Quick Start Guide
Cisco Small Business
WRV210 Wireless-G VPN Router with
RangeBooster
Package Contents
•WRV210 Router
•Ethernet Cable
•Power Adapter
•Product CD-ROM
•Quick Start Guide

Cisco Small Business WRV210 Quick Start Guide 1
Welcome
Thank you for choosing the Cisco WRV210, a Wireless-G VPN Router with
RangeBooster. The WRV210 router is a secure wireless networking device
for your small business.
This guide describes how to physically install your WRV210 and how to
install and launch the WRV210 Configuration Utility.
Before You Begin
Before you begin the installation, make sure that you have the following
equipment and services:
•Broadband Internet access account
•PC with Ethernet interface (RJ-45)
Getting to Know the WRV210
Front Panel
POWER—(Green) Shines steady when the router is powered on.
DMZ—(Green) Shines steady when the router has an available DMZ port. If
the LED is flashing, the router is sending or receiving data over the DMZ
port. A DMZ can be configured to allow Internet traffic to access a
specified computer on your network, while protecting the rest of your LAN
from exposure.
1
2

2 Cisco Small Business WRV210 Quick Start Guide
INTERNET—(Green) Shines steady when the router is connected to your
broadband network device (cable, DSL modem, or other). Flashes when
the router is sending or receiving data over the Internet port.
WIRELESS—(Green) Shines steady when there is a successful wireless
connection. Flashes when the router is actively sending or receiving data
over the wireless network.
1-4 (ETHERNET)—(Green) Shines steady when a device is connected to
the specified port. Flashes when the router is actively sending or receiving
data over the specified port.
Back Panel
POWER—Connects the router to power, using the AC power cable.
RESET—Performs the following functions:
•Warm reboot—Press the button for one second to restart the router
without losing any of the current configuration settings.
•Factory reset—Press the button for approximately 15 seconds to reset
the router to the factory default settings. You can also restore the
factory default settings from the Administration > Factory Defaults page
in the web-based Configuration Utility.
INTERNET—Connects the router to your broadband network device
(cable, DSL modem, or other).
1-4 (ETHERNET)—Connects the router to your PCs and network devices.

Cisco Small Business WRV210 Quick Start Guide 3
Default Settings
Installing the WRV210
Placement Options
You can place the router horizontally on a desktop or mount it on the wall.
Desktop Option
For desktop placement, place the router horizontally on a surface so it sits
on its four rubber feet.
Wall Option
To mount the router on the wall, follow these steps.
STEP 1Determine where you want to mount the router.
STEP 2Install two screws (not supplied) 2-9/16 in. apart (approximately
6.45 cm.) Leave about 1/8 in. (about 3 mm) of the head exposed.
STEP 3With the back panel pointing up (if installing vertically), position the
router so that the wall-mount crisscross slots on the bottom panel
line up with the two screws.
STEP 4Place the wall-mount slots over the screws and slide the router
down until the screws fit snugly into the wall-mount slots.
Parameter Value
Username admin
Password admin
LAN IP 192.168.1.1
DHCP Range 192.168.1.100 to 192.168.1.253
3
193817
Wall
mount
slots
2-9/16

4 Cisco Small Business WRV210 Quick Start Guide
Connecting the Equipment
STEP 1Make sure that all of your network hardware is powered off,
including the router, PCs, and broadband network device.
STEP 2Connect one end of an Ethernet cable to one of the LAN ports
(labeled 1-4) on the back of the router, and the other end to an
Ethernet port on a PC.
NOTE You must connect one computer with an Ethernet cable for the
purpose of the initial configuration. After you complete the initial
configuration, administrative tasks can be performed from a
wireless connection.
STEP 3Repeat the previous step to connect more PCs, a switch, or other
network devices to the router.
4

Cisco Small Business WRV210 Quick Start Guide 5
STEP 4Connect an Ethernet cable from the Broadband network device to
the Internet port on the router’s back panel.
STEP 5Connect the power adapter to the router’s Power port, and then
insert the other end into an electrical outlet.
NOTE Use only the power adapter that is supplied with the router.
Using a different power adapter could damage the router.
The Power and Internet LEDs on the front panel will shine green as
soon as the power adapter is connected properly.
STEP 6Power on the connected devices and the broadband network
device.
The hardware installation is now complete.

6 Cisco Small Business WRV210 Quick Start Guide
Verifying the Hardware
Installation
To verify the hardware installation, complete the following tasks:
•Check the LED states, as described in Getting to Know the WRV210,
page 1.
•If the LED does not show the expected status, check the cable
connections.
NOTE If you need help resolving a problem, visit the Cisco Small
Business Support Community at www.cisco.com/go/
smallbizsupport. For technical documentation and other links, see
Where to Go From Here, page 14.
Getting Started with the
Configuration
The following instructions explain how to set up the Internet connection,
configure the wireless network, and secure the wireless network.
Setting Up the Internet Connection
Before you begin, make sure that you have the setup information for the
specific type of Internet connection for your Internet Service Provider
(ISP). The installation technician from the ISP should have provided this
information when installing the broadband connection. If not, contact your
ISP to request the settings.
STEP 1Using one of the PCs that you previously connected to the router,
start your web browser.
NOTE You must complete the initial installation from a PC that is
physically connected to the router. You cannot configure the
router from a PC that is connected wirelessly.
5
6

Cisco Small Business WRV210 Quick Start Guide 7
STEP 2To connect to the web-based Configuration Utility, enter the
router’s default LAN IP address in the browser’s Address bar:
http://192.168.1.1
A password request prompt appears.
STEP 3Enter the following user name and password, and then click OK.
•User name: admin
•Password: admin
NOTE For added security, you should later set a new administrator
password by using the Administration > Management page in
the web-based Configuration Utility.
The web-based Configuration Utility appears, displaying the Basic
Setup page.
STEP 4In the Internet Setup section, choose the Internet Connection
Type that was specified by your ISP:
• Automatic Configuration - DHCP: This type of connection
allows your router to obtain an IP address dynamically from
your ISP’s network.
•StaticIP:This type of connection requires that your ISP
assigned a fixed IP address to your account.
• PPPoE: This type of connection requires a login for each
Internet connection.
• PPTP: This type of connection is used in Europe only.
•L2TP:This type of connection is used mostly in Europe.
•HeartBeatSignal:This type of connection is used in Australia.
STEP 5Enter the information that your ISP provided. The fields vary,
depending on the selected connection type.
• IP Address, Subnet Mask, and Default Gateway: Enter the
information that the ISP provided for your fixed IP address.
• Primary DNS and Secondary DNS: Enter the IP address of at
least one Domain Name System (DNS) server for your ISP.

8 Cisco Small Business WRV210 Quick Start Guide
• Username and Password: Enter the login information for your
ISP account.
• PPTP Server or Authentication Server: Enter the server IP
address or name, as provided by your ISP.
• Host Name and Domain Name: Complete these fields only if
required by your ISP (often required by cable ISPs).
• Connect on Demand and Max Idle Time: Choose this option to
automatically disconnect from the Internet if the connection is
idle for the specified number of seconds. This option is helpful
if you are billed based on the amount of connection time.
• Keep Alive: Choose this option to remain connected to the
Internet regardless of the level of activity.
STEP 6When you are finished entering the Internet connection settings,
click Save to save the changes.
STEP 7To test the Internet connection, start a web browser on any
connected computer and enter a valid website address, such as
www.cisco.com.
Configuring the Wireless Network
STEP 1To configure the router for the wireless network, click Wireless >
Basic Wireless Settings in the navigation tree.
STEP 2From the Wireless Network Mode drop-down list, choose the
appropriate mode for your network devices:
•Mixed:Supports Wireless-G and Wireless-B devices
•G-Only:Supports only Wireless-G devices
•B-Only:Supports only Wireless-B devices
• Disable: Disables wireless networking
STEP 3Enter the following information in the SSID table to configure up to
four wireless networks:
• Wireless Network Name (SSID): Enter a name for your
network to identify it to the wireless devices that connect to the
router.
•TXRateLimitation:Keep the default value for the transmission
rate.

Cisco Small Business WRV210 Quick Start Guide 9
• SSID Broadcast: Click Enabled to allow all wireless devices in
range to see the SSID for this wireless network. Click Disabled
for increased privacy. With this feature disabled, your users will
need to know the SSID in order to configure their wireless
connections, since the SSID will not appear automatically when
they scan the area for available networks.
•WMM:Check this box to enable Wi-Fi Multimedia. This feature
provides basic prioritization of data packets to support voice
and video applications.
STEP 4From the drop-down list, choose the Wireless Channel to be used
by the wireless network devices. In most cases, the default
selection should be sufficient, but you may need to change this
setting if there is interference from other wireless networks in the
area.
NOTE During the initial configuration, ignore the Wireless LAN
Schedule section of this page. Later, if needed, you can
configure a schedule to enable or disable each wireless
network during specified days and times.
STEP 5When you are finished entering the wireless network settings, click
Save to apply the changes.
Securing the Wireless Network
STEP 1To choose the security options for your network, click Wireless >
Wireless Security in the navigation tree.
STEP 2From the Select SSID drop-down list, choose the SSID that you
want to configure. You will need to repeat this procedure for each
SSID that you enabled on the Basic Wireless Settings page.
STEP 3Choose the Security Mode. Cisco recommends using the highest
level of security that is supported by your network devices.
Choose from the following options:
•WEP:Weak security with a basic encryption method that is not
as secure as WPA. WEP may be required if your network
devices do not support WPA.

10 Cisco Small Business WRV210 Quick Start Guide
•WPAPersonal:Provides strong wireless security with
advanced encryption. Choose WPA Personal (TKIP or AES
encryption), WPA2 Personal (AES encryption), WPA2
Personal Mixed (TKIP or AES encryption).
•WPAEnterprise:Strong security using authentication by a
RADIUS server that is connected to the router. Choose WPA
Enterprise (TKIP or AES encryption), WPA2 Enterprise (AES),
or WPA2 Enterprise Mixed (TKIP or AES encryption).
•RADIUS(WEP):Weak security (WEP) with a basic encryption
method that is not as secure as WPA. WEP may be required if
your network devices do not support WPA. Authentication is
provided by a RADIUS server that is connected to the router.
STEP 4From the Wireless Isolation within SSID drop-down list, choose
Enabled to allow communication and file transfers between all
wireless PCs that are connected to this SSID. This feature is useful
when setting up a wireless hotspot location. Choose Disabled (the
default option) to prevent communication and file transfers
between the PCs.
STEP 5In the final section of the page, enter the required information,
based on the chosen security mode, as described below.
For WPA Enterprise modes and RADIUS (WEP) mode:
• RADIUS Server IP Address: Enter the IP address for the
RADIUS server.
•RADIUSServerPort: Enter the port number for the RADIUS
server.
For WPA Personal modes and WPA Enterprise modes:

Cisco Small Business WRV210 Quick Start Guide 11
•Encryption: For WPA Personal and WPA Enterprise, choose
either TKIP or AES encryption. The encryption method is
chosen automatically for the other WPA modes.
•SharedSecret: Enter 8-32 characters. The Shared Secret is
also known as a Pre-Shared Key.
- For WPA Personal, this key also must be configured in the
wireless clients who want to connect to the network.
- For WPA Enterprise and RADIUS, this key is shared
between the router and the RADIUS server.
•KeyRenewal: For all security modes except WEP, enter the
interval in seconds. The Key Renewal instructs the router how
often it should change the encryption keys. The default is 3600
seconds, which is 1 hour.
For WEP mode and RADIUS (WEP) mode:
• Authentication Type: Choose one of the following options:
-Open System: A wireless client doesn't need to provide a
shared key in order to access the wireless network. Any
client can associate to the router.
-Share Key: A wireless client must provide the correct
shared key in order to to access the wireless network.
• Default Transmit Key: To indicate which WEP key to use,
select the appropriate Default Transmit Key number.
•Encryption:Choose the level of WEP encryption, 64 bits (10
hex digits) or 128 bits (26 hex digits). Higher encryption levels
offer higher levels of security, but due to the complexity of the
encryption, they may decrease network performance.

12 Cisco Small Business WRV210 Quick Start Guide
• Passphrase: If you want to generate a key instead of entering a
key manually, type a passphrase in the field. You can enter up to
32 alphanumeric characters. Then click Generate. A valid key
appears in each of the Key 1 - Key 4 fields.
• Key 1 - Key 4: If you did not use the Generate feature, enter a
valid WEP key. Do not leave a field blank, and do not enter all
zeroes; they are not valid key values.
- If you chose 64-bit WEP encryption, the key must be
exactly 10 hexadecimal characters in length.
- If you chose 128-bit WEP encryption, the key must be
exactly 26 hexadecimal characters in length. Valid
hexadecimal characters are “0” to “9” and “A” to “F”.
STEP 6Keep the default values for all other settings.
STEP 7Click Save to save the changes.
STEP 8To test the wireless setup, use the wireless client on any computer
to enter the correct SSID and shared key for your wireless
network. Verify that you can connect by entering a website
address, such as www.cisco.com.
Congratulations! The installation of the Wireless-G VPN router with
RangeBooster is complete. For more advanced settings and security
options, refer to the Administration Guide (see Where to Go From Here,
page 13).
Suggested Next Steps
The WRV210 is ready for use. It is not necessary to change any settings.
However, the following steps are recommended:
•To protect your network, Cisco recommends that you reset the
administrative password. Click Administration > Management in the
navigation tree. In the Admin Password field, enter the new password.
Enter it again in the Re-enter to confirm field. Click Save to save your
settings.
7

Cisco Small Business WRV210 Quick Start Guide 13
•If you want to access the Configuration Utility from a PC that is
connected wirelessly or is located outside the local network, use the
Local Router Access section of the Administration > Management
page to enable these features.
As needed, you can use the Configuration Utility to customize the router
and to monitor the status of your network. Below is a brief guide to the
main modules of the Configuration Utility.
•Setup:Set up the Internet connection, configure the Data and Voice
VLANs, set up Dynamic DNS services for domain name resolution,
clone a MAC address if required by your ISP, and set up advanced
routing.
•Wireless:Adjust the basic wireless settings and security settings,
restrict wireless network access, and configure advanced wireless
settings. You also can configure a Wireless Distribution System (WDS)
to allow wireless clients to connect through a repeater such as
WAP54GP or WAP54GPE.
• Firewall: The default firewall settings provide security for your network.
You can adjust the basic settings, or allow public access to specified
services by enabling port forwarding or port triggering or by setting up
a DMZ. You also can restrict your users’ access to the Internet by
configuring access policies and URL filtering.
•VPN:Configure a Virtual Private Network (VPN) to allow network
access to your remote workers and business travelers.
•QoS:Adjust the default Quality of Service (QoS) settings to prioritize
traffic for demanding, real-time applications such as videoconferencing.
• Administration: Manage access, set up alerts and system logs,
perform diagnostic tests, back up and restore the configuration,
upgrade the firmware, reboot the router, and revert to factory default
settings.
•Status:Monitor the status and view statistics for your router, local
network, wireless network, and VPN.

14 Cisco Small Business WRV210 Quick Start Guide
Where to Go From Here
Support
Cisco Small Business Support
Community
www.cisco.com/go/smallbizsupport
Online Technical Support and
Documentation (Login Required)
www.cisco.com/support
Phone Support Contacts www.cisco.com/en/US/support/tsd_cisco_
small_business_support_center_contacts.html
Software Downloads
(Login Required)
Go to tools.cisco.com/support/downloads,
and enter the model number in the Software
Search box.
Product Documentation
Administration Guides for Cisco
Small Business Routers
www.cisco.com/en/US/products/ps9923/
prod_maintenance_guides_list.html
Cisco Small Business
Cisco Partner Central for Small
Business (Partner Login
Required)
www.cisco.com/web/partners/sell/smb
Cisco Small Business Home www.cisco.com/smb
Marketplace www.cisco.com/go/marketplace
8

Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
Cisco, Cisco Systems, the Cisco logo, and the Cisco Systems logo are registered trademarks
or trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other
countries. All other trademarks mentioned in this document or Website are the property of
their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0705R)
© 2009 Cisco Systems, Inc. All rights reserved.
Printed in the USA on recycled paper containing 10% postconsumer waste.
78-19169-01
