CHAPTER
2-1
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
2
Installing the Cisco ONS 15530
This chapter describes the installation procedures for the Cisco ONS 15530 chassis and its components.
This chapter includes the following sections:
•Before Installing, page 2-1
•Chassis-Lifting Guidelines, page 2-2
•Rack-Mounting the Shelf, page 2-4
•Grounding the Shelf, page 2-14
•Installing and Removing Line Cards or Motherboards, page 2-17
•Installing and Removing Modules, page 2-24
•Replacing the Fan Assembly, page 2-27
•Power Guidelines, page 2-29
•Powering Up the Shelf, page 2-31
Note Before you install, operate, or service the system, read the Regulatory Compliance and Safety
Information for the Cisco ONS 15500 Series for important safety information you should know before
working with the system.
Note To ensure that your Cisco IOS software release supports your hardware, see the “New and Changed
Information” section on page vii. Also refer to the “Hardware Supported” section of the latest release
notes for the Cisco ONS 15530.
Before Installing
Before you install the Cisco ONS 15530, you must complete the following tasks:
•Unpack and inspect the shelf.
•Maintain a network record.
•Assemble required tools and equipment.
•Mount the shelf.

2-2
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Chassis-Lifting Guidelines
Caution Use extreme care when removing or installing connectors so you do not damage the connector housing
or scratch the end-face surface of the fiber. Always install protective covers on unused or disconnected
components to prevent contamination. Always clean fiber connectors before installing them.
Unpacking and Inspecting the Shelf
The Cisco ONS 15530 comes with the standard mounting set. The shelf is thoroughly inspected before
shipment. If any damage has occurred during transportation or if any item is missing, notify your Cisco
customer service representative immediately.
Upon receipt, inspect the equipment as follows:
Step 1 Take inventory.
Compare the equipment inside with the packing slip and the equipment list provided by customer
service. If there are any discrepancies, notify the Customer Service Center.
Step 2 Check for external damage.
Visually check all components and immediately report any shipping damage to your customer service
representative. Have the following information ready:
•Invoice number of shipper (see packing slip)
•Model and serial number of the damaged unit
•Description of damage
•Effect of damage on the installation
Keep a record of all of your hardware, configuration options, and network settings.
Mounting the Shelf
The unit is designed for rack-mounting in a cabinet rack. Use star-type lock washers on the rack screws
to ensure a good conductive connection between the chassis and the rack. For information about
installing the units in a customer cabinet, see the instructions from the cabinet manufacturer.
Chassis-Lifting Guidelines
The fully configured system weighs approximately 71 pounds. The chassis is not intended to be moved
frequently. Before you install the system, ensure that your site is properly prepared so you can avoid
having to move the chassis later to accommodate power sources and network connections.
Two or more people are required to lift the chassis. Each time you lift the chassis or any heavy object,
follow these guidelines:
•Never attempt to lift the chassis by yourself. Because of the size and weight of the chassis, use at
least two people to safely lift and move it without causing injury or damaging the equipment.
•Ensure that your footing is solid, and balance the weight of the chassis between your feet.

2-3
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Chassis-Lifting Guidelines
•Lift the chassis slowly; never move suddenly or twist your body as you lift.
•Keep your back straight and lift with your legs, not your back. If you must bend down to lift the
chassis, bend at the knees, not at the waist, to reduce the strain on your back muscles.
•Do not remove installed components from the chassis.
•Always disconnect all external cables before lifting or moving the chassis.
To safely lift the chassis, follow these steps:
Warning Two people are required to lift the chassis. To prevent injury, keep your back straight and lift with
your legs, not your back.
Step 1 Each person should stand on either side of the chassis, and place one hand under the air intake at the
bottom front of the chassis.
Step 2 With the other hand, grasp the handle on the chassis and carefully lift the chassis as shown in Figure 2-1
and Figure 2-2.
Figure 2-1 Lifting the Cisco ONS 15530 CHAS-E
77694
FASTENERSMUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X

2-4
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Rack-Mounting the Shelf
Figure 2-2 Lifting the Cisco ONS 15530 CHAS-N
Rack-Mounting the Shelf
Rack-mounting the shelf is the preferred method of installation for the Cisco ONS 15530. This section
gives general rack-mount installation guidelines and explains how to install the rack-mount and
cable-management brackets on the Cisco ONS 15530 for the following types of installations:
•General Rack-Mount Installation Guidelines, page 2-5
•Flush-Mounting the Cisco ONS 15530 CHAS-N in a 19-Inch Rack, page 2-5
•Flush-Mounting the Cisco ONS 15530 CHAS-E in a 21-Inch Rack, page 2-7
FASTENERSMUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
77693

2-5
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Rack-Mounting the Shelf
General Rack-Mount Installation Guidelines
When planning your rack-mount installation, consider the following guidelines:
•Allow a minimum of 11 rack units (17.7 inches or 45.0 cm) of vertical rack space for the
Cisco ONS 15530 CHAS-E chassis with the air ramp baffle. The Cisco ONS 15530 CHAS-N
chassis requires a minimum of 9 rack units (15.7 inches or 39.9 cm) of vertical rack space. Measure
the proposed rack location before mounting the chassis in the rack.
Note The Cisco ONS 15530 CHAS-E chassis cannot be installed in a 19-inch rack.
•Check for obstructions (such as a power strip) that could impair rack-mount installation before using
a particular rack. If a power strip does impair a rack-mount installation, remove the power strip
before installing the chassis, and then replace it after the chassis is installed.
•Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it
back near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving
line cards, connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches
(48.3 cm) of clearance to remove FRUs (field replaceable units).
•Maintain a minimum clearance of 3 inches (7.62 cm) on the front, top, and sides of the chassis for
the cooling air inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested
rack or directly next to another equipment rack; otherwise, the heated exhaust air from other
equipment can enter the inlet air vents and cause an over temperature condition inside the chassis.
Caution To prevent chassis overheating, never install a Cisco ONS 15530 in an enclosed rack or room
that is not properly ventilated or air conditioned.
Caution Always install the air ramp baffle below the Cisco ONS 15530 CHAS-E.
•Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to
prevent the rack from falling over.
•Install and use the cable-management brackets included with the Cisco ONS 15530 to keep cables
organized and out of the way of the line cards and CPU switch modules. Ensure that cables from
other equipment already installed in the rack do not impair access to the line cards, or require you
to disconnect cables unnecessarily to perform equipment maintenance or upgrades.
•Install rack stabilizers (if available) before you mount the chassis.
•Provide an adequate chassis ground (earth) connection for your chassis.
Flush-Mounting the Cisco ONS 15530 CHAS-N in a 19-Inch Rack
The Cisco ONS 15530 CHAS-N can be flush-mounted in a 19-inch equipment rack using the
rack-mounting kit provided with your system. The rack-mounting kit contains the following parts:
•Two mounting brackets and screws
•Cable management brackets
•Optional 23-inch rack-mount brackets

2-6
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Rack-Mounting the Shelf
Note The Cisco ONS 15530 CHAS-E chassis cannot be installed in a 19-inch rack.
Warning At least three people are required to mount the chassis in the equipment rack: two people are needed
to hold the chassis in place while a third person tightens the mounting screws. When handling the
chassis,alwaysfollowproperliftingpracticesasoutlinedinthe“Chassis-LiftingGuidelines”section
on page 2-2.
To flush-mount the Cisco ONS 15530 CHAS-N chassis in a 19-inch equipment rack, follow these steps :
Step 1 Attach the mounting brackets to the shelf (see Figure 2-3).
Step 2 Lift the shelf into position between the rack posts (requires two people).
Step 3 Align the mounting bracket holes with the rack post holes (see Figure 2-4) and attach the shelf to the
rack (performed by the third person).
Figure 2-3 Attaching Mounting Brackets to Shelf
15530-FCGE-8P
77898
FASTENERS MUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
0
1
2
3
4
5
6
7
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
FAN
STATUS

2-7
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Rack-Mounting the Shelf
Figure 2-4 Attaching Shelf to Equipment Rack
Step 4 Check that all release levers are in the closed position, the chassis mounting screws are tight, and all
CPU switch module and line card captive screws are tight.
Flush-Mounting the Cisco ONS 15530 CHAS-E in a 21-Inch Rack
The Cisco ONS 15530 CHAS-E can be flush-mounted in a 21-inch equipment rack using the
rack-mounting kit provided with your system. The rack-mounting kit contains the following parts:
•Two mounting brackets and screws
•Cable management brackets
Caution At least three people are required to mount the chassis in the equipment rack: two people are needed to
hold the chassis in place while a third person tightens the mounting screws. When handling the chassis,
always follow proper lifting practices as outlined in the “Chassis-Lifting Guidelines” section on
page 2-2.
77899
FASTENERS MUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
FAN
STATUS

2-8
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Rack-Mounting the Shelf
To flush-mount the Cisco ONS 15530 CHAS-N chassis in a 19-inch equipment rack, use the following
steps:
Step 1 Attach the mounting brackets to the shelf (see Figure 2-5).
Step 2 Lift the shelf into position between the rack posts (requires two people).
Step 3 Align the mounting bracket holes with the rack post holes (see Figure 2-6) and attach the shelf to the
rack (performed by the third person).
Figure 2-5 Attaching Mounting Brackets to Shelf
91396
15530-FCGE-8P
  
  
   

1
3
6












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8





 



1


15530-CP



 



1









15530-CP







E

E












E

E

























0
1

3

5





E

E






2-9
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Rack-Mounting the Shelf
Figure 2-6 Attaching Shelf to Equipment Rack
Step 4 Check that all release levers are in the closed position, the chassis mounting screws are tight, and all
CPU switch module and line card captive screws are tight.
Step 5 Proceed to the “Attaching the Air Ramp Baffle” section on page 2-10.
15530-FCGE-8P
FASTENERS MUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
A
H
GOOD
STATUS










15530-C-000
0
1

3

5


8

STATUS










15530-C-000
0
1

3

5


8

STATUS










15530-C-000
0
1

3

5


8

STATUS










15530-C-000
0
1

3

5


8

STATUS
STATUS
RESET
ATIE
OMPAT
FLASH
IRTIAL
MAOR
FD
MBPS
UTOFF
HIST
LR
15530-CP

RESET
ATIE
OMPAT
FLASH
IRTIAL
MAOR
FD
MBPS
LIN
LIN
AU
ON
ON
UTOFF
HIST
LR
UTOFF
MINOR
15530-CP

AU
ON
STATUS



E

E








STATUS



E

E








STATUS
















0
1

3

5


STATUS


E

E






FAN
STATUS

2-10
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Rack-Mounting the Shelf
Attaching the Air Ramp Baffle
The air ramp baffle redirects the intake of cooling air from directly below, to the front of the
Cisco ONS 15530 CHAS-E chassis, while deflecting hot exhaust air from equipment installed below.
To attach the air ramp baffle to the Cisco ONS 15530 CHAS-E chassis, follow these steps:
Step 1 Attach the mounting brackets to the air ramp baffle as shown in Figure 2-7.
Figure 2-7 Air Ramp Baffle Mounting Brackets
Step 2 Position the air ramp baffle directly under the Cisco ONS 15530 CHAS-E chassis.
Step 3 Screw the air ramp baffle to the equipment rack as shown in Figure 2-8.
79553

2-11
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Rack-Mounting the Shelf
Figure 2-8 Installing the Air Ramp Baffle
79544
15530-FCGE-8P
  
  
  

4
5
5












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8












15530-C-000
0
1

3

5


8





 






15530-CP



 













15530-CP







E

E












E

E

























0
1

3

5





E

E







2-12
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Rack-Mounting the Shelf
Installing the Fiber Routing Management System
The fiber routing management system contains two main components; the cable routing tray and the
cable routing drawer. The fiber routing tray is installed directly over the fan assembly, and the fiber
routing drawer is installed below the Cisco ONS 15530 chassis. (See Figure 2-9.)
Figure 2-9 Fiber Management System
85009
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
15530-CPU
AUX
15530-CPU
AUX

2-13
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Rack-Mounting the Shelf
Installing the Fiber Routing Tray
To install the fiber routing tray, follow these steps:
Step 1 Place the fiber routing tray (2) over the fan assembly, ensuring that the fan assembly can be accessed
when the fiber routing tray is locked (1 and 2) in the raised position. (See Figure 2-10.)
Figure 2-10 Raising the Fiber Routing Tray
Step 2 Secure the fiber routing tray to the rack with four 12-24 screws, two on each side.
Step 3 Hold the fiber routing drawer with both hands and position it in the rack beneath the chassis.
(See Figure 2-9.)
Step 4 Align the mounting holes on the bracket with the mounting holes in the equipment rack.
Step 5 Install the 12-24 or 10-32 screws through the elongated holes in the brackets and into the threaded holes
in the mounting post. Repeat this step for the other side.
1Hook 3Latch
2Flip up
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
T
X
R
X
T
X
R
X
15530-LCMB-0200
15530-CPU
AUX
15530-CPU
AUX
1
3
85011
1
2
2
2
23

2-14
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Grounding the Shelf
Installing the Fiber Routing Drawer
To install the fiber routing drawer, follow these steps:
Step 1 Hold the drawer with both hands and position the drawer in the rack beneath the chassis.
(See Figure 2-9.)
Step 2 Align the mounting holes on the bracket with the mounting holes in the equipment rack.
Step 3 Install the 12-24 or 10-32 screws through the elongated holes in the brackets and into the threaded holes
in the mounting post. Repeat this step for the other side.
Grounding the Shelf
Two system (earth) grounding holes are provided under the power supplies at the bottom right of the
shelf.
Shelf Grounding Guidelines
To make an adequate grounding connection, you need the following parts and tools:
•Grounding lug.
•Two M4 (metric) hex-head screws with locking washers.
•One grounding wire (6 AWG recommended).
•Number 2 Philips head screwdriver.
•Crimping tool. This tool must be large enough to accommodate the girth of the grounding lug when
you crimp the grounding cable into the lug.
•Wire-stripping tool.
Note The grounding lug and M4 screws are included in your accessory kit that ships with the system.
Shelf Grounding Procedures
This section describes how to connect the Cisco ONS 15530 to earth ground. You must complete this
procedure before connecting system power or powering up your shelf.

2-15
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Grounding the Shelf
To ground the shelf, follow these steps:
Step 1 Use a wire-stripping tool to remove approximately 0.75 inch (20 mm) of the covering from the end of
the grounding wire (see Figure 2-11).
Figure 2-11 Attaching the Grounding Wire to Grounding Lug
Step 2 Insert the stripped end of the grounding wire into the open end of the grounding lug (see Figure 2-11).
Step 3 Use the crimping tool to secure the grounding wire in place in the grounding lug.
Step 4 Locate the grounding receptacles on the chassis (see Figure 2-12).
Figure 2-12 Cisco ONS 15530 ESD Sockets
Step 5 Place the grounding lug against the grounding receptacle at the bottom right of the chassis (see
Figure 2-13).
0.75 in.
(2 cm)
Grounding lugWire
30020
FASTENERS MUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
77692
Grounding
receptacle
ESD sockets
FAN
STATUS

2-16
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Grounding the Shelf
Figure 2-13 Installing the Grounding Lug
Step 6 Insert two screws through the holes in the grounding lug and the grounding receptacle. Ensure that the
grounding lug does not interfere with other hardware or rack equipment.
Step 7 Install the locking washers and nuts; tighten them to secure the grounding lug to the grounding
receptacle.
Step 8 Prepare the other end of the grounding wire and connect it to an appropriate grounding point in your site
to ensure adequate earth ground for the Cisco ONS 15530.
Note The Grounding lug shown in Figure 2-13 should be positioned at a 45 degree angle to allow room for
cables.
FASTENERS MUST BE
FULLYENGAGED PRIOR TO
OPERATINGTHE POWER SUPPLY
FAIL
100-240V
8.0-3.5A
50-60HZ
GOOD
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
T
X
R
X
15530-LCMB-0200
0
1
2
3
4
5
6
7
8
9
STATUS
STATUS
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
CUTOFF
HIST
CLR
15530-CPU
A
L
A
R
M
S
RESET
ACTIVE
COMPACT
FLASH
CIRTICAL
MAJOR
FDX
100MBPS
LINK
LINK
AUX
CON
CON
CUTOFF
HIST
CLR
CUTOFF
MINOR
15530-CPU
A
L
A
R
M
S
AUX
CON
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
R
X
T
X
R
X
STATUS
T
X
T
X
E
A
S
T
W
E
S
T
R
X
T
X
R
X
R
X
79144
Grounding lug
Wire
Screws Locking
washers
Grounding holes
FAN
STATUS

2-17
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Installing and Removing Line Cards or Motherboards
Preventing ESD Damage
Electrostatic discharge (ESD) damage occurs when electronic cards or components are mishandled and
can result in complete or intermittent failures. Note the following guidelines before you install or service
the system:
•Always wear an ESD-preventive wrist or ankle strap when handling electronic components. Connect
one end of the strap to an ESD jack or an unpainted metal component on the system (such as a
captive installation screw).
•Handle cards by the faceplates and edges only; avoid touching the printed circuit board and
connector pins.
•Place any removed component on an antistatic surface or in a static shielding bag.
•Avoid contact between the cards and clothing. The wrist strap only protects the card from ESD
voltages on the body; ESD voltages on clothing can still cause damage.
Note For safety, periodically check the resistance value of the antistatic strap. The measurement should be
between 1 and 10 megohms (Mohms).
Installing and Removing Line Cards or Motherboards
The line cards and modules used on the Cisco ONS 15530 are hot-swappable. This section describes the
procedures for installing and removing the following line cards and motherboards from the chassis:
•ESCON aggregation cards
•4-port 1-Gbps/2-Gbps FC aggregation cards
•8-port FC/GE aggregation cards
•8-port multi-service muxponders
•2.5-Gbps ITU trunk cards
•10-Gbps ITU trunk cards
•10-Gbps ITU tunable trunk cards
•10-Gbps uplink cards
•Transponder line cards
•Carrier motherboards
•CPU switch modules
Installing Line Cards or Motherboards
To install a line card or motherboard, follow these steps:
Step 1 Take the new line card or motherboard from the shipping container.
Step 2 Insert the line card or motherboard carefully into the chassis slot while guiding the upper and lower
edges line card or of the motherboard in the tracks until its connectors come into contact with the
backplane.

2-18
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Installing and Removing Line Cards or Motherboards
Step 3 Use the release levers to push the line card or motherboard or processor card in until it is fully seated in
the backplane connector.
Step 4 Push the release levers in simultaneously to lock the line card or motherboard into the slot.
Step 5 Use a number 1 Philips screwdriver to tighten the captive installation screws.
Step 6 Check the LED to ensure proper installation while powered.
Removing Line Cards or Motherboards
To remove a line card or motherboard, follow these steps:
Step 1 Remove all cables from the line card or motherboard.
Step 2 Install appropriate dust covers on the fiber cable connectors and the blind plugs into the connectors on
the motherboard.
Step 3 Use a number 1 Philips screwdriver to loosen the captive installation screws.
Step 4 Pull the release levers out to release the line card or motherboard from the slot in the chassis.
Step 5 Use the release levers to pull the line card or motherboard out of the chassis.
Step 6 Place the removed line cards in a container appropriate for shipping and storage.
Installing SFPs into Aggregation Cards and Muxponders
To install SFPs into the ESCON aggregation cards, 8-port FC/GE aggregation cards, and 8-port
multi-service muxponders, follow these steps:
Step 1 Take the desired SFP from the shipping container.
Step 2 Install the SFP by inserting it in the aggregation card or muxponder.
Step 3 Push the SFP until you hear a click. The click indicates that it is securely set in the module.
Installing SFP with Mini SMB Coax Connectors
To install the 15500-XVRA-10E1SFP with mini SMB coax connectors into the 8-port multi-service
muxponder, follow these steps:
Step 1 Take the desired SFP from the shipping container.
Step 2 Install the mini SMB coax connector into the SFP by pushing the cable into the SFP. (See Figure 2-14.)
Note If you are installing the 15500-XVRA-10E1, you must attach the cable to the SFP before
installing the SFP into the 8-port multi-service muxponder.

2-19
Cisco ONS 15530 Hardware Installation Guide
OL-7706-01
Chapter 2 Installing the Cisco ONS 15530 Installing and Removing Line Cards or Motherboards
Figure 2-14 Installing the 15500-XVRA-10E1 SFP
Step 3 Twist the cable to secure it in the SFP.
Step 4 Install the SFP by inserting it in the muxponder.
Tip In an unlikely event of the pull-tab is damaged or missing, use a screwdriver to push on the hinge pin to
unlock the SFP cage latch and pull the SFP out from SFP port
Removing SFP from Aggregation Cards and Muxponders
The SFPs used on the aggregation cards and muxponders have different types of connectors. The
different connector types on the SFP optics are:
•RJ-45 connector (for 8-port multi-service muxponders)
•MT-RJ connector (for ESCON aggregation cards)
•LC connector (for 8-port FC/GE aggregation cards)
•Mini SMB coax connector (for 8-port multi-service muxponders)
Each connector requires a different method of removal.
Note Use the show hardware command to see what SFP you have currently installed in your module.
Removing Pull Tab SFPs with RJ-45 Connectors
To remove an SFP with an RJ-45 connector from the muxponder, follow these steps:
Step 1 Remove the cable from the desired SFP.
Step 2 Use the thumb on your left hand to push against the RJ-45 connector.
Step 3 Use your right hand to pull the pull tab on the SFP.
Step 4 Rotate the SFP while simultaneously pushing against the connector and pulling the pull tab. This
releases the SFP from the latch lock of the cage. (See Figure 2-15.)
113974

2-20
Cisco ONS 15530 Hardware Installation Guide OL-7706-01
Chapter 2 Installing the Cisco ONS 15530
Installing and Removing Line Cards or Motherboards
Figure 2-15 Releasing the SFP
Step 5 Pull the SFP out and place it in a container appropriate for shipping and storage. (See Figure 2-16.)
Figure 2-16 Removing the SFP
Tip In an unlikely event of the pull-tab is damaged or missing, use a screwdriver to push on the hinge pin to
unlock the SFP cage latch and pull the SFP out from SFP port
Note SFPs with RJ-45 connectors require cabling after it is installed, and removal of cables is required before
removing the SFP from the card.
Removing Non-Pull Tab SFPs with RJ-45 Connectors
To remove an SFP with an RJ-45 connector from the muxponder, follow these steps:
Step 1 Remove the cable from the desired SFP.
Step 2 Pull the latch on the SFP out. This releases the SFP from the latch lock of the cage.
Step 3 Pull the SFP out and place it in a container appropriate for shipping and storage.
120369
120370
