Technical specifications
Installation instructions
Operating instructions
Maintenance
Cissell Manufacturing Co.
831 S. First St. - P.O.Box 32270 - Louisville, Ky. - 40232-2270
Tel: (502) 587-1292 - Fax: (502) 585-2333
Sales Fax: (502) 585-3625 - Service/Parts Fax: (502) 681-1275
OWNER'S MANUAL
20 lb. HD LAUNDRY DRYER
HD20.1
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER
MANHD20.1 5/02
Gas: Natural and LP
Electric
Steam
Page 2
IMPORTANTNOTICESPLEASEREAD
For optimum efficiency and safety, we recommend that you read the manual before operating the equipment. Store this
manual in a file or binder and keep for future reference.
WARNING: Purchaser must post the following notice in a prominent location:
WARNING: For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion or to prevent property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this
or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your building.
 Clear the room, building, or area of all occupants.
 Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
 If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency
or the gas supplier.
WARNING: In the event the user smells gas odor, instructions on what to do must be posted in a
prominent location. This information can be obtained from the local gas supplier.
WARNING: Wear safety shoes to prevent injuries.
WARNING: Purchaser must post the following notice in a prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING: A clothes dryer produces combustible lint and should be exhausted outside the building.
The dryer and the area around the dryer should be kept free of lint.
WARNING: Be safe, before servicing machine, the main power should be shut off.
Page 3
ATTENTION: LACHETEUR DOIT PLACER LAVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
ATTENTION: LACHETEUR DOIT PLACER LAVERTISSEMENT
SUIVANT DANS UN ENDROIT CLAIR ET VISIBLE:
AVERTISSEMENT. Assurez-vous de bien
suivre les instructions donnees dans cette
notice pour reduire au minimum le risque
dincendie ou dexplosion ou pour eviter tuot
dommage materiel, toute blessure ou la mort.
__ Ne pas entreposer ni utiliser dessence ni
dautres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
apparell.
__ QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
Ne pas tenter dallumer dapparell.
 Ne touchez a aucun interrupteur. Ne pas
vous servir des telephones se trouvant dans
le batiment ou vous vous trouvez.
 Evacuez la piece, le batiment ou la zone.
Appelez immediatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
__ linstallation et lentretien doivent etre assures
par un installateur ou un service dentretien
qualifie ou par le fournisseur de gaz.
POUR VOTRE SECURITE
Ne pas entreposer ni utiliser d essence
ni dautres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.
Page 4
WARNING: To avoid fire hazard, do not dry articles containing foam rubber or similar texture
materials. Do not put into this dryer flammable items such as baby bed mattresses, throw rugs,
undergarments (brassieres, etc.) and other items which use rubber as padding or backing. Rubber
easily oxidizes causing excessive heat and possible fire. These items should be air dried.
WARNING: Synthetic solvent fumes from drycleaning machines create acids when drawn through the
dryer. These fumes cause rusting of painted parts, pitting of bright or plated parts, and completely
removes the zinc from galvanized parts, such as the tumbler basket. If drycleaning machines are in the
same area as the tumbler, the tumbler's make-up air must come from a source free of solvent fumes.
WARNING: Do not operate without guards in place.
WARNING: Check the lint trap often and clean as needed but at least a minimum of once per day.
WARNING: Alterations to equipment may not be carried out without consulting with the factory and
only by a qualified engineer or technician. Only Manufacturers parts may be used.
WARNING: Remove clothes from dryer as soon as it stops. This keeps wrinkles from setting in and
reduces the possibility of spontaneous combustion.
WARNING: Be Safe - shut main electrical power and gas supply off externally before attempting
service.
WARNING: Never use drycleaning solvents, gasoline, kerosene, or other flammable liquids in the dryer.
FIRE AND EXPLOSION WILL OCCUR. NEVER PUT FABRICS TREATED WITH THESE
LIQUIDS INTO THE DRYER. NEVER USE THESE LIQUIDS NEAR THE DRYER..
WARNING: Do not place items exposed to cooking oils in your dryer. Items contaminated
with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.
WARNING: Never let children play near or operate the dryer. Serious injury could occur if a child
should crawl inside and the dryer is turned on.
WARNING: Never tumble fiberglass materials in the dryer unless the labels say they are machine
dryable. Glass fibers break and can remain in the dryer. These fibers cause skin irritation if they
become mixed with other fabrics.
WARNING: Before operating gas ignition system - purge air from natural gas or propane gas lines
per manufacturers instructions.
WARNING: To reduce the risk of electric shock, disconnect this appliance from the power supply
before attempting any user maintenance other than cleaning the lint trap. Turning the controls to the
OFF position does not disconnect this appliance from the power supply.
Page 5
CISSELL DRYER WARRANTY
The Cissell Manufacturing Company (Cissell) warrants all new equipment (and the original parts thereof)
to be free from defects in material or workmanship for a period of three (3) years from the date of sale thereof to an original
purchaser for use, except as hereinafter provided. With respect to non-durable parts normally requiring replacement in less
than three (3) years due to normal wear and tear, and with respect to all new repair or replacement parts for Cissell equipment
for which the three (3) year warranty period has expired, or for all new repair or replacement parts for equipment other than
Cissell equipment, the warranty period is limited to ninety (90) days from date of sale. The warranty period on each new
replacement part furnished by Cissell in fulfillment of the warranty on new equipment or parts shall be for the unexpired
portion of the original warranty period on the part replaced.
With respect to electric motors, coin meters and other accessories furnished with the new equipment, but
not manufactured by Cissell, the warranty is limited to that provided by the respective manufacturer.
Cissell's total liability arising out of the manufacture and sale of new equipment and parts, whether under
the warranty or caused by Cissell's negligence or otherwise, shall be limited to Cissell repairing or replacing,
at its option, any defective equipment or part returned f.o.b. Cissell's factory, transportation prepaid, within
the applicable warranty period and found by Cissell to have been defective, and in no event shall Cissell be
liable for damages of any kind, whether for any injury to persons or property or for any special or
consequential damages. The liability of Cissell does not include furnishing (or paying for) any labor such
as that required to service, remove or install; to diagnose troubles; to adjust, remove or replace defective
equipment or a part; nor does it include any responsibility for transportation expense which is involved
therein.
The warranty of Cissell is contingent upon installation and use of its equipment under normal operating
conditions. The warranty is void on equipment or parts; that have been subjected to misuse, accident, or
negligent damage; operated under loads, pressures, speeds, electrical connections, plumbing, or conditions
other than those specified by Cissell; operated or repaired with other than genuine Cissell replacement
parts; damaged by fire, flood, vandalism, or such other causes beyond the control of Cissell; altered or
repaired in any way that effects the reliability or detracts from its performance, or; which have had the
identification plate, or serial number, altered, defaced, or removed.
No defective equipment or part may be returned to Cissell for repair or replacement without prior written
authorization from Cissell. Charges for unauthorized repairs will not be accepted or paid by Cissell.
CISSELL MAKES NO OTHER EXPRESS OR IMPLIED WARRANTY, STATUTORY OR OTHERWISE,
CONCERNING THE EQUIPMENT OR PARTS INCLUDING, WITHOUT LIMITATION, A WARRANTY
OF FITNESS FOR A PARTICULAR PURPOSE, OR A WARRANTY OF MERCHANTABILITY. THE
WARRANTIES GIVEN ABOVE ARE EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED. CISSELL NEITHER ASSUMES, NOR AUTHORIZES ANY PERSON TO ASSUME FOR IT,
ANY OTHER WARRANTY OR LIABILITY IN CONNECTION WITH THE MANUFACTURE, USE OR SALE
OF ITS EQUIPMENT OR PARTS.
For warranty service, contact the Distributor from whom the Cissell equipment or part was purchased. If
the Distributor cannot be reached, contact Cissell.
IDENTIFICATION NAMEPLATE
The Identification Nameplate is located on the rear wall of the dryer. It contains the dryer serial number, product
number, model number, electrical specifications and other important data that may be needed when servicing
and ordering parts, wiring diagrams, etc. Do not remove this nameplate.
Page 6
Contents
Safety Instructions ........................................................................................... 2-4
Cissell Dryer Warranty ..................................................................................... 5
Table of Contents .............................................................................................. 6
Symbols ............................................................................................................. 7
Unpacking / General Installation .................................................................... 8-9
Technical Data and Dimensions ......................................................................10-11
Electric Connections ........................................................................................ 12
Gas Connections ............................................................................................... 13
Gas Piping Installation .................................................................................... 14-15
Gas service Installation Instructions ............................................................... 16
Gas Pipe Size Chart .......................................................................................... 17
Steam Piping Installation Instructions ............................................................18-19
Dryer Installation with Multiple Exhaust .......................................................20-21
Dryer Make-Up Air Requirements ................................................................... 22
Dryer Installation with Seperate Exhaust ....................................................... 23
Exhaust and Venting ........................................................................................ 24
Rules for Safe Operation of Dryer .................................................................... 25
Direct-Spark Ignition Operation ...................................................................... 26-27
General Maintenance ....................................................................................... 28-29
Air Switch Adjustment ...................................................................................... 30
Operating Instruction for Double Timer .......................................................... 31
PARTS ............................................................................................................... 32-59
Aligning Basket ............................. 32
Front View ..................................... 33
Access Door Assembly ................... 34
Door Assembly ............................... 35
Front Panel Assembly - OPL ......... 36
Front Panel Assembly - Coin ........ 37
Thermostat Assembly ..................... 38-39
DMP Coin Control Assembly ........ 40
Mech. Coin Control Asm. .............. 41
DMP OPL Control Assembly ........ 42
2 Timer Control Assembly ............. 43
PRO/HC Control Assembly ........... 44
PRO/HC Sensor Assembly ............. 45
Lint Door Assembly .......................46
Basket & Spider Assembly.............47
Rear View ....................................... 48
Air Switch Assembly ......................49
Basket Bearings/Sheave Assy .......50
Motor & Fan Assembly .................51-52
Idler Assembly ...............................53
Rear Control Box Asm-Gas ........... 54
Rear Control Box Asm.-Elec. ........ 55
Nat. Gas Heating Unit Asm. .......... 56
L.P. Gas Heating Unit Asm. ...........57
Steam Heating Unit Asm. .............. 58
Electric Heating Unit Asm. ........... 59
Recommended Spare Parts List .... 60
Page 7
Rotation in two directions
Rotation dans les deux sens
Drehbewigung in zwei
Richtungen
Movimiento rotativo en los
dos sentidos
Caution
Attention
Achtung
Atencion; precaucion
Direction of rotation
Sens de mouvement continu
De rotation Drehbewegung
in Pfeilrichtung movimiento
Giratorio o rotatorio en el
sentido de la flecha
The following symbols are used in this manual and/or on the machine. The numbers between ()
refer to the numbers on the machine surveys.
NOTE!
On
Marche
Ein
Conectado
Off
Arrêt
Aus
Desconectado
Hot! Do Not Touch
Heiß! Nicht Beruhren
Haute temperature! Ne pas
toucher
Caliente! no tocar
Start
Demarrage
Start
Arranque de un
movimiento
Emission of heat in general
Emission de chaleur en
general
Warmeabgabe allgemein
Emisión de calor
Cooling
Refroidissement
Kühlen
Enfriamiento
dangerous voltage
tension dangereuse
Gefährliche elektrische
Spannung
tension peligrosa End of Cycle
DescriptionSymbol
SYMBOLS
Symbol
Page 8
Unpacking/General Installation (All Dryers)
Upon arrival of the equipment, any damage in shipment
should be reported to the carrier immediately.
Upon locating permanent location of a unit, care should be
taken in movement and placement of equipment.
See outline clearance diagrams for correct dimensions.
Remove all packing material such as: tape, manuals, skid,
etc
Leveling: Use spirit level on top of dryer. Adjust leveling
bolts on dryer (see adjustable leveling bolts in maintenance
section).
Check voltage and amperes on rating plate before
installing the dryer.
The construction of the dryers permits installation side-by-
side to save space or to provide a wall arrangement.
Position dryer for the least amount of exhaust piping and
elbows, and allow free access to the rear of dryer for future
servicing of belts, pulleys and motors. Installation
clearance from all combustable material is 0 ceiling
clearance, 0 rear clearance, and 0 side clearance.
Before operating dryer, open basket door and remove
blocking between front panel and basket. Read the
instruction tags, owners manual, warnings, etc.
IMPORTANT
Opening the clothes loading door deactivates the
door switch to shut off the motors, fan, gas, steam,
or electric element. To restart the dryer, close
the door and press in the push to start button.
IMPORTANT
This dryer is designed for a capacity maximum
load. Overloading it will result in long drying
times and damp spots on some clothes.
IMPORTANT
Maximum operating efficiency is dependent upon
proper air curculation. The lint screen must be
kept cleaned daily to insure proper air circulation
throughout the dryer.
IMPORTANT
Provide adequate clearance for air opening into
the combustion chamber.
UNPACKING
GENERAL
INSTALLATION
(ALL DRYERS)
Page 9
Unpacking/General Installation (All Dryers)
The dryer is so designed that when an operator opens the
dryer door, the basket and exhaust fan stop. You can
expect fast drying from a laundry dryer. Hot, dry air is
properly and effectively moved through the basket and
exhausted through a lint trap to the atmosphere. The
dryer comes equipped with an inclined self-cleaning lint
screen. In this system, lint accumulates on the underside
of the screen until a blanket of lint will fall from the
screen to the bottom of the dryer cabinet, and should be
removed daily or as required, to prevent an over-
accumulation.
IMPORTANT
Provide adequate clearance for air openings into
the combustion chamber.
Permanent press, durable press and other modern day
fabrics require the care that your laundry dryers now
provide. At the end of the drying cycle, a timed Cool-
Down control automatically takes over and continues the
rotation of the fan and basket without heat until the
garment load reaches a safe cool temperature. This
function is performed at the end of each drying cycle and
continues for two minutes.
Replacement parts for this dryer are available from your
distributor or by contracting the factory at the address or
phone number printed on the cover page of this manual.
GENERAL
INFORMATION
DRYER
COOL-DOWN
CYCLE
REPLACEMENT
PARTS
Page 10
20lb. Dryer Dimensions - Standard Gas, Steam and Electric Heated
Spe cifications U .S. M e asure Metric
Measure
Capacity
(Dry Linen) 20 lbs. 9 kg
Basket
Diameter 27 inches 685mm
Depth 24 inches 610 mm
Volume 7.9 ft3225 liter
Cabinet
Height 68-5/16 inches 1735 mm
Width 28 3/4 inches 730 mm
Depth 41 inches 1041 mm
Door Opening
Diameter 22-5/8 inches 575 mm
Loading height 29 1/2 inches 750 mm
Temperature
Minimum 1000F38
oC
Maximum 1850F85
0C
Motor
Non-reversing 1/2 H.P. 0.37 kW
Reversing - Drum 1/2 H.P. 0.37 kW
Fan 1/2 H.P. 0.37 kW
Exhaust
Flow Rate 450 cfm 750 m3/h
Diameter 6-8 inches 152-203 mm
Electric Conn. - Electric Dryers Non-Reversing Reversing
208 V 60 - 3 PH 47 A 48 A
220/240 V 50/60 - 3 PH 44/41 A 45/42 A
380/415 V 50 - 3 PH 28/26 A 29/27 A
480 V 60 - 3 PH 23 A 24 A
Electric Conn. - Steam, G as Dryers Non-Reversing Reversing
115/208-240 V 50/60 - 1 PH 9.5 A N/A
380/415 V 50/60 - 3 PH 1.4 A 4.3 A
480 V 50/60 - 3 PH 1.3 A 2.5 A
Power
Electric 15 kW 12,900 kcal/h
Gas 62,500 Btu/h 15,750 kcal/h
Steam 2.3 B.H.P 19,430 kcal/h
Steam connection
Inlet 3/4" DN20
Outlet 1/2" DN15
G as Connection
Gas Connection 1/2" DN15
Gas Pressure 5" - 12" 12-30 mb
Shipping
Dimensions
(H xW x D) 75 X 31 X 46
inches 1905 X 787
X 1168 mm
Weight
Net 433 lbs. 196 kg
Gross 468 lbs. 212 kg
