnetic
interference (EMI) compliance. Be careful when cleaning and replacing the filter.
Caution
This table describes the air filter locations for the Cisco ASR 9000 Series Routers.
Table 1: Air Filter Locations for the Cisco ASR 9000 Series Routers
Air Filter LocationRouter
Located underneath the fan trays.Cisco ASR 9010 Router
Located along the right side of the chassis and is accessible from the rear.Cisco ASR 9006 Router
Single air filter located along the right side of the chassis and is accessible from
the rear.
Cisco ASR 9904 Router
Located underneath the card cage.Cisco ASR 9910 Router
Located underneath the card cage.Cisco ASR 9906 Router
Replacing Cisco ASR 9000 Series Router Components
4
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Air Filter LocationRouter
Three air filters located on the front of the middle card cage (Figure 5: Cisco
ASR 9922 Router Chassis Air Filters, on page 7).
Cisco ASR 9922 Router
Three air filters on the front of the RP and FC card cage (Figure 7: Cisco ASR
9912 Router Chassis Air Filter , on page 8).
Cisco ASR 9912 Router
Follow these steps to replace an air filter:
Procedure
Step 1 For the Cisco ASR 9006 Router, Cisco ASR 9010 Router, Cisco ASR 9904 Router, Cisco ASR 9906 Router,
and Cisco ASR 9910 Router, choose the procedure for your router:
• For the Cisco ASR 9010 Router, Cisco ASR 9906 Router, and Cisco ASR 9910 Router, remove the air
filter by simply sliding it out of the chassis.
If the accessory grill has been installed on the front of the Cisco ASR 9010 Router, remove it
from the front of the chassis by simply pulling on the grill until it comes loose. See the Installing
Base Chassis Accessories on the Cisco ASR 9010 Router, and Figure 2 for information about
the accessory grill.
Note
Figure 1: Replacing the Cisco ASR 9010 Router Chassis Air Filter
Replacing Cisco ASR 9000 Series Router Components
5
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Figure 2: Replacing the Cisco ASR 9906 Router Chassis Air Filter
• For the Cisco ASR 9006 Router and Cisco ASR 9904 Router, loosen the thumb screw that secures the
filter to the chassis, and then slide the air filter out of the chassis.
Figure 3: Replacing the Cisco ASR 9006 Router Chassis Air Filter
Thumb screw2Air filter1
Replacing Cisco ASR 9000 Series Router Components
6
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Figure 4: Replacing the Cisco ASR 9904 Router Chassis Air Filter
Thumb screw2Air filter1
Step 2 For the Cisco ASR 9922 Router and Cisco ASR 9912 Router, remove the three air filters by pulling them off
the front of the chassis (Cisco ASR 9922 Router Chassis Air Filters) and (Cisco ASR 9912 Router Chassis
Air Filter ). Then, for each filter, loosen the thumb screws, rotate the inner frame out, and replace the foam
media (Removing the Cisco ASR 9922 Router Chassis Center Air Filter—Version 1 and Removing the Cisco
ASR 9922 Router Chassis Side Air Filter —Versions 1 and 2).
In the Cisco ASR 9922 Router (version 2 air filter) the center air filter, shown in Cisco ASR 9922
Router Chassis Center Air Filter—Version 2, does not contain replaceable foam media. The left
and right air filters are the same as version 1 and contain replaceable foam media.
Note
Figure 5: Cisco ASR 9922 Router Chassis Air Filters
Replacing Cisco ASR 9000 Series Router Components
7
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Figure 6: Cisco ASR 9922 Router Chassis Center Air Filter—Version 2
Figure 7: Cisco ASR 9912 Router Chassis Air Filter
Replacing Cisco ASR 9000 Series Router Components
8
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

Figure 8: Removing the Cisco ASR 9922 Router Chassis Center Air Filter—Version 1
Remove foam filter media3Loosen thumb screws1
Rotate and lower inner
frame
2
Figure 9: Removing the Cisco ASR 9922 Router Chassis Side Air Filter —Versions 1 and 2
Remove foam filter media3Loosen thumb screws1
Rotate and lower inner
frame
2
Step 3 Visually check the condition of the air filter and/or its foam media to determine whether to install a new
replacement filter or foam media.
Step 4 Install the new air filter.
• For the Cisco ASR 9010 Router, Cisco ASR 9906 Router, and Cisco ASR 9910 Router, slide the new
air filter into the air filter door (honeycomb side up).
Replacing Cisco ASR 9000 Series Router Components
9
Replacing Cisco ASR 9000 Series Router Components
Replacing the Chassis Air Filter

• For the Cisco ASR 9006 Router and Cisco ASR 9904 Router, tighten the thumb screw to secure the filter
to the chassis.
• For the Cisco ASR 9922 Router (version 1 air filter) and Cisco ASR 9912 Router, tighten the thumb
screws that attach the inner frame to the air filter and re-attach the three air filters to the front of the
chassis. For the Cisco ASR 9922 Router (version 2 air filter) tighten the thumb screws that attach the
inner frame to the left and right air filters only. Attach the new center air filter, with arrows pointing
upwards, and re-attach both side filters to the front of the chassis.
For the version 2 air filter on the Cisco ASR 9922 Router, the center does not have thumb screws
because it does not have replaceable foam media.
Note
Align and seat the door carefully to avoid damaging the EMI-preventive gaskets on the door. The
air filter door must be closed and secured at all times to maintain correct EMI performance.
Caution
Removing and Replacing the Fan Trays
Prerequisites
• For the Cisco ASR 9010 Router remove the accessory grill before removing and replacing the fan trays.
• For the Cisco ASR 9906 Router, Cisco ASR 9922 Router and Cisco ASR 9912 Router, remove the fan
tray cover before removing the fan trays for replacement.
Required Tools and Equipment
• 6-inch long number 2 Phillips screwdriver (torque 10 in-lb)
Removing a Fan Tray
Follow these steps to remove and replace the fan trays:
Never unplug all the fan trays at the same time.
Caution
Be sure that the fans have stopped running before removing the fan tray. The fans can take from 3 to 5 seconds
to completely stop running after disengaging the fan tray latch. Handling the fan tray before the fans have
stopped running could cause fingertip injury.
Caution
Replacing Cisco ASR 9000 Series Router Components
10
Replacing Cisco ASR 9000 Series Router Components
Removing and Replacing the Fan Trays

Due to air leakage, the chassis should not be operated with any of the fan trays completely missing. Replace
any missing fan tray within five minutes. Any fan tray replacement should be performed when the chassis is
back to room temperature.
Note
If the accessory grill has been installed on the front of the Cisco ASR 9010 Router, you must remove it before
you can remove the lower fan tray. You can remove the accessory grill by simply pulling on the grill until it
comes loose. See Installing Base Chassis Accessories on the Cisco ASR 9010 Router, and Figure 2 for
information about the accessory grill.
Note
If the fan tray cover has been installed on the front of the Cisco ASR 9922 Router or Cisco ASR 9912 Router,
you must remove it before you can remove the fan tray. Remove the fan tray cover by simply pulling on the
cover until it comes loose.
Note
To remove a fan tray from the chassis (see Figure 1,Figure 3,Figure 4, or Figure 1):
Procedure
Step 1 Use the 6-inch long number 2 Phillips screwdriver to loosen the captive screw(s) that secure the fan tray.
Step 2 Use the handle on the fan tray front panel to pull the fan tray halfway out of the module bay.
Step 3 Slide out the fan tray completely from the chassis while supporting it with your other hand.
Use two hands when handling the fan tray. Each Cisco ASR 9010 Router version 1 fan tray weighs
about 16 pounds (7.27 kg). Each Cisco ASR 9910 Router version 1 fan tray weighs about 26.55
pounds (12.04 kg). Each Cisco ASR 9906 Router fan tray weighs about 8.0 pounds (3.63 kg). Each
Cisco ASR 9922 Router fan tray or Cisco ASR 9010 Router version 2 fan tray weighs about 18
pounds (8.18 kg).
Caution
Installing a Fan Tray
If you are upgrading a fan tray, follow these guidelines:
• Remove and install fan trays one at a time.
• Perform FPD upgrade on the fan tray. Refer to the "Upgrading Field-Programmable Devices" chapter
in the System Management Configuration Guide for Cisco ASR 9000 Series Routers.
Note
To install a fan tray into the chassis:
Replacing Cisco ASR 9000 Series Router Components
11
Replacing Cisco ASR 9000 Series Router Components
Installing a Fan Tray

Procedure
Step 1 Lift the fan tray (with two hands) and slide it halfway into the module bay.
Step 2 Slowly push the fan tray into the chassis until it mates with the backplane connector at the back of the module
bay.
To prevent damage to the connectors, do not use excessive force when inserting the fan tray into
the chassis.
Caution
Step 3 Tighten the captive screw(s) on the fan tray using the 6-inch long number 2 Phillips screwdriver to a torque
of 10 +/–1 in-lb to secure it to the chassis.
Step 4 Verify that the (green) OK status indicator on the front of the fan tray goes on. If the OK indicator does not
light, see Troubleshooting the Cooling Subsystem.
Removing and Replacing Power System Components
The Cisco ASR 9000 Series Routers support OIR of power modules. If you are replacing a redundant power
module, you can remove and install the power module while the system remains powered on without causing
an electrical hazard or damage to the system. This feature enables you to replace a power module while the
system maintains all routing information and ensures session preservation.
However, to maintain operational redundancy and proper cooling, and to meet EMI compliance standards,
you must have at least one working power module installed (more than one for a fully configured system).
When you remove a failed power module with the router in operation, perform the replacement as quickly as
possible. Make sure you have the replacement power module ready before beginning the removal and installation
procedure.
For the RSP/RP to communicate properly to a power module in a power tray, input power to at least one of
the power modules in the power tray should be present.
Note
This section contains procedures on how to remove and install AC and DC power modules used in the Cisco
ASR 9000 Series Routers.
Do not turn off the switch on the power tray to remove individual power modules. Power modules support
OIR, so they can be removed and replaced with the power on and the system operating.
Caution
Changing Between Version 1, Version 2, Version 3, AC, and DC Power Modules
The pwrmod_change command is not supported on the Cisco ASR 9912 Router and Cisco ASR 9922 Router.
Note
Follow these steps when changing between version 1, version 2, version 3, AC, and DC power modules:
Replacing Cisco ASR 9000 Series Router Components
12
Replacing Cisco ASR 9000 Series Router Components
Removing and Replacing Power System Components

Procedure
Step 1 Before making any physical changes, check the software configuration to ensure no ROMMON variable
CHASSIS_TYPE (such as CHASSIS_TYPE=10_SLOT) is set to override the chassis type.
Step 2 At the Cisco IOS-XR command prompt on the RSP console, run the pwrmod_change command. This
command displays the current power module and system information.
Example:
RP/0/RSP0/CPU0:RO9_P2RSP3# run
Wed Jul 4 20:18:58.034 UTC
#pwrmod_change
Current system:
power supply type : AC power supply version 2
chassis type : 10-slot
chassis bpid: 0x2fa, PID: ASR-9010-AC
UDI name: ASR-9010 AC, UDI desc: ASR-9010 AC
Step 3 Enter your new power module type.
Example:
Please enter the number that corresponds to the power supply type that is being migrated
to. Do not enter the current power system information, use the future power system type.
1) AC power supply version 1, fits 3 across in single power shelf
2) DC power supply version 1, fits 3 across in single power shelf
3) AC power supply version 2, fits 4 across in single power shelf
4) DC power supply version 2, fits 4 across in single power shelf
5) AC power supply version 3, fits 3 across in single power shelf
6) DC power supply version 3, fits 4 across in single power shelf
ATTENTION: You are about to commit a change in the power system type for the chassis.
Please confirm that the OLD and NEW power system information listed here is correct.
Once the system software change is committed, you must physically remove the OLD power
system and replace it with the NEW power system of the type specified below here. Any
mismatch between the programmed system value and the actual physical installation may
cause boot and power management issues in the system.
OLD POWER SYSTEM:
power supply type: AC power supply version 2
chassis type: 10-slot
chassis bpid: 0x2fa, PID: ASR-9010-AC
UDI name: ASR-9010 AC, UDI desc: ASR-9010 AC
NEW POWER SYSTEM:
power supply type: DC power supply version 2
chassis type: 10-slot
chassis bpid: 0x2fa, PID: ASR-9010-DC
UDI name: ASR-9010 DC, UDI desc: ASR-9010 DC
Step 4 Confirm your choice.
Example:
Please confirm that you wish to upgrade from AC power supply version 2 power system to
DC power supply version 2 power system by typing "yes" at the prompt below. Any other
response will cancel the power system change operation [yes/cancel]?
yes
Step 5 After the success message appears, power down the chassis.
Replacing Cisco ASR 9000 Series Router Components
13
Replacing Cisco ASR 9000 Series Router Components
Changing Between Version 1, Version 2, Version 3, AC, and DC Power Modules

Example:
start update CBC eeprom, offset = 0x0,length=1000
..............................................................
done update CBC eeprom
start update I2C eeprom
...............................................................
done update I2C eeprom
The power system programming change is complete. The system must now be completely powered
down, and the NEW power system hardware installed. When the system is rebooted the software
will recognize the new power system. Please power down the system at this point.
#
Step 6 Remove the old power module (see Removing a Version 1 AC or DC Power Module, on page 14 or Removing
a Version 2 or Version 3 AC or DC Power Module).
Use two hands to remove the power module. The power supply weighs about 6.5 pounds (2.95 kg).
Caution
Step 7 Install the new power module (see Installing a Version 1 AC or DC Power Module, on page 16 or Installing
a Version 2 or Version 3 AC or DC Power Module, on page 16).
To prevent damage to the power tray backplane connector, do not use excessive force when inserting
the power module into the power tray.
Caution
Step 8 Power up the chassis.
Step 9 Verify that the (green) Power Input indicator on the front of the power module goes on. If the indicator does
not light, see Troubleshooting the Power Subsystem .
Removing a Version 1 AC or DC Power Module
Follow these steps to remove a version 1 AC or DC power module from the power tray (figure below).
Procedure
Step 1 Push the door latch to the left to release the door.
Step 2 Pivot the door to the right to eject the power module from its bay.
Step 3 Slide the power module out of its bay while supporting it with your other hand.
Use two hands to remove the power module. The power supply weighs about 6.5 pounds (2.95 kg).
Caution
Replacing Cisco ASR 9000 Series Router Components
14
Replacing Cisco ASR 9000 Series Router Components
Removing a Version 1 AC or DC Power Module

Figure 10: Removing or Installing a Version 1 AC or DC Power Module
Removing a Version 2 or Version 3 AC or DC Power Module
Follow these steps to remove a version 2 or version 3 AC or DC power module from the chassis (see figure
titled Removing or Installing a Version 2 or Version 3 AC or DC Power Module). The Cisco ASR 9904 Router
chassis only has one power tray as shown in the figure titled Removing or Installing a Version 2 AC or DC
Power Module from the Cisco ASR 9904 Router .
Procedure
Step 1 Pull the handle down.
Unscrew the screw that secures the power module using a 7/16 hex socket and torque wrench with
the torque set to 50 in-lb.
Note
Step 2 Slide the power module out of its bay while supporting it with your other hand.
Figure 11: Removing or Installing a Version 2 or Version 3 AC or DC Power Module
Replacing Cisco ASR 9000 Series Router Components
15
Replacing Cisco ASR 9000 Series Router Components
Removing a Version 2 or Version 3 AC or DC Power Module

Figure 12: Removing or Installing a Version 2 AC or DC Power Module from the Cisco ASR 9904 Router
Installing a Version 1 AC or DC Power Module
Follow these steps to install a new version 1 AC or DC power module (Figure 10: Removing or Installing a
Version 1 AC or DC Power Module, on page 15):
Procedure
Step 1 Slide the power module into the bay until it mates with its backplane connector.
Step 2 Pivot the door to the left until the door latch locks.
To prevent damage to the power tray backplane connector, do not use excessive force when inserting
the power module into the power tray.
Caution
Step 3 Verify that the (green) Power Input indicator on the front of the power module goes on. If the indicator does
not light, see Troubleshooting the Power Subsystem .
Installing a Version 2 or Version 3 AC or DC Power Module
Follow these steps to install a new version 2 or version 3 AC or DC power module (Figure 11: Removing or
Installing a Version 2 or Version 3 AC or DC Power Module, on page 15):
Replacing Cisco ASR 9000 Series Router Components
16
Replacing Cisco ASR 9000 Series Router Components
Installing a Version 1 AC or DC Power Module

Procedure
Step 1 Slide the power module into the bay until it mates with its backplane connector.
Step 2 Move the handle up.
Step 3 Tighten the screw that secures the power module using a 7/16 hex socket and torque wrench with the torque
set to 50 in-lb.
To prevent damage to the power tray backplane connector, do not use excessive force when inserting
the power module into the power tray.
Caution
Step 4 Verify that the (green) Power Input indicator on the front of the power module goes on. If the indicator does
not light, see Troubleshooting the Power Subsystem.
Disconnecting AC Power
Follow these steps to disconnect an individual AC power cord:
Procedure
Step 1 Power OFF (0) the circuit breaker assigned to the AC power source you are disconnecting.
Step 2 Loosen the retainer bracket holding the AC power cord to the power tray receptacle.
Step 3 Unplug the AC power cord from the power tray receptacle.
Do not turn off the switch on the power tray to remove AC power cords. An individual AC power
cord can be unplugged while the system is powered from other AC power sources.
Caution
Disconnecting AC Power
If it becomes necessary to disconnect all AC power from the router, follow these steps:
Procedure
Step 1 Set the power switch at the rear of the Version 1 AC power tray to the OFF (0) position. For Version 2 and
Version 3 AC power trays, set the power switch at the front of the to the OFF (0) position.
Do not disconnect all power from the router to replace components, including power modules. See
Removing and Replacing Power System Components, on page 12.
Caution
Step 2 Power OFF (0) the circuit breakers assigned to the AC power sources you are disconnecting.
To ensure that power remains off while you are performing this procedure, lock-out/tag-out the
circuit breaker switch in the OFF (0) position until you are ready to turn it on.
Caution
Replacing Cisco ASR 9000 Series Router Components
17
Replacing Cisco ASR 9000 Series Router Components
Disconnecting AC Power

Step 3 Loosen the retainer bracket holding the AC power cords to the power tray receptacle.
Step 4 Unplug the AC power cords from the power tray receptacles.
Reconnecting AC Power
Follow these steps to reconnect an individual AC power cord to a power tray:
Procedure
Step 1 Power OFF (0) the circuit breaker assigned to the AC power source you are reconnecting.
Step 2 Plug the AC power cord into the power tray receptacle.
Step 3 Close and tighten the retainer bracket holding the AC power cord to the power tray receptacle.
Step 4 Power on the AC power source circuit breaker.
Do not turn off the switch on the power tray to reconnect AC power cords. An individual AC power
cord can be plugged in while the system is powered from other AC power sources.
Caution
Reconnecting AC Power
If power has been totally disconnected from the router, follow these steps to reconnect AC power to the AC
power tray:
Procedure
Step 1 Verify that the power switch at the rear of the Version 1 AC power tray is set to the OFF (0) position. For
Version 2 and Version 3 AC power trays, verify that the power switch at the front of the power tray set to the
OFF (0) position.
Step 2 Check that the circuit breaker assigned to the AC power source you are connecting is set to OFF (0).
To ensure that power remains off while you are performing this procedure, lock-out/tag-out the
circuit breaker switch in the OFF (0) position until you are ready to turn it on.
Caution
Step 3 Plug the AC power cords into the power tray receptacle (Figure 1).
Step 4 Close the retainer bracket to secure the AC power cord plug to the power tray receptacle.
Step 5 Power on the AC power source circuit breaker.
Step 6 Set the power switch at the rear of the AC power tray to the ON (1) position.
The following procedure is only to be used when reconnecting power to all power trays in a system
that has been powered down completely.
Caution
Replacing Cisco ASR 9000 Series Router Components
18
Replacing Cisco ASR 9000 Series Router Components
Reconnecting AC Power

Disconnecting DC Power
Follow these steps to disconnect an individual DC power source from a power tray (Figure 2 for version 1
DC power, Figure 3 for version 2 DC power, or Figure 3 for version 3 DC power):
Procedure
Step 1 Power off the circuit breaker assigned to the DC power source you are disconnecting.
To ensure that power remains off while you are performing this procedure, lock-out/tag-out the
circuit breaker switch in the STANDBY (0) position until you are ready to turn it on.
Caution
Step 2 Remove the clear plastic safety covers that fit over the DC power connection terminal studs.
To prevent injury and damage to the equipment, always remove the source DC power cables and
ground from the power tray terminals in the following order : (1) negative (–), (2) positive (+), (3)
ground.
Caution
Step 3 Disconnect the DC power cables from their terminals in the following order and note the color of each cable
(Figure 2 for version 1 DC power, Figure 3 for version 2 DC power, or Figure 3 for version 3 DC power):
a) Negative (PWR) cables first.
b) Positive (RTN) cables next.
c) Ground cable last.
Step 4 Repeat Step 1 through Step 3 for the other power tray, if installed.
It is not necessary to disconnect all power from the router to replace components, including power
modules. See Removing and Replacing Power System Components, on page 12.
Caution
Disconnecting DC Power
If it becomes necessary to disconnect all DC power from the router, follow these steps (Figure 2 for version
1 DC power, Figure 3 for version 2 DC power, or Figure 3 for version 3 DC power):
Procedure
Step 1 Set the power tray switch to the STANDBY (0) position.
Step 2 Power OFF (0) the circuit breaker assigned to the DC power source you are disconnecting.
To ensure that power remains off while you are performing this procedure, lock-out/tag-out the
circuit breaker switch in the OFF (0) position until you are ready to turn it on.
Caution
Step 3 Remove the clear plastic safety covers that fit over the DC power connection terminal studs.
To prevent injury and damage to the equipment, always remove the source DC power cables and
ground from the power tray terminals in the following order : (1) negative (–), (2) positive (+), (3)
ground.
Caution
Replacing Cisco ASR 9000 Series Router Components
19
Replacing Cisco ASR 9000 Series Router Components
Disconnecting DC Power

Step 4 Disconnect the DC power cables from their terminals in the following order and note the color of each cable
(Figure 2 for version 1 DC power, Figure 3 for version 2 DC power, or Figure 3 for version 3 DC power):
a) Negative (PWR) cables first.
b) Positive (RTN) cables next.
c) Ground cable last.
Step 5 Repeat Step 1 through Step 4 for the other power tray, if installed.
This procedure describes how to disconnect DC power from all power modules in a single DC
power tray. The procedure is the same for each DC power tray, if more than one is installed.
Note
If only one power tray is installed, performing the following procedure turns off all power to the
router.
Caution
Reconnecting DC Power
Follow these steps to reconnect DC power to a DC power tray:
Procedure
Step 1 Set the power switch to the OFF (0) position.
Step 2 Check that the circuit breaker assigned to the DC power source you are reconnecting is powered OFF (0).
Step 3 Reconnect the DC power cables in the following order:
a) Ground cables first.
b) Positive (RTN) cables next.
c) Negative (PWR) cable last.
d) Repeat Step 1 through Step 3 for the other power tray (Cisco ASR 9010 Router only)
To prevent injury and damage to the equipment, always attach the ground and source DC power
cable lugs to the power tray terminals in the following order: (1) ground to ground, (2) positive
(+) to positive (+), (3) negative (–) to negative (–).
Caution
Do not overtighten the nuts that secure the DC power cables to the power tray terminals. The
nuts should be tightened using the 7/16 hex socket and torque wrench to a torque of 45 to 50
in-lb.
Caution
Step 4 Replace the clear plastic safety covers over the DC power connection terminal studs and tighten the screws.
Step 5 Set the DC power source circuit breaker to ON (1).
Step 6 Set the power tray switch to ON (1).
Use this procedure only when reconnecting power to all power modules in a system that is powered
down completely.
Caution
Replacing Cisco ASR 9000 Series Router Components
20
Replacing Cisco ASR 9000 Series Router Components
Reconnecting DC Power
