Quick Start Guide
Cisco Small Business
Model SD2008
8-Port 10/100/1000 Gigabit Switch
Package Contents
•SD2008 Gigabit Switch
•Power Adapter
•Quick Start Guide
Product Overview
Thank you for choosing the Cisco 8-Port 10/100/1000 Gigabit Switch. The
Switch provides non-blocking, wire speed switching for your 10,100, and 1000
Mbps network clients.
Front Panel
The Port Status and System Status LEDs are located on the front panel of the
Switch.
System—(Green) This LED lights up and remains lit when the Switch is
powered on.
Ports 1-8—(Green) Each LED lights up when a connection is made through its
corresponding port. It flashes when the corresponding port is active.
Back Panel
The Ethernet network ports are located on the back panel of the Switch. All
ports are auto-negotiating and have automatic MDI/MDI-X crossover detection.
1-8—These ports connect the Switch to network devices, such as computers.
1
Side Panel
The power port and security slot are located on the side panels of the Switch.
The power port is where you will connect the power adapter.
The security slot is where you can attach a lock to protect the Switch from theft.
Placement Options
Set the Switch on its four rubber feet, or mount the Switch on a wall.
The Switch offers two wall-mount slots, which are the two crisscross slots on
the bottom panel. The measurement between the two slots is 2.52 inches
(64 mm).
To use the wall-mount option, follow these instructions:
STEP 1Attach two screws to the wall, 2.52 inches (64 mm) apart, so that the
Switch’s wall-mount slots can line up with the two screws.
STEP 2Maneuver the Switch to insert the screws into the two slots.
Typical Installation Scenario
The application diagram shown here is an example of a typical network
configuration.
When you connect your network devices, make sure you don’t exceed the
maximum cabling distances, which are listed in the following table:
NOTE Use Category 5e Ethernet network cables for your Gigabit
connections.
From To Maximum Distance
Switch Switch 100 meters (328 feet)
Switch Computer 100 meters (328 feet)
2

Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
Cisco, Cisco Systems, the Cisco logo, and the Cisco Systems logo are registered trademarks or
trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other
countries. All other trademarks mentioned in this document or Website are the property of their
respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0705R)
© 2008 Cisco Systems, Inc. All rights reserved.
Printed in the USA on recycled paper containing 10% postconsumer waste.
78-18820-01
Installation
Perform the steps in this section to install the hardware.
STEP 1Make sure all of the devices you will connect to the Switch are
powered off.
STEP 2Connect a Category 5 Ethernet network cable to one of the numbered
ports on the Switch. Connect the other end to a computer or other
network device.
NOTE Use Category 5e Ethernet network cables for your Gigabit
connections.
STEP 3Repeat step 2 to connect additional devices.
STEP 4Connect the supplied power adapter to the power port on the Switch’s
back panel. Plug the other end of the adapter into an electrical outlet.
3
!
CAUTION Make sure you use the power adapter included with the
Switch. Using a different power adapter may damage the
Switch.
STEP 5Power on the devices connected to the Switch. Each active port’s
corresponding LED will light up on the Switch.
Congratulations! The installation of the 10/100/1000 Gigabit Switch is
complete!
Specifications
The following table lists the specifications for the SD2008 10/100/1000 Gigabit
Ethernet Switch.
Item Specification
Model SD20008
Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab
Ports 8 RJ-45 10/100/1000 Mbps ports
Cabling Type Cat5e
LEDs System, 1 through 8
Security Feature Security Slot
Dimensions WxHxD
5.12" x 1.18" x 5.00"
130 x 30 x 127 mm
Unit Weight 0.94 lbs (0.425 kg
Power DC12V/1A
Certification FCC Class B, CE
Operating Temperature 32 to 104ºF (0 to 40ºC)
Storage Temperature -40 to 158ºF (-40 to 70ºC)
Operating Humidity 20 to 95%, noncondensing
Storage Humidity 5 to 90%, noncondensing
