Cisco DMC350 User manual

Quick Installation Guide
Wireless Home Audio
Conductor
Wireless-N Digital Music Center
DMC350
UK English
DK Dansk
DE Deutsch
NL Nederlands

Table of Contents
iWireless-N Digital Music Center
Table of Contents
English............................................................1
ConductorOverview........................................2
Installation..................................................3
Troubleshooting...........................................13
OnlineServices ............................................14
Dansk............................................................15
Conductor-oversigt........................................16
Installation.................................................17
Fejlnding.................................................27
Online-tjenester ...........................................28
Deutsch..........................................................29
Conductor–Übersicht.....................................30
Installation.................................................31
Fehlerbehebung...........................................41
Online-Dienste.............................................42
Nederlands.......................................................43
Conductor-Overzicht......................................44
Installatie..................................................45
Problemenoplossen.......................................55
Onlineservices.............................................56

1Wireless-N Digital Music Center
English
English
Thank you for making a great decision and choosing to purchase the
Linksys by Cisco Conductor – Wireless-N Digital Music Center.
The Conductor lets you stream music from your PC, storage device, iPod®††,
or from online services such as audiolounge® and RadioTime® to Wireless
Home Audio devices throughout your home. Play the same music in every
room or select different tracks for playback in different rooms. You can
search your music and create playlists through the Conductor’s 7" LCD color
touchscreen. Using online services such as audiolounge and RadioTime, you
can access millions of songs and radio stations all across the world.
Wireless Home Audio Product Family†
Conductor
(DMC350)
Director
(DMC250)
Player
(DMP100)
Speakers
(DMSPK50)
Controller
(DMRW1000)
Remote Control
(DMRIR500)
Docking Station for
iPod (MCCI40)
Package Contents
Conductor Power Cable Ethernet Cable
0
1 2 3
4 5 6
7 8 9
abc def
ghi jkl mno
pqrs tuv wxyz
presets
IR Remote CD-ROM Quick Installation Guide
† The maximum performance for wireless is derived from IEEE Standard 802.11 specifications.Actual performance can vary,including lower wireless
network capacity, data throughput rate, range and coverage. Performance depends on many factors,conditions and variables, including distance from
the access point, volume of network traffic, building materials and construction, operating system used, mix of wireless products used, interference and
other adverse conditions.
†† Requires optional Linksys by Cisco Docking Station for iPod (MCCI40).

2 Wireless-N Digital Music Center
Conductor Overview English
Conductor Overview
Front Panel
Now Playing 3:18 PM
Beethoven
Classic Music
Moonlight Sonata
Pause
Stop
Repeat
1:45 4:15
LCD Touchscreen
Headphone Output
Power/Standby
CD Eject ButtonUSB Port
Auxiliary Analog Input
Speaker Grill
Power LED and IR
Receiver Window
Back Panel
ETHERNET
10/100
IPOD
USB2
0.5A MAX
AUDIO IN
Connector
for iPod
Ethernet Port
Power Connector
USB Port
Auxiliary Audio In
Wi-Fi Protected Setup™

3Wireless-N Digital Music Center
InstallationEnglish
Installation
EasyLink Advisor guides you through the setup of your Linksys by Cisco
Wireless Home Audio devices.
EasyLink Advisor is compatible with the following operating systems:
•Windows XP
•Windows Vista
If you’ve already installed the EasyLink Advisor software on your computer
when you set up other Wireless Home Audio devices, launch EasyLink
Advisor, go to Add Device, select Wireless Home Audio, and skip to Step G.
If you have not yet installed EasyLink Advisor on your computer, perform all
of the steps starting at step A.
A. To begin, insert the CD into your CD-ROM drive.
B. Click Start Setup.
Start Setup

4 Wireless-N Digital Music Center
Installation English
C. Click Next to continue.
D. Read the license agreement and if you agree, check
I accept the terms of the license agreement. Click Next to continue.
E. Click Next to continue.

5Wireless-N Digital Music Center
InstallationEnglish
F. Click Next to continue.
G. If you have an existing Cisco account, enter the email and password
associated with the account, click Next and skip to step I. If you do not
have an account, click the I do not have an account link.

6 Wireless-N Digital Music Center
Installation English
H. Create a Cisco account by entering your e-mail address in the Email
field and type in a password in the Password and Retype Password fields.
Click Next to continue.
I. Select the device that you want to set up, in this case it is the Conductor
(DMC350). Click Next.

7Wireless-N Digital Music Center
InstallationEnglish
J. Connect one end of an Ethernet cable to your Router and the other end
of the cable to your Conductor. Connect the power adapter to the back
of the Conductor and the other end to a power outlet. Click Next.
K. EasyLink Advisor will search for the Conductor. This may take a few
minutes.

8 Wireless-N Digital Music Center
Installation English
L. Select the area that best represents where you will be placing the
device or personalize the device name in the text field below Or,
personalize the name here:. Click Next to continue.
M. Enter your wireless network name (SSID) and click Next.

9Wireless-N Digital Music Center
InstallationEnglish
N. Select the Security Type used on your wireless network and enter your
security key in the Enter passkey field. Click Next to continue.
NOTE: If you want to see the security key as you type it in,
click on Show Passkey.
O. EasyLink Advisor applies the settings to the Conductor.

10 Wireless-N Digital Music Center
Installation English
P. Unplug the Ethernet cable from your router and from the Conductor.
Click Next to continue.
Q. EasyLink Advisor will search the network to find your Conductor
wirelessly.

11Wireless-N Digital Music Center
InstallationEnglish
R. A message should appear that you have successfully configured your
Conductor. Click Next to continue.
S. If you have any additional devices to configure, select one and click
Next. If you do not have any additional devices, click I don’t have any
more devices to connect and click Next.

12 Wireless-N Digital Music Center
Installation English
T. Once you’ve configured all of your devices, the Music Services window
will be displayed. If you have an existing account, click the here link
and enter your account information. If not enter a User Name and
Password to sign up for a 30-day free trial and click Next.
U. Once you’ve set up your music services, a Congratulations message will
appear. Click Finish to complete the setup.

13Wireless-N Digital Music Center
TroubleshootingEnglish
Troubleshooting
Do I need to run the CD to congure my Wireless Home Audio devices?
•Yes. Basic settings can be applied on some devices via their screens, but
in order to fully configure your Wireless Home Audio devices you must
use the CD.
How do I congure my rewall to work with my Wireless Home Audio
devices?
•It is possible that firewalls can prevent your devices from being found
and configured. Please visit www.linksysbycisco.com/homeaudio/ug
for details on how to fix your firewall settings.
How do I share my music from additional computers and allow them to
control my Wireless Home Audio devices?
•Run the CD on your additional computers and select the Connect
Computers option on the first screen.
Where do I nd the Cisco Media Center software after installation is
complete?
•Go to Start > Programs and select Cisco Media Center. You can start the
Cisco Media Player from here.
What do I do if my iTunes library or other audio les are not found by Cisco
Media Center?
•Some iTunes files may not be available. Songs purchased from iTunes*
may be protected with Digital Rights Management (DRM); DRM files
cannot be played to yourWireless Home Audio devices directly from your
PC. The optional Linksys by Cisco Docking Station for iPod (MCCI40) will
allow you to connect your iPod to your Director or Conductor and play
back all of the songs from your iPod.
*iTunes Plus files are not protected

14 Wireless-N Digital Music Center
Online Services English
•During the initial configuration, you are asked to select directories
where your music is stored. To change or add additional directories,
right-click on the icon on the taskbar and select Properties.
Modify or type in a new directory by typing in the entire path such as
C:\Documents and Settings\username\My Documents\My Music; in
the Local Media Directory field. Additional directories are separated by a
semicolon. Click OK after all updates are complete.
WEB: If you need additional support, contact us on the web at
www.linksysbycisco.com/support
Online Services
AudioLounge is a new online music service that gives you unlimited access
to millions of songs. You can listen to full length CD quality tracks, discover
new music and old favorites, and even create and share playlists with
friends and family. With your new Wireless Home Audio products and the
audiolounge service, you can play your music where you want and when
you want.
Radiotime provides streaming access to over 100,000 radio stations and
shows. You can locate shows based on location, topic, or music genre.

15Wireless-N Digital Music Center
Dansk
Dansk
Tak fordi du valgte Linksys by Cisco Conductor - Wireless-N Digital
MusicCenter.
Conductor lader dig streame musik fra din pc, lagerenhed, iPod®†† eller fra
online-tjenester, som f.eks. audiolounge® og RadioTime® til Wireless Home
Audio-enheder i dit hjem. Afspil den samme musik i alle rum, eller vælg
at afspille forskellige numre i de forskellige rum. Du kan søge i din musik
og oprette spillelister via Conductors 7" LCD-berøringsskærm i farver. Ved
hjælp af online-tjenester som f.eks. audiolounge® og RadioTime® får du
adgang til millioner af sange og radiostationer fra hele verden.
Wireless Home Audio-produktserien†
Conductor
(DMC350)
Director
(DMC250)
Player
(DMP100)
Højttalere
(DMSPK50)
Controller
(DMRW1000)
Fjernbetjening
(DMRIR500)
Dockingstation til
iPod (MCCI40)
Pakkens indhold
Conductor Netledning Ethernet-kabel
0
1 2 3
4 5 6
7 8 9
abc def
ghi jkl mno
pqrs tuv wxyz
presets
IR-fjernbetjening Cd-rom Installationsvejledning
† Den maksimale ydeevne for trådløse produkter er baseret på specifikationerne i IEEE 802.11-standarden.Den faktiske ydeevne kan variere,
herunder lavere kapacitet i det trådløse netværk, datagennemløbshastighed, område og dækning.Ydeevne afhænger af mange faktorer, forhold og
variabler, herunder afstanden fra access point’et, mængden af netværkstrafik, bygningsmaterialer og- konstruktion, det anvendte operativsystem,
sammensætningen af de anvendte trådløse produkter, forstyrrelser samt andre ugunstige forhold.
†† Kræver Linksys-Cisco-dockingstation til iPod (MCCI40) (ekstraudstyr).

16 Wireless-N Digital Music Center
Conductor-oversigt Dansk
Conductor-oversigt
Forside
Now Playing 3:18 PM
Beethoven
Classic Music
Moonlight Sonata
Pause
Stop
Repeat
1:45 4:15
LCD-berøringsskærm
Hovedtelefonudgang
Tænd/Standby
Eject-knap til cdUSB-port
Analog indgang til ekstraudstyr
Højttalergitter
LED-strømindikator og
vindue til IR-receiver
Tilbage
ETHERNET
10/100
IPOD
USB2
0.5A MAX
AUDIO IN
Stik til iPod
Ethernet-port
Strømtilslutning
USB-port
Lydindgang til ekstraudstyr
Wi-Fi Protected Setup™
