Citizen CT-D150ET User manual

MODEL : CT-D150ET
Ethernet Interface function
Manual
Ver.1.01

2
Contents
Contents.........................................................................................................................2
Read before using .........................................................................................................3
1. Introduction .............................................................................................................4
1-1. Specifications ......................................................................................................................... 4
1-2. Part Names and Functions................................................................................................... 5
1-3. LED Functions....................................................................................................................... 6
1-4. Using the Panel Button ........................................................................................................ 7
1-4-1. Printing the Network Configuration................................................................................... 7
1-4-2. Returning the Network Configuration to Factory Default Settings ................................. 8
1-5. Print Server ........................................................................................................................... 9
1-5-1. Accessing Print Server Configuration screen..................................................................... 9
1-5-2. Changing the Print Server Configuration ........................................................................ 10
2. Network Settings...................................................................................................12
2-1. Network settings from the browser ................................................................................... 12
2-1-1. Accessing the Print Server configuration screen ............................................................. 12
2-1-2. Setting the IP address........................................................................................................ 12
2-1-3. Changing other settings..................................................................................................... 13
2-2. Network setting from “Network Seeker”........................................................................... 14
2-2-1. Starting Network Seeker ................................................................................................... 14
2-2-2. Changing Settings.............................................................................................................. 16

3
Read before using
Be sure to read this manual carefully before using the product. After you read it, store it in a
safe place so that you can reread it when necessary.
⚫Contents of this manual may be changed without notice.
⚫Reproducing and/or copying the contents of this manual by any means without
permission are prohibited.
⚫We will not be responsible for any adverse occurrence that results from the use of this
manual, regardless if it contains omissions, errors/misprints, etc.
⚫Note that we will not be responsible for (a) loss caused by improper operation or
mishandling of the device by the user, or (b) loss due to operational environment.
⚫Data etc., are basically impermanent; long time or permanent storing/saving of data by
the device is not possible.
⚫Note that we will not be responsible for any loss or loss of profits owing to loss of data
due to breakdown, repairs, inspections, etc.
⚫Please contact us if there are omissions, errors, ambiguities, etc. in this manual.
⚫Refer to this document along with the user manual of the printer.
⚫This product operates by setting up a wireless connection between itself and other
wireless LAN equipment for data transmission. Therefore, other wireless LAN
equipment is required to use this product. While we have confirmed the operation of
this product with certain wireless LAN equipment, operation with all types of wireless
LAN equipment is not guaranteed. Carry out a sufficient evaluation before using this
product.
Trademarks
・Microsoft, Windows XP, Windows Vista, Windows 7, Windows 8 and Windows10 are
registered trademarks of Microsoft Corporation U.S.A.
・Ethernet is a registered trademark of Fuji Xerox Co., Ltd.
・Other company names and product names mentioned here are trademarks or
registered trademarks of those companies.

4
1. Introduction
Thank you for purchasing the Citizen CT-D150 printer.
This manual is to explain the details of the Ethernet interface function of the printer.
Using Ethernet function, you can relay data between a network of multiple computers and
the printer. In addition, the computers and printer are able to communicate with each other:
the operational status, print settings, and other information about the printer can be
checked from computers on the network.
1-1. Specifications
Printer model name
CT-D150ET （Ethernet Interface model）
Operation panel
LED: 2 (RJ45 connector)
Button: 1 (on panel)
Network Interface
Auto-Negotiation (100Base-TX/10-Base-T)
AUTO-MDIX (Straight/Cross cable auto detection)
IP Version
IPv4
Network protocols
TCP, UDP, HTTP, SNMP, ICMP, DHCP
Port number for printing
TCP 9100 (Default)
Configuration changes
from the browser
Yes
Interactive communication
Yes (only when CITIZEN TCP/IP port driver is used)
Safety standards
VCCI Class A

CITIZEN Label Printer Library for Windows - Programming Manual
5
1-2. Part Names and Functions
External view of Ethernet interface
①Cash Drawer connector
Connection for cash drawer
②USB connector
Works as standard USB connector
③RJ45 connector (compatible with 10Base-T/100Base-TX)
Connection for LAN cable.
④Green LED
Shows network transmission speed with steady/blinking light.
⑤Yellow LED
Shows network connection status (disconnected, receiving data, etc.)
⑥Panel button
Used to operate the Ethernet function.
