Cisco ONS 15454 M12 User manual

Maintaining the ONS 15454 M12 (ANSI and ETSI),
ONS 15454 M2 and ONS 15454 M6 Shelf
This chapter explains how to maintain the ONS 15454 (ANSI and ETSI), ONS 15454 M2 and ONS 15454
M6 shelf installations.
Unless otherwise specified, “ONS 15454” refers to both ANSI and ETSI M12 shelf assemblies.
Note
Due to memory limitations, TCC2/TCC2P cards are not supported as the node controller in multi-shelf
configuration from R10.5.2.6. Hence, it is recommended to use TCC3 card as the node controller in multi-shelf
configuration. However, the TCC2/TCC2P cards can be used as a subtended controller and also in a stand-alone
configuration.
Note
•NTP-G114 Inspect and Replace the Air Filter, on page 1
•NTP-G274 Replace the Air Filter of the ONS 15454 M2 Shelf Assembly, on page 5
•NTP-G262 Replace the Air Filter of the ONS 15454 M6 Shelf Assembly, on page 7
•NTP-G263 Replace the Air Filter of the AC Power Module in the ONS 15454 M6 Shelf Assembly, on
page 10
•NTP-G115 Clean Fiber Connectors, on page 11
•NTP-G40 Replace the Front Door , on page 14
•NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly, on page 16
•NTP-G272 Replace the Fan-Tray Assembly of the ONS 15454 M2 Shelf Assembly, on page 22
•NTP-G260 Replace the Fan-Tray Assembly of the ONS 15454 M6 Shelf Assembly, on page 24
•NTP-G117 Replace the ANSI Shelf Alarm Interface Panel, on page 26
•NTP-G118 Replace the ANSI Shelf Plastic Lower Backplane Cover, on page 29
•NTP-G795 Change System Mode Using LCD, on page 30
NTP-G114 Inspect and Replace the Air Filter
This procedure ensures that the air filter is free from dirt and dust, which allows
optimum air flow and prevents dirt and dust from entering the shelf.
Purpose
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
1

New air filter, pinned hex key toolTools/Equipment
NonePrerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Do not reach into a vacant slot or chassis while you install or remove a module or a fan. Exposed circuitry
could constitute an energy hazard. Statement 206
Warning
The air filters are single-use only. They must not be cleaned and reused. This is a Telcordia NEBS requirement,
GR-63-CORE Issue 4.
Note
Air filters must be inspected every month. If they are dirty or clogged with dust, they must be replaced with
a new air filter.
Note
If you install the air filter below 15454E-CC-FTA or 15454-CC-FTA, only filters with part numbers
700-23193-01 and 700-23194-01 can be used in this configuration.
Note
Although the air filter can work with older fan trays if it is installed with either side facing up, it is recommended
that you install it with the metal bracing facing up to preserve the surface of the filter. You must install the
air filter with the metal bracing facing up with 15454E-CC-FTA or 15454-CC-FTA.
Caution
To install the air filter inside the air ramp unit (15454E-AIR-RAMP or 15454-AIR-RAMP), use the ETSI
version of the air filter (15454-FTF2 or 15454E-FTF4).
Note
Procedure
Step 1 If the air filter is installed in the external filter brackets, slide the filter out of the brackets while being careful
not to dislodge any dust that might have collected on the filter and proceed to Step 8. Figure 1: ANSI Shelf
Fan-Tray Air Filter in an External Filter Bracket (Front Door Removed), on page 3 shows the fan-tray air
filter in an external filter bracket on an ANSI shelf. Figure 2: ETSI Shelf Fan-Tray Air Filter in an External
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
2
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G114 Inspect and Replace the Air Filter

Filter Bracket (Front Door Removed), on page 4 shows the fan-tray air filter in an external filter bracket on
an ETSI shelf.
Step 2 If the filter is installed below the fan tray and not in the external filter brackets, open the front door of the
shelf assembly. If the front door is already open, proceed to Step 3.
a) Open the front door lock.
The ONS 15454 comes with a pinned hex key for locking and unlocking the front door. Turn the key
counterclockwise to unlock the door and clockwise to lock it.
b) Press the door button to release the latch.
c) Swing the door open.
Step 3 (Optional) Remove the front door using the DLP-G10 Remove the Front Door. If you do not want to remove
the door or it is already removed, proceed to Step 4.
Figure 1: ANSI Shelf Fan-Tray Air Filter in an External Filter Bracket (Front Door Removed)
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
3
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G114 Inspect and Replace the Air Filter

Figure 2: ETSI Shelf Fan-Tray Air Filter in an External Filter Bracket (Front Door Removed)
Step 4 Push the outer side of the handles on the fan-tray assembly to expose the handles.
Step 5 Pull the handles and slide the fan-tray assembly one half inch (12.7 mm) out of the shelf assembly and wait
until the fans stop.
Step 6 When the fans have stopped, pull the fan-tray assembly completely out of the shelf assembly.
Step 7 Gently remove the air filter from the shelf assembly. Be careful not to dislodge any dust that might have
collected on the filter.
Step 8 Visually inspect the air filter material for dirt and dust.
Step 9 Replace the air filter with a new one if the air filter is dirty or clogged with dust.
Do not leave the fan tray out of the chassis for an extended period of time because excessive heat
can damage the ONS 15454 cards.
Caution
Step 10 Replace the air filter:
a) If the air filter is installed in the external filter brackets, slide the new air filter all the way to the back of
the brackets.
b) If the filter is installed below the fan-tray assembly, slide the new air filter into the recessed compartment
at the bottom of the shelf assembly. Put the front edge of the air filter flush against the front edge of the
recessed compartment. Push the fan tray back into the shelf assembly.
If the fan tray does not slide all the way to the back of the shelf assembly, pull the fan tray out
and readjust the position of the air filter until the fan tray fits correctly.
Caution
On a powered-up ONS 15454, the fans start immediately after the fan-tray assembly is correctly
inserted.
Note
Step 11 To verify that the tray is plugged into the backplane, ensure that the LCD on the front of the fan-tray assembly
is activated and displays node information.
Step 12 Rotate the retractable handles back into their compartments.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
4
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G114 Inspect and Replace the Air Filter

Step 13 If you removed the door, complete the NTP-G40 Replace the Front Door , on page 14. If not, close and lock
the door.
Stop. You have completed this procedure.
NTP-G274 Replace the Air Filter of the ONS 15454 M2 Shelf
Assembly
This procedure replaces the air filter of the ONS 15454 M2 shelf assembly.Purpose
New air filterTools/Equipment
•NTP-G266 Install the ONS 15454 M2 Shelf
• Connect the chassis to the office ground. For detailed instructions on how
to ground the chassis, refer to the Electrostatic Discharge and Grounding
Guide for Cisco CPT and Cisco ONS Platforms.
Prerequisite Procedures
As NeededRequired/As Needed
RemoteOnsite/Remote
Provisioning or higherSecurity Level
The air filters are single-use only. They must not be cleaned and reused. This is a Telcordia NEBS requirement,
GR-63-CORE Issue 4.
Note
Air filters must be inspected every month. If they are dirty or clogged with dust, they must be replaced with
a new air filter.
Note
Procedure
Step 1 Untighten the screw on the air-filter (see the following figure).
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
5
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G274 Replace the Air Filter of the ONS 15454 M2 Shelf Assembly

Figure 3: Replacing the Air Filter
Screw2Air filter1
Step 2 Extract the air filter from the shelf assembly as shown in the following figure.
Figure 4: Replacing the Air Filter
Filter grid2Air filter1
Step 3 Separate the cable guides from the air filter as shown in the following figure.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
6
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G274 Replace the Air Filter of the ONS 15454 M2 Shelf Assembly

Figure 5: Replacing the Air Filter
Step 4 Replace the air filter with a new one if the air filter is dirty or clogged with dust.
Step 5 Attach the cable guide and insert the air filter into the shelf assembly.
The air filter must be inserted with the grid facing the shelf assembly as shown in Figure 5: Replacing
the Air Filter, on page 7.
Note
Step 6 Tighten the screw on the air-filter.
Stop. You have completed this procedure.
NTP-G262 Replace the Air Filter of the ONS 15454 M6 Shelf
Assembly
This procedure replaces the air filter of the ONS 15454 M6 shelf assembly.Purpose
New air filterTools/Equipment
•NTP-G252 Install the ONS 15454 M6 Shelf
• Connect the chassis to the office ground. For detailed instructions on how
to ground the chassis, refer to the Electrostatic Discharge and Grounding
Guide for Cisco CPT and Cisco ONS Platforms .
Prerequisite Procedures
As NeededRequired/As Needed
RemoteOnsite/Remote
Provisioning or higherSecurity Level
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
7
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G262 Replace the Air Filter of the ONS 15454 M6 Shelf Assembly

The air filters are single-use only. They must not be cleaned and reused. This is a Telcordia NEBS requirement,
GR-63-CORE Issue 4.
Note
Air filters must be inspected every month. If they are dirty or clogged with dust, they must be replaced with
a new air filter.
Note
Procedure
Step 1 Open the front door of the shelf assembly (see NTP-G259 Open and Remove the Standard Door of the ONS
15454 M6 Shelf). If the shelf assembly does not have a front door, continue with Step 3.
Step 2 (Optional) Complete the DLP-G577 Remove the Standard Door of the ONS 15454 M6 Shelf to remove the
front door. If you do not want to remove the door, proceed to Step 3.
Step 3 Push the retention feature present on the right side of the shelf assembly to the left side (see the following
figure).
Figure 6: Replacing the Air Filter
Step 4 Extract the air filter from the shelf assembly (see the following figure).
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
8
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G262 Replace the Air Filter of the ONS 15454 M6 Shelf Assembly

Figure 7: Extracting the Air Filter
Step 5 Replace the air filter with a new one if the air filter is dirty or clogged with dust.
Step 6 Insert the air filter into the shelf assembly (see Figure 7: Extracting the Air Filter, on page 9).
The air filter must be inserted with the grid facing the shelf assembly as shown in Figure 7: Extracting
the Air Filter, on page 9.
Note
Step 7 Push the retention feature to the right side (see the following figure).
Figure 8: Replacing the Air Filter
Step 8 Close the front door. If you removed the door, complete the NTP-G258 Install the Standard Door of the ONS
15454 M6 Shelf.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
9
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G262 Replace the Air Filter of the ONS 15454 M6 Shelf Assembly

Stop. You have completed this procedure.
NTP-G263 Replace the Air Filter of the AC Power Module in the
ONS 15454 M6 Shelf Assembly
This procedure replaces the air filter of the AC power module in the ONS 15454
M6 shelf assembly.
Purpose
New air filterTools/Equipment
•NTP-G252 Install the ONS 15454 M6 Shelf
• Connect the chassis to the office ground. For detailed instructions on how
to ground the chassis, refer to the Electrostatic Discharge and Grounding
Guide for Cisco CPT and Cisco ONS Platforms .
•DLP-G569 Install the AC Power Module in the ONS 15454 M6 Shelf
Prerequisite Procedures
As NeededRequired/As Needed
RemoteOnsite/Remote
Provisioning or higherSecurity Level
The air filters are single-use only. They must not be cleaned and reused. This is a Telcordia NEBS requirement,
GR-63-CORE Issue 4.
Note
Air filters must be inspected every month. If they are dirty or clogged with dust, they must be replaced with
a new air filter.
Note
Procedure
Step 1 Open the front door of the shelf assembly (see DLP-G576 Open the Standard Door of the ONS 15454 M6
Shelf). If the shelf assembly does not have a front door, continue with Step 3.
Step 2 (Optional) Complete the DLP-G577 Remove the Standard Door of the ONS 15454 M6 Shelf to remove the
front door. If you do not want to remove the door, proceed to Step 3.
Step 3 Remove the air filter on the AC power module (see Figure 6: Replacing the Air Filter, on page 8).
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
10
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G263 Replace the Air Filter of the AC Power Module in the ONS 15454 M6 Shelf Assembly

Figure 9: Replacing the Air Filter—AC Power Module
Step 4 Replace the air filter with a new one if the air filter is dirty or clogged with dust.
Step 5 Close the front door. If you removed the door, complete the NTP-G258 Install the Standard Door of the ONS
15454 M6 Shelf
Stop. You have completed this procedure.
NTP-G115 Clean Fiber Connectors
This procedure cleans the fiber connectors.Purpose
Inspection microscope
Type A Fiber Optic Connector Cleaner (CLETOP reel)
Optical swab
Optical receiver cleaning stick
Tools/Equipment
NonePrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
11
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G115 Clean Fiber Connectors

NoneSecurity Level
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do
not view directly with optical instruments. Viewing the laser output with certain optical instruments
(for example, eye loupes, magnifiers, and microscopes) within a distance of 100 mm may pose an eye
hazard. Statement 1056
Warning
Procedure
Step 1 Using an inspection microscope, inspect each fiber connector for dirt, cracks, or scratches.
Step 2 Replace any damaged fiber connectors.
Replace all dust caps whenever the equipment is unused for 30 minutes or more.
Note
Step 3 Complete the DLP-G262 Clean Fiber Connectors with CLETOP, on page 13 as necessary.
Step 4 Complete the DLP-G263 Clean the Fiber Adapters, on page 13 as necessary.
To clean multi-fiber optic connectors, complete the DLP-G261 Clean Multi Fiber-Optic Cable
Connectors, on page 12 as necessary.
Note
Stop. You have completed this procedure.
DLP-G261 Clean Multi Fiber-Optic Cable Connectors
This task cleans the multi fiber optic connectorsPurpose
Cleaning Cartridge for multi fiber optic connectorsTools/Equipment
NonePrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into beams
or view directly with optical instruments. Statement 1051
Warning
Procedure
Step 1 Remove the protective cap on the optical fiber cable connector.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
12
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
DLP-G261 Clean Multi Fiber-Optic Cable Connectors

Step 2 Read the manufacturer (cleaning cartridge) instructions to insert the connector into the cleaning cartridge.
Step 3 Slide the lever on the cartridge to swipe the connector surface.
Step 4 Insert the fiber connector into the applicable adapter or attach a dust cap to the fiber connector.
If you must replace a dust cap on a connector, first verify that the dust cap is clean.
Note
Step 5 Return to your originating procedure (NTP).
DLP-G262 Clean Fiber Connectors with CLETOP
This task cleans the fiber connectors with CLETOP.Purpose
Type A Fiber Optic Connector Cleaner (CLETOP reel)
Optical receiver cleaning stick
Tools/Equipment
NonePrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 Remove the dust cap from the fiber connector.
Step 2 Press the lever up to open the shutter door. Each time you press the lever, you expose a clean wiping surface.
Step 3 Insert the connector into the CLETOP cleaning cassette slot, rotate one quarter turn, and gently swipe
downwards.
Step 4 Use an inspection microscope to inspect each fiber connector for dirt, cracks, or scratches. If the connector
is not clean, repeat Steps 1 to 3.
Step 5 Insert the fiber connector into the applicable adapter or attach a dust cap to the fiber connector.
If you must replace a dust cap on a connector, first verify that the dust cap is clean. To clean the
dust cap, wipe the outside of the cap using a dry, lint-free wipe and the inside of the dust cap using
a CLETOP stick swab (14100400).
Note
Step 6 Return to your originating procedure (NTP).
DLP-G263 Clean the Fiber Adapters
This task cleans the fiber adapters.Purpose
CLETOP stick swabTools/Equipment
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
13
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
DLP-G262 Clean Fiber Connectors with CLETOP

NonePrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 Remove the dust plug from the fiber adapter.
Step 2 Insert a CLETOP stick swab (14100400) into the adapter opening and rotate the swab.
Step 3 Place dust plugs on the fiber adapters when not in use.
Step 4 Return to your originating procedure (NTP).
NTP-G40 Replace the Front Door
This procedure replaces the front door and door ground strap after installing cards
and fiber-optic cables.
Purpose
#2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Tools/Equipment
NTP-G259 Open and Remove the Standard Door of the ONS 15454 M6 ShelfPrerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Be careful not to crimp any fiber cables that are connected to the MXP/TXP cards or DWDM cards. Some
might not have the fiber boot attached.
Note
Procedure
Step 1 Insert the front door into the hinges on the shelf assembly.
Step 2 (ANSI only) Attach one end of the ground strap terminal lug (72-3622-01) to the male stud on the inside of
the door. Attach and tighten the #6 Kepnut (49-0600-01) using the open-end wrench.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
14
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G40 Replace the Front Door

Figure 10: Installing the Door Ground Strap Retrofit Kit
Step 3 (ANSI only) Attach the other end of the ground strap to the longer screw on the fiber guide.
a) Attach the lock washer.
b) Attach the terminal lug.
c) Using the open-end wrench, attach and tighten the #4 Kepnut (49-0337-01) on the terminal lug.
To avoid interference with the traffic (line) card, make sure the ground strap is in a flat position
when the door is open. To move the ground strap into a flat position, rotate the terminal lug
counterclockwise before tightening the Kepnut.
Note
Step 4 Replace the left cable-routing channel if it was removed. If not, continue with Step 5.
Step 5 Using a Phillips screwdriver, insert and tighten the screws for the cable-routing channel.
The following figure shows the shelf assembly with the front door and ground strap installed.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
15
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G40 Replace the Front Door

Figure 11: Shelf Assembly with Door Ground Strap Retrofit Kit Installed (ANSI)
Step 6 Swing the door closed and lock the door with the provided pinned-hex key. Turn the key clockwise to lock
the door; counterclockwise to unlock it.
Stop. You have completed this procedure.
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454
Shelf Assembly
This procedure replaces a malfunctioning fan-tray assembly.Purpose
NoneTools/Equipment
NTP-G257 Install the Fan-Tray Assembly in the ONS 15454 M6 ShelfPrerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
16
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly

NoneSecurity Level
The 15454-FTA3 fan-tray assembly can only be installed in ONS 15454 R3.1 and later shelf assemblies
(15454-SA-ANSI, P/N: 800-19857; 15454-SA-HD, P/N: 800-24848). The fan-tray assembly includes a pin
that prevents it from being installed in ONS 15454 shelf assemblies released before ONS 15454 R3.1
(15454-SA-NEBS3E, 15454-SA-NEBS3, and 15454-SA-R1, P/N: 800-07149). Equipment damage can result
from attempting to install the 15454-FTA3 in a incompatible shelf assembly.
Caution
Do not force a fan-tray assembly into place. Doing so can damage the connectors on the fan tray and/or the
connectors on the backplane.
Caution
15454-CC-FTA (ANSI) is compatible with Software R2.2.2 and greater, and shelf assemblies 15454-SA-ANSI
and 15454-SA-HD. 15454E-CC-FTA (ETSI) is compatible with Software R4.0 and greater, and shelf assembly
15454-SA-ETSI.
Caution
As with the FTA3, the 15454E-CC-FTA and 15454-CC-FTA Fan Fail LED on the front of the fan-tray
assembly illuminates when one or more fans fail to indicate that a fan-tray assembly or AIP replacement is
required. But the Fan Fail LED on the 15454E-CC-FTA and 15454-CC-FTA will also illuminate when only
one power source is connected to the chassis, and or any fuse blows. In such conditions, the Fan Alarm is
triggered and the fans run at maximum speed.
Caution
To replace the fan-tray assembly, it is not necessary to move any of the cable management facilities.
Note
Procedure
Step 1 Review Table 1: Incompatibility Alarms for ONS 15454 ANSI , on page 17 (ANSI) or Table 2: Incompatibility
Alarms for ONS 15454 ETSI , on page 18 (ETSI) to ensure that you have compatible components when
replacing the fan-tray assembly. Note the alarms that will be generated when an incompatibility occurs.
If you need to determine the hardware that has been installed on a node, click the Inventory tab in
node view.
Note
Table 1: Incompatibility Alarms for ONS 15454 ANSI
AlarmsEthernet Cards5 10G Cards4 AIP3 Fan Tray2 Shelf Assembly1
Mismatch of equipment attributes
(MEA) on the alarm interface
panel (AIP)
——No fuse——
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
17
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly

None—No2A2ANEBS3E or NEBS3
MEA on 10G—Yes2A2ANEBS3E or NEBS3
None—No5A2ANEBS3E or NEBS3
MEA on 10G—Yes5A2ANEBS3E or NEBS3
None—No2A2AANSI or HD
MEA on fan tray, AIP, and
Ethernet
2.5G compatibleYes2A2AANSI or HD
MEA on fan tray and AIP10G compatibleYes2A2AANSI or HD
NoneEitherNo5A2AANSI or HD
MEA on fan tray and Ethernet2.5G compatibleYes5A2AANSI or HD
MEA on fan tray10G compatibleYes5A2AANSI or HD
MEA on AIPEitherNo2A5AANSI or HD
MEA on AIP and Ethernet2.5G compatibleYes2A5AANSI or HD
MEA on AIP10G compatibleYes2A5AANSI or HD
NoneEitherNo5A5AANSI or HD
NoneEitherYes5A5AANSI or HD
115454-SA-NEBS3E (P/N: 800-07149-xx) or 15454-SA-NEBS3 (P/N: 800-06741-xx) = shelf
assemblies released before ONS 15454 Release 3.115454-SA-ANSI (P/N: 800-19857-01) =
ONS 15454 Release 3.1 and later shelf assembly15454-SA-HD (P/N: 800-24848) = ONS 15454
Release 3.1 and later shelf assembly
25A Fan Tray = 15454-FTA3 (P/N: 800-19858-xx), 15454-FTA3-T (P/N: 800-21448-xx),
15454-CC-FTA (P/N: 800-27558-xx)2A Fan Tray = 15454-FTA2 (P/Ns: 800-07145-xx,
800-07385-xx, 800-19591-xx, 800-19590-xx)
35A AIP (P/N: 73-7665-01), 2A AIP (P/N: 73-5262-01)
410G cards include the XC10G, OC192, and OC48AS.
52.5G compatible indicates cards that are compatible with the XCVT cross-connect card. 10G
compatible indicates cards that are compatible with the XC10G and XC-VXC-10G cross-connect
cards.
Table 2: Incompatibility Alarms for ONS 15454 ETSI
AlarmsEthernet Cards10G Cards8 Fan Tray7 Shelf Assembly 6
None—No2A15454E-SA-ETSI
MEA on 10G—Yes2A15454E-SA-ETSI
None—No2A15454E-SA-ETSI
MEA on 10G—Yes2A15454E-SA-ETSI
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
18
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly

MEA on fan tray—No5A15454E-SA-ETSI
MEA on fan tray and 10G cards—Yes5A15454E-SA-ETSI
None—No5A15454E-SA-ETSI
MEA on 10G—Yes5A15454E-SA-ETSI
None—No2AETSI
MEA on fan tray or Ethernet2.5G compatibleYes2AETSI
MEA on fan tray10G compatibleYes2AETSI
NoneEitherNo2AETSI
MEA on fan tray, Ethernet2.5G compatibleYes2AETSI
MEA on fan tray10G compatibleYes2AETSI
MEA on Ethernet2.5G compatibleYes5AETSI
NoneEitherNo5AETSI
NoneEitherYes5AETSI
615454-SA-ETSI (P/N: 800-08708-XX) = ONS 15454 SDH Release 3.3 and later shelf assembly
75A Fan Tray = 15454E-FTA-60V, 15454E-CC-FTA2A Fan Tray = 15454E-FTA-48V
810G cards = XC10G, XC-VXL-10G, XC-VXC-10G
Step 2 Open the front door of the shelf assembly. If the shelf assembly does not have a front door, continue with
Step 4.
a) Open the front door lock.
The ONS 15454 comes with a pinned hex key for locking and unlocking the front door. Turn the key
counterclockwise to unlock the door and clockwise to lock it.
b) Press the door button to release the latch.
c) Swing the door open.
Step 3 (Optional) Complete the DLP-G577 Remove the Standard Door of the ONS 15454 M6 Shelf to remove the
front door. If you do not want to remove the door, proceed to Step 4.
Step 4 Push the outer side of the handles on the fan-tray assembly to expose the handles.
Step 5 Fold out the retractable handles at the outside edges of the fan tray.
Step 6 Pull the handles and slide the fan-tray assembly one inch (25.4 mm) out of the shelf assembly and wait until
the fans stop.
Step 7 When the fans have stopped, pull the fan-tray assembly completely out of the shelf assembly. The following
figure shows the location of the fan tray on the ONS 15454 ANSI shelf.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
19
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly

Figure 12: Removing or Replacing the Fan-Tray Assembly (Front Door Removed) (ANSI)
The following figure shows the location of the fan tray on the ONS 15454 ETSI shelf.
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
20
Maintaining the ONS 15454 M12 (ANSI and ETSI), ONS 15454 M2 and ONS 15454 M6 Shelf
NTP-G116 Replace the Fan-Tray Assembly of the ONS 15454 Shelf Assembly
