Installing a Cisco MDS 9132T Switch
This chapter describes how to install a Cisco MDS 9132T switch and its components.
Before you install, operate, or service the system, see the Regulatory Compliance and Safety Information for
the Cisco MDS 9000 Family document for important safety information.
This unit is intended for installation in restricted access areas. A restricted access area can be accessed
only through the use of a special tool, lock and key, or other means of security. Statement 1017
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
Each new switch requires a license. See the Cisco MDS 9000 Family NX-OS Licensing Guide for instructions
on installing a license.
•Preinstallation, on page 1
•Installing the Switch, on page 7
•Grounding the Switch, on page 15
•Installing and Removing Components, on page 16
Preinstallation
This section includes the following information:
Installation Options
A Cisco MDS 9132T Switch can be installed using the following methods:
• In an open EIA rack
• In a perforated EIA cabinet
The rack-mount kit enables you to install the switch into racks of varying depths. You can use the rack-mount
kit parts to position the switch with easy access to either the port connections end of the chassis or the end of
Installing a Cisco MDS 9132T Switch
1

the chassis with the fan and power supply modules. For instructions on how to install the rack-mount kit, see
the Installing the Switch section.
Cisco MDS 9000 Series Telco and EIA Shelf Bracket
The optional Telco and EIA Shelf Bracket Kit (part number DS-SHELF=) can temporarily or permanently
support the Cisco MDS 9132T switch during installation. After the front rack-mount brackets are securely
attached to the rack-mounting rails, the shelf bracket can be removed.
The Telco and EIA Shelf Bracket kit supports the following configurations:
• A Cisco MDS 9132T Switch in a two-post Telco rack
• A Cisco MDS 9132T Switch in a four-post EIA rack
Telco and EIA Shelf Bracket optional kit is not provided with the switch; to order the kit, contact your switch
supplier.
Note
This section describes the procedure for installing a Cisco MDS 9132T switch in a rack or cabinet using the
optional Telco and EIA Shelf Bracket Kit.
Shelf-Installation Guidelines
• If the rack is on wheels, ensure that the brakes are engaged or the rack is otherwise stabilized.
• If you are installing this kit in an EIA rack, attach the shelf to all four rack-mounting posts; the EIA posts
may not be thick enough to prevent flexing of shelf brackets if only two posts are used.
Caution
Before Installing the Shelf Brackets
Before installing the shelf brackets, inspect the contents of your kit. The following table lists the contents of
the shelf bracket kit:
Part DescriptionQuantity
Slider brackets2
Shelf brackets2
Crossbar1
10-32 x 3/8-in. Phillips pan-head screws2
12-24 x 3/4-in. Phillips screws16
10-24 x 3/4-in. Phillips screws16
Installing a Cisco MDS 9132T Switch
2
Installing a Cisco MDS 9132T Switch
Cisco MDS 9000 Series Telco and EIA Shelf Bracket

Required Equipment
You need the following equipment for this installation:
• Number 2 Phillips screwdriver
• Tape measure and level (to ensure that shelf brackets are at level with each other)
• NEBS plate - If the airflow is port-side intake
Installing the Shelf Bracket Kit into a Two-Post Telco Rack
The following figure shows the installation of the shelf bracket kit into a two-post Telco rack:
Figure 1: Installing the Shelf Bracket Kit into a Telco Rack
10-32 screws3Rack-mounting post1
Crossbar4Shelf bracket2
To install the shelf brackets in a Telco rack, follow these steps:
Step 1 Position a shelf bracket inside a rack-mounting post as shown in Figure 1: Installing the Shelf Bracket Kit into a Telco
Rack, on page 3 and align the screw holes at the front of the shelf bracket with the holes in the rack-mounting post.
Then, attach the shelf bracket to the rack-mounting post using a minimum of four 12-24 or 10-24 screws.
The bottom hole of the shelf bracket should align with the bottom hole (the hole immediately above the 1/2 in.
spacing) of a rack unit on the rack-mounting post.
Note
Step 2 Repeat Step 1 with the other shelf brackets.
Step 3 Verify that the shelf brackets are at the same height (using the level or tape measure, as desired).
Step 4 Attach the crossbar to the rear of the shelf brackets, as shown in Figure 1: Installing the Shelf Bracket Kit into a Telco
Rack, on page 3, using the 10-32 screws.
Installing a Cisco MDS 9132T Switch
3
Installing a Cisco MDS 9132T Switch
Required Equipment

Installing the Shelf Bracket Kit into a Four-Post EIA Rack
The following figure shows the installation of the shelf bracket kit into a four-post EIA rack:
Figure 2: Installing the Shelf Bracket Kit into an EIA Rack
Crossbar4Rack-mounting post1
10-32 screws5Shelf bracket2
Slider post3
To install the shelf brackets in an EIA rack, follow these steps:
Step 1 Position a shelf bracket inside the rack-mounting posts, as shown in Figure 2: Installing the Shelf Bracket Kit into an
EIA Rack, on page 4. Align the screw holes at the front of the shelf bracket with the holes in the front rack-mounting
post. Then, attach the shelf bracket to the front rack-mounting post using a minimum of four 12-24 or 10-24 screws.
The bottom hole of the shelf bracket should align with the bottom hole (the hole immediately above the 1/2 in.
spacing) of a rack unit on the rack-mounting post.
Note
Step 2 Repeat Step 1 with the other shelf brackets.
Step 3 Verify that the shelf brackets are at the same height (using the level or tape measure, as desired).
Step 4 Attach the crossbar to the shelf brackets, as shown in Figure 2: Installing the Shelf Bracket Kit into an EIA Rack, on page
4, using the 10-32 screws.
Step 5 Insert the slider posts into the shelf brackets, as shown in Figure 2: Installing the Shelf Bracket Kit into an EIA Rack, on
page 4. Attach them to the rear rack-mounting posts, using a minimum of four 12-24 or 10-24 screws.
Installing a Cisco MDS 9132T Switch
4
Installing a Cisco MDS 9132T Switch
Installing the Shelf Bracket Kit into a Four-Post EIA Rack

Preinstallation Guidelines
Airflow Considerations
The switch comes with fan modules and power-supply modules that have either port-side intake or port-side
exhaust airflow for cooling the switch. If you are positioning the port-end of the switch in a cold aisle, make
sure that the switch has a port-side intake fan and power supply modules with red colorings. If you are
positioning the fan and power supply modules in a cold aisle, make sure that the switch has port-side exhaust
fan and power supply modules with blue colorings. All fan modules and power-supply modules must have
the same direction of airflow.
Connection Guidelines for AC-Powered Systems
To connect to the Cisco MDS 9132T switch AC power supplies to the site power source, follow these guidelines:
• Each power supply should have its own dedicated branch circuit.
• Circuits should be sized according to local and national codes.
• The AC power receptacles that are used to plug in the chassis must be the grounding type. The grounding
conductors that connect to the receptacles should connect to protective earth ground in the service
equipment.
Installation Guidelines
Follow these guidelines when installing the Cisco MDS 9132T switch:
• Plan your site configuration and prepare the site before installing the switch. The recommended site
planning tasks are listed in the Site Planning and Maintenance Records section.
• Ensure that there is adequate space around the switch to allow for servicing the switch and for adequate
airflow. The airflow requirements are listed the Technical Specifications section.
• Ensure that you are positioning the switch in a rack so that it takes in cold air from the cold aisle and
sends out air to the hot aisle. For more informatiom, see the Airflow Considerations section.
• Ensure that the air-conditioning meets the heat-dissipation requirements listed in the Technical
Specifications section.
• Ensure that the cabinet or rack meets the requirements listed in the Cabinet and Rack Installation section.
• Ensure that the chassis is adequately grounded. If the switch is not mounted on a grounded rack, we
recommend that you connect both the system ground on the chassis and the site power ground to an earth
ground.
• Ensure that the site power meets the power requirements listed in the Technical Specifications section.
If available, you can use an uninterruptible power supply (UPS) to protect against power failures.
Avoid UPS types that use ferro-resonant technology. These UPS types can become
unstable with systems such as the Cisco MDS 9000 Series, which can in turn
have substantial current draw fluctuations because of fluctuating data traffic
patterns.
Caution
Installing a Cisco MDS 9132T Switch
5
Installing a Cisco MDS 9132T Switch
Preinstallation Guidelines

• Ensure that circuits are sized according to local and national codes.
For North America, the 650-W power supplies require a 15-A circuit. If you are using a 200 or 240 VAC
power source in North America, the circuit must be protected by a two-pole circuit breaker.
To prevent loss of input power, ensure that the total maximum loads on the circuits
supplying power to the switch are within current ratings for wiring and breakers.
Caution
•As you install and configure the switch, record the information listed in the Site Planning and Maintenance
Records section.
Unpacking and Inspecting the Switch
When handling switch components, wear an ESD strap and handle modules using only the carrier edges. An
ESD socket is provided on the chassis. For an ESD socket to be effective, the chassis must be grounded
through the power cable, the chassis ground, or the metal-to-metal connection with a grounded rack.
Caution
Retain the shipping container in case the chassis has to be shipped in the future.
Tip
The switch is thoroughly inspected before shipment. If any damage occurs during transportation, or if any
item is missing, contact your customer representative immediately. If you purchased Cisco support through
a Cisco reseller, contact the reseller directly. If you purchased support directly from Cisco, contact Cisco
Technical Support.
Note
To inspect the shipment, follow these steps:
1. Compare the shipment to the equipment list provided by your customer service representative and verify
that you have received all items, including the following:
• Grounding lug kit
• Rack-mount kit
• ESD wrist strap
• Cables and connectors
• Optional items, if any, ordered
2. Check for damage and report any discrepancies or damage, to your customer service representative. Have
the following information ready:
• Invoice number of shipper (see packing slip)
• Model and serial number of the damaged unit
• Description of damage
Installing a Cisco MDS 9132T Switch
6
Installing a Cisco MDS 9132T Switch
Unpacking and Inspecting the Switch

• Effect of damage on the installation
3. Check to be sure that all the power supplies and the fan trays have the expected direction of airflow.
Port-side intake airflow modules have a red coloring, and port-side exhaust airflow modules have blue
coloring. For more information, see the Power Supplies and Fan Modules sections.
Installing the Switch
This section describes how to use the rack-mount kit to install the Cisco MDS 9132T switch into a cabinet or
rack that meets the requirements described in the Cabinet and Rack Requirements section.
Installing the Switch on Shelf Brackets
This section provides general instructions for installing the switch on top of the shelf brackets. Note that this
is an optional task.
Before you install, operate, or service the system, refer to Regulatory Compliance and Safety Information for
the Cisco MDS 9000 Family for important safety information.
Note
To install the switch on top of the shelf brackets, follow these steps:
Step 1 Verify that the shelf brackets are level and securely attached to the rack-mounting posts, the crossbar is securely attached
to the shelf brackets, and the rack is stabilized.
Step 2 Slide the switch onto the shelf brackets, ensuring that it is squarely positioned.
Step 3 Attach the switch to the rack-mounting posts.
We recommend that you ground the chassis even if the rack is already grounded. A grounding pad with two
threaded M4 holes is provided on the chassis for attaching a grounding lug.
Caution
The grounding lug must be NRTL listed and compatible with copper conductors. Only copper conductors
(wires) must be used and these conductors must comply with National Electrical Code (NEC) for ampacity.
Note
NEBS Compliance
In case of port-side intake airflow, the chassis has to be NEBS compliant. To be NEBS compliant, install the
NEBS kit by following these steps:
1. Install two NEBS rack–mount brackets onto the switch.
2. Install the NEBS air-baffle onto the switch, and ensure that the direction is as shown in the following
images.
Installing a Cisco MDS 9132T Switch
7
Installing a Cisco MDS 9132T Switch
Installing the Switch

Figure 3: NEBS Kit for 2-post installation
Figure 4: NEBS Kit for 4-post installation
NEBS air-baffle1.
For more information on how to install the switch, see the Installing the Switch in a 4-Post Rack and Installing
the Switch into a 2-Post Rack.
Installing a Cisco MDS 9132T Switch
8
Installing a Cisco MDS 9132T Switch
NEBS Compliance

Installing the Switch in a 4-Post Rack
To install the switch, you must attach the front and rear mounting brackets to the switch, install the slider rails
on the rear of the rack, slide the switch into the slider rails, and secure the switch to the front of the rack.
Typically, the front of the rack is the side that is easiest to access for maintenance.
Before you begin
• Inspect the switch shipment to ensure that you have everything you ordered.
• Make sure that the switch rack-mount kit includes the following parts:
• Front rack-mount brackets (2)
• Rear rack-mount brackets (2)
• Slider rails (2)
• M4 x 0.7 x 8-mm Phillips countersink screws (12)
• The rack is installed and secured to its location.
Step 1 Install two front-mount brackets to the switch as follows:
1. Determine which end of the chassis is to be located in the cold aisle as follows:
• If the switch has port-side intake modules (fan modules with red coloring), position the switch so that its ports
are in the cold aisle.
• If the switch has port-side exhaust modules (fan modules with blue coloring), position the switch so that its fan
and power-supply modules are in the cold aisle.
2. Position a front-mount bracket so that four of its screw holes are aligned to the screw holes on the side of the chassis.
You can align any four of the holes in the front rack-mount bracket to four of the six screw holes on the
side of the chassis. The holes that you use depend on the requirements of your rack and the amount of
clearance required for interface cables (3 in. [76 mm] minimum) and module handles (1 in. [25 mm]
minimum).
Note
Installing a Cisco MDS 9132T Switch
9
Installing a Cisco MDS 9132T Switch
Installing the Switch in a 4-Post Rack

2 & 3. Front rack-mount bracket1 & 4. Four M4 screws
3. Secure the front-mount bracket to the chassis using the four M4 screws and tighten each screw to 12 in-lb (1.36 N·m)
of torque.
4. Repeat Step 1 for the other front rack-mount bracket on the other side of the switch, and be sure to position that
bracket the same distance from the front of the switch.
Step 2 Install the two rear rack-mount brackets on the chassis, as follows:
1. Align the two screw holes on a rear rack-mount bracket to the middle two screw holes in the remaining six screw
holes on a side of the chassis if you are aligning the guide to holes that are near the port connections end of the chassis.
2. Attach the guide to the chassis using two M4 screws. Tighten the screws to 12 in-lb (1.36 N·m) of torque.
3. Repeat Step 2 for the other rear rack-mount bracket on the other side of the switch.
Step 3 If you are not installing the chassis into a grounded rack, you must attach a customer-supplied grounding wire to the
chassis, as explained in Grounding the Switch. However, if you are installing the chassis into a grounded rack, you can
skip this step.
Step 4 Install the slider rails into the rack or cabinet, as follows:
1. Determine which two posts of the rack or cabinet you should use for the slider rails. Of the four vertical posts in the
rack or cabinet, two will be used for the front-mount brackets attached to the easiest-accessed end of the chassis, and
the other two posts will have the slider rails.
2. Position a slider rail at the desired level on the back side of the rack and use two 12-24 screws or two 10-32 screws,
depending on the rack thread type, to attach the posts to the rack. Tighten the 12-24 screws to 30 in-lb (3.39 N·m)
of torque, and tighten the 10-32 screws to 20 in-lb (2.26 N·m) of torque.
3. Repeat Step 3 to attach the other slider rail to the other side of the rack.
To make sure that the slider rails are at the same level, you should use a level tool or tape measure, or carefully count
the screw holes in the vertical mounting posts.
Installing a Cisco MDS 9132T Switch
10
Installing a Cisco MDS 9132T Switch
Installing the Switch in a 4-Post Rack

Step 5 Insert the switch into the rack and attach it as follows:
2. Customer-supplied rack-mount screw.1. Fan-tray end of the chassis.
1. Holding the switch with both hands, position the two rear rack-mount brackets on the switch between the rack or
cabinet posts that do not have slider rails attached to them.
2. Align the two rear rack-mount guides on either side of the switch with the slider rails installed in the rack. Slide the
rack-mount guides onto the slider rails, and then gently slide the switch all the way into the rack until the front
rack-mount brackets come in contact with two rack or cabinet posts.
If you attached a grounding cable to the chassis, you will need to bend one of the rack-mount posts slightly
to allow the grounding lug to go behind the post.
Note
3. Holding the chassis level, insert two screws (12-24 or 10-32, depending on the rack type) into each of the two front
rack-mount brackets (using a total of four screws), and into the cage nuts or threaded holes in the vertical rack-mounting
posts.
4. Tighten the 10-32 screws to 20 in-lb (2.26 N·m), or tighten the 12-24 screws to 30 in-lb (3.39 N·m).
Step 6 If you have attached a grounding wire to the chassis grounding pad, connect the other end of the wire to the facility
ground.
Installing the Switch into a 2-Post Rack
Step 1 Install two rack–mount brackets onto the switch as follows:
a) Determine which end of the chassis is to be located in the cold aisle as follows:
• If the switch has port-side intake modules (fan modules with red coloring), position the switch so that its ports
is in the cold aisle.
Installing a Cisco MDS 9132T Switch
11
Installing a Cisco MDS 9132T Switch
Installing the Switch into a 2-Post Rack

• If the switch has port-side exhaust modules (fan modules with blue coloring), position the switch so that its fan
and power supply modules is in the cold aisle.
b) Position a rack–mount bracket so that four of its screw holes are aligned to the screw holes on the side of the chassis.
Then, secure the front-mount bracket to the chassis using four M4 screws.
You can align four of the holes in the front rack-mount bracket to four of the screw holes on the front side
of chassis or four of the screw holes on the rear side of the chassis. The holes that you use depend on which
side of your chassis needs to be put in the cold aisle.
Note
Figure 5: Installing Rack-mount Brackets on the Front Side of the Chassis
Installing a Cisco MDS 9132T Switch
12
Installing a Cisco MDS 9132T Switch
Installing the Switch into a 2-Post Rack

Figure 6: Installing Rack-mount Brackets on the Rear Side of the Chassis
c) Repeat Step 1b, for the other front rack-mount bracket on the other side of the switch and be sure to position that
bracket the same distance from the front of the switch.
Step 2 Install the switch onto the 2-post rack:
a) Holding the switch with both hands, position the back of the switch between the two posts of the rack. Then gently
move the switch until the front rack-mount brackets come in contact with two rack posts.
b) Holding the chassis level, insert two screws (12-24 or 10-32, depending on the rack type) into each of the two front
rack-mount brackets (using a total of four screws) and into the cage nuts or threaded holes in the vertical rack-mounting
posts.
Installing a Cisco MDS 9132T Switch
13
Installing a Cisco MDS 9132T Switch
Installing the Switch into a 2-Post Rack

Figure 7: Installing the Switch onto the 2-post Rack
c) Tighten the 10-32 screws to 20 in-lb (2.26 N.m) or tighten the 12-24 screws to 30 in-lb (3.39 N.m).
Removing the Shelf Bracket Kit (Optional)
The shelf bracket kit can be removed after the Cisco MDS 9132T switch has been installed in a four-post EIA
rack, and the front rack-mount brackets and the C brackets are securely attached to the rack-mounting posts.
To remove the shelf bracket kit, follow these steps:
Step 1 Remove the screws fastening the slider brackets to the rear rack-mounting posts, and then slide the slider brackets out of
the shelf brackets.
Step 2 Remove the screws fastening the crossbar to the shelf brackets, and then remove the crossbar.
Step 3 Remove the screws fastening the shelf brackets to the front rack-mounting posts and remove the shelf brackets from the
rack.
Installing a Cisco MDS 9132T Switch
14
Installing a Cisco MDS 9132T Switch
Removing the Shelf Bracket Kit (Optional)

Grounding the Switch
The switch chassis is automatically grounded when you install the switch properly in a grounded rack with
metal-to-metal connections between the switch and rack.
Alternatively, you can ground the chassis (this is required if the rack is not grounded) by attaching a
customer-supplied grounding cable to the chassis grounding pad and the facility ground.
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence
of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician
if you are uncertain that suitable grounding is available. Statement 1024
Warning
When installing or replacing the unit, the ground connection must always be made first and disconnected last.
Statement 1046
Warning
To connect the switch chassis to the facility ground, you need the following tools and materials:
• Grounding lug—A two-holed standard barrel lug that supports up to 6 AWG wire. This lug is supplied
with the accessory kit.
• Grounding screws—Two M4 x 8 mm (metric) pan-head screws. These screws are shipped with the
accessory kit.
•Grounding wire—Not supplied with the accessory kit. This wire should be sized to meet local and national
installation requirements. Depending on the power supply and system, a 12 AWG to 6 AWG copper
conductor is required for U.S. installations. We recommend that you use commercially available 6 AWG
wire. The length of the grounding wire depends on the proximity of the switch to proper grounding
facilities.
• Number 1 manual Phillips-head torque screwdriver.
• Crimping tool to crimp the grounding wire to the grounding lug.
• Wire-stripping tool to remove the insulation from the grounding wire.
Step 1 Use a wire-stripping tool to remove approximately 0.75 in. (19 mm) of the covering from the end of the grounding wire.
Step 2 Insert the stripped end of the grounding wire into the open end of the grounding lug, and use a crimping tool to crimp
the lug to the wire. Verify that the ground wire is securely attached to the grounding lug by attempting to pull the wire
out of the crimped lug.
Step 3 Secure the grounding lug to the chassis grounding pad with two M4 screws, and tighten each screw to 11.5 to 15 in-lb
(1.3 to 1.7 N·m) of torque.
Step 4 Prepare the other end of the grounding wire and connect it to an appropriate grounding point in your site to ensure an
adequate earth ground for the switch. If the rack is fully bonded and grounded, connect the grounding wire, as explained
in the documentation provided by the vendor from whom you bought the rack.
Installing a Cisco MDS 9132T Switch
15
Installing a Cisco MDS 9132T Switch
Grounding the Switch

Installing and Removing Components
Hazardous voltage or energy is present on the backplane when the system is operating. Use caution
when servicing. Statement 1034
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the switch.
Caution
Installing and Removing the Linecard Expansion Module
This section provides instructions for installing and removing the Linecard Expansion Module.
Installing the Linecard Expansion Module
To install a Linecard Expansion Module, follow the steps provided in this section:
Before you begin
If the LEM blank module is installed, remove it as follows:
1. Unscrew the locking screw.
2. Gently pull the linecard expansion module ejector till the linecard expansion blank module is slightly
ejected.
3. Remove the linecard expansion blank module.
Step 1 Power off the switch.
Step 2 Gently pull the LEM ejector so as to insert the LEM.
Step 3 Gently slide the LEM into the LEM bay till it clicks into place with the help of the Linecard Expansion Module ejector.
Step 4 Secure the Linecard Expansion Module ejector with the locking screw.
Removing the Linecard Expansion Module
To remove a Linecard Expansion Module, follow these steps:
Step 1 Power off the switch.
Step 2 Unscrew the locking screw.
Step 3 Gently pull the LEM ejector till the LEM is slightly ejected.
Step 4 Remove the LEM.
Step 5 Physically insert the linecard expansion blank module to ensure proper system cooling.
Installing a Cisco MDS 9132T Switch
16
Installing a Cisco MDS 9132T Switch
Installing and Removing Components

Installing and Removing Power Supplies
This section provides instructions for installing and removing the power supplies in the Cisco MDS 9132T
Switch.
Installing Power Supplies
You can replace one power supply while the other one provides power to the switch.
Before you begin
If the PSU blank module is inserted, remove it as follows:
1. Unscrew the locking screw.
2. Gently pull the power supply blank module out of the bay.
Figure 8: Inserted Power Supply Blank Module
Power supply blank module1
• To implement n+n redundancy, there must be two external power sources and two PSUs attached to each
power source. Otherwise, only one power source is required.
• There must be an earth ground connection to the chassis to which you are installing the replacement
module. Typically, the chassis is grounded by its metal-to-metal connection with a grounded rack. If you
need to ground the chassis, see Grounding the Switch.
Step 1 Holding the power supply unit with one hand underneath it and the other hand holding the handle, turn the power supply
so that its release latch is on the right side, and align the back end of the power supply (the end with the electrical
connections) to the open power supply slot. Carefully slide the power supply unit all the way into the slot until it clicks
into place.
If the power supply unit does not fit into the slot opening, turn the unit over and try again.
Note
Step 2 Test the installation by trying to pull the power supply out of the slot without using the release latch.
If the power supply does not move out of place, it is secured in the slot. If the power supply moves, carefully press it all
the way into the slot until it clicks in place and tighten the locking screw.
Step 3 Attach the power cable to the electrical outlet on the front of the power supply.
Step 4 Make sure that the other end of the power cable is attached to the appropriate power source for the power supply. If the
power source has a switch, slide it to the On position.
Installing a Cisco MDS 9132T Switch
17
Installing a Cisco MDS 9132T Switch
Installing and Removing Power Supplies

Depending on the outlet receptacle on your power distribution unit, you might need the optional jumper cable
to connect the switch to your outlet receptacle.
Note
Step 5 Verify that the power supply is operational by making sure that the power supply LED is green. For information on what
the power supply LEDs indicate, see the Switch LEDs section.
Removing Power Supplies
You can remove one faulty power supply, while the other one provides enough power to the switch. Install a
new power supply or a power supply blank module in the open slot.
Step 1 Holding the plug for the power cable, pull the plug out from the power receptacle on the power supply, and verify that
both the power supply LEDs are off.
Step 2 Grasp the power supply handle while pressing the release latch towards the power supply handle.
Step 3 Place your other hand under the power supply to support it while you slide it out of the chassis.
Do not touch the electrical connectors on the back side of the module and prevent anything else from coming
into contact with and damaging the connectors.
Caution
Step 4 Insert a power supply blank module, as shown in Figure 8: Inserted Power Supply Blank Module if you do not have a
new power supply unit.
Installing and Removing Fan Modules
This section provides instructions for installing and removing the fan modules for the Cisco MDS 9132T
switch.
You can replace one of the four fan modules even when the switch is operating so long as you perform the
replacement within one minute of removing the old fan module. If you cannot perform the replacement within
one minute, leave the original fan module in the chassis to maintain the designed airflow until you have the
replacement fan module on hand and can perform the replacement.
If you are replacing a module during operations, be sure that the replacement fan module has the correct
direction of airflow, which means that it has the same airflow direction as the other modules in the chassis.
Also, be sure that the airflow direction takes in air from a cold aisle and sends it out to a hot aisle. Otherwise,
the switch can overheat and shut down.
If you are changing the airflow direction of all the modules in the chassis, you must shut down the switch
before replacing all the fan and power supply modules with modules using the other airflow direction. During
operations, all the modules must have the same direction of airflow.
Caution
Installing a Fan Module
To install a new fan module, follow these steps:
Installing a Cisco MDS 9132T Switch
18
Installing a Cisco MDS 9132T Switch
Removing Power Supplies

Before you begin
If a fan blank module is installed, remove it as follows:
• Press the two sides of the fan blank module handle and pull on the handles enough to unseat it from its
connectors.
• Holding the handle, pull the module out of the chassis.
Figure 9: Inserted Fan Blank Modules
Fan blank modules1
• A fan slot must be open and ready for the new fan module to be installed.
• You must have a new fan module on hand and ready to install within one minute of removing the original
fan module if the switch is operating.
• The new fan module must have the same airflow direction as the other fan and power supply modules
installed in the switch. All of these modules must have either red coloring (port-side intake airflow) or
they must all have blue coloring (port-side exhaust airflow).
Step 1 Holding the fan module by its handle, align the back of the fan module (the side with the electrical connectors) to the
open fan slot in the chassis.
Step 2 Slide the fan module into the fan module bay until it clicks into place and tighten the locking screw.
Step 3 Verify that the Status LED turns on and becomes green.
Removing a Fan Module
The fan module is designed to be removed and replaced while the system is operating without presenting an
electrical hazard or damaging the system.
The Cisco MDS 9000 Series Switches have internal temperature sensors that can shut down the system if the
temperature within the chassis exceed certain safety thresholds. To accurately monitor the system temperature,
the temperature sensors require sufficient airflow through the chassis. In the event that a fan module is removed
from the chassis and the airflow is reduced, the system will bypass the temperature sensor information and
shut down after five minutes to prevent undetected overheating. However, the switches will shut down sooner
if the major temperature threshold is exceeded.
Caution
Installing a Cisco MDS 9132T Switch
19
Installing a Cisco MDS 9132T Switch
Removing a Fan Module

While removing the fan module, keep your hands and fingers away from the spinning fan blades. Let
the fan blades completely stop before you remove the fan module. Statement 258
Warning
To remove an existing fan module, follow these steps:
Step 1 On the fan module that you are removing, press the two sides of the fan module handle next to where it connects to the
fan module and pull on the handles enough to unseat it from its connectors.
Step 2 Holding the handle, pull the module out of the chassis.
Do not touch the electrical connectors on the back side of the module and prevent anything else from coming
into contact with and damaging the connectors.
Caution
Step 3 Insert a fan blank module, as shown in Figure 9: Inserted Fan Blank Modules, on page 19 if you do not have a new fan
module.
Installing a Cisco MDS 9132T Switch
20
Installing a Cisco MDS 9132T Switch
Removing a Fan Module
